1 OVERVIEW
www.elcometer.com en-2
R
Available in two versions; Manual and Motorised, the Elcometer 3000
Clemen Unit is a robust and simple-to-use instrument for evaluation of
the resistance to scratching of a coated surface. The sample can be
metal, wood, glass, plastic or other hard materials.
A tool fitted with a hemispherical ball is lowered gradually onto the
surface of the sample and moved in a straight line a distance of 60mm
(2.4"). The downward force exerted by the tool onto the surface is
adjustable by means of a sliding weight.
Depending on the purpose of the test and the force applied, varying
degrees of penetration of the tool into the coating are observed, from a
superficial trace to total destruction.
Elcometer 3000 Manual Clemen Unit: The sample is clamped
to a sliding platform which is moved manually.
Elcometer 3000 Motorised Clemen Unit: The sample is
clamped to a fixed platform. At the press of a button, the tool is
moved across the sample and stops automatically at the end of
its travel. Contact between the tool and a metallic sample is
indicated by a lamp and voltmeter.
1.1 MANUAL CLEMEN UNIT
1 Weight
2 Clamp
3 Load Beam
4 Tool
5 Sample Platform
1
2
3
4
5

1 Weight
2 Support for additional 1kg
(2.2lb) weights
3 Load Beam
4 Clamp
5 Voltmeter
6 Start Button
7 Power On/Off Button
8 Sample Platform
9 Tool
1 OVERVIEW (continued)
R
www.elcometer.com
en-3

Elcometer 3000 Clemen Unit

Tungsten Carbide Ball Tool; 1mm (0.04")

Calibration Certificate - if ordered

User Guide
Additional items supplied with the Elcometer 3000 Motorised
Clemen Unit

1kg Weight (x4)

Mains Leads: UK, EUR & US
The Elcometer 3000 Clemen Unit is packed in a plywood and / or heavy duty cardboard and foam
package. It is recommended that this packaging is retained and reused in the event that the
instrument needs to be transported. If the packaging is disposed of, please ensure that this is done in
an environmentally sensitive manner. Consult your local Environmental Authority for further guidance.
2 BOX CONTENTS
1.2 MOTORISED CLEMEN UNIT
3 WORKING SAFELY
To reduce the risk of electric shock, do not open the housing of
the Elcometer 3000 Motorised Clemen Unit. There are no
user-servicable parts inside. The warranty will be invalidated if
the instrument has been opened.
To reduce the risk of fire or electric shock, do not expose the
Elcometer 3000 Motorised Clemen Unit to rain or excess
moisture.
5
1
3
4
67
8
9
2

3 WORKING SAFELY (continued)
4.1 INSTALLATION
The Elcometer 3000 Motorised Clemen Unit is heavy; manual
lifting of the tester must be carried out by at least two people.
Place the Elcometer 3000 on a flat level surface suitable for the load
imposed by the tester. The Elcometer 3000 Motorised Clemen Unit
has adjustable feet which can be used to level the tester.
4.2 SWITCHING ON / OFF - MOTORISED CLEMEN UNIT ONLY
Press the On/Off button to switch the unit on. The button will
illuminate when the unit is switched on. Press the On/Off button again
to switch the unit off.
The IEC inlet is protected by one fuse - see Section 10 ‘Technical
Specification’ on page en-10 for fuse rating.
The UK mains plug is fitted with a fuse. When replacing this fuse,
ensure a fuse of the correct rating is used - see Section 10 ‘Technical
Specification’ on page en-10 for details.
Elcometer recommends using mains leads approved by a recognised
testing authority. Examples of suitable mains leads are UK, EUR
H05RN-F 3G 0.75mm 2 cable, US SJT 18AWG/3C cable.
4 GETTING STARTED
5 TESTING A SAMPLE - MANUAL CLEMEN UNIT
Before a sample can be tested, the height of the tool must be adjusted.
5.1 ADJUSTING THE TOOL HEIGHT
1 Place the sample onto the sample platform and fix into position by
rotating the clamp handle.
2 Lift and hold the load beam in its raised position and slide the
sample platform until the centre of the sample is underneath the
tool.
www.elcometer.com en-4
R

