Eizo FLEXSCAN T2351W User manual

Important
Please read PRECAUTIONS, this User’s Manual, and Setup Guide
(separate volume) carefully to familiarize yourself with safe and
effective usage.
• Please refer to the Setup Guide for basic information ranging from
connection of the monitor to a PC or external equipment to using the
monitor.
• The latest User’s Manual is available for download from our Web site:
http://www.eizo.com
Cover

2
Location of Caution Statement
Product specication may vary with sales areas. Conrm the specication in the manual written in language of the
region of purchase.
Copyright© 2010 EIZO NANAO CORPORATION All rights reserved.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.
EIZO NANAO CORPORATION is under no obligation to hold any submitted material or information condential
unless prior arrangements are made pursuant to EIZO NANAO CORPORATION’s receipt of said information.
Although every effort has been made to ensure that this manual provides up-to-date information, please note that
EIZO monitor specications are subject to change without notice.

3

Notice for this monitor
This product is suited to creating documents, viewing multimedia content, and other general purposes.
This product has been adjusted specically for use in the region to which it was originally shipped. If the product is
used outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable for power cords and signal cables specied by us.
Use optional products manufactured or specied by us with this product.
As it takes about 30 minutes for the performance of electrical parts to stabilize, adjust the monitor 30 minutes or more
after the monitor power has been turned on.
In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in
lower brightness is recommended.
When the screen image is changed after displaying the same image for extended periods of time, an afterimage may
appear. Use the screen saver or power save function to avoid displaying the same image for extended periods of time.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer to
“Cleaning” (page 4)).
The LCD panel is manufactured using high-precision technology. However, missing pixels or lit pixels may appear on
the LCD panel, this is not malfunction. Percentage of effective dots: 99.9994% or higher.
The backlight of the LCD panel has a xed life span. When the screen becomes dark or begins to icker, please contact
your dealer.
Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do not attempt
to brush with tissues as this may scratch the panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation
may occur inside and outside the monitor. In that case, do not turn the monitor on and wait until dew condensation
disappears, otherwise it may cause some damages to the monitor.

4
Cleaning
Attention
• Never use any solvents or chemicals, such as thinner, benzene, wax, alcohol, and abrasive cleaner, which may
damage the cabinet or panel.
• Do not soak liquid into the clearance between the panel and the panel frame.
● Panel
• Clean the panel with a soft cloth such as cotton cloth or lens cleaning paper.
• If necessary, stubborn stains can be removed by using the provided cleaning cloth, or moistening part of a
cloth with water to enhance its cleaning power. After that, clean the panel again with a dry cloth for better
nishing.
● Cabinet
• Clean the cabinet with a soft cloth dampened with a little mild detergent.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according
to the environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.

