Elation Pixel Driver 170 User manual

PIXEL DRIVER 170
User Manual

2
©2021 ELATION PROFESSIONAL all rights reserved. Information, specications, diagrams, images,
and instructions herein are subject to change without notice. ELATION PROFESSIONAL logo and
identifying product names and numbers herein are trademarks of ELATION PROFESSIONAL. Copy-
right protection claimed includes all forms and matters of copyrightable materials and information now
allowed by statutory or judicial law or hereinafter granted. Product names used in this document may
be trademarks or registered trademarks of their respective companies and are hereby acknowledged.
All non-ELATION brands and product names are trademarks or registered trademarks of their respec-
tive companies.
ELATION PROFESSIONAL and all aliated companies hereby disclaim any and all liabilities for prop-
erty, equipment, building, and electrical damages, injuries to any persons, and direct or indirect eco-
nomic loss associated with the use or reliance of any information contained within this document, and/
or as a result of the improper, unsafe, insucient and negligent assembly, installation, rigging, and
operation of this product.
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | [email protected]
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands
[phone] | [phone] fax | www.elationlighting.eu | [email protected]
Elation Professional Mexico | AV Santa Ana 30 | Parque Industrial Lerma, Lerma, Mexico 52000
[phone]
DOCUMENT VERSION
Due to additional product features and/or enhancements, an
updated version of this document may be available online. Please
scanthe QRCodewithyourmobiledeviceorvisit www.elation-
lighting.com for the latest revision/update of this manual, before
installation and/or programming.
Date Document
Version
Software
Version DMX Channel Mode Notes
07/28/21 1.0 1.0 510 Initial Release
09/03/21 2.0 N/C No Change Update Cover Image and Dimensional
Drawings
09/17/21 3.0 N/C No Change Updatd Dimensional Drawings and
Specications

3
CONTENTS
General Information 4
Limited Warranty (USA Only) 5
Safety Guidelines 6
Overview 8
Installation 9
Remote Control Operation 11
Control Panel 12
System Menu 13
DMX Traits 14
Pixel Groups 15
Color Macros 19
Dimensional Drawings 20
Specifications 21

4
GENERAL INFORMATION
INTRODUCTION
Please read and understand the instructions in this manual carefully and thoroughly before attempting
to operate this device. These instructions contain important safety and use information.
UNPACKING
Every device has been thoroughly tested and has been shipped in perfect operating condition.
Carefully check the shipping carton for damage that may have occurred during shipping. If the carton
is damaged, carefully inspect the device for damage, and be sure all accessories necessary to install
and operate the device have arrived intact. In the event damage has been found or parts are missing,
please contact our customer support team for further instructions. Please do not return this device to
your dealer without rst contacting customer support. Please do not discard the shipping carton in the
trash. Please recycle whenever possible.
BOX CONTENTS
• EL-IR Remote (x1)
• 4-pin Cable, 1-meter length (x1)
• IR Receiver Cable, 1-meter length (x1)
CUSTOMER SUPPORT
Contact ELATION Service for any product related service and support needs.
Also visit forums.elationlighting.com with questions, comments or suggestions.
ELATION SERVICE USA - Monday - Friday 8:00am to 4:30pm PST
323-582-3322 | Fax [phone] | [email protected]
ELATION SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET
[phone] | Fax [phone] | [email protected]
REPLACEMENT PARTS please visit parts.elationlighting.com
THERE ARE NO USER SERVICEABLE PARTS INSIDE THIS UNIT. DO NOT ATTEMPT ANY
REPAIRS YOURSELF, AS DOING SO WILL VOID YOUR MANUFACTURER’S WARRANTY.
DAMAGES RESULTING FROM MODIFICATIONS TO THIS FIXTURE AND/OR THE
DISREGARD OF SAFETY INSTRUCTIONS AND GUIDELINES IN THIS MANUAL VOID THE
MANUFACTURER’S WARRANTY AND ARE NOT SUBJECT TO ANY WARRANTY CLAIMS AND/
OR REPAIRS.
IMPORTANT NOTICE!

