Electrolux 36" Ceramic User manual

GAS COOKTOP INSTALLATION INSTRUCTIONS
(For 36" Models with 6 Sealed Burners)
1
AB
C
E
H***
F
G
D
INSTALLATION AND SERVICE MUST BE PERFORMED BY
A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
318201455 (0403) Rev. D
English - pages 1-8
Español - páginas 9-16
Français - pages 17-23
Wiring Diagram page - 24
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
FOR YOUR SAFETY:
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
All dimensions are in inches (cm).
NOTE: Wiring diagrams for this cooktop are enclosed in this booklet
**Note: D &E are critical to the proper
installation of the cooktop. Please make
sure to respect those dimensions. Dreflects
a finished dimension it is recommended to
undercut this dimension and adjust upon
installation of the appliance due to the
variation in countertop materials.
Figure 1
* 30" (76.2 cm) min. for
unprotected cabinet
24" (61 cm) min. for protected
surface
Gas Cooktop Dimensions
Gas Cooktop Cutout
Dimensions
30"(76.2 cm)
Min.*
4"X 4" (10.2 cm x 10.2 cm)
opening to route gas supply.
2"(5.1 cm) Dia.
Opening to route
power cable
For Standard
Installation:
1" (2.5 cm)
2"(5.1 cm)
71/4"
(18.4 cm)
3"(7.6 cm)
2
1/2
"
(6.4 cm)
All dimensions are in inches (cm).
Do not slide unit into cabinet cutout.
Protruding screws on the bottom of unit
may damage the bottom front finish.
CUTOUT DIMENSIONS H. DEPTH BELOW
MODEL A. LENGTH B. WIDTH C. DEPTH LENGTH WIDTH COOKTOP***
D** E** FG
36 (91.4 ) 35
7
/
8
(91.1) 25¾ (65.4) 7¾ (19.7) 35
15
/
16
(91.3) 35
3
/
16
(89.4) 22 (55.9) 1
1
/
8
(2.9) Max. 7
1
/
2
(19.1)
351/8"
(89.2 cm)

GAS COOKTOP INSTALLATION INSTRUCTIONS
(For 36" Models with 6 Sealed Burners)
2
Figure 2
A
D
B
C
D
E
H***
F
G
* 30" (76.2 cm) min. for unprotected cabinet
24" (61 cm) min. for protected surface
Gas Cooktop Dimensions
Gas Cooktop Cutout Dimensions
30"(76.2 cm)
Min.*
For Installation with the optional Stainless Steel Backsplash.
2"(5.1 cm)
4"X 4" (10.2 cm x 10.2 cm) opening
to route gas supply.
2"(5.1 cm)
3"(7.6 cm)
2"(5.1 cm) Dia.
opening to route
power cable.
351/8"
(89.2 cm)
2
1/2
"
(6.4 cm)
1" (2.5 cm)
9"(22.9cm)
Optional
Stainless Steel
Backsplash
7¼"(18.4 cm)
**Note: D &E are critical to the proper
installation of the cooktop. Please make sure
to respect those dimensions. Dreflects a
finished dimension it is recommended to
undercut this dimension and adjust upon
installation of the appliance due to the
variation in countertop materials.
Do not slide unit into cabinet cutout.
Protruding screws on the bottom of unit
may damage the bottom front finish.
All dimensions are in inches (cm).
CUTOUT DIMENSIONS H. DEPTH BELOW
MODEL A. LENGTH B. WIDTH C. DEPTH LENGTH WIDTH COOKTOP***
D** E** F G
36 (91.4 ) 35
7
/ 8 (91.1) 25¾ (65.4) 7¾ (19.7) 35
15
/ 16 (91.3) 35
3
/ 16 (89.4) 22 (55.9) 1
1
/ 8 (2.9) Max. 7
1
/ 2 (19.1)

