Electro-Harmonix OD GLOVE User manual

FCC COMPLIANCE
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the CC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could void the user's
authority to operate the equipment under CC rules.
OD GLOVE
Congratulations on your purchase of the OD Glove overdrive, a
versatile modern overdrive/distortion unit in a compact nano
enclosure. The OD Glove is capable of chunky high-gain distortion,
sweet overdrive, mild crunch, and even powerful clean-boost. An easy
to use but powerful tone control helps you dial in the right sound.
True-bypass switching keeps your original clean tone intact.
- CONTROLS -
GAIN Knob – Controls the amount of input gain and overdrive. As
you turn this knob clockwise, the OD GLOVE ranges from sweet
cleans to full-power distortion.
TONE Knob – The TONE knob on the OD GLOVE filters out high
frequencies. When fully clockwise, the full tonal range of the
overdrive comes through. As the knob is turned counter-clockwise,
high frequencies are rolled off. Use this to achieve a smoother tone or
to reduce any high-frequency harshness.
VOL Knob – Sets the output level of the OD GLOVE.
TONE SHIFT Switch – This switch controls the mid-frequency
emphasis of the TONE knob. Setting this switch to O creates a
flatter EQ, with some emphasis on low mids. Setting the SHI T switch
to ON emphasizes mids and high mids. There is also a small increase
in volume when the switch is set to ON.
FOOTSWITCH an LED – The ootswitch selects whether the OD
GLOVE is engaged or in true bypass mode. When the effect is
engaged, the LED is lit.

INPUT Jack – This ¼” jack is the audio input for the OD GLOVE.
The input impedance is 300kΩ.
AMP Jack – This ¼” jack is the audio output from the OD GLOVE.
The output impedance depends on the VOLUME setting, ranging from
12kΩ to 100kΩ.
9V Power Jack – The OD Glove can run off of a 9V battery or you
can use an optional 9VDC AC Adapter capable of delivering at least
50mA to the 9V power jack. We recommend the EHX9.6DC-200.
The AC Adapter must have a center negative plug. The battery may
be left in or taken out when using an AC Adapter. The OD Glove
draws 12mA at 9VDC. The maximum voltage that may be
connecte to the 9V Power Jack is 10VDC.
INTERNAL VOLTAGE SWITCH – The OD GLOVE includes an
internal slide switch to change its internal power supply voltage from
9V to 18V. Operation at 18V results in a less compressed, more open
tone that may work better for some guitar/amplifier combinations.
Operation at 9V results in a tighter sound, and reduces the current
draw to 5mA. Experiment with the voltage setting at full volume to
find the best sound for your playing style. Please remember: do not
exceed 10VDC at the 9V Power Jack. The OD Glove generates the
18V internally.
To select the operating voltage, remove the four screws on the
bottom of the OD GLOVE and take off the bottom plate. There is a
slide switch near the input jack labeled “Voltage Select.” Slide this
switch to the right for normal 9V operation. Slide it to the left for 18V
operation. You do not need to change the battery or adapter when
changing the internal voltage.
- CHANGING THE BATTERY -
To change the battery, remove the four screws on the bottom of the
OD GLOVE and take off the bottom plate. The battery clip is in the
bottom of the unit. Take care not to touch the circuit board while
changing the battery in order to avoid damaging a component.
- WARRANTY INFORMATION -
Please register online at http://www.ehx.com/product-registration or complete and
return the enclosed warranty card within 10 days of purchase. Electro-Harmonix will
repair or replace, at its discretion, a product that fails to operate due to defects in
materials or workmanship for a period of one year from date of purchase. This
applies only to original purchasers who have bought their product from an authorized
Electro-Harmonix retailer. Repaired or replaced units will then be warranted for the
unexpired portion of the original warranty term.
If you should need to return your unit for service within the warranty period, please
contact the appropriate office listed below. Customers outside the regions listed
below, please contact EHX Customer Service for information on warranty repairs at
[email protected] or [phone]. USA and Canadian customers: please obtain a
Return Authorization Number (RA#) from EHX Customer Service before returning
your product. Include with your returned unit: a written description of the problem
as well as your name, address, telephone number, e-mail address, and RA#; and a
copy of your receipt clearly showing the purchase date.
Unite States & Cana a
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
55-01 2ND STREET
LONG ISLAND CITY, NY 11101
Tel: [phone]
Email: [email protected]
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: [phone]
Email: [e-mail]
This warranty gives a purchaser specific legal rights. A purchaser may have even
greater rights depending upon the laws of the jurisdiction within which the product
was purchased.
To hear demos on all EHX pedals visit us on the web at www.ehx.com
Email us at [email protected]