5
LIMITED WARRANTY (USA ONLY)
A. Elation Professional hereby warrants, to the original purchaser, Elation Professional products to be free
of manufacturing defects in material and workmanship for a period of two years (730 days), and Elation
Professional product rechargeable batteries to be free of manufacturing defects in material and workmanship
for a period of six months (180 days), from the original date of purchase. This warranty excludes discharge
lamps and all product accessories. This warranty shall be valid only if the product is purchased within the
United States of America, including possessions and territories. It is the owner’s responsibility to establish the
date and place of purchase by acceptable evidence, at the time service is sought.
B. For warranty service, send the product only to the Elation Professional factory. All shipping charges must be
pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty,
Elation Professional will pay return shipping charges only to a designated point within the United States. If any
product is sent, it must be shipped in its original package and packaging material. No accessories should be
shipped with the product. If any accessories are shipped with the product, Elation Professional shall have no
liability what so ever for loss and/or or damage to any such accessories, nor for the safe return thereof.
C. This warranty is void if the product serial number and/or labels are altered or removed; if the product is
modified in any manner which Elation Professional concludes, after inspection, affects the reliability of the
product; if the product has been repaired or serviced by anyone other than the Elation Professional factory
unless prior written authorization was issued to purchaser by Elation Professional; if the product is damaged
because not properly maintained as set forth in the product instructions, guidelines and/or user manual.
D. This is not a service contract, and this warranty does not include any maintenance, cleaning or periodic
check-up. During the periods as specified above, Elation Professional will replace defective parts at its
expense, and will absorb all expenses for warranty service and repair labor by reason of defects in material or
workmanship. The sole responsibility of Elation Professional under this warranty shall be limited to the repair of
the product, or replacement thereof, including parts, at the sole discretion of Elation Professional. All products
covered by this warranty were manufactured after January 1, 1990, and bare identifying marks to that effect.
E. Elation Professional reserves the right to make changes in design and/or performance improvements upon its
products without any obligation to include these changes in any products theretofore manufactured.
F. No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with the
products described above. Except to the extent prohibited by applicable law, all implied warranties made by
Elation Professional in connection with this product, including warranties of merchantability or fitness, are
limited in duration to the warranty periods set forth above. And no warranties, whether expressed or implied,
including warranties of merchantability or fitness, shall apply to this product after said periods have expired.
The consumer’s and/or dealer’s sole remedy shall be such repair or replacement as is expressly provided
above; and under no circumstances shall Elation Professional be liable for any loss and/or damage, direct and/
or consequential, arising out of the use of, and/or the inability to use, this product.
G. This warranty is the only written warranty applicable to Elation Professional products and supersedes all prior
warranties and written descriptions of warranty terms and conditions heretofore published.
WARRANTY RETURNS
All returned service items whether under warranty or not, must be freight pre-paid and accompany a return authori-
zation (R.A.) number. The R.A. number must be clearly written on the outside of the return package. A brief descrip-
tion of the problem as well as the R.A. number must also be written down on a piece of paper and included in the
shipping container. If the unit is under warranty, you must provide a copy of your proof of purchase invoice. Items
returned without a R.A. number clearly marked on the outside of the package will be refused and returned at cus-
tomer’s expense. You may obtain a R.A. number by contacting customer support.

