Electronics Line Penta User manual

-2-
Table of Contents
Introduction......................................................................................................... 2
Chapter One: Overview...................................................................................... 3
1.1: Specifications....................................................................................................3
1.2: Zones................................................................................................................3
1.3: Telephone Communication................................................................................4
1.4: Remote Programming.......................................................................................5
Chapter Two: Installation .................................................................................... 6
2.1: Parts and Options..............................................................................................6
2.2: Wiring Diagram.................................................................................................7
2.3: Terminal Connections........................................................................................8
2.4: Mounting the Keypad.........................................................................................9
2.5: Turning on the System ....................................................................................10
Chapter Three: System Operation .................................................................... 11
3.1: General ...........................................................................................................11
3.2: Keypad Layout................................................................................................11
3.3: Command Codes............................................................................................12
3.4: Arming/Disarming............................................................................................12
3.5: Distress Keys ..................................................................................................13
3.6: User Codes.....................................................................................................14
3.7: Zone Bypassing/Unbypassing .........................................................................15
3.8: Event Logs......................................................................................................15
3.9: Additional Operations......................................................................................16
Chapter Four: Programming ............................................................................. 17
4.1: General ...........................................................................................................17
4.2: Guide to Programming....................................................................................17
4.3: Programming Parameters...............................................................................18
4.4: Periodic Test Timer Reset...............................................................................23
Appendix A: Hexadecimal Conversion Chart .................................................... 24
Appendix B: Glossary of Terms ........................................................................ 25
Index ................................................................................................................ 28
Introduction
This manual is designed to help you with the installation process for the Penta control
panel. We strongly urge you to read through this manual, in its entirety, before beginning
the installation process so that you can best understand all that this security system has
to offer your customers. This manual is not intended for end user use. End users are
encouraged to read the user manual provided with the system. If you have any questions
concerning any of the procedures described in this manual please contact Electronics
Line at ([phone] (International) or 1-800-683-6835 (USA).
Catalog Number: ZI0094E (6/00)

-3-
Chapter One: Overview
1.1: Specifications
Power Input Secondary: 15Vac, 22-30VA transformer
Battery backup: 12Vdc/3.2Ah
Power Output Auxiliary power: 13.5 - 14.0V (AC operated)
12.0V Nominal (Battery operated)
Bell/siren output: 13.5 - 14.0V (AC operated)
12.0V Nominal (Battery operated)
Zones 4 security zones supervised by 2.2K ¼W end of line resistors
1 tamper/ ON/OFF keyswitch zone
Keypads Up to 3 individually addressed.
3 user initiated distress keys
Current draw: 100mA max. for each keypad,
200mA max. if three keypads are installed
User Codes 6 (1 master code, 3 standard user codes, 1 duress code and
1 installer code
Number of digits per user code: 4
Operating
Temperature 0°to 50°C
1.2: Zones
The Penta control panel includes four security zones plus one tamper zone which can be
defined for use with an ON/OFF keyswitch. The four security zones are fully pro-
grammable and supervised by end of line resistors. The Penta offers five zone response
types for customized programming to suit a wide range of installations. Each zone can be
programmed to activate a siren/bell when tripped or to generate a silent alarm where only
a message is sent to the central station. The following is a summary of the operational
characteristics for each zone response type:
Perimeter Zone
Perimeter zones instantly generate an alarm when opened.
Suggested Use: Magnetic contacts or detectors protecting the doors and windows which
are never used to enter the premises.
Perimeter Zone With Delay
This zone type starts the entry delay when opened, allowing the user time to disarm the
system.
Suggested Use: Magnetic contacts or detectors protecting the doors commonly used to
enter or leave the premises.
Conditional Zone
If a perimeter zone with delay is opened first, conditional zones do not generate an alarm
when opened during the entry delay. If a conditional zone is opened first, an alarm is
generated instantly.
Suggested Use: Detectors protecting the area in which a keypad has been installed or the
area crossed in order to reach the keypad.