5
CONTENTS
CONTENTS
Cover ...................................................................... 1
Notice for this monitor ............................................ 3
CONTENTS ............................................................. 5
Chapter 1 Introduction ....................................... 7
1-1. Features ......................................................... 7
1-2. Controls and Functions ............................... 8
●Standinstallation............................................. 9
●Foldingthestand............................................. 9
1-3. EIZO LCD Utility Disk...................................10
●Diskcontentsandsoftwareoverview............10
●Touse“ScreenManagerProfor
LCD(DDC/CI)/EIZOScreenSlicer”.................10
●Tousetouchpaneldriverand
calibrationutility.............................................10
1-4. Basic Operations and Functions ...............11
●BasicAdjustmentmenuoperations...............11
●Functions........................................................12
Chapter 2 Adjusting Screens .......................... 13
2-1. Compatible Resolutions/Formats ..............13
AnalogInput(D-Sub)..................................13
DigitalInput(DVI-D,HDMI:PCsignal).......13
DigitalInput(HDMI:videosignal)...............13
2-2. Setting the Resolution ................................14
Windows7..................................................14
WindowsVista............................................14
WindowsXP................................................14
MacOSX....................................................14
2-3. Displaying Screen Correctly.......................15
●DigitalSignalInput.........................................15
●AnalogSignalInput........................................15
2-4. Adjusting Color ............................................19
●Toselectthedisplaymode
(FineContrastmode)......................................19
●Toperformadvancedadjustments................19
●Adjustablesettingsineachmode................. 20
●Toadjustbrightness<Brightness>............... 20
●Toadjustblacklevel<BlackLevel>...............21
●Toadjustcontrast<Contrast>........................21
●Toadjustcolortemperature<Temperature>. 22
●Toadjustgamma<Gamma>......................... 22
●Toadjustthecolorsaturation<Saturation>.. 23
●Toadjusthue<Hue>..................................... 23
●Toadjustgain<Gain>....................................24
●Toreduceimageblur<PowerResolution>....24
●Tosetoverdriveintensity<Overdrive>......... 25
2-5. Changing the Screen Size .......................... 26
●Tochangescreensize<ScreenSize>......... 26
●Tochangethebrightnessofthenon-
displayarea<BorderIntensity>.................... 26
Chapter 3 Setting Monitor ............................... 27
3-1. Adjusting Volume <Volume> ..................... 27
3-2. Switching sound source for HDMI signal
input <Source> ............................................ 27
3-3. Setting Adjustment Menu Display ............ 28
●ChangingAdjustmentMenuDisplay
Size<MenuSize>......................................... 28
●ChangingAdjustmentMenuDisplay
Position<MenuPosition>............................. 28
●ChangingAdjustmentMenuDisplay
Time<MenuOffTimer>................................ 28
●ChangingTransparencyofAdjustment
MenuDisplay<Translucent>......................... 29
3-4. Locking Buttons .......................................... 29
3-5. Setting the EIZO Logo Display <Logo> .... 29
3-6. Setting Language <Language> ................. 29
3-7. Enabling/Disabling DDC/CI
communication ........................................... 30
3-8. Resetting the Monitor to the Default
Settings <Reset> ......................................... 30
●Toresetthecoloradjustments...................... 30
●Toresetalladjustmentstothedefault
settings.......................................................... 30
Chapter 4 Power Saving Functions ................ 31
4-1. Setting Power Saving <Power Save> .........31
●Monitor...........................................................31
●AudioOutput................................................. 32
4-2. Setting Power Indicator <Power
Indicator> ..................................................... 32
4-3. Enabling/Disabling Automatic
Brightness Adjustment “Auto EcoView” . 33
4-4. Setting Indicator “EcoView Index” ........... 33
4-5. Enabling/Disabling Auto Power-OFF
<Off Timer> .................................................. 33
Chapter 5 Connecting Cables ......................... 34
5-1. Connecting Multiple External Devices ..... 34
●Toswitchamonginputsignals...................... 35
Chapter 6 Troubleshooting .............................. 36
Chapter 7 Reference ........................................ 41
7-1. How to Attach the Optional Arm ................41
7-2. Displaying Monitor Information
<Information> .............................................. 42
7-3. Specications ............................................. 43
7-4. Glossary ....................................................... 46
7-5. Preset Timing .............................................. 48

6CONTENTS
Appendix .............................................................. 49
Trademark ............................................................... 49
ENERGY STAR ........................................................ 49
TCO .......................................................................... 50
FCC Declaration of Conformity ............................ 50
Hinweise zur Auswahl des richtigen
Schwenkarms für Ihren Monitor ......................51
LIMITED WARRANTY ............................................. 52
China Measures for RoHS Compliance in
ChinaRoHS .........................................................61