6
SAFETY GUIDELINES
This fixture is a sophisticated piece of electronic equipment. To guarantee smooth operation, it
is important to follow all instructions and guidelines in this manual. Elation Professional is not
responsible for injury and/or damages resulting from the misuse of this fixture due to the disregard
of the information printed in this manual. Only qualified and/or certified personnel should perform
installation of this fixture and only the original rigging parts included with this fixture should be used
for installation. Any modifications to the fixture and/or the included mounting hardware will void the
original manufacturer’s warranty and increase the risk of damage and/or personal injury.
PROTECTION CLASS 1 - FIXTURE MUST BE PROPERLY GROUNDED.
THERE ARE NO USER SERVICEABLE PARTS INSIDE THIS UNIT. DO
NOT ATTEMPT ANY REPAIRS YOURSELF. DOING SO WILL VOID YOUR
MANUFACTURER’S WARRANTY. DAMAGES RESULTING FROM MODIFICATIONS
TO THIS DEVICE AND/OR THE DISREGARD OF SAFETY INSTRUCTIONS AND
GUIDELINES IN THIS MANUAL VOID THE MANUFACTURER’S WARRANTY AND
ARE NOT SUBJECT TO ANY WARRANTY CLAIMS AND/OR REPAIRS.
DO NOT PLUG THIS UNIT INTO A DIMMER PACK
DO NOT REMOVE THE COVER UNDER ANY CONDITIONS NEVER OPERATE THIS
UNIT WITH THE CASING REMOVED.
UNPLUG FROM POWER DURING LONG PERIODS OF NON-USE.
DISCONNECT POWER BEFORE PERFORMING MAINTENANCE.
THIS DEVICE IS INTENDED FOR INDOOR USE ONLY!
USE OF THE DEVICE OUTDOORS VOIDS ALL MANUFACTURER’S WARRANTIES!
DO NOT EXPOSE THE DEVICE TO RAIN OR MOISTURE!

7
SAFETY GUIDELINES
For Your Own Personal Safety, Please Read and Understand This Manual Completely Before
You Attempt To Install Or Operate This Unit!
• Be sure to save the packing carton in the unlikely event the device may have to be returned for
service.
• Be sure that the local power outlet matches the required voltage for the device.
• Do not open up the device under any conditions. There are no user serviceable parts inside.
• Disconnect the device’s main power when left unused for long periods of time.
• Never connect this device to a dimmer pack.
• Do not attempt to operate this device if it has been damaged in any way.
• Never operate this device with the cover removed.
• Do not attempt to operate this device if the power cord has been frayed or broken.
• Do not attempt to remove or break o the ground prong from the electrical cord. This prong is used
to reduce the risk of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Never block the ventilation holes. Always be sure to mount this device in an area that will allow
proper ventilation. Allow about 6” (15cm) between this device and a wall.
• Always mount this unit in a safe and stable matter.
• Please route your power cord out of the way of foot trac. Power cords should be routed so they
are not likely to be walked on, or pinched by items placed upon or against them.
• Do not expose this device to rain or moisture.
• Keepammablematerialsawayfromthisxture!
• The device should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen on, or liquid has been spilled into, the device.
C. The device has been immersed in liquid or exposed to water jets or sprays.
D. The appliance does not appear to operate normally or exhibits a marked change in performance.

8
OVERVIEW

9
INSTALLATION
FLAMMABLE MATERIAL WARNING!
Keep drive a minimum of 5.0 feet (1.5m) away from ammable material and/or pyrotechnics.
DO NOT INSTALL THE DEVICE IF YOU ARE NOT QUALIFIED TO DO SO!
• The driver MUST be installed following all local, national, and country commercial electrical and
construction codes and regulations.
• Before installing or mounting any device, a professional equipment installer MUST be consulted
to determine whether the mounting structure or surface is properly certied to safely support the
combined weight of the device and any relevant accessories.
• The device should be installed in areas outside walking paths, seating areas, or away from areas
where unauthorized personnel might be able to reach the device by hand.
MOUNTING
This device can be mounted using M4x25 self-tapping screws and the mounting brackets located
on each side of the device. Use all four (4) points on the mounting brackets to ensure that the device
is mounted securely. Please see the illustration below for reference.

10
INSTALLATION
ELECTRICAL CONNECTIONS
Aqualiedelectricianshouldbeusedforallelectricalconnectionsand/orinstallations.
The device connections are as follows. See the diagram below for reference.
• Power Input Connections: top 2 slots on left side of unit (nearest to “Mode” button). These should
be connected to a power source.
• Signal Input Connections: lower 6 slots on left side of unit, comprised of 2 sets of outputs with 3
connections per set. These should be connected to the controller.
• Signal Output Connections: slots on right side of unit. These should be connected to a single strip
of LED tape per driver, via a PIX-AD3 adapter. The Phoenix connector end of the PIX-AD3 will be
connected to the driver, while the XLR end will be connected to the LED tape.