5 TESTING A SAMPLE - MANUAL CLEMEN UNIT (continued)
3 Insert the metal shim (a) between the nylon wheel (b) and the
load beam (c) and then lower the load beam.
4 Adjust the height of the tool (d) until it is touching the surface of
the sample then tighten the knurled wheel (e), turning clockwise,
to lock the tool into position.
5 Raise the load beam, remove the metal shim and slide the
sample platform back to its starting position.
6 Slide the weight along the load beam to the required load and
lock in place by tightening the knurled wheel. The load can be
set from 0 to 2kg (0 to 4.4lb).
The instrument and sample are now ready for the test to be carried
out.
5.2 TEST PROCEDURE
1 Pull the sample platform towards you in a single smooth action;
the standard speed of movement is approximately 30mm/s
(1.2"/s).
2 The tool will lower down onto the sample at the start of the test
and raise up at the end of the test.
3 Inspect the sample for damage in accordance with the
requirements of the test standard. Repeat the test as necessary,
increase the loading between test.
(a)
(b)
(c )
(d)
(e)
R
www.elcometer.com
en-5

6 TESTING A SAMPLE - MOTORISED CLEMEN UNIT
Before a sample can be tested, the height of the tool must be adjusted.
6.1 ADJUSTING THE TOOL HEIGHT
1 Connect the unit to the mains power supply and press the Power
On/Off button to switch on the instrument.
2 Place the sample onto the sample platform and fix in position by
rotating the clamp handle.
3 Adjust the height of the tool to its upper position to clear the
sample.
4 With the tool positioned at either end, press the Start button then
immediately press the Power On/Off button. This will stop the
load beam near the centre.
5 Insert the metal shim (a) between the nylon wheel (b) and the
load beam (c) and then lower the load beam.
6 Adjust the height of the tool (d) until it is touching the surface of
the sample then tighten the knurled wheel (e), turning clockwise,
to lock the tool into position.
(a)
(b)
(c )
(d)
(e)
7 Raise the load beam, remove the metal shim and whilst
supporting the load beam, press the Power On/Off button
followed by the Start button to return the tool to its starting
position.
 Supporting the load beam whilst the tool is moving to its starting position
prevents damage to the sample surface, the tool or the sample platform.
8 Slide the weight along the load beam to the required load and
lock in place by tightening the knurled wheel. The load can be
set from 0 to 1.5kg (0 to 3.3lb) using the sliding weight.
www.elcometer.com en-6
R

6 TESTING A SAMPLE - MOTORISED CLEMEN UNIT (continued)
For loads between 1.5 and 5kg (3.3 and 11lb) use the additional 1kg
(2.2lb) supplied. Place the required number of weights on the vertical
rod on the load beam to obtain the correct load. For example, if a load
of 3.5kg (7.7lb) is required, place three of the 1kg (2.2lb) weights on to
the vertical rod and slide the weight to the 0.5kg (1.1lb) mark on the
scale.
The instrument and sample are now ready for the test to be carried
out.
6.2 TEST PROCEDURE
Keep fingers clear of the mechanism during use.
1 Press the Start button. The tool will start to move and will lower
down onto the sample at the start of the test, raise up at the end
of the test and then stop automatically.
2 Inspect the sample for damage in accordance with the
requirements of the test standard. Repeat the test as necessary,
increase the loading between test.
The complete destruction of a paint film on a metallic sample is
observed when the voltmeter needle indicates 10 V to 12 V and when
the Start button flashes (the electrical detection device operates only
on metallic samples which are uncoated on the reverse side).
6.3 TESTING THICK SAMPLES
The Elcometer 3000 Motorised Clemen Unit as supplied can be used
to test samples with a maximum thickness of 3mm (0.12"). An
Adjustment Kit is available to purchase as an optional accessory which
allows testing of samples up to 20mm (0.8") thick.
The Adjustment Kit consists of the items listed below. Refer to Figure 1
on page en-8 for the location of the parts.
Part
Description
Qty
A
Load Beam Spacer; 55 x 39 x 5mm
3
B
Sample Clamp Spacer; 35 x 30 x 12mm
1
C
Height Gauge for Wheel; 5 & 15mm
1
Height Gauge for Wheel; 10 & 20mm
1
www.elcometer.com
en-7
R