7
Chapter1Introduction
Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
• 23″ wide format LCD
• Applicable to the resolution of 1920 × 1080.
• Standard touch panel
- Infrared optical imaging system
Supports the Windows Touch function (multi-touch) of Microsoft Windows 7.
* This product supports up to two simultaneous touches (multi-touch support).
• Uses high-contrast panel (3000:1).
Enables the display of sharp images.
• VA panel with 89° horizontal and vertical viewing angles
• HDMI connector
- Applicable to the PC input signal using HDMI input, allowing three different inputs from a PC.
• The FineContrast function allows the user to select the display mode optimum to the displayed image.
- The Paper mode reproduces a printed paper effect on the monitor.
See “To select the display mode (FineContrast mode)” (page 19).
• The LaidBack Stand allows the monitor to be adjusted to a wide range of tilt angles with one touch.
The stand can be used at an angle suitable for reading books.
In addition, the setting to prevent screen vibration is also applied during the touch operation.
• The software “ScreenManager Pro for LCD (DDC/CI)” to adjust the screen using the mouse and keyboard
is included.
See “1-3. EIZO LCD Utility Disk” (page 10).
• HDCP (High-bandwidth Digital Content Interface)
• Built-in speakers and headphone jack
See “1-2. Controls and Functions” (page 8).

8Chapter1Introduction
1-2. Controls and Functions
 


 
 




1. Auto EcoView sensor Detectsambientbrightness.AutoEcoViewfunction(page33).
2. button Displaysthesettingmenuofthepowersavingfunction(AutoEcoViewandEcoView
Index)(page33).
3. button Switchesinputsignalsfordisplay(page35).
4. button DisplaystheAdjustmentmenu,determinesanitemonthemenuscreen,andsaves
valuesadjusted(page11).
5. button
• Choosesandincreases/decreasesadjustmentsettingsforadvancedadjustment
usingtheAdjustmentmenu.
•  button( ):
ChangesFineContrastmode(page19).
• button( ):
DisplaystheBrightnessandVolumeadjustmentmenu(page20,page27).
6. button Turnsthepoweronoroff.
7. Power indicator
Indicatesthemonitor’soperationstatus.
Blue: Operating
Orange: Powersavingmode
OFF: Mainpower/Poweroff
8. Main power switch Turnsthemainpoweronoroff.
9. Power connector Connectsthepowercord.
10. USB port (UP) ConnectsaUSBcablewhenthisproductisusedasatouchpanelmonitor.
11. Stereo mini jack Connectsthestereominijackcable.
12. Input signal connector Top:D-Submini15-pinconnector/Center:DVI-Dconnector/Bottom:HDMIconnector
13. Headphone jack Connectstheheadphones.
14. Security lock slot ComplieswithKensington’sMicroSaversecuritysystem.
15. Stand*2, 3 Usedtoadjusttheangleofthemonitorscreen.
16. Speaker Outputsaudiosource.
*1ScreenManagerisanEIZO’snicknameoftheAdjustmentmenu.Seepage11forhowtouse.
*2See“Standinstallation”(page9)forinstallation.
*3Anoptionalarm(oranoptionalstand)canbeattachedbyremovingthestand(see“7-1.HowtoAttachtheOptional
Arm”(page41)).
Adjustmentmenu
(ScreenManager*1)

9
Chapter1Introduction
● Stand installation
This product can be adjusted to angles of 15°, 25°, 35°, 45°, 55°, and 65°.
CAUTION
Do not use the stand in its packaged state.
Thestandisfoldedwhenitispackagedforshipment.Usingitinthisstatewill
makethemonitorunstable,potentiallyresultinginitfallingoverandcausing
injuriesorequipmentdamage.Whenusingthestand,unfoldittoatleast15°and
setitupcorrectly.
● Folding the stand
Perform the following procedure to fold the stand when re-packing the monitor.
1. Lay the LCD monitor on a soft cloth spread over on a stable surface with the
panel surface facing down.
2.
Press the lever up and move the stand forward to its minimum angle of 15°.
3.
Keeping the lever in the up position, press the lock release button.
The stand will fold into its packaging position.
Lockreleasebutton
Lever
Max.65º
Min.15º

