ekwb EK-RES X3 Series Manual

All disclosures, notices and warranty conditions are being written on the EKWB website. Please read terms of use. Revision 1.0. Released on September 18th 2012!
Installation and mounting manual for EK-RES X3 series reservoir
This product is intended for installation only by expert users. Please consult with a qualified technician for installation. Improper installation may result in damage to your equipment. EK Water Blocks assumes no liability
whatsoever, expressed or implied, for the use of these products, nor their installation. The following instructions are subject to change without notice. Please visit our web site at www.ekwb.com for updates. Before
installation of this product please read important notice, disclosure and warranty conditions printed on the back of the box.
Before you start using this product please follow these basic guidelines:
1. Please carefully read the manual before through before beginning with the installation process!
2. The EK High Flow and EK-PSC type fittings require only a small amount of force to screw them firmly in place since the liquid seal is ensured by the rubber o-ring gaskets.
3. The use of corrosion inhibiting coolants is always recommended for any liquid cooling system.
4. DO NOT USE any kind of alcohol or alcohol derivate with this reservoir or the acrylic tube may crack and fail! Do not clean it using alcohol either!
STEP 1: GENERAL INFORMATION. Factory provided EK-RES X3 series reservoir
Congratulations on your purchase of EK-RES X3 series reservoir! By default the EK-RES X3 series reservoir comes with the following:
-EK-RES X3 series reservoir with preinstalled EK-RES X3 - Anticyclone
-EK-Multioption RES X2 Holder 60mm (2 pcs)
-Polyether anti-vortex foam (H=15mm)
-Mounting mechanism:
o4x G1/4 Plug
o2x EK-G1/4 Extender
oAllen Key 6mm
STEP 2: INSTALLING THE RESERVOIR HOLDERS
EK-RES X3 series reservoirs comes with a pair of special EK-Reservoir holders. These holders are meant to be installed directly on the computer chassis. User
may need to drill 2 (two) Φ4mm holes through chassis metal using electric power drill if there are no appropriate mounting holes available.
STEP 2.1
STEP 2.2
STEP 2.3
Use enclosed M4 screw, washer and
nut to mount the reservoir holder
through the pre-drilled hole to the
computer chassis.
Install reservoir onto reservoir holders.
Using a gentle force the reservoir will
easily 'click' into position. The clamps
should always hold onto acrylic tube and
not the acetal top or bottom.
Once the reservoir is positioned please use
enclosed 2.5mm Allen key to tighten the
hex head screw in order to clamp the
reservoir. Do not use high force. Partially
unscrew the aforementioned screw when
removing the reservoir.
Alternatively one can purchase various reservoir holders, such as EK-UNI Holder 50/70 (EAN: 3830046997715): One can use the EK-UNI Holder 50/70 if the
chassis lack the appropriate holes to install the reservoir and the drilling is out of the question. EK-UNI Holder 50/70 can be install on 5.25” Drive Bay cage and
fixated with M4 screws and nuts to carry the Reservoir Holders.
For more reservoir add-ons please EK Webshop!
TUBE
EK-RES X3 –Sealing gasket
(O-Ring 52x2.5mm)
EK-RES X3 –TUBE
(64-, 104-, 204- or 354mm)
depending on the variant
EK-RES X3 –Sealing gasket
(O-Ring 52x2.5mm)
EK-RES X3 –Anticyclone
(Short, Long)
EK-RES X3 –Reservoir Bottom
EK-RES X3 –Reservoir Top

All disclosures, notices and warranty conditions are being written on the EKWB website. Please read terms of use. Revision 1.0. Released on September 18th 2012!
STEP 3 (optional): USING POLYETHER ANTI-VORTEX FOAM:
EK-RES X3 series reservoir comes preinstalled with EK-RES X3 –Anticyclone by default (long or short –depending on the variant). In case your system suffers
from excessive vortex issues, air bleeding problems or if the pump is sucking in air you may replace the anticyclone with the enclosed polyether foam. There are
two ways to use the polyether anti-vortex foam:
Default configuration
PE foam –use whole
PE foam –trim to fit recess
This is the default configuration of
EK-RES X3 series reservoir.
Use the foam as a whole to replace EK-
RES X3 –Anticyclone.
Trim the foam to size to fit into the
desired recess on the Reservoir Bottom.
STEP 4: RECOMMENDED RESERVOIR CONFIGURATION
EK-RES X3 series reservoir features 5 (five) G1/4 threaded inlet/outlet openings on the Reservoir Bottom plus additional one on the Reservoir Top. In order for
reservoir to function properly one port must be used as an inlet and one as an outlet. Unused ports must be closed with plugs using enclosed 6mm Allen key!
GENERAL OVERVIEW OF ALL G1/4 THREADED PORTS:
IMPORTANT NOTES:
1. When using ports #3, #4 or #6 it is mandatory to use the enclosed EK-Extender G1/4 (EAN: 3831109845165) due the ports being recessed into the plastic
Reservoir Bottom.
2. When using EK-Extender G1/4 make sure not to use fittings or barbs with G1/4 thread longer than 5mm! All EK-PSC and High Flow fittings are
compatible!
3. When using ports #1 and #2 make sure not to use fittings or barbs with diameter larger than 25mm! All EK-PSC and High Flow fittings are compatible!
4. EK recommends the use of EK-PSC fittings. When using fittings other than EK-PSC series please use hose clamps or appropriate substitute to secure the
tubing to the barb. The use of biocide containing and corrosion inhibiting coolant is always recommended for any liquid cooling system.
5. Port #6 of EK-RES X3 series reservoir should only be used to connect this reservoir with external fill port!
TIPS AND ADVICES:
-Using a horizontal pass-through configuration (using ports #1 and #5 as inlet/outlet) will yield in most optimal hydraulic conditions but may result in
difficult initial bleeding of air in low restriction- or high pumping power water cooling systems.
-When using a bottom feeding vertical configuration (using ports #3 and #4 as inlet/outlet) you may experience severe vortex issues. Using a PE foam as
a whole to replace the EK-RES X3 Anticyclone will remedy this issue. Please see STEP 3!
-Visit EK Webshop to purchase various add-ons (such as reservoir holders, tube extenders, alternative reservoir tops and many more) for your EK-RES X3
series reservoir!
REQUIRED TOOLS AND ACCESSORIES:
philips screwdriver power drill with 4mm drill bit (optional)
1- Horizontal Port
2- Horizontal Port
3- Vertical Port
4- Vertical Port
6- Vertical Port (Top)
5- Horizontal Port (back)
RECOMMENDED RESERVOIR CONFIGURATION:
Allen Key 6mm
EK-Plug G1/4
EK-PSC fitting
Tubing