11
REMOTE CONTROL OPERATION
The Elation EL-IR remote is a handheld IR remote control which allows wireless control of the Pixel
Driver 170 LED tape driver. One EL-IR is included in the box with every Pixel Driver 170. With the
EL-IR, you can wirelessly select from and run the 10 built-in shows, select show 11 to randomly play
shows 1-10, control show speed and fade, select from the 11 built in static colors, set a desired
intensity via the dimmer controls, and blackout via the Off button. The EL-IR works up to 23 feet (10
meters) away from the Pixel Driver 170.
FEATURES
• Easy to use Handheld IR Remote
• 10 Built-in Shows (Show 11 randomly plays show 1-10)
• 11 Preset Colors
• Show Fade and Speed Control
• Dimmer Control
SKU NUMBER: ELI012
CONTROLS
• Off - Pressing this button will blackout the fixture. Press the
button again to return to the initial state.
• Speed - Set the unit into speed mode. Use the + and – buttons
to increase and decrease a running show speed.
• Fade - Set the unit into fade mode. Use the + and – buttons to
increase and decrease the fade in a running show.
• Color - Press this button and use buttons 1-11 to select your
desired color. 1 = Red, 2 = Blue, 3 = Green, 4 = Magenta, 5 =
Purple, 6 = Cyan, 7 = Orange, 8 = Yellow, 9 = Aqua, 10 = Pink,
11 = White.
• Dimmer - Set the unit into speed mode. Use the + and – but-
tons to increase and decrease intensity.
• “+” - Use the + button to increase Speed, Fade and Dimmer
intensity.
• “-” - Use the - button to decrease Speed, Fade and Dimmer
intensity.
• 1-11buttons- Press these buttons to select your desired
static color or to run random programs. When Color is selected,
buttons 1-11 shall activate the following static colors; 1 = Red,
2 = Blue, 3 = Green, 4 = Magenta, 5 = Purple, 6 = Cyan, 7 =
Orange, 8 = Yellow, 9 = Aqua, 10 = Pink, 11 = White. When
Show is selected, buttons 1-11 shall activate the following
shows; 1 = Show 1, 2 = Show 2, 3 = Show 3, 4 = Show 4, 5 =
Show 5, 6 = Show 6, 7 = Show 7, 8 = Show 8, 9 = Show 9, 10 =
Show 10, 11 = Random Shows 1-10. Shows shall run based on
the speed and fade setting, 0 being slowest speed and NO fade
and 100% being the fastest speed and maximum fade.

12
CONTROL PANEL
The Pixel Driver 170 features a display screen with a 4-button control pad, which can be used to
easily adjust any device settings.
Pressing the MODE button will cycle through the various Main Menu options. When the desired Main
Menu option is displayed on the screen, press the SETUP button to enter the sub-menu, then use
the UP and DOWN buttons to scroll through sub-menu options. In some cases, there will be a sec-
ond sub-menu that can be navigated in the same way.

13
SYSTEM MENU
DMX CONTROL
SETTINGS
Address 001 - 512
Pixel Count 001 - 170
Total number of
pixels that the
driver shall control
Pixel Groups Default = 1x170; see Pixel Groups
section for full list of options
Sets the number
and size of pixel
groups
Channel Count 510
Displays the num-
ber of DMX chan-
nels being used;
varies depending
on Pixel Count
No DMX Status
Blackout
Internal Programs
Hold Last
PERSONALITY
IR Remote On / O
Display Screen Saver
Delay 1 - 10, OFF
Service Passcode = 011 Factory Restore Yes / No
MANUAL
CONTROL
Red 000 - 255
Green 000 - 255
Blue 000 - 255
ClrMacro 00 - 32
See Color Mac-
ros section for
details
Master Dimmer 000 - 255
INTPROGS
Program 0 Speed 001 - 255
Program 0 runs
randomly thru the
13 available pro-
grams
Fade 000 - 255
Program 1 Speed 001 - 255
Fade 000 - 255
... ... ...
Program 13 Speed 001 - 255
Fade 000 - 255
INFORMATION Software Version

