ElectrIQ DCF12P User manual

USER MANUAL
FLOOR STANDING FAN
DCF12P
Thank you for choosing electriQ
Please read this user manual before using this air circulator and keep it safe for future reference.
Visit our page www.electriQ.co.uk for our entire range of Intelligent Electricals

Page 2of 7
CONTENTS
SAFETY
3
FEATURES
4
PRODUCT DIAGRAM
4
OPERATION
5
REMOTE CONTROL
5
MAINTENANCE
6
TROUBLESHOOTING
6
TECHNICAL SPECIFICATION
7
SUPPORT
7

Page 3of 7
SAFETY INSTRUCTIONS
•Carefully read the instructions before operating the unit
•This appliance is for indoor use only.
•Rating: This unit must be only connected to a 220-240 V / 50 Hz earthed outlet.
•Installation must be in accordance with regulations of the country where the unit is
used.
•If you are in any doubt about the suitability of your electrical supply have it checked
and, if necessary, modified by a qualified electrician.
•This fan has been tested and is safe to use. However, as with any electrical appliance -
use it with care.
•Disconnect the power from the unit before dismantling, assembling or cleaning the unit
•Avoid touching any moving parts of the appliance.
•Never insert fingers, pencils or any other objects though the guard
•This appliance can be used by Children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children without
supervision.
•Do not clean the unit by spraying or immersing it in water.
•Never connect the unit to an electrical outlet using an extension cord. If an outlet is not
available, one should be installed by a qualified electrician.
•Never operate this appliance if the cord or plug is damaged. Ensure the power cord is
not stretched or exposed to sharp object/edges.
•A damaged supply cord should be replaced by the manufacturer or a qualified
electrician in order to avoid a hazard.
•Any service other than regular cleaning should be performed by an authorized service
representative. Failure to comply could result in a voided warranty.
•Do not use the appliance for any purpose other than for its intended use.
•Never use the mains plug as a switch to start and turn off the fan. Use the provided
ON/OFF switch located on the control panel.
•Always place the unit on a dry and stable surface. Do not move or tilt the unit
•The appliance should not be installed in laundry or wet rooms
•Do not use this unit in environments with flammable and explosive gases.
•Avoid keeping the unit in direct sunlight for a long period of time
•For maximum performance the minimum distance from a wall or objects should be
50cm.

Page 4of 7
FEATURES
•Slim design for seamless home installation.
•High Speed Motor with 6 Fan Speed Settings.
•Swing Function.
•7-hour standby timer.
•Remote Control allowing all functions to be changed for ease of use.
DIAGRAM
PROTECTIVE HOUSING
BASE
CONTROL BUTTONS
REMOTE CONTROL
For more information see the
operation section on page 5.

Page 5of 7
OPERATION
SWING BUTTON
Press to start the swing function. The fan
will slowly turn from side to side. The
swing button light will turn on. Press the
button again to turn off the swing
function.
TIMER BUTTON
Press to start the timer function. Each
press will increase the timer by 1 hours.
The timer function can be set between 1
and 7 hours.
ON OFF/ FAN SPEED BUTTON
Press the button once to turn on the fan.
When the fan is on, press the button
repeatedly to cycle through the fan
speeds, you can choose between speeds
1-6, when the speed is 4, the indicator
will display 1-3. Press and hold the
button to turn off the fan.
REMOTE CONTROL
Your fan is supplied with a remote, which allows full control of all the units
functions. The Buttons on the remote have the same functions as the buttons
on the main control panel.
REPLACING THE BATTERIES
The remote control is powered by a Lithium Button Cell Battery (CR2025). Should the
remote become unresponsive, replace the battery following the instructions below:
1. Turn over the remote and press tab A to the right.
2. Slide out the battery tray B.
3. Replace the battery with the same type, ensuring the positive side is facing upwards.

Page 6of 7
MAINTENANCE
ATTENTION: Turn off the unit and unplug from the mains before cleaning or performing any
maintenance.
CLEANING THE SURFACE
•Clean the fan with a duster or a soft wet cloth.
•Do not submerge any part of the fan.
•Do not use chemical solvents (such as benzene, alcohol or gasoline) as they may cause
irreversible damage. Make sure no water enters the control panel or fan motor.
•Do not run the unit until completely dry.
•Place the fan in its original box or cover the fan to protect it from dust.
•Store the fan in a cool dry place.
TROUBLESHOOTING
Do not repair or disassemble the unit by yourself, unauthorized repair attempts will invalidate the
warranty and may cause bodily harm.
Issue
Possible Reason
Solution
No power
1. Power cord is unconnected
2. There is no power from socket
3. The power switch is not on.
1. Connect the power cord
2. Check socket is turned on
3. Turn the unit on
Odour emission
from unit
1. New unit. When the unit is used for
the first time the fan motor may
produce and odour which will dissipate
within a week of use
1. No action required
Strong
vibrations and
noise
1. Fan is not used on a flat surface
2. Fan may be damaged
1. Place on a flat surface. May put
an anti-vibration mat underneath
2. If fan is damaged discontinue
use and contact service centre.
If the above solutions do not resolve the problem please contact the supplier.

Page 7of 7
TECHNICAL DATA
ENVIRONMENTAL PROTECTION
Recycling facilities are now available for all customers at which you can deposit your
old electrical products. Customers will be able to take any old electrical equipment to
participating civic amenity sites run by their local councils. Please remember that this
equipment will be further handled during the recycling process, so please be
considerate when depositing your equipment. Please contact the local council for
details of your local household waste recycling centers
electriQ UK SUPPORT
www.electriQ.co.uk/support
Call: 0330 390 3061
Office hours: 9AM - 5PM Monday to Friday
www.electriQ.co.uk
Unit J6, Lowfields Business Park
Lowfields Way, Elland
West Yorkshire, HX5 9DA
Model
DCF12P
Fan Speeds
6
Cable length (M)
1.5
Rated Input (W)
20
Fan Speed (r/min)
945
Power Supply (V)
12
Net Weight (kg)
1.9
Dimensions (mm)
334 x 334 x900