6 TESTING A SAMPLE - MOTORISED CLEMEN UNIT (continued)
Part
Description
Qty
D
Hexagonal Wrench; 3mm
1
E
M4 x 20 Screw for Load Beam
4 sets
F
M4 x 25 Screw for Sample Clamp
2 sets
G
Height Adjustable Wheel
1
A + E
G + C
B + F
Fit the parts in accordance with the recommendations given in the
table below.
Sample Thickness
5mm Spacers for
Load Beam Base (Qty)
12mm Spacer for
Sample Clamp
Height Gauge
for Wheel
mm
inches
0.5 - 5
0.02 - 0.2
0
Not Required
5mm
5 - 10
0.2 - 0.4
1
Not Required
10mm
10 - 15
0.4 - 0.6
2
Required
15mm
15 - 20
0.6 - 0.8
3
Required
20mm
Note:
1) Fit the load beam base and sample clamp to the spacers using screws of an appropriate length
(Parts E & F above).
2) Use the height gauge (Part C above) to adjust the height of the nylon wheel and then tighten the
knurled wheel to lock in place.
www.elcometer.com en-8
R

7.1 BALL TOOL
Each Elcometer 3000 is supplied with a 1mm (0.04") tungsten carbide
ball tool as standard.
Due to the nature of the test, the ball tool will wear with use. Spare /
replacement tools are available to purchase from Elcometer or your
local Elcometer supplier.
Description Part Number
Tungsten Carbide Ball Tool; 1mm (0.04") KT003000P021
7.2 CUTTING TOOL FOR SCRATCH TESTING
Available to purchase as an optional accessory, the cutting tool gives a
much more aggressive scratch than the standard ball tool supplied
with each instrument. When using the cutting tool, follow the same
adjustment procedure and test procedure as given for the standard ball
tool.
Description Part Number
Tungsten Carbide Cutting Tool; 2mm (0.08") KT003000N001
7.3 ADJUSTMENT KIT
Available to purchase as an optional accessory for the Elcometer 3000
Motorised Clemen Unit, the adjustment kit allows testing of samples up
to 20mm (0.8") thick - see Section 6.3 ‘Testing Thick Samples’ on page
en-7 for further details.
Description Part Number
Adjustment Kit from 5 - 20mm/0.02 - 0.8" KT003000N015
www.elcometer.com
en-9
7 SPARES & ACCESSORIES
8 CARE & MAINTENANCE
The top of the instrument around the test sample area should be
regularly wiped clean using a dry cloth.
The Elcometer 3000 does not contain any user-serviceable
components. In the unlikely event of a fault, the instrument should be
returned to your local Elcometer supplier or directly to Elcometer.
The warranty will be invalidated if the instrument has been opened.
R

