ekwb EK-FC Strix RTX 2080 Ti Backplate Classic User manual

EK-FC Strix RTX 2080 Ti Backplate Classic
BACKPLATE
INSTALLATION MANUAL

- 2 -
This product is intended for installation only by expert users. Please
consult with a qualified technician for installation. Improper installation
may result in damage to your equipment. EK Water Blocks assumes no
liability whatsoever, expressed or implied, for the use of these products,
nor their installation. The following instructions are subject to change
without notice. Please visit our web site at www.ekwb.com for updates.
Before installation of this product please read important notice, disclosure
and warranty conditions printed on the back of the box.
Before you start using this product please follow these basic guidelines:
Please carefully read the manual thoroughly before beginning
with the installation process!
Please remove your graphics card from the computer to assure
safest mounting process in order to prevent any possible
damages to your GPU and/or graphics card circuit board (PCB).
The EK fittings require only a small amount of force to screw
them firmly in place since the liquid seal is ensured by the
rubber O-ring gaskets.
The use of corrosion inhibiting coolants is always recommended
for any liquid cooling system.
Do not use pure distilled water! For best results EK recommends
the use of EK-CryoFuel coolants!

- 3 -
TABLE OF CONTENT
GENERAL INFORMATION 4
PREPARING YOUR GRAPHICS CARD 4
ATTACHING EK-FC Strix RTX 2080 Ti Backplate Classic TO THE GRAPHICS CARD 5
REQUIRED TOOLS 5
IMPORTANT DISCLOSURES 6
SUPPORT AND SERVICE 7
SOCIAL MEDIA 7

- 4 -
GENERAL INFORMATION
STEP 1
Sample picture of ASUS ROG Strix RTX 2080 Ti graphics card.
STEP 1
EK-FC Strix RTX 2080 Ti Backplate Classic is very easy to install.
First install EK–FC STRIX RTX 2080 TI water block according to its
installation manual. If you have it already installed, please check
the picture below to see which mounting screws are to be left in
their position and which are to be removed. Please remove the
six (6) M2.5x4 AX1 screws and their PVC washers as well (marked
with arrow).
STEP 1
STEP 1
PREPARING YOUR GRAPHICS CARD

- 5 -
ATTACHING EK-FC Strix RTX 2080 Ti Backplate Classic TO THE GRAPHICS CARD
STEP 1
Take enclosed mounting screws and install them as shown on
picture below. Use six (6) M2.5x8 AX1 screws, and tighten them
using Philips head screwdriver.
HINT: Do not tighten screws until they are all positioned in their
mounting holes. The backplate has milled in standoffs, so there
is no fear of over tightening of the screws. Nevertheless, do not
exaggerate with screwing force as there is no need for it.
By all means users must also consider that this product is intended to
be used only with EK-FC STRIX 2080 TI Classic series water blocks.
No other 3rd party heat sinks or coolers are officially supported! EK
does not offer any assistance or support in the latter application.
STEP 1
M2.5x8 AX1
REQUIRED TOOLS
Phillips-head screwdriver Scissors

- 6 -
IMPORTANT DISCLOSURES
VERY IMPORTANT NOTICE:
Once the installation is completed, it is a recommended practice to
test the cooling circuit for leaks prior to powering up the computer.
We recommend a 24 hour leak test prior to powering up the
computer. Do not test the water block using city water pressure. This
will rupture the top of the housing and render the block unusable
(and will void your warranty).While all efforts have been made to
provide the most comprehensive tutorial possible, EK Water Blocks
assumes no liability expressed or implied for any consequential
damage(s) occurring to your equipment as a result of using EK Water
Blocks cooling products, either due to errors or omissions on our
part in the above instructions, or due to failure or defect in the EK
Water Blocks cooling products.
WARRANTY:
Our products are warranted against defects in materials or
workmanship for a period of 24 months beginning from the date
of delivery to the final user. During this period, products will
be repaired or have parts replaced at our discretion provided
that: (I) the product is returned to the agent from whom it was
purchased; (II) the product has been purchased by an end user
and has not used for commercial purposes; (III) the product has
not been misused, handled carelessly, or used in a manner other
than in accordance with the instructions provided describing its
installation and proper use. This warranty does not confer rights
other than those expressly set out above and does not cover any
claims for consequential loss or damage. This warranty is offered
as an extra benefit and does not affect your statutory rights as a
consumer. This warranty is voided if the product comes in contact
with aggressive UV additives or other improper liquids.
EK blocks are sealed with warranty void circular label, which proves
that the block has withstood a pressure leak test. Removing it will
void leak-free guarantee and not the guarantee on the product
itself. Any other RMA issues can be reported to EK Support at
www.ekwb.com/support for further analysis.

For assistance please contact:
http://support.ekwb.com/
EKWB d.o.o.
Pod lipami 18
1218 Komenda
Slovenia - EU