10 Chapter1Introduction
1-3. EIZO LCD Utility Disk
An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk
contents and the overview of the software programs.
● Disk contents and software overview
The disk includes adjustment software, touch panel software, and user’s manuals. Refer to Readme.txt le on
the disk for software startup procedures or le access procedures.
Item Overview Windows
Macintosh
AReadme.txtle √ √
Screenadjustmentpatternles Usedwhenadjustingtheimageofanalog
signalinputmanually.
√ √
Touchpaneldriver Driversoftwareforthetouchpanel √ -
Calibrationutility Utilityforcorrectingthetouchposition. √ -
ScreenManagerProforLCD(DDC/
CI)
Softwareforadjustingthescreenusingthe
mouseandkeyboard
ThissoftwaredoesnotrunonaPC
connectedviatheHDMIinput.
√ -
EIZOScreenSlicer Softwarethatdividesascreenandlaysout
multiplewindowsefciently.
√ -
User’sManualofthismonitor(PDFle) √ √
InstallationGuideforthetouchpaneldriver/calibrationutility(PDFle) √ -
● To use “ScreenManager Pro for LCD(DDC/CI)/EIZO ScreenSlicer”
For the installation and use of “ScreenManager Pro for LCD(DDC/CI)/EIZO SceenSlicer”, refer to the
respective User’s Manual on the disk.
● To use touch panel driver and calibration utility
For information on the system requirements of the touch panel driver and calibration utility and how to
install or operate them, see the Installation Guide included on the supplied CD-ROM.
The latest software and installation guide are available for download from our web site.
http://www.eizo.com

11
Chapter1Introduction
1-4. Basic Operations and Functions
● Basic Adjustment menu operations
1. Displaying Adjustment Menu
1. Press . The adjustment menu appears.
2.
Adjusting/Setting
1. Choose a menu to adjust/set with , , , , and then press . The Sub menu appears.
2. Choose an item to adjust/set with , , , , and then press . The adjustment/ setting menu
appears.
3. Adjust/set the selected item with , , , , and then press .
3.
Exiting
1. Choose <Return> from the Sub menu and press . The Main menu appears.
2. Choose <Exit> from the Main menu and press . The Adjustment menu exits.
Note
• The Adjustment menu can also be exited by pressing twice quickly.
• <Exit> or <Return> can also be selected by pressing twice or three times in the Main menu or Sub menu.

12 Chapter1Introduction
● Functions
The following table shows all the Adjustment menu’s adjustment and setting menus.
Main menu Setting Reference
AutoAdjustment*1 Screen “2-3.DisplayingScreenCorrectly”
(page15)
Range
Screen Clock*1
Phase*1
Position*1
Smoothing
Return
Color*2 Brightness “2-4.AdjustingColor”(page19)
BlackLevel
Contrast
Temperature
Gamma
Saturation
Hue
Gain
PowerResolution
Overdrive
Reset
Sound Volume “3-1.AdjustingVolume<Volume>”
(page27)
Source*3 “3-2.Switchingsoundsourcefor
HDMIsignalinput<Source>”(page
27)
PowerSave “4-1.SettingPowerSaving<Power
Save>”(page31)
PowerManager PowerSave
OffTimer “4-5.Enabling/DisablingAuto
Power-OFF<OffTimer>”(page33)
Others ScreenSize “2-5.ChangingtheScreenSize”
(page26)
BorderIntensity
Menu
Settings
MenuSize “3-3.SettingAdjustmentMenu
Display”(page28)
MenuPosition
MenuOffTimer
Translucent
Powerindicator “4-2.SettingPowerIndicator
<PowerIndicator>”(page32)
ColorSpace*3 “Chapter6Troubleshooting”(page
36)
Reset “3-8.ResettingtheMonitortothe
DefaultSettings<Reset>”(page30)
Information “7-2.DisplayingMonitorInformation
<Information>”(page42)
Language “3-6.SettingLanguage
<Language>”(page29)
*1Analogsignalinputonly
*2Theadjustment/settingsavailableonthe<Color>menudependontheselectedFineContrastmode.The
abovetableshowsthesubmenuswhentheUser1orUser2modeisselected.
*3ThisfunctionisavailablewithHDMIsignalinput.