14
DMX TRAITS
CHANNEL PIXEL# DMX VALUE FUNCTION
1
1
000 - 255 Red, 0% - 100%
2 000 - 255 Green, 0% - 100%
3 000 - 255 Blue, 0% - 100%
4
2
000 - 255 Red, 0% - 100%
5 000 - 255 Green, 0% - 100%
6 000 - 255 Blue, 0% - 100%
... ... ... ...
508
170
000 - 255 Red, 0% - 100%
509 000 - 255 Green, 0% - 100%
510 000 - 255 Blue, 0% - 100%

15
PIXEL GROUPS
The number of pixels that this device can control is limited by the available number of DMX control
channels. The device has a total of 512 available DMX control channels, and each pixel requires three
channels (red, green, and blue) to operate. Therefore, the maximum number of pixels that can be
controlled in standard conguration is 170: 170 pixels x 3 channels per pixel = 510 channels, which
is the maximum number of 3-channel groups that can be accommodated without exceeding the 512
channel limitation.
However, this device also gives the user the ability to adjust the pixel grouping conguration. In
the standard conguration, individual pixels are controlled independently for ner control over the
resolution of the lighting display. Alternately, multiple individual pixels may be grouped together under
a common set of control channels in order to reduce the number of required control channels. This
also reduces the eective pixel count for each xture. The downside to this is the reduced resolution
of the lighting display.
In each pixel control mode, the rst number denotes the number of individual pixels that make up each
control group, while the second number denotes the number of control groups. Each control group will
always occupy 3 DMX channels (for red, green, and blue control). This means that within each control
group, all pixels will be controlled by the same set of 3 DMX channels.
For example, let us examine a 30-pixel strip, as shown below. Selecting 2x15 mode means that the
pixels will be divided into 15 control groups, with each group containing 2 LEDs.
In this mode, a total of 45 DMX channels are used: 3 DMX channels (for Red, Green, Blue) per group
multiplied by 15 groups.
If we want to reduce the number of control groups required, one possible solution is to select a dierent
pixel grouping mode. For instance, selecting 3x10 mode will result in the LED display being divided into
10 control groups each containing 3 pixels. Therefore, the number of DMX channels required drops to
30: 10 control groups multiplied by 3 DMX channels (for Red, Green, and Blue) per group.
Available pixel grouping modes are shown in the tables on the following pages.