-4-
Interior Zone
Interior zones are automatically bypassed when the system is armed using the ‘Stay’
command Q, 9.
Suggested Use: Detectors protecting the interior areas in which the user requires
unrestricted movement when ‘Stay’ arming. For example bedrooms, bathrooms and
interior offices.
24hr Zone
24hr zones always generate an alarm when opened whether the system is armed or
disarmed.
Suggested Use: Panic buttons, glassbreak detectors and areas which require 24 hour
protection.
Fast Loop Perimeter Zone
This zone is a perimeter zone with a 50ms loop response time (compared to 150ms for all
other zone types).
Suggested Use: Shock sensors used to detect attempts to breach the exterior of a
protected area.
1.3: Telephone Communication
The Penta allows for up to two telephone numbers (primary and backup) to be
programmed into the system dedicated to central station communications or for use with
the ‘Follow-me’ format. An additional number can be programmed for use in conjunction
with the RP callback feature. Up to 16 digits can be programmed for each telephone
number. The Penta offers a number of communication options and supports either pulse
or DTMF dialing.
Central Station Communication
The Penta’s on-board dialer uses the following protocols for central station
communication:
•Contact ID
•20pps 4/2 no parity
•10pps 3/1 no parity
Follow-me
Using the ‘Follow-me’ feature, the panel informs the user that an event has occurred by
dialing the user’s telephone number and sounding two beeps. After hearing the two
beeps, pressing 3, 6, 9 or # on the telephone sounds a number of tones to indicate
exactly which type of alarm has occurred. The number of tones indicates the type of
alarm generated.
1 tone = Alarm from zone 1 1 long = F key alarm
2 tones = Alarm from zone 2 Tone
3 tones = Alarm from zone 3 2 long = E or P key alarms, zone
4 tones = Alarm from zone 4 Tones or keypad tamper
After the alarm tones have been sounded, pressing 3, 6, 9 or # on the telephone either
causes the panel to hang up or, if additional alarms have occurred, sound another set of
alarm tones. Note: Electronics Line recommends using a telephone unit with
Continuous DTMF mode. If only Burst mode is available it may be necessary to
press more than once. If using the Follow-me feature, program the relevant event
codes (addresses 11 – 18) with any value greater than 00.

-5-
Voice Message (3601)
The 3601 is an add-on module that enables the recording of a short message. In the
event of an alarm, the panel dials the user’s telephone number and this message is
played back. Pressing 3, 6, 9 or # on the telephone acknowledges that the message has
been received.
1.4: Remote Programming
Electronics Line’s remote programming software enables programming and operation
from a PC. The software provides a comprehensive interface to the Penta control panel,
facilitating and cutting down the time taken in programming the system. RP access is
gained using a four digit code programmed at address 57. Without this code all remote
programming and operation is restricted.
Answering Machine Override
Answering machine override enables the control panel to distinguish between regular
incoming calls and a communication attempt by the RP (remote programmer) software.
An RP call is identified by the control panel as a sequence of two calls within a 30-second
time window.
1. The control panel does not answer the first incoming call.
2. The control panel opens a 30-second time window from the moment the telephone
stops ringing.
3. The control panel answers after 1 ring and RP communication is established.
This method enables the panel to share the same telephone line with answering
machines and fax machines.
RP Callback
RP call back is a toll-saver feature that makes remote programming more cost-effective.
When the remote programmer contacts the panel, the panel hangs up and calls the
telephone number programmed at address 56.