13
Chapter2AdjustingScreens
Chapter 2 Adjusting Screens
2-1. Compatible Resolutions/Formats
The monitor supports the following resolutions and signal format.
Analog Input (D-Sub)
Resolution Applicable Signals Vertical Scan
Frequency Dot Clock
640×480 VGA,VESA,CEA-861 upto75Hz
148.5MHz
(Max.)
720×400 VGATEXT 70Hz
800×600 VESA upto75Hz
1024×768 VESA upto75Hz
1280×720 CEA-861 60Hz
1280×960 VESA 60Hz
1280×1024 VESA upto75Hz
1680×1050 VESACVT,VESACVTRB 60Hz
1920×1080* CEA-861 60Hz
Digital Input (DVI-D, HDMI: PC signal)
Resolution Applicable Signals Vertical Scan
Frequency Dot Clock
640×480 VGA,CEA-861 60Hz
148.5MHz
(Max.)
720×400 VGATEXT 70Hz
800×600 VESA 60Hz
1024×768 VESA 60Hz
1280×720 CEA-861 60Hz
1280×960 VESA 60Hz
1280×1024 VESA 60Hz
1680×1050 VESACVT,VESACVTRB 60Hz
1920×1080* CEA-861 60Hz
A graphics board in conformance with the VESA and CEA-861 standards is required.
*Recommended resolution
Digital Input (HDMI: video signal)
• Video signal
- VGA / 525i (480i)/525p (480p)/1125i (1080i)/750p (720p)/1125p (1080p): 60 Hz
- 625i (576i)/625p (576p)/1125i (1080i)/750p (720p)/1125p (1080p): 50 Hz
• Audio signal
- 2ch linear PCM (32 kHz / 44.1 kHz / 48 kHz)

14 Chapter2AdjustingScreens
2-2. Setting the Resolution
When you connect the monitor to the PC and nd that the resolution is improper, or when you want to change
the resolution, follow the procedure below.
Windows 7
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Screen resolution”.
3. On the “Screen Resolution” dialog box, select the monitor.
4. Click “Resolution” to select the desired resolution.
5. Click the [OK] button.
6. When a conrmation dialog box is displayed, click [Keep changes].
Windows Vista
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Personalize”.
3. On the “Personalization” window, click “Display Settings”.
4. On the “Display Settings” dialog box, select the “Monitor” tab and select desired resolution in the
“Resolution” eld.
5. Click the [OK] button.
6. When a conrmation dialog box is displayed, click [Yes].
Windows XP
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Properties”.
3. When the “Display Properties” dialog box is displayed, click the “Settings” tab and select desired
resolution for “Screen resolution” under “Display”.
4. Click the [OK] button to close the dialog box.
Mac OS X
1. Select “System Preferences” from the Apple menu.
2. When the “System Preferences” dialog box is displayed, click “Displays” for “Hardware”.
3. On the displayed dialog box, select the “Display” tab and select desired resolution in the “Resolutions”
eld.
4. Your selection will be reected immediately. When you are satised with the selected resolution, close
the window.

15
Chapter2AdjustingScreens
2-3. Displaying Screen Correctly
● Digital Signal Input
When digital signals are input, images are displayed correctly based on the preset data of the monitor, but if
characters and/or lines appear blurred, go to “6. Modify blurred characters or lines.” (page 18).
When performing more advanced adjustment, see “2-4. Adjusting Color” (page 19) and subsequent pages.
● Analog Signal Input
Attention
• The monitor will take about 30 minutes before its internal electric components stabilize. Wait 30 minutes or more
after turning the monitor power on before starting adjustment.
• The Self Adjust (automatic screen adjustment) function does not work for the images under the resolution of 800 ×
600 (SVGA).
The monitor screen adjustment is used to suppress ickering of the screen or adjust screen position and
screen size correctly according to the PC to be used.
Note
• The Self Adjust function works when all of the following conditions are satised:
- When a signal is input into the monitor for the rst time or when a resolution or vertical/horizontal scan frequency
not used before is set
If the screen is not displayed correctly even after performing the Self Adjust operation, adjust the screen
according to the procedures on the following pages to use the monitor comfortably.
Setting Procedures
1. Perform the auto adjustment.
● To adjust ickering, screen position, and screen size automatically <Screen>
Procedure
1. Choose <Auto Adjustment> from the Adjustment menu, and press .
2. Choose <Screen> from the <Auto Adjustment> menu, and press .
The <Auto Adjustment> menu appears.
3. Select <Execute> with or , and press .
Flickering, screen position, and screen size are corrected by the auto-adjustment function.
Attention
• This function works correctly when an image is fully displayed over the Windows or Macintosh display area. It does
not work properly when an image is displayed only on a part of the screen (command prompt window, for example)
or when a black background (wallpaper, etc.) is in use.
• This function does not work correctly with some graphics boards.
Ifthescreenisnotdisplayedcorrectlyevenafterperforming“1.Performtheautoadjustment.”(page15),
performtheadjustmentsaccordingtotheproceduresonthefollowingpages.Ifthescreenisdisplayed
correctly,goto“5.Adjustingcolorgradation.”(page18).

