Electro-Harmonix nano SMALL STONE User manual

FCC COMPLIANCE
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the CC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could void the user's
authority to operate the equipment under CC rules.
SMALL STONE
Phase Shifter
Congratulations on your purchase of the Electro-Harmonix Nano Stone! The
Nano Stone is identical to the Electro-Harmonix Small Stone, just smaller.
The Small Stone was first manufactured back in the early 70’s making it one
of the first compact phase shifters on the market. To this day, the Small
Stone is still the pedal to use when musicians want a fat, warm analog phase
shifter.
- OPERATING INSTRUCTIONS -
Connect your instrument to the INPUT jack. Connect your amplifier to the
AMP jack. Please note that whenever a plug is inserted into the INPUT jack,
the Nano Stone is ON and it is draining current from the battery.
The STATUS LED will light up when the Nano Stone is in effect mode. When
in True Bypass mode, the LED will be off. Use the OOTSWITCH to toggle
between effect and True Bypass mode.
The RATE control adjusts the speed of the phasing sweep, turn RATE
clockwise for a faster sweep.
The COLOR Switch changes the sound of the phase shift between a full and
robust phase shift in the DOWN position to a more pronounced instance
phase shift in the UP position. When in the UP position, notice how the Nano
Stone carves into the frequency spectrum hollowing out the sound.
undamentals and harmonics glide in and out for an extremely pronounced
shifting effect. Return the COLOR switch to the down position and notice the
fullness.

- POWER -
Power from the internal 9-volt battery is activated by plugging into the
INPUT jack. The input cable should be removed when the unit is not in use
to avoid running down the battery. If a battery eliminator is used, the Nano
Stone will be powered up as long as a wall-wart is plugged into the wall.
The barrel connector on the front of the Nano Stone is for a 9-volt battery
eliminator capable of delivering 100 mA of current. The inner ring of the 9-
volt battery eliminator must be negative, the outer ring positive. The unit’s
battery may be left in or taken out when the eliminator is in use.
To change the 9-volt battery, you must remove the 4 screws on the bottom
of the Nano Stone. Once the screws are removed, you can take off the
bottom plate and change the battery. Please do not touch the circuit board
while the bottom plate is off or you risk damaging a component.
The input impedance presented at the Input Jack is 100 k-ohms. The output
impedance at the Output Jack is 15 k-ohms.
- WARRANTY INFORMATION -
Please register online at http://www.ehx.com/product-registration or complete and
return the enclosed warranty card within 10 days of purchase. Electro-Harmonix will
repair or replace, at its discretion, a product that fails to operate due to defects in
materials or workmanship for a period of one year from date of purchase. This
applies only to original purchasers who have bought their product from an authorized
Electro-Harmonix retailer. Repaired or replaced units will then be warranted for the
unexpired portion of the original warranty term.
If you should need to return your unit for service within the warranty period, please
contact the appropriate office listed below. Customers outside the regions listed
below, please contact EHX Customer Service for information on warranty repairs at
[email protected] or [phone]. USA and Canadian customers: please obtain a
Return Authori ation Number (RA#) from EHX Customer Service before returning
your product. Include with your returned unit: a written description of the problem
as well as your name, address, telephone number, e-mail address, and RA#; and a
copy of your receipt clearly showing the purchase date.
United States & Canada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
55-01 2ND STREET
LONG ISLAND CITY, NY 11101
Tel: [phone]
Email: [email protected]
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: [phone]
Email: [e-mail]
This warranty gives a purchaser specific legal rights. A purchaser may have even
greater rights depending upon the laws of the jurisdiction within which the product
was purchased.