-6-
Chapter Two: Installation
2.1: Parts and Options
Standard Parts
Penta household burglary alarm control panel 1
3104 LED keypad 1
2.2KΩ¼W resistors 5
6 x ¼ screws 4
Mounting studs 4
PCB support 1
Installation manual 1
User manual 1
Optional Parts
Additional 3104 LED keypad
3601 voice message module
Remote Programmer up/downloading software
3911 remote programming device
230 - 15VAC transformer
Cabinet tamper protection switch

Z4
Z3
Z2
Z1
ZONE
CONNECTIONS
AUX
-
+KPD
K2 K1
BATTERY PROTECTION FUSE: Replace with a 1.0A/250V fuse
Electronics Line (E.L.) recommends testing the system at least once a week. Refer to the testing procedure found in the user manual.
AUX OUTPUT CURRENT DRAW: The auxiliary output current allowed for peripheral units must not exceed 300mA when one keypad is installed. For each additional keypad (up to 3 max.) the permitted current draw is reduced by 50mA.
AUXILIARY POWER OUTPUT: AC Operated: 13.5 - 14.0V Battery Operated: 12V Nominal
AC Transformer
50/60Hz
15Vac
22-30VA
Do not connect to a switch controlled receptacle.
LED Keypad
BELL/SIREN OUTPUT: 600mA max.
12345678910 11 12 14 15
PGM
13 16
Telephone Line
Connections
Tamper
Zone
B
L
A C K
R
E
D
12V/3.2Ah BATTERY: Replace the battery every 3 - 5 years. The maximum charging current is 350mA.
+
-
JPD Jumper for factory default restore
Electronics Line (E.L.) Ltd. - Penta
Household Burglary Alarm Panel
N.C.
2.2K 1/4W2.2K
1/4W
Typical End
of Line
Resistor
Zone
Connections
(EOLR)
N.C.
-
+
Connector for 3601
Voice Module
Optional
Earth
Connection
78
-
+
2.2K
Supervised
Bell
Connections
(USA
hardware
only)
2 3 4 5
1
2.2: Wiring Diagram
-7-

-8-
+
377 448 59
6
LOAD
(100mA max.)
AUXPGM
2.3: Terminal Connections
15-16.5Vac Input
Terminals 1 & 2: Connect a 15Vac transformer rated at 22-30VA, using 18 AWG wire.
Auxiliary Power Output
Terminals 3(+), 4(-): The auxiliary power output connections supply power to keypads
and peripheral units such as detectors and other powered sensors.
Keypad Data Bus Connections
Terminals 5 & 6: Connect up to three individually addressed LED keypads to terminals
5 (K2), and 6 (K1). Make sure that the wires are connected to the same connections on
the keypad, see 2.4: Mounting the Keypad.
Bell Power Output
Terminals 7(+), 8(-): Connect these terminals to supply power
to the bell. The bell power output supplies AUX power, rated at
600mA max.
Bell Supervision (USA hardware only)
The bell connections must be terminated by a 2.2K ¼W
resistor as shown in Figure 2.1.
PGM Programmable Output
Terminal 9: The PGM output switches to
ground when activated, enabling the
connection of additional system status
indicators. Connect the PGM output as
shown in the Figure 2.2.
Tamper Zone/Keyswitch Connections
Terminal 10: Connect a tamper switch or ON/OFF keyswitch
to terminals 10(+) and 12(-). Note: If neither the tamper
zone nor keyswitch are used, short terminal 10 to 12 and
define this zone as Tamper Zone at Address 01.
Zone Connections
Terminals 11, 12, 13, 14, 15 & 16:
ZONE 1: Terminals 11(+) & 12(-) ZONE 3: Terminals 14(+) & 15(-)
ZONE 2: Terminals 13(+) & 12(-) ZONE 4: Terminals 16(+) & 15(-)
101112
+
Tamper Switch or
ON/OFF Keyswitch
2.2K
78
+
Figure 2.1: Bell
Supervision Connections
Figure 2.2: PGM Output Connections
Figure 2.3: Tamper Zone/
Keyswitch Connections