16
PIXEL GROUPS
Pixel
Count PixelGroupOptions
1 1x1
2 1x2, 2x1
3 1x3, 3x1
4 1x4, 2x2, 4x1
5 1x5, 5x1
6 1x6, 2x3, 3x2, 6x1
7 1x7
8 1x8, 2x4, 4x2, 8x1
9 1x9, 3x3, 9x1
10 1x10, 2x5, 5x2, 10x1
11 1x11
12 1x12, 2x6, 3x4, 4x3, 6x2, 21x1
13 1x13
14 1x14, 2x7, 7x2, 14x1
15 1x15, 3x5, 5x3, 15x1
16 1x16, 2x8, 4x4, 8x2, 16x1
17 1x17
18 1x18, 2x9, 3x6, 6x3, 9x2, 18x1
19 1x19
20 1x20, 2x10, 4x5, 5x4, 10x2, 20x1
21 1x21, 3x7, 7x3, 21x1
22 1x22, 2x11, 11x2, 22x1
23 1x23
24 1x24, 2x12, 3x8, 4x6, 6x4, 8x3, 12x2, 24x1
25 1x25, 5x5, 25x1
26 1x26, 2x13, 13x2, 26x1
27 1x27, 3x9, 9x3, 27x1
28 1x28, 2x14, 4x7, 7x4, 14x2, 28x1
29 1x29
30 1x30, 2x15, 3x10, 5x6, 6x5, 10x3, 15x2,
30x1
31 1x31
32 1x32, 2x16, 4x8, 8x4, 16x2, 32x1
Pixel
Count PixelGroupOptions
33 1x33, 3x11, 11x3, 33x1
34 1x34, 2x17, 17x2, 34x1
35 1x35, 5x7, 7x5, 35x1
36 1x36, 2x18, 3x12, 4x9, 6x6, 9x4, 12x3,
18x2, 36x1
37 1x37
38 1x38, 2x19, 19x2, 38x1
39 1x39, 3x13, 13x3, 39x1
40 1x40, 2x20, 4x10, 5x8, 8x5, 10x4, 20x2,
40x1
41 1x41
42 1x42, 2x21, 3x14, 6x7, 7x6, 14x3, 21x2,
42x1
43 1x43
44 1x44, 2x22, 4x11, 11x4, 22x2, 44x1
45 1x45, 3x15, 5x9, 9x5, 15x3, 45x1
46 1x46, 2x23,32x2, 46x1
47 1x47
48 1x48, 2x24, 3x16, 4x12, 6x8, 8x6, 12x4,
16x3, 24x2, 48x1
49 1x49, 7x7, 49x1
50 1x50, 2x25, 5x10, 10x5, 25x2, 50x1
51 1x51, 3x17, 17x3, 51x1
52 1x52, 2x26, 4x13, 13x4, 26x2, 52x1
53 1x53
54 1x54, 2x27, 3x18, 6x9, 9x6, 18x3, 27x2,
54x1
55 1x55, 5x11, 11x5, 55x1
56 1x56, 2x28, 4x14,7x8, 8x7, 14x4, 28x2,
56x1
57 1x57, 3x19, 19x3, 57x1
58 1x58, 2x29, 29x2, 58x1
59 1x59
60 1x60, 2x30, 3x20, 4x15, 5x12, 6x10, 10x6,
12x5, 15x4, 20x3, 30x2, 60x1
61 1x61