GAS COOKTOP INSTALLATION INSTRUCTIONS
(For 36" Models with 6 Sealed Burners)
3
Important Notes to the Installer
1. Read all instructions contained in these installation
instructions before installing the cooktop.
2. Remove all packing material before connecting the
electrical supply to the cooktop.
3. Observe all governing codes and ordinances.
4. Be sure to leave these instructions with the consumer.
5. Note: For operation at 2000 ft. elevations above see
level, appliance rating shall be reduced by 4 percent
for each additional 1000 ft.
Important Note to the Consumer
Keep these instructions with your Use and Care Guide for
future reference.
Depth Adjustment Filler Kit #903051-9010
This cooktop is designed to replace existing unit. If the
depth of your countertop opening is bigger than 7¼" (18.4
cm) and less than 8½" (21.6 cm) you can order a free filler
kit #903051-9010 by calling Service Center at 1-877-
4ELECTROLUX (1-877-435-3287).
Optional Items Available:
•A 9" (22.9cm) Stainless Steel Backsplash Kit
#903048-9010
•A Black Knobs Kit #903049-9100
Those kits can be order through the Service Center at
1-877-4ELECTROLUX (1-877-435-3287). However all cost
related to those kits will be at customer charges.
IMPORTANT SAFETY
INSTRUCTIONS
Installation of this cooktop must conform with local codes
or, in the absence of local codes, with the National Fuel
Gas Code ANSI Z223.1/NFPA54—latest edition in the
United States, or in Canada, with the Canadian Fuel Gas
Code, CAN/CGA B149 and CAN/CGA B149.2.
• When installed in a manufactured (mobile) home
installation must conform with the Manufactured Home
Construction and Safety Standard, title 24 CFR, part
3280 [Formerly the Federal Standard for Mobile Home
Construction and Safety, title 24, HUD (part 280)] or,
when such standard is not applicable, the Standard for
Manufactured Home Installation, ANSI/NCSBCS A225.1
or with local codes where applicable.
This cooktop has been design certified by International
Approval Services (I.A.S). As with any appliance using
gas and generating heat, there are certain safety
precautions you should follow. You will find them in the
Use and Care Guide, read it carefully.
•Be sure your cooktop is installed and grounded
properly by a qualified installer or service
technician.
•This cooktop must be electrically grounded in
accordance with local codes or, in their absence,
with the National Electrical Code ANSI/NFPA No.
70—latest edition in the United States, or in
Canada, with the Canadian Electrical Code, CSA
C22.1 Part 1.
•The burners can be lit manually during an
electrical power outage. To light a burner, hold a
lit match to the burner head, then slowly turn the
Surface Control knob to LITE. Use caution when
lighting burners manually.
•Do not store items of interest to children in
cabinets above the cooktop. Children could be
seriously burned climbing on the cooktop to reach
items.
•To eliminate the need to reach over the surface
burners, cabinet storage space above the burners
should be avoided.
•Adjust surface burner flame size so it does not
extend beyond the edge of the cooking utensil.
Excessive flame is hazardous.
•Never use your cooktop for warming or heating
the room. Prolonged use of the cooktop without
adequate ventilation can be hazardous.
•Do not store or use gasoline or other flammable
vapors and liquids near this or any other
appliance. Explosions or fires could result.
The electrical power to the cooktop
must be shut off while gas line connections are
being made. Failure to do so could result in serious
injury or death.

GAS COOKTOP INSTALLATION INSTRUCTIONS
(For 36" Models with 6 Sealed Burners)
4
A
C
B
Figure 3 – CABINET DESIGN
To eliminate the risk of
burns or fire by reaching over heated
surfaces, cabinet storage space located
above the cooktop should be avoided. If
cabinet storage is provided, risk can be
reduced by installing a range hood that
projects horizontally a minimum of 7"
(17.8 cm) beyond the bottom of the
cabinets.
MODEL A B. Minimum C. Minimum
Clearance from Clearance from
Left Side Right Side
36" (91.4 cm) 36" (91.4 cm) 7" (17.8 cm) 7" (17.8 cm)
18" (45.7 cm)
Min.
1" (2.5 cm) min. distance
between rear edge of
cutout and nearest
combustible surface
above countertop
13" (33 cm) max. depth
for cabinet installed above
cooktop
Drawers cannot be used with this
cooktop since burner box extends 7"
(17.8 cm) below surface of coutertop.
30" (76.2 cm) min.
clearance between
the top of the
cooking platform and
the bottom of an
unprotected wood or
metal cabinet.
24" (61 cm)
30" (76.2 cm) Min.
Clearance Between the
Top of the Cooking
Platform and the Bottom
of an Unprotected Wood
or Metal Cabinet
24" (61 cm) Min.
when Bottom of Wood
or Metal Cabinet is
Protected by Not Less
Than 1/8" Flame
Retardant Millboard
Covered With Not Less
Than No. 28 MGS
Sheet Steel, 0.015"
(0.4 mm) Stainless
Steel, 0.024" (0.6 mm)
Aluminum or 0.020"
(0.5 mm) Copper

