48 cm (19")
COLOR LCD MONITOR
Controlled
Imaging
Newly designed ergonomic
cabinet, customized image adjustment,
and digital and analog inputs — the
FlexScan L767 offers business, admin-
istrative, and CAD professionals all this
and more in a large 19" screen size at a
native resolution of 1280 ×1024. The
inclusion of EIZO original functions such
as Fine Contrast and DesktopViewer, as
well as support for Seiko Epson Cor-
poration’s PRINT Image Matching
(P.I.M.) II technology deliver the high-
precision image control required for
complex text and graphics-based appli-
cations. The FlexScan L767 is one of the
first products on the market to receive
TCO’03 certification, ensuring it meets
strict new guidelines for ergonomics and
recyclability.
NEW ERGONOMIC DESIGN
With slim side bezels only 18 mm wide, the newly designed
cabinet is more space-efficient than ever. Navigating is easier too —
control buttons are now arranged in a simple cross pattern, and set
on a tiered front panel. The desktop stand allows height adjustment
over a 50 mm range, and a VESA-compliant mounting interface lets
you install the unit on an adjustable arm or the wall.
FINE CONTRAST
A one-touch button on the front panel accesses five special-
ized image adjustment modes: Text, Picture, Movie, Custom and
sRGB, each with its own settings for parameters such as color
temperature, brightness and saturation. Using the bundled
ScreenManager Pro for LCD1software’s Auto Fine Contrast func-
tion, any mode can be assigned to an application. When the applica-
tions is opened, the screen changes automatically to that mode.
DESKTOP VIEWER
This EIZO-designed utility2can display a JPG, BMP or TIFF
image, or any selected part of the screen, in an overlay window to a
maximum brightness of 250 cd/m2, as well as enlarging or reducing
it and freely altering its brightness, contrast, saturation, hue and
gamma values3.

(Unit: mm)
216
50
32
~
82 374
303
190
13
62
8.7
378.3
415
30.5 2
54
30˚
5˚
140.5
85
~
135
406
~
456
34
31 ~ 60
48 cm (19")
COLOR LCD MONITOR
Additional Features
P.I.M. II AND EXIF 2.2
Support for these image optimization technologies enable
digital camera images to be viewed, edited and printed out
at the highest level of quality. (Digital camera and printer
must be P.I.M. II- and Exif 2.2-enabled.)
GAMMA CORRECTION
Internal circuitry automatically converts 8-bit data from the
PC to 10-bit and back to 8-bit, producing smooth, accurate
color tones. Gamma values are also user adjustable from 1.4
to 3.0 in increments of 0.2.
REGULATORY STANDARDS
The FlexScan L767 complies with current international
standards relating to safety, ergonomics, and power manage-
ment as well as “EIZO Eco Products 2002”, an in-house
label covering such environmental issues as manufacture
with lead-free solder and chrome-free steel plates.
Accessories
High-transparency screen cover for
protection from dust and scratches.
This EIZO-developed software enables various important
setup and management tasks of client PCs and monitors to
be executed across a network from a single server PC.
Dimensions
Specifications
1ScreenManager Pro for LCD is compatible with the Microsoft®Windows® 98SE/
ME/ 2000/XP OS only. 2DesktopViewer is compatible with the Windows 2000/XP
OS only. 3Support for editing functions varies with the graphics card used.
48 cm (19") TFT color LCD panel
Gray, Black
0.294 mm ×0.294 mm
16.7 million
H: 170°, V: 170°
Analog: 24.8 – 80 kHz, 50 – 75 Hz
Digital: 31 – 64 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz)
1280 ×1024
250 cd/m
2
(typical)
500:1 (typical)
25 ms (typical)
Analog: 135 MHz, Digital: 108 MHz
RGB Analog, DVI Standard 1.0
D-Sub mini 15 pin, DVI-D 24 pin (switchable)
1 Upstream / Rev.1.1
376 mm ×301 mm
482 mm (diagonal)
VESA DDC 2B
ScreenManager
®
, ScreenManager Pro for LCD
1
,
One Touch Auto Adjustment Function
AC 100 – 120V / 200 – 240V, 50 – 60 Hz
VESA DPMS, DVI-DMPM
45 watts (maximum)
Less than 2 watts
English, French, German, Italian, Japanese, Spanish, Swedish
With Stand: 415 mm ×406 – 456 mm ×216 mm
Without Stand: 415 mm ×374 mm ×54 mm
With Stand: 6.6 kg, Without Stand: 5.1 kg
Dual 1W built-in speakers, input/headphone jacks
30°Up, 5°Down
TCO’03 (gray), TCO’99 (black), TÜV/Ergonomics,
TÜV/GS, c-Tick CE, CB, UL 60950: 2000,
CSA C22.2 No. 60950-00, FCC-B,
Canadian ICES-003-B, TÜV/S, VCCI-B,
EPA ENERGY STAR
®
, EIZO Eco Products 2002
AC power cord, signal cable (D-Sub mini 15 pin),
USB cable, audio cable, setup guide, EIZO LCD
Utility Disk (ScreenManager Pro for LCD, ICC
Profile, HTML user’s manual), 4 screws for
mount option, warranty registration card
Panel Size and Type
Available Cabinet Colors
Pixel Pitch
Display Colors
Viewing Angles
Scanning Frequency
Recommended Resolution
Brightness
Contrast Ratio
Response Time
Dot Clock
Input Signals
Input Terminals
USB Port / Standard
Active Display Size (H ×V)
Viewable Image Size
Plug & Play
Screen Control
Power Requirements
Power Management
Power Consumption
Power Save Mode
OSD Languages
Dimensions (W ×H ×D)
Net Weight
Audio
Tilt
Certifications and Standards
Supplied Accessories
Specifications are subject to change without notice.
This product supports PRINT Image Matching. A combination of PRINT Image Matching
and PRINT Image Matching II enabled digital still cameras, printers, and software help
photographers to produce images which are more faithful to their intentions.
Copyright© 2003 Eizo Nanao Corporation. All rights reserved. All product names are
trademarks or registered trademarks of their respective companies. Screen Administrator
is a trademark, and FlexScan, EIZO, and ScreenManager are registered trademarks
of Eizo Nanao Corporation.
