Elation ChaseBar User manual

Product Descriptions
This is a T-bar 4 channels chaser, features 17 built-in chase patterns and 7 fixed scenes,
each pattern has four operating modes: Audio, Fast, Medium and Slow. When linkup, this unit
can be used as a either a Master or Slave. A DMX controller or a foot controller(supplied) can
be used to control this unit after proper connection.
24-004-1535
Rev 1.0
User Instructions
1. Channel Output: 5A/CH., Total 15A max.
2. Channel Fuse: F6A 250V 5x20mm
3. Blackout Selector: Moving this slider will enable or disable Stand by function when power is
. switched on.
4. Linkup Selector: Move this slider to select between Master and Slave.
5. Function Selector: This slider is used to select Audio/Fast/Medium/Slow mode for the patterns.
6. Channel LEDs: These LEDs indicate the intensity of corresponding channel or activity of the
pattern or scene.
7. Stand By Button: This button serves several functions. In Master mode, tap this button to
activate or deactivate Stand By(its LED flashes when Stand By is active).
Pressing this button for three seconds can activate 17 chase patterns or 7
fixed scenes. When chase patterns are activated, each tap of Pattern button
will select a chase pattern. When the scenes are activated, each tap of Pattern
button will forward a scene step by step.
8. Pattern Button: In Master mode, use this button to select chase pattern or scene.
9. Power Cable: AC 120V~60Hz, 15 A max.
10. Link In: In Master mode, this connector can be plugged in a foot controller(supplied) for
remote control. In DMX mode, this connector is used to receive an incoming
DMX signal from either a DMX controller or Link out(11) on another unit.
11. Link Out: This connector can be used to link to next unit.
Control & Functions
N'OUVREZ PAS..RISQUE DE CHOCELECTRIQUE
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING:
THIS APPARATUS MUST BE EARTHED
POWER INPUT:
AC 120V~60Hz,15A MAX.
OUTPUT:
5A / Channel
Total 15A MAX. Made in PRC
LINK OUTLINK IN
1 = Ground
2 = Data-
3 = Data+
43
2
1 FUSES
4
32
1
OUTPUT: 5A/CH, TOTAL 15A Max.
F6A 250V(5x20mm)
Monitor
PATTERN STAND BY
ON
Stand by
Master
Slave
Audio
Fast
Medium
Slow
Function
Linkup Select
1 2
34
5
6
789 10 11

Technical Specifications:
Power Input .................................................................................. AC 120V~60Hz, 15A max.
Channel Output ......................................................................................... 5A/CH., Total 15A
Link In ................................................................................................ 3 pin XLR male socket
Link Out .......................................................................................... 3 pin XLR female socket
Fuse
Dimensions ..................................................................................................... 616x80x60mm
Weight ........................................................................................................................... 3.8Kg
.................................................................................................... F6A 250V 5x20mm
Product Instructions:
I. Master mode: Slide Linkup selector(3) to "Master", this unit will serve as a Master,
you can use this unit directly or by a foot controller(sold separately).
By linkup function, several unit can be linked together and controlled
by the Master.(There is only a Master in the linkup.)
II. Slave mode: Slide Linkup selector(3) to "Slave", this unit will serve as a Slave, all
function buttons on this unit will be disabled and this unit will be contr-
olled by the Master unit when available.
II. DMX mode Be sure the Linkup selector is in "Slave" position. Connect this unit with
a DMX controller, this unit will be controlled by a DMX controller. Within
the DMX value 0-249, Stand by, 7 scenes and 17 chase patterns will be
be controlled by the 1st channel of the DMX controller. When the DMX
value of channel 1 is among 250-255, this unit will act as a 4 channel
dimmer pack and will be controlled by the controller starting from the
2nd DMX Channel.
IV. Stand By: Tap Stand By button(6) to activate Stand By, its LED flashes indicating
Stand By is active, which will kill all output momentarily. The second
tap of Stand By will deactivate this function.
V. Full On: Keep pressing Pattern and Stand By buttons at a time, Full On will be
activated, all output will be brought to full intensity. Release these two
buttons to leave.
Accessory(not supplied)
The Foot Controller incorporating a 3-pin female
XLR connector is specially designed for cable
remote control of the Chase Bar. When the Chase
Bar is in Master mode, it serves as the two buttons:
Pattern and Stand by on the Chase Bar, has the
same functions and operations.
About the accessory:

DMX Control & Selection
Please refer to the following table for the DMX control of the channel 1 of the
DMX controller.
DMX Values
of channel 1
10-19
20-29
30-39
40-49
50-59
60-69
70-79
Functions
0-9 Stand by
Scene 1
Scene 2
Scene 3
Scene 4
Scene 5
Scene 6
Scene 7
80-89
90-99
100-109
110-119
120-129
130-139
140-149
150-159
160-169
170-179
180-189
190-199
200-209
210-219
220-229
230-239
240-249
Pattern 1
Pattern 2
Pattern 3
Pattern 4
Pattern 5
Pattern 6
Pattern 7
Pattern 8
Pattern 9
Pattern 10
Pattern 11
Pattern 12
Pattern 13
Pattern 14
Pattern 15
Pattern 16
Pattern 17
250-255
T16F serves as a 4-
channel dimmer pack
and will be controlled by
the DMX controller
starting from the 2nd
channel
NOTE:
1. When the DMX value of channel 1 is within 0-9, the T16F will be in Stand by mode.
2. When the 1st DMX channel is set to 250-255, the T16F will serves as a 4 channel dimmer
pack, and be controlled by the DMX controller starting from the 2nd channel.
This Product must be earthed.
Disconnect power cable before opening.
To prevent fire or shock hazard, do not expose this product to a high
temperature or high humidity area.
WARNING!
Caution! No user serviceable parts inside, do not attempt repairs. In the event your unit
should fail, please contact your authorized dealer.