GAS COOKTOP INSTALLATION INSTRUCTIONS
(For 36" Models with 6 Sealed Burners)
5
The conversion must be performed by a qualified service
technician in accordance with the kit instructions and all
local codes and requirements. Failure to follow
instructions could result in serious injury or property
damage. The qualified agency performing this work
assumes responsibility for the conversion.
Failure to make the appropriate
conversion can result in personal injury and property
damage.
Important: Remove all packing material and
literature from cooktop before connecting gas and
electrical supply to cooktop.
Install Pressure Regulator
Install the pressure regulator with the arrow on the
regulator pointing up toward the unit in a position where
you can reach the access cap.
Do not make the connection too tight.
The regulator is die cast. Overtightening may crack the
regulator resulting in a gas leak and possible fire or
explosion.
Wall Outlet Location
Provide an Adequate Gas Supply
This cooktop is designed to operate on natural gas at 4"
(10.2 cm) of manifold pressure only.
A pressure regulator is connected in series with the
manifold on the cooktop and must remain in series with
the supply line.
For proper operation, the maximum inlet pressure to
the regulator must be no more than 14" (35.6 cm) of
water column (W.C.) pressure.
For checking the regulator, the inlet pressure must be at
least 1"(2.5 cm) (or 2.5 kPa) greater than the regulator
manifold pressure setting. The regulator is set for 4"
(10.2 cm) of manifold pressure, the inlet pressure must
be at least 5" (12.7 cm).
The gas supply line to the range should be 1/2" (1.3 cm)
or 3/4" (1.9 cm) pipe.
LP/Propane Gas Conversion
This appliance can be used with Natural gas or LP/
Propane gas. It is shipped from the factory for use with
natural gas.
A kit for converting to LP gas is supplied with your
cooktop. The kit is marked "FOR LP/PROPANE GAS
CONVERSION".
All connections must be wrench-tightened
Figure 5
Assemble the flexible connector from the gas supply pipe
to the pressure regulator in the following order:
1. manual shutoff valve
2. 1/2" (1.3 cm) nipple
3. 1/2" (1.3 cm) flare union adapter
4. flexible connector
5. 1/2" (1.3 cm) flare union adapter
6. 1/2" (1.3 cm) nipple
7. pressure regulator
Use pipe-joint compound made for use with Natural and
LP/Propane gas to seal all gas connections. If flexible
connectors are used, be certain connectors are not
kinked.
Figure 4
Recommended
area for 120V
grounded
outlet on rear
wall.
CENTRE
LINE
OF UNIT
CENTRE
LINE
OF UNIT
NOTE: If an
outlet is not
available, have
one installed by
a qualified
technician.
16"
(40.6 cm)
5"
(12.7 cm)
4"
(10.2 cm)

GAS COOKTOP INSTALLATION INSTRUCTIONS
(For 36" Models with 6 Sealed Burners)
6
Grounding Instructions
IMPORTANT Please read carefully.
For personal safety, this appliance must be properly
grounded.
The power cord of this appliance is equipped with a 3-
prong (grounding) plug which mates with a standard 3-
prong grounding wall receptacle (see Figure 7) to
minimize the possibility of electric shock hazard from the
appliance.
The supply line should be equipped with an approved
shutoff valve. This valve should be located in the same
room as the cooktop and should be in a location that
allows ease of opening and closing. Do not block access
to the shutoff valve. The valve is for turning on or
shutting off gas to the appliance.
Open the shutoff valve in the gas supply line. Wait a few
minutes for gas to move through the gas line.
Check for leaks. Leak testing of the appliance shall
be conducted according to the manufacturer's
instructions. After connecting the cooktop to the gas
supply, check the system for leaks with a manometer. If
a manometer is not available, turn on the gas supply and
use a liquid leak detector (or soap and water) at all
joints and connections to check for leaks.
Do not use a flame to check for leaks
from gas connections. Checking for leaks with a flame
may result in a fire or explosion.
Tighten all connections if necessary to prevent gas
leakage in the cooktop or supply line.
Check alignment of valves after connecting the
cooktop to the gas supply to be sure the cooktop
manifold pipe has not been moved.
Disconnect this cooktop and its individual shutoff
valve from the gas supply piping system during any
pressure testing of that system at test pressures greater
than 1/2 psig (3.5 kPa or 14" (35.6 cm) water column).
Isolate the cooktop from the gas supply piping
system by closing its individual manual shutoff valve
during any pressure testing of the gas supply piping
system at test pressures equal to or less than 1/2 psig
(3.5 kPa or 14" (35.6 cm) water column).
Electrical Requirements
120 volt, 60 Hertz, properly grounded branch circuit
protected by a 15 amp circuit breaker or time delay fuse.
Do not use an extension cord with this cooktop.
Figure 6
Figure 7
Preferred Method
Grounding type
wall receptacle
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
Power supply
cord with 3-prong
grounding plug.
The wall receptacle and circuit should be checked by a
qualified electrician to make sure the receptacle is
properly grounded.
Where a standard 2-prong wall receptacle is installed, it
is the personal responsibility and obligation of the
consumer to have it replaced by a properly grounded 3-
prong wall receptacle.
Do not, under any circumstances, cut or remove the
third (ground) prong from the power cord.
Disconnect electrical supply cord from
wall receptacle before servicing cooktop.
Cooktop Installation
1. Visually inspect the cooktop for damage.
2. If you are installing the optional Stainless Steel
backsplash, first fix it at the back of the cooktop using
the screws supplied with the kit and follow the
instructions attached.
Go to step 3, If you are not installing the Optional
Stainless Steel backsplash.
3. Set the cooktop into the countertop cutout.
NOTE: Do not use caulking compound; cooktop should
be removable for service when needed.