-9-
Telephone Line
Terminals 17, 18, 19, 20: The telephone line should be connected (using the
standard Telco wires - minimum 26 AWG) as follows: 17 - Home Tip, 18 - Home Ring,
19 - Telco Tip and 20 - Telco Ring.
Note: The equipment has been approved in accordance with Council Decision 98/482/EC for
pan-European single terminal connection to the public switched telephone network (PSTN).
However, due to differences between the individual PSTNs provided in different countries, the
approval does not, of itself, give an unconditional assurance of successful operation on every
PSTN network termination point. In the event of problems you should contact your equipment
supplier in the first instance.
2.4: Mounting the Keypad
1234
A
B
Figure 2.4: 3104 LED Keypad (cover removed)
Up to 3 LED keypads can be connected to the Penta control panel. To mount the
keypad:
1. Separate the front and back cover of the keypad by pressing the locking tabs,
situated at the bottom of the keypad, with a small flathead screwdriver.
2. Pull the keypad wires through the opening in the back cover nearest the terminal
block and mount the back cover to the wall.
3. Define the keypad address by configuring jumpers A & B according to the following
diagram.
Jumper
Removed
Keypad 3Keypad 2Keypad 1
B
A
B
A
B
A
Jumper
Installed
Figure 2.5: Keypad Jumper Configuration
Configuration
Jumpers
Buzzer
Tamper
Switch
Terminal
Block

-10-
4. Connect the keypad to the control panel according to the following diagram.
Figure 2.6: Keypad Connections
5. Reassemble the front and back cover of the keypad.
2.5: Turning on the System
Once all of the systems components are properly connected to their destination
terminals, the Penta is ready to be turned on. To avoid the risk of electrical shock or
damage to the control panel, make sure that both the AC supply and the battery are
connected properly before plugging in the system. If you experience any difficulties in
applying power to the unit, please contact Electronics Line’s Technical Support
Department. The Penta control panel is supplied with a default program that includes
typical programming data which means that minimum programming is required for
typical installations.
To turn on the system:
1. Install the JPD jumper located at the top of the control panel board.
2. Reapply power and wait for 10 seconds; the keypad beeps to indicate the end of the
10 second period.
3. Disconnect both the AC and battery power supply.
4. Remove the JPD jumper.
5. Reapply power and wait for 10 seconds; the keypad beeps to indicate that the
default program has been restored.
The default settings can be reset at any time by disconnnecting the power supply and
repeating the above procedure.
+
+
K2
K2
K1
K1 CONTROL PANEL
KEYPAD
345656

-11-
Chapter Three: System Operation
3.1: General
All operation and programming of the Penta can be performed using any one of the
three LED keypads that can be installed with each system. This section offers a
complete explanation of the keypad functions and of the LED display, incorporating a
summary of command codes used in system operation.
3.2: Keypad Layout
READY
1234
SYSTEM
F
E
P
Figure 3.1: Keypad Layout
The numeric keypad is used for operation and programming of the system.
Additionally, three distress keys enable the user to send one of three individual distress
signals to the central station - see 3.5: Distress Keys for further information.
LED Display
1 - 4: LEDs 1 - 4 are used to display zone status. The corresponding LED lights up if a
zone is open. If a zone is bypassed the corresponding LED blinks.
READY: The Ready LED lights up to indicate that there are no open zones or tamper
conditions and the system is ready to be armed.
SYSTEM: The System LED blinks to indicate that new events have been recorded in
one of the logs and when displaying additional system information such as
programming mode or bypass mode.
ARMED: The Armed LED lights to indicate the system is armed or in
programming mode and flashes during the exit delay.
POWER: The Power LED lights up when both AC & battery power are OK, blinks
when the battery is low & AC power is OK, and goes out in the event of AC failure.
Zone
Indicators
Status
Indicators
Numeric
Keypad
Buzzer
Distress Keys
Status
Indicators