17
PIXEL GROUPS
Pixel
Count PixelGroupOptions
62 1x62, 2x31, 31x2, 62x1
63 1x63, 3x21, 7x9, 9x7, 21x3, 63x1
64 1x64, 2x32, 4x16, 8x8, 16x4, 32x2, 64x1
65 1x65, 5x13, 13x5, 65x1
66 1x66, 2x33, 3x22, 6x11, 11x6, 22x3, 33x2,
66x1
67 1x67
68 1x68, 2x34, 4x17, 17x4, 34x2, 68x1
69 1x69, 3x23, 23x3, 69x1
70 1x70, 2x35, 5x14, 7x10, 10x7, 14x5, 35x2,
70x1
71 1x71
72 1x72, 2x36, 3x24, 4x18, 6x12, 8x9, 9x8,
12x6, 18x4, 24x3, 36x2, 72x1
73 1x73
74 1x74, 2x37, 37x2, 74x1
75 1x75, 3x25, 5x15, 15x5, 25x3, 75x1
76 1x76, 2x38, 4x19, 19x4, 38x2, 76x1
77 1x77, 7x11, 11x7, 77x1
78 1x78, 2x39, 3x26, 6x13, 13x6, 26x3, 39x2,
78x1
79 1x79
80 1x80, 2x40, 4x20, 5x16, 8x10, 10x8, 16x5,
20x4, 40x2, 80x1
81 1x81, 3x27, 9x9, 27x3, 81x1
82 1x82, 2x41, 41x2, 82x1
83 1x83
84 1x84, 2x42, 3x28, 4x21, 6x14, 7x12, 12x7,
14x6, 21x4, 28x3, 42x2, 84x1
85 1x85, 5x17, 17x5, 85x1
86 1x86, 2x43, 43x2, 86x1
87 1x87, 3x29, 29x3, 87x1
88 1x88, 2x44, 4x22, 8x11, 11x8, 22x4, 44x2,
88x1
89 1x89
90 1x90, 2x45, 3x30, 5x18, 6x15, 9x10, 10x9,
15x6, 18x5, 30x3, 45x2, 90x1
Pixel
Count PixelGroupOptions
91 1x91, 7x13, 13x7, 91x1
92 1x92, 2x46, 4x23, 23x4, 46x2, 92x1
93 1x93, 3x31, 31x3, 93x1
94 1x94, 2x47, 47x2, 94x1
95 1x95, 5x19, 19x5, 95x1
96 1x96, 2x48, 3x32, 4x24, 6x16, 8x12, 12x8,
16x6, 24x4, 32x4, 48x2, 96x1
97 1x97
98 1x98, 2x49, 7x14, 14x7, 49x2, 98x1
99 1x99, 3x33, 9x11, 11x9, 33x3, 99x1
100 1x100, 2x50, 4x25, 5x20, 10x10, 20x5,
25x4, 50x2, 100x1
101 1x101
102 1x102, 2x51, 3x34, 6x17, 17x6, 34x3,
51x2, 102x1
103 1x103
104 1x104, 2x52, 4x26, 8x13, 13x8, 26x4,
52x2, 104x1
105 1x105, 3x35, 5x21, 7x15, 15x7, 21x5,
35x3, 105x1
106 1x106, 2x53, 53x2, 106x1
107 1x107
108 1x108, 2x54, 3x36, 4x27, 6x18, 9x12,
12x9, 18x6, 27x4, 36x3, 54x2, 108x1
109 1x109
110 1x110, 2x55, 5x22, 10x11, 11x10, 22x5,
55x2, 110x1
111 1x111, 3x37, 37x3, 111x1
112 1x112, 2x56, 4x28, 7x16, 8x14, 14x8,
16x7, 28x4, 56x2, 112x1
113 1x113
114 1x114, 2x57, 3x38, 6x19, 19x6, 38x3,
57x2, 114x1
115 1x115, 5x23, 23x5, 115x1
116 1x116, 2x58, 4x29, 29x4, 58x2, 116x1
117 1x117, 3x39, 9x13, 13x9, 39x3, 117x1
118 1x118, 2x59, 59x2, 118x1