GAS COOKTOP INSTALLATION INSTRUCTIONS
(For 36" Models with 6 Sealed Burners)
7
2. Turn on Electrical Power and Open Main Shutoff
Gas Valve
3. Check the Igniters
Operation of electric igniters should be checked after
cooktop and supply line connectors have been
carefully checked for leaks and the cooktop has
been connected to electric power.
To operate the surface burner:
A. Push in and turn a surface burner knob to the
LITE position. You will hear a ticking noise; this
is the sound of the electric ignitor which lights
the burner.
B. After the burner lights, turn to the desired flame
size. The controls do not have to be set at a
particular mark. Use the marks as a guide and
adjust the flame as needed.
4. Adjust the "LO" or "SIMMER" Setting of Surface
Burner Valves (see Figure 9)
Push in and turn each control knob to the "LO" (or
"SIMMER") setting. The "LO" setting of each
burner has been set at the factory to the lowest
setting available to provide reliable reignition of the
burner. If it does not stay lit on the "LO" setting,
check the setting as follows.
Be careful when performing this
operation.
A. Allow cooktop to cool to room temperature.
B. Light all burners by turning each control knob to
LITE until burners ignite, and then set them at
"HI".
C. Quickly turn the knob to the LOWEST POSITION.
D. If burner goes out, readjust valve as follows:
Remove the surface burner control knob, insert a
thin-bladed screw driver into the hollow valve
stem and engage the slotted screw inside. Flame
size can be increased or decreased with the turn
of the screw. To increase flame size turn the
screw counterclockwise and to decrease turn
clockwise. Adjust flame until you can quickly
turn knob from HI to LOWEST POSITION without
extinguishing the flame. Flame should be as
small as possible without going out.
E. If you need to adjust another burner, repeat the
steps from A to D above until all burners operate
properly.
Checking Operation
Refer to the Use and Care Guide packaged with the
cooktop for operating instructions and for care and
cleaning of your cooktop.
Do not touch the burners. They may be
hot enough to cause burns.
1. Install Burner Caps
This cooktop is equipped with sealed burners as
shown (see Figure 8).
A. Unpack your burner heads and burner caps.
B. Place burner head over each gas orifice,
matching the head with the orifice size. Be
careful not to damage the electrode while
placing the head over the orifice. Make sure
electrode fits correctly into slot in burner head.
C. Place a burner cap on each burner head,
matching the cap size to the head size. Each
burner cap has an inner locating ring which
centers the cap correctly on the burner head.
D. Be sure that all the burner caps and burner
heads are correctly placed BEFORE using your
cooktop.
NOTE: There are no burner adjustments necessary on
this cooktop.
Figure 8
Burner Cap
Cooktop Surface
Electrode
Gas Opening
Burner Head

GAS COOKTOP INSTALLATION INSTRUCTIONS
(For 36" Models with 6 Sealed Burners)
8
Figure 9
Model and Serial Number Location
The serial plate is located on the underside of the
cooktop.
When ordering parts for or making inquires about your
range, always be sure to include the model and serial
numbers and a lot number or letter from the serial plate
of your cooktop.
Your serial plate also tells you the rating of the burners,
the type of fuel and the pressure the cooktop was
adjusted for when it left the factory.
Before You Call for Service
Read the Before You Call Checklist and operating
instructions in your Use and Care Guide. It may save
you time and expense. The list includes common
occurrences that are not the result of defective
workmanship or materials in this appliance.
Refer to your Use and Care Guide for Sears service
phone numbers. Please call if you have inquiries about
your product and/or need to order parts.
When All Hookups are Complete
Make sure all controls are left in the OFF position.
Make sure the flow of combustion and ventilation air to
the cooktop is unobstructed.