-12-
3.3: Command Codes
Commands are executed by pressing the ‘Q‘ button followed by the corresponding
command number and, in some cases, a valid user code. The following is a summary
of the command codes used in system operation.
Q0Quick Arm Q5+ (User Code 1) Program User Codes
Q1+ (User Code) Bypass Mode Q6Zone Chime
Q2Emergency/Trouble
Event Log Q7 + (Installer Code) Programming Mode
Q3Zone Alarm
Event Log Q8+ (User Code) Forced Arming
Q41
Q42 + (User Code 1) Bell/LED Test
Walk Test
Q9+ (User Code)
ENTER 1 + (User Code 1)
Stay Arming
Stop Communications
3.4: Arming/Disarming
The following section explains the various arming and disarming methods.
Arming
When all zones are secured the system can be armed normally. Arming the system
transmits a message to the central station identifying which user performed the
operation.
To arm the system:
1. Check that all zones are closed; the Ready LED lights up to indicate that the
system is ready to be armed.
2. Enter a valid user code; the keypad beeps until the end of the exit delay.
ForcedArming
Forced arming enables the user to arm the system with open zones. Electronics Line
recommends waiting until all of the zones are secured and the system can be armed
normally. Note: If zones are still not secured after the exit delay has ended, an
alarm will be generated.
To force arm the system:
1. Press Q, 8.
2. Enter a valid user code; the keypad beeps until the end of the exit delay.
Quick Arming
This feature allows the Penta to be armed without a valid user code. Quick arming the
system transmits an “Armed by User 1” message to the central station.
To “Quick” arm the system:
1. Check that all zones are closed; the Ready LED lights up to indicate that the
system is ready to be armed.
2. Press Q, 0; the keypad beeps until the end of the exit delay.

-13-
Stay Arming
This feature only arms perimeter zones – i.e. Perimeter, Perimeter with Delay and Fast
Loop Perimeter zones. This allows the user to stay within the protected area while the
system is armed.
To “Stay” arm the system:
1. Check that all zones are closed apart from the interior zones; the Ready LED lights
up to indicate that the system is ready to be armed.
2. Press Q, 9.
3. Enter a valid user code; the keypad beeps until the end of the exit delay.
Immediate Arming
The system can be operated without an entry/exit delay. Pressing Qduring the exit
delay or when the system is armed cancels both the exit and entry delay times.
Note: It is not recommended to use this feature with an external keypad.
Disarming
The Penta can be disarmed by entering a valid user code during the entry delay. If an
error is made entering the code, press ‘#’ and enter the code again. When the code is
accepted the Armed LED and the pulsed delay tone are turned off. If the correct code is
not entered by the end of the delay time, an alarm will be generated.
Keyswitch Arming/Disarming
The system can be armed and disarmed using an ON/OFF keyswitch. The keyswitch
has two operation modes.
1. Latching - closing the keyswitch arms the system, opening disarms the system.
2. Momentary - opening and closing the keyswitch either arms or disarms the system.
3.5: Distress Keys
In the case of an emergency, 3 types of alarms can be generated by pressing and
holding down the desired distress key for more than 2 seconds. These alarms will send
the relevant distress codes to the central station. The distress keys are as follows:
F
E
P
FIRE: Sounds the fire bell, sends the ‘Fire’ event code to the central
station (address 17) and registers in the Emergency/Trouble event log.
EMERGENCY: Sends the ‘Emergency’ event code to the central station
(address 18), sounds the siren (if programmed at address 01) and
registers in the Emergency/Trouble event log.
POLICE: Sends the ‘Police’ event code to the central station (address 16),
sounds the siren (if programmed at address 01) and registers in
the Emergency/Trouble event log.

