Eldom PERFECT MIX2 MFC2500 User manual

Make sure that the appliance is disconnected from the
mains and switched o (power switch (9) in “0” position),
Insert the drive shaft and the gasket into the hole at the
bottom of the container and lock it with the xing nut.
Place the selected attachment on the drive shaft mounted
in the container (8) or put the steam basket (7) into the
container (8).
Attach the lid (2) with the gasket (3) or the steam kit
(16+17+18+19) or the shredder lid (23) to the container
with the gasket (22).
Connect the power cord to the mains according to the
parameters given in the manual, and then switch it on
using the button (9).
Insert the container
(8) into the body. The
container (8) can only
be inserted in one
position - the scale
should be visible on the
rear panel.
Place the ingredients in
the container (8). When
using the shredder,
grate the products by
putting them through
the tunnel in the
shredding lid (23).
CAUTION! The appliance is equipped with a built-in lock. This function ensures that the appliance can only
be turned on if it is assembled correctly. When assembled correctly, the built-in microswitch is unlocked.
Do not remove the lid (2 or 23) of the unit during operation, as hot contents and the rotating attachments
may pose a threat to life and health. The lid (2 or 23) can only be removed when the appliance is switched
o and the mounted attachment stops.
1 2
4
6
3
5

Move the corresponding icon or rotate the knob to set
temperature, time and speed.
To quickly set the exact time, click the minute or second on
the time icon.
To set the reverse rotation, click on the icon – setting
the reverse rotation is indicated by the icon.
To activate the "Automatic Programs" interface, swipe
right, or press the right dot (as marked in the gure) or
turn the knob to the right.
When you press the button or the middle dot (as
marked in the gure), the home page is displayed.
To start operation, after setting the temperature, time and
speed, click the button , the icon changes to – the
device is working.
If you click the button or press the knob, the appliance
stops working. After pressing the button or pressing the
knob continuously for a long time, the appliance stops and
ends the set program.
After switching on the "Automatic Programs" interface,
select one of them by pressing the icon – the parameters
that can be set in a given program will be displayed.
Follow the guidelines in steps “6” and “7”.
When the button is pressed , the appliance goes to the
home page.
7
9
8
10

When the "Automatic Recipes" interface is activated,
choose one of them by pressing the picture.
The details of the recipe will be displayed.
To activate, press the button and then follow the
instructions shown on the screen.
To tag a recipe as a favourite, press the button
To activate the "Automatic Recipes" interface, swipe left,
or press the left dot (as marked in the gure above) or turn
the knob to the left.
When you press the button or the middle dot (as marked
above), the start page is displayed.
The recipes have preset parameters. To see all the
preparation steps, press the button . The number at the
bottom of the screen indicates a working step.
When you have nished cooking, a message will appear on
the screen indicating that you have nished working.
To stop the process earlier, press the knob. The next press
starts working at the moment of interruption. To interrupt
the process completely, press and hold the knob.
11
13
14
12

15 16
Once you have nished cooking, wash the appliance
and accessories – the items shown in the gure are
dishwasher safe.
The container (8) is NOT dishwasher safe.
Do NOT immerse the unit in water or other liquids.
For detailed cleaning guidelines, see the CLEANING AND
MAINTENANCE section.
