200397 (NCPG800U) Gas Pasta Cooker
120 V/1p/60z – 0.9 A
Item No. ___________________________________
Unit to be Electrolux Double Well Gas Pasta Cooker 200397.
The unit is a free-standing, 10.5 gallon, double well Gas Pasta
Cooker.The unit shall feature constant water level refill and starch
removal during cooking process. IPX 5 water jet protection
(NEMA 4 equivalent). The two 10.5 gallon tanks are pressed in
AISI 316 stainless steel and features only rounded corners. 5″
long, height adjustable legs. The unit to be completely in AISI
304 stainless steel.
Covered by Electrolux Platinum Star® Service Program two-
year parts and one-year labor warranty, installation start-up
and performance check-up after one year from installation.
Short Form Specification
Electrolux Professional, Inc.
www.electroluxusa.com/professional
3225 SW 42nd Street, Fort Lauderdale, Florida, 33312 • Telephone Number: 866-449-4200 • Fax Number: 954-327-6789
ITEM # _______________________________________________
MODEL # _____________________________________________
PROJECT NAME # ______________________________________
SIS # _________________________________________________
AIA # _________________________________________________
Pasta Solutions
Free-standing, Double-well
Pasta Cooker – Gas
Main features
• Two 10.5 gallon tanks.
• 9-position energy regulator.
• 3-position water fill regulator.
• Constant water level refill.
• Automatic starch removal function during cooking: improved water quality
over time.
• Automatic low-water level shut-off: no accidental over-heating.
• Electrolux Platinum Star® Service package included:
• 2-year parts, 1-year labor warranty, 5-year compressor warranty.
• Start-up install check.
• Equipment check-up after 12 month from installation.
Construction
• Pressed 10.5 gal tanks: only rounded corners for improved cleanability.
• AISI 316 stainless steel tank: maximum corrosion resistance.
• All stainless steel construction.
• IPX 5 water jet protection (NEMA 4 equivalent).
Included Accessories
•5″long, height adjustable legs.
Optional Accessories
• Bulk cooking basket.
• 2 of 1/2 size bulk cooking baskets.
• 3 of 1/3 size bulk cooking baskets.
• 3 of round individual-portion baskets.
• False bottom for round individual-portion baskets.
• Castors.
Pasta Solutions
Free-standing, Double-well Pasta Cooker – Gas
Pasta Solutions
Free-standing, Double-well
Pasta Cooker – Gas

Pasta Solutions
Free-standing, Double-well
Pasta Cooker – Gas
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
6-26-09
Front View
Top View
Side View
Pasta Solutions
Free-standing, Double-well Pasta Cooker – Gas
Net weight: 254 lbs. (115 kg)
Height, inch/mm: 33-7/16″(849 mm)
Width, inch/mm: 31-1/2″(800 mm)
Depth, inch/mm: 35-7/16″(900 mm)
Shipping weight: 301 lbs. (140 kg)
Shipping width: 34.5″(880 mm)
Shipping height: 44.1″(1120 mm)
Shipping depth: 41″(1040 mm)
Shipping volume: 36.37 cu. ft. (1.03 m³)
Key Information
Supply voltage:
200397 (NCPG800U) 120 V/1p/60Hz - 0.9 A
Connected load: 0.1 kW
Electric
Clearance: 4″(10 cm) from back.
Installation
Max.: 2 x 10.5 gal
Min.: 2 x 8.5 gal
Capacity
Water inlet “CW” – 3/4″″
″″
″connection:
Total hardness: 5-50 ppm
Drain “D” 1″connection
Electrolux recommends the use of treated water, based on
testing of specific water conditions.
Please refer to user manual for detailed water quality
information.
Water
Gas (Natural or LPG)
ISO 7/1 Gas connection
diameter: 3/4″NPT
Nominal Thermal load: BTU 106,000 (31 kW)
Pressure
Natural Gas: 4″w.c. (10 mbar)
LPG: 10″w.c. (25 mbar)