16 Chapter2AdjustingScreens
2.
Prepare to use analog screen adjustment patterns.
Load the “EIZO LCD Utility Disk” to your PC, and then open the “Screen adjustment pattern les”.
Note
• For details and instructions on opening the “Screen adjustment pattern les”, refer to the Readme.txt le.
3.
Perform the auto adjustment again with the analog screen adjustment pattern
displayed.
● To adjust ickering, screen position, and screen size automatically <Screen>
Procedure
1. Display Pattern 1 in full screen on the monitor using the “Screen adjustment pattern les”.
2. Choose <Auto Adjustment> from the Adjustment menu, and press .
3. Choose <Screen> from the <Auto Adjustment> menu, and press .
The <Auto Adjustment> menu appears.
4. Select <Execute> with or , and press .
Flickering, screen position, and screen size are corrected by the auto-adjustment function.
Ifthescreenisnotdisplayedcorrectlyevenafterperforming“3.Performtheautoadjustmentagain
withtheanalogscreenadjustmentpatterndisplayed.”(page16),performtheadjustmentsaccordingto
theproceduresonthefollowingpages.Ifthescreenisdisplayedcorrectly,goto“5.Adjustingcolor
gradation.”(page18).
4.
Choose <Screen> from the Adjustment menu to perform advanced
adjustments.
Adjust the clock, phase and position, in this order.
● To eliminate vertical bars <Clock>
Procedure
1. Choose <Clock> from the <Screen> menu, and press .
The <Clock> menu appears.
2. Adjust the clock with or to eliminate vertical bars.
Press or slowly so as not to miss the adjustment point.
3. Press to exit the adjustment.
When blurring, ickering or bars appear on the screen after adjustment, proceed to “Phase” to remove ickering or
blurring.

17
Chapter2AdjustingScreens
● To remove ickering or blurring <Phase>
Procedure
1. Choose <Phase> from the <Screen> menu, and press .
The <Phase> menu appears.
2. Adjust the phase with or to minimize ickering or blurring.
3. Press to exit the adjustment.
When vertical bars appear on the screen after adjustment, go back to “To eliminate vertical bars <Clock>”.
(Clock → Phase → Position)
Attention
• Flickering or blurring may not be eliminated depending on your PC or graphics board.
● To correct the screen position <Position>
Note
• Since the number of pixels and the pixel positions are xed on the LCD monitor, only one position is provided to
display images correctly. The position adjustment is made to shift an image to the correct position.
Procedure
1. Choose <Position> from the <Screen> menu, and press .
The <Position> menu appears.
2. Adjust the position with / / / .
3. Press to exit the adjustment.
4. Close Pattern 1.

