Electrolux 200398 User manual

Approval: ___________________________________________
200398 (NCPE400U) Electric Pasta Cooker
208 V/3p/60z – 28 A
Item No. ___________________________________
Unit to be Electrolux Single Well Electric Pasta Cooker 200398.
The unit is a free-standing, 10.5 gallon, single well Electric Pasta
Cooker.The unit shall feature constant water level refill and starch
removal during cooking process. IPX 5 water jet protection
(NEMA 4 equivalent). The 10.5 gallon tank is pressed in AISI
316 stainless steel and features only rounded corners. 5″long,
height adjustable legs. The unit to be completely in AISI 304
stainless steel.
Covered by Electrolux Platinum Star® Service Program two-
year parts and one-year labor warranty, installation start-up
and performance check-up after one year from installation.
Short Form Specification
Electrolux Professional, Inc.
www.electroluxusa.com/professional
3225 SW 42nd Street, Fort Lauderdale, Florida, 33312 • Telephone Number: 866-449-4200 • Fax Number: 954-327-6789
ITEM # _______________________________________________
MODEL # _____________________________________________
PROJECT NAME # ______________________________________
SIS # _________________________________________________
AIA # _________________________________________________
Pasta Solutions
Free-standing, Single-well
Pasta Cooker – Electric
Main features
• 10.5 gallon tank.
• 9-position energy regulator.
• 3-position water fill regulator.
• Constant water level refill.
• Automatic starch removal function during cooking: improved water quality
over time.
• Automatic low-water level shut-off: no accidental over-heating.
• Electrolux Platinum Star® Service package included:
• 2-year parts, 1-year labor warranty, 5-year compressor warranty.
• Start-up install check.
• Equipment check-up after 12 month from installation.
Construction
• Pressed 10.6 gal tank: only rounded corners for improved cleanability.
• AISI 316 stainless steel tank: maximum corrosion resistance.
• All stainless steel construction.
• IPX 5 water jet protection (NEMA 4 equivalent).
Included Accessories
•5″long, height adjustable legs.
Optional Accessories
• Bulk cooking basket.
• 2 of 1/2 size bulk cooking baskets.
• 3 of 1/3 size bulk cooking baskets.
• 3 of round individual-portion baskets.
• False bottom for round individual-portion baskets.
• Castors.
Pasta Solutions
Free-standing, Single-well Pasta Cooker – Electric
Pasta Solutions
Free-standing, Single-well
Pasta Cooker – Electric

Pasta Solutions
Free-standing, Single-well
Pasta Cooker – Electric
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
6-26-09
Front View
Top View
Side View
Pasta Solutions
Free-standing, Single-well Pasta Cooker – Electric
Net weight: 137 lbs. (62 kg)
Height, inch/mm: 33-7/16″(849 mm)
Width, inch/mm: 15-3/4″(400 mm)
Depth, inch/mm: 35-7/16″(900 mm)
Shipping weight: 170 lbs. (77 kg)
Shipping width: 19″(480 mm)
Shipping height: 44.1″(1120 mm)
Shipping depth: 41″(1040 mm)
Shipping volume: 19.8 cu. ft. (0.56 m³)
Key Information
Supply voltage:
200398 (NCPE400U) 208 V/3p/60z - 28 A
Connected load: 10 kW
Electric
Clearance: 4″(10 cm) from back.
Installation
Max.: 2 x 10.5 gal
Min.: 2 x 8.5 gal
Capacity
Water inlet “CW” – 3/4″″
″″
″connection:
Total hardness: 5-50 ppm
Drain “D” 1″connection
Electrolux recommends the use of treated water, based on
testing of specific water conditions.
Please refer to user manual for detailed water quality
information.
Water