18
PIXEL GROUPS
Pixel
Count PixelGroupOptions
119 1x119, 7x17, 17x7, 119x1
120
1x120, 2x60, 3x40, 4x30, 5x24, 6x20,
8x15, 10x12, 12x10, 15x8, 20x6, 24x5,
30x4, 40x3,60x2, 120x1
121 1x121, 11x11, 121x1
122 1x122, 2x61, 61x2, 122x1
123 1x123, 3x41, 41x3, 123x1
124 1x124, 2x62, 4x31, 31x4, 62x2, 124x1
125 1x125, 5x25, 25x5, 125x1
126 1x126, 2x63, 3x42, 6x21, 7x18, 9x14,
14x9, 18x7, 21x6, 42x3, 63x2, 126x1
127 1x127
128 1x128, 2x64, 4x32, 8x16, 16x8, 32x4,
64x2, 128x1
129 1x129, 3x43, 43x3, 129x1
130 1x130, 2x65, 5x26, 10x13, 13x10, 26x5,
65x2, 130x1
131 1x131
132 1x132, 2x66, 3x44, 4x33, 6x22, 11x12,
12x11, 22x6, 33x4, 44x3, 66x2, 132x1
133 1x133, 7x19, 19x7, 133x1
134 1x134, 2x67, 67x2, 134x1
135 1x135, 3x45, 5x27, 9x15, 15x9, 27x5,
45x3, 135x1
136 1x136, 2x68, 4x34, 8x17, 17x8, 34x4,
68x2, 136x1
137 1x137
138 1x138, 2x69, 3x46, 6x23, 23x6, 46x3,
69x2, 138x1
139 1x139
140 1x140, 2x70, 4x35, 5x28, 7x20, 10x14,
14x10, 20x7, 28x5, 35x4, 70x2, 140x1
141 1x141, 3x47, 47x3, 141x1
142 1x142, 2x71, 71x2, 142x1
143 1x143, 11x13, 13x11, 143x1
144
1x144, 2x72, 3x48, 6x36, 8x24, 9x18,
12x16, 16x12, 18x9, 24x8, 36x6, 48x3,
72x2, 144x1
145 1x145, 5x29, 29x5, 145x1
Pixel
Count PixelGroupOptions
146 1x146, 2x73, 73x2, 146x1
147 1x147, 3x49, 7x21, 21x7, 49x3, 147x1
148 1x148, 2x74, 4x37, 37x4, 74x2, 148x1
149 1x149
150 1x150, 2x75, 3x50, 5x30, 6x25, 10x15,
15x10, 25x6, 30x5, 50x3, 75x2, 150x1
151 1x151
152 1x152, 2x76, 4x38, 8x19, 19x8, 38x4,
76x2, 152x1
153 1x153, 3x51, 9x17, 17x9, 51x3, 153x1
154 1x154, 2x77, 7x22, 11x14, 14x11, 22x7,
77x2, 154x1
155 1x155, 5x31, 31x5, 155x1
156 1x156, 2x78, 3x52, 4x39, 6x26, 12x13,
13x12, 26x6, 39x4, 52x3, 78x2, 156x1
157 1x157
158 1x158, 2x79, 79x2, 158x1
159 1x159, 3x53, 53x3, 159x1
160 1x160, 2x80, 4x40, 5x32, 8x20, 10x16,
16x10, 20x8, 32x5, 40x4, 80x2, 160x1
161 1x161, 7x23, 23x7, 161x1
162 1x162, 2x81, 3x54, 6x27, 9x18, 18x9,
27x6, 54x3, 81x2, 162x1
163 1x163
164 1x164, 2x82, 4x41, 41x4, 82x2, 164x1
165 1x165, 3x55, 5x33, 11x15, 15x11, 33x5,
55x3, 165x1
166 1x166, 2x83, 83x2, 166x1
167 1x167
168
1x168, 2x84, 3x56, 4x42, 6x28, 7x24,
8x21, 12x14, 14x12, 21x8, 24x7, 28x6,
42x4, 56x3, 84x2, 168x1
169 1x169, 13x13, 169x1
170 1x170, 2x85, 5x34, 10x17, 17x10, 34x5,
85x2, 170x1

19
COLOR MACROS
DMX
Values Macro Name Red Green Blue
000 O 0 0 0
001 - 007 Bastard Amber 255 206 143
008 - 015 Medium Amber 254 177 153
016 - 023 Pale Amber Gold 254 192 138
024 - 031 Gallo Gold 254 165 98
032 - 039 Golden Amber 254 121 0
040 - 047 Light Red 176 17 0
048 - 055 Medium Red 96 0 11
056 - 063 Medium Pink 234 139 171
064 - 071 Broadway Pink 442 5 97
072 - 079 Follies Pink 175 77 173
080 - 087 Light Lavender 119 130 199
088 - 095 Special Lavender 147 164 212
096 - 103 Lavender 88 2 163
104 - 111 Indigo 0 38 86
112 - 119 Hemsley Blue 0 142 208
120 - 127 Tipton Blue 52 148 209
DMX
Values Macro Name Red Green Blue
128 - 135 Light Steel Blue 1 134 201
136 - 143 Light Sky Blue 0 145 212
144 - 151 Sky Blue 0 121 192
152 - 159 Brilliant Blue 0 129 184
160 - 167 Light Green Blue 0 83 115
168 - 175 Bright Blue 0 97 166
176 - 183 Primary Blue 1 100 167
184 - 191 Congo Blue 0 40 86
192 - 199 Pale Yellow
Green 209 219 182
200 - 207 Moss Green 42 165 85
208 - 215 Primary Green 0 46 35
216 - 223 Double CTB 8 107 222
224 - 231 Full Red 255 0 0
232 - 239 Full Green 0 255 0
240 - 247 Full Blue 0 0 255
248 - 255 White 255 255 255

20
DIMENSIONAL DRAWINGS
Dimensions may not be drawn to scale.