18 Chapter2AdjustingScreens
5.
Adjusting color gradation.
● To adjust color gradation automatically <Range>
Every color gradation (0 to 255) can be displayed by adjusting the signal output level.
Procedure
1. Display Pattern 2 in full screen on the monitor using the “Screen adjustment pattern les”.
2. Choose <Auto Adjustment> from the Adjustment menu, and press .
3. Choose <Range> from the <Auto Adjustment> menu, and press .
The <Range> menu appears.
4. Select <Execute> with or , and press .
The output range is set automatically.
5. Close Pattern 2.
6.
Modify blurred characters or lines.
● To modify blurred characters/lines <Smoothing>
When an image is displayed with a resolution other than recommended, the characters or lines of the
displayed image may blur.
Attention
• Smoothing setting may not be required depending on the display resolution. (You cannot choose the smoothing icon.)
Adjustable range
1 to 5
Procedure
1. Choose <Screen> from the Adjustment menu, and press .
2. Choose <Smoothing> from the <Screen> menu, and press .
The <Smoothing> menu appears.
3. Use or for adjustment.
4. Press to exit the adjustment.

19
Chapter2AdjustingScreens
2-4. Adjusting Color
● To select the display mode (FineContrast mode)
This function allows easy selection of a desired mode according to monitor application.
Display Modes
Mode Purpose
User1 Selectoneoftheseusermodestodeneadesiredsetofparametersettings.
User2
sRGB SuitableforcolormatchingwithsRGBcompatibleperipherals.
Paper Producesaprintedpapereffectbydecreasingcontrastandcolortemperature.
Game Suitablefordisplayinggameimages.
Cinema Suitablefordisplayingmovie-likeimages.
Displaysthecurrentmode.
Procedure
1. Press or .
A mode name appears at the lower left of the screen.
2. Change the mode by pressing or while the mode name is displayed.
→User1←→User2←→sRGB←→Paper←→Game←→Cinema←
Note
• The Adjustment menu cannot be displayed when a mode name appears.
• “ScreenManager Pro for LCD (DDC/CI)” allows you to select the FineContrast mode automatically according to the
application used (see “Chapter 3 Auto FineContrast” in the “ScreenManager Pro for LCD (DDC/CI)” User’s Manual).
● To perform advanced adjustments
The <Color> menu of the Adjustment menu allows you to congure and save a separate set of color settings
for each mode.
Attention
• The monitor will take about 30 minutes before its internal electric components stabilize. Wait 30 minutes or more
after turning the monitor power on before starting adjustment.
• Perform the range adjustment rst when adjusting color for analog signals (see “To adjust color gradation
automatically <Range>” (page 18)).
• The same image may be seen in different colors on multiple monitors due to their monitor-specic characteristics.
Make ne color adjustment visually when matching colors on multiple monitors.
Note
• The values shown in “%” or “K” are available only as reference.
• Using the “ScreenManager Pro for LCD (DDC/CI)” allows you to perform the color adjustment by using the mouse
and keyboard of your PC. (Refer to “Chapter 4 Color Adjustment” in the User’s Manual for “ScreenManager Pro for
LCD (DDC/CI)”.)

20 Chapter2AdjustingScreens
● Adjustable settings in each mode
The adjustable settings depend on the mode. (You cannot select any non-adjustable or non-settable function.)
For instructions on how to adjust or set each function, refer to subsequent pages.
√: Adjustable -: Not adjustable
Icon Function
FineContrast mode
User1
User2 sRGB Paper Game Cinema
Brightness √√√√√
BlackLevel √ - - √ √
Contrast √ - - √ √
Temperature √ - √ √ √
Gamma √--√-
Saturation √ - - √ √
Hue √ - - √ √
Gain √----
PowerResolution √ - - √ √
Overdrive √--√-
Reset √√√√√
● To adjust brightness <Brightness>
The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD
back panel).
Adjustable range
0 to 100%
Procedure
1. Choose <Color> from the Adjustment menu, and press .
2. Choose <Brightness> from the <Color> menu, and press .
The <Brightness> menu appears.
3. Use or for adjustment.
4. Press to exit the adjustment.
Note
• Alternatively, you can use the or button for adjustment.
• If you feel that the image is too bright even if the brightness is set to 0% or that the image is too dark even if the
brightness is set to 100%, adjust the contrast.