The Elcometer 3000 is supplied with a 12 month warranty against
manufacturing defects, excluding contamination and wear.
Replacement consumable parts and accessories, including but not
limited to, ball and cutting tools, are excluded from the warranty.
9 WARRANTY STATEMENT
10 TECHNICAL SPECIFICATION
10.1 ELCOMETER 3000 MANUAL CLEMEN UNIT
Load Range
0 - 2kg (0 - 4.4lb)
Sample Size
75 x 150mm (3 x 6")
Sample Thickness
0.5 - 3mm (0.02 - 0.12")
Dimensions
410 x 200 x 155mm (16.1 x 7.9 x 6.1")
Weight
6kg (13.2lb)
Can be used in accordance with:
AS/NZS 1580.403.1, BS 3900-E2, DIN 53799, ECCA T12, EN 13523-12, ISO 1518-1:2011
10.2 ELCOMETER 3000 MOTORISED CLEMEN UNIT
Load Range
0 - 5kg (0 - 11lb)
Sample Size
75 x 150mm (3 x 6")
Sample Thickness
Standard:
0.5 - 3mm (0.02 - 0.12")
a
Extended :
5 - 20mm (0.2 - 0.8")
Operating Voltage
UK / EU:
230V AC; 0.1A; 50Hz
US:
120V AC; 0.2A; 60Hz
Transient Overvoltage
Category II
Fuse Rating
Power Inlet:
1 x T2AH250V
b
DC Fuse :
1 x T315MAH250V
UK Plug:
1 x T3AH250V
Operating Temperature
(ambient air)
5 to 40°C (41 to 104°F)
Transportation & Storage
Temperature
-10 to 55°C (14 to 131°F)
Humidity Range
Not to exceed 80% relative humidity up to 31°C
(88°F), decreasing linearly to 50% at 40°C (104°F).
continued on page en-11
a Using the optional Adjustment Kit - see Section 6.3 ‘Testing Thickness Samples’ on page en-7.
b Located above power inlet.
www.elcometer.com en-10
R

Declaration of Conformity:
The Elcometer 3000 Motorised Clemen Unit complies with the requirements of the following EU Directives:
2006/42/EC Machinery Directive, as amended by 2009/127/EC and 2014/33/EU
2014/30/EU Electromagnetic Compatibility
The Declaration of Conformity is available to download via:
www.elcometer.com/images/stories/PDFs/Datasheets/Declaration_of_Conformity/English/DoC_3000_Motorised.pdf
This product is Class B, Group 1 ISM equipment according to CISPR 11.
Class B product: Suitable for use in domestic establishments and in establishments directly connected to a low voltage
power supply network which supplies buildings used for domestic purposes.
Group 1 ISM product: A product in which there is intentionally generated and/or used conductively coupled radio
frequency energy which is necessary for the internal functioning of the equipment itself.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
-- Consult the dealer or an experienced radio/TV technician for help.
To satisfy FCC RF Exposure requirements for mobile and base station transmission devices, a separation distance of
20 cm or more should be maintained between the antenna of this device and persons during operation. To ensure
compliance, operation at closer than this distance is not recommended. The antenna(s) used for this transmitter must
not be co-located or operating in conjunction with any other antenna or transmitter.
Modifications not expressly approved by Elcometer Limited could void the user's authority to operate the equipment
under FCC rules.
is a registered trademark of Elcometer Limited, Edge Lane, Manchester,
M43 6BU. United Kingdom
All other trademarks acknowledged.
The Elcometer 3000 Clemen Unit is packed in a plywood and / or heavy duty cardboard and foam package. It is
recommended that this packaging is retained and reused in the event that the instrument needs to be transported. If
the packaging is disposed of, please ensure that this is done in an environmentally sensitive manner. Consult your
local Environmental Authority for further guidance.
Head-Office: Elcometer Limited, Edge Lane, Manchester, M43 6BU, United Kingdom.
10 TECHNICAL SPECIFICATION (continued)
10.2 ELCOMETER 3000 MOTORISED CLEMEN UNIT (continued)
Pollution Degree
2
Enclosure IP Rating
IP20
Dimensions
460 x 280 x 330mm (18 x 11 x 13")
Weight
20kg (44lb)
Note: For indoor use only at altitudes up to 2000m (6562ft).
Mains supply fluctuations up to 10% of the nominal voltage.
Temporary overvoltages occurring on the supply.
Can be used in accordance with:
AS/NZS 1580.403.1, BS 3900-E2, DIN 53799, ECCA T12, EN 13523-12, ISO 1518-1:2011,
JIS K 5600-5-5
11 LEGAL NOTICES & REGULATORY INFORMATION
TMA-0326 Issue 04 - Text with cover 19438
R
R
