ElectrIQ TF13OSCW User manual

USER MANUAL
TF13OSCW (White)
TF13OSCB (Black)
13 INCH TOWER FAN
Thank you for choosing ElectriQ
Please read this user manual before using this air circulator and keep it safe for future reference.
Visit our page www.electrIQ.co.uk for our entire range of Intelligent Electricals

Page 2of 8
CONTENTS
SAFETY INSTRUCTIONS
3
FEATURES
4
PARTS
4
OPERATION
5
CONTROL PANEL AND SETTINGS
5
MAINTENANCE
6
TROUBLE SHOOTING
6 6
APPENDIX
7

Page 3of 8
SAFETY INSTRUCTIONS
Important!
Carefully read the instructions before operating the unit
This appliance is for indoor use only.
Rating: This unit must be only connected to a 220-240 V / 50 Hz earthed outlet.
Installation must be in accordance with regulations of the country where the unit is used.
If you are in any doubt about the suitability of your electrical supply have it checked and, if
necessary, modified by a qualified electrician.
This fan has been tested and is safe to use. However, as with any electrical appliance - use
it with care.
Disconnect the power from the unit before dismantling, assembling or cleaning the unit
Avoid touching any moving parts of the appliance.
Never insert fingers, pencils or any other objects though the guard
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities. It is also not intended for use by those with a lack of
experience and knowledge, unless they have been given supervision or instruction
concerning the use of the appliance by a person responsible for their safety.
Do not leave children unsupervised with this appliance.
Do not clean the unit by spraying it or immersing it in water.
Never connect the unit to an electrical outlet using an extension cord. If an outlet is not
available, one should be installed by a qualified electrician.
Never operate this appliance if the cord or plug is damaged. Ensure the power cord is not
stretched or exposed to sharp object/edges.
A damaged supply cord should be replaced by the manufacturer or a qualified electrician
in order to avoid a hazard.
Any service other than regular cleaning should be performed by an authorized service
representative. Failure to comply could result in a voided warranty.
Do not use the appliance for any purpose other than for its intended use.
Never use the mains plug as a switch to start and turn off the fan. Use the provided
ON/OFF switch located on the control panel.
Always place the unit on a dry and stable surface. Do not move or tilt the unit
High Velocity fans are designed to create rapid air movement, therefore make sure the fan
is not placed near curtains or any objects that may be drawn into the fan inlet.
The appliance should not be installed in laundry or wet rooms
Do not use this unit in environments with flammable and explosive gases.
Avoid keeping the unit in direct sunlight for a long period of time
Energy Saving and Unit Safety Protection Tips
Do not cover or restrict the airflow. Do not use in dusty environment.
For maximum performance the minimum distance from a wall or objects should be 50cm.
Warning: To reduce the risk of fire or electrical shock, DO NOT USE THIS FAN with any SOLID
STATE Speed Control Device or any variable speed controllers.

Page 4of 8
TF13OSCW13 Inch Tower Fan with 3 Speed Settings
FEATURES
Slim design takes minimal space
High Speed Motor with 3 Fan Speed Settings
Swing Function
PARTS

Page 5of 8
OPERATION
1. Set your tower fan on a level dry surface.
2. Plug the power cord into a standard 220~240 V wall outlet.
CONTROL PANEL AND SETTINGS
Twist the dial to select the desired fan speed, following the table below, twisting to select
operationwith or withoutthe swing function.
Low Fan Speed
Medium Fan Speed
High Fan Speed
Swing will gently change the horizontal direction of of the air to help with circulation over a
larger area.
With
Swing
Function
Without
Swing
Function

Page 6of 8
MAINTENANCE
CLEANING AND STORAGE
ATTENTION: Please shut off the unit and unplug from the mains before cleaning or
performingany maintenance.
Cleaning the surface
Clean the grills with a duster or a soft wet cloth.
Do not use chemical solvents (such as benzene, alcohol or gasoline) as they may cause
irreversible damage.Make sure no water enters the control panel or fan motor
Do not run the unit until completely dry.
Place the fan in its original box or cover the fan to protectit from dust.
Store it in a cool dry place.
TROUBLESHOOTING
Do not repair or disassemble the unit by yourself, unauthorized repair attempts will invalidate
the warranty and may cause bodily harm.
Issue
Possible Reason
Solution
No power
1. Power cord is unconnected
2. The There is no power from socket
3. The power switch is not on.
4. The fuse has blown
1. Connect the power cord
2. Check socket is turned on
3. Turn the unit on
4. Replace the fuse in the plug
Odour emission
from unit
1. New unit. When the unit is used for
the first time the fan motor may
produce and odour which will
dissipate within a week of use
1. No action required
Strong vibrations
and noise
1. Fan is not used on a flat surface
2. Fan may be damaged
1. Place on a flat surface. May put an
anti-vibration matt underneath
2. if fan is damaged discontinue use
and contact service centre
If the above solutions do not resolve the problem please contact the service centre.

Page 7of 8
APPENDIX
Disposal: Do not dispose this product as unsorted municipal waste. Collection of such
waste must be handled separately as special treatment is necessary.
Recycling facilities are now available for all customers at which you can deposit your
old electrical products. Customers will be able to take any old electrical equipment to
participating civic amenity sites run by their local councils. Please remember that this
equipment will be further handled during the recycling process, so please be considerate
when depositing your equipment. Please contact the local council for details of your local
household waste recycling centres.
TECHNICAL DATA
Model
TF13OSCW / TF13OSCB
Fan Speeds
3
Cable length
1.5 meters
Rated Input
20 Watt
Running Current
0.1 Amps
Air Flow
3.5 m3/min
Noise
Max 56dB(A)
Power Supply
220-240V~50/60Hz
Net Weight
1.25 kg
Gross Weight
1.45 kg
Net Size (assembled)
110 x 110 x 325mm
Gross Size (packed)
128 x 116 x 332mm

Page 8of 8
ElectrIQ UK SUPPORT
www.ElectrIQ.co.uk/support
Please, for your own convenience, make these simple checks
before calling the service line.
If the unit still fails to operate call: 0871 620 1057 or complete
the online form
1. Is the unit plugged into the mains?
2. Is the fuse OK?
3. Switch the unit off and wait three minutes to see if the issue
is resolved. Restart the unit.
Office hours: 9AM - 5PM Monday to Friday
www.ElectrIQ.co.uk
Unit 2, The Nursery
Berristow Lane
South Normanton
Derbyshire, DE55 2FX