-14-
3.6: User Codes
The Penta is capable of maintaining four user codes, a duress code and an installer
code. Each of these codes are four digits long. Of the four user codes, only User
Code 1 (default 1111) has authorization to modify other user codes and the duress
code. The installer’s code (default 1234) is the only user code which grants access to
the programming parameters and is programmable at address 59.
To program user codes 1-4:
1. Press Q, 5.
2. Enter User Code 1; the Armed and System LEDs flash and the zone LEDs indicate
the programming status of each user code as follows:
OFF: NOT PROGRAMMED
ON: PROGRAMMED
FLASHING: CURRENTLY BEING PROGRAMMED
3. Enter the number of the code to be changed (1-4); the requested zone LED flashes.
4. Enter the new user code; the LED stops flashing.
5. Enter the next code to be changed or press # to exit.
Note: If the new code is identical to an existing user code, an error tone will be
sounded and the new code will not be accepted.
To erase a user code:
1. Press Q, 5.
2. Enter User Code 1.
3. Enter the number of the code to be erased (1-4); the requested zone LED flashes.
4. Enter Q, Q, Q, Q; the LED stops flashing and the code is erased.
5. Enter the next code to be erased or press # to exit.
Note: Do not erase User Code 1! Erasing this code denies the user the ability to
program user codes. If User Code 1 is accidentally erased, reset the default
program as described in 2.5: Turning on the System.
Duress Code
In the event that the user is forced to disarm the system and/or cancel the bell, entering
the duress code will send a silent alarm to the central station.
To program the duress code:
1. Press Q, 5.
2. Enter User Code 1.
3. Press 5; the Ready LED flashes.
4. Enter a new duress code or Q, Q, Q, Qto erase the existing code.
5. Press # to exit.

-15-
3.7: Zone Bypassing/Unbypassing
The Penta offers the user the ability to bypass zones. When a zone is bypassed, it is
ignored by the system and will not generate an alarm when tripped.
To bypass a zone:
1. Press Q, 1.
2. Enter a valid user code; the System LED flashes and the LEDs of any currently
bypassed zones light up.
3. Enter the number of the zone to be bypassed; the corresponding zone LED lights up.
4. Press #to exit bypass mode; the bypassed zones flash.
To unbypass a zone:
1. Press Q, 1.
2. Enter a valid user code; the System LED flashes and the LEDs of any currently
bypassed zones light up.
3. Enter the number of the zone to be unbypassed; the corresponding zone LED turns off.
4. Press #to exit bypass mode.
Note: Disarming the system automatically unbypasses all bypassed zones.
3.8: Event Logs
The event logs record events that the system has undergone since the last arming. If
any events have been recorded in either event log, the System LED flashes until the
relevant event log has been viewed. In the event that a trouble condition still exists, the
System LED continues to flash until the condition has been remedied.
Emergency/Trouble Event Log
Zone tamper, keypad trouble or any of the three distress key alarms are registered in
the Emergency/Trouble event log.
To view the Emergency/Trouble event log:
1. Press Q, 2; the various trouble conditions are indicated by the zone LEDs.
The following is a summary of the trouble condition that each LED indicates when lit:
1- Tamper or Keypad Trouble 2 - Alarm from P key
3- Alarm from F key 4- Alarm from E key
2. Press #to exit the event log.
Note: The event logs can only be viewed when the system is disarmed.
Zone Alarm Event Log
The Zone Alarm event log displays the zones from which an alarm was generated since
the system was last armed.
To view the Zone Alarm event log:
1. Press Q, 3; an alarm from a specific zone is indicated by the corresponding zone
LED.
2. Press #to exit the event log.
Both logs are automatically reset when the system is next armed.

-16-
3.9: Additional Operations
Bell Cancel
To cancel the bell:
•Enter a valid user code or turn the keyswitch as if disarming the system.
Bell/LED Test
To perform a bell/LED test:
•Press Q, 4,1; the siren is sounded and all LEDs on the keypad are lit for a period
of two seconds.
Walk Test
Walk test mode enables the testing of peripheral detection devices, such as PIR
detectors and magnetic door contacts. In this mode, when a zone is opened or closed,
the keypad chimes.
To perform a walk test:
1. Press Q, 4,2.
2. Enter User Code 1; the Ready, System, Power and Armed LEDs flash to indicate
that the system is in Walk Test mode. To end Walk Test mode, press #. This mode
is automatically terminated after 4 minutes.
Note: The Tamper Zone always generates an alarm if opened, even if the system
is in Walk Test mode.
Stop Communications
To cancel the transmission of all unsent messages:
1. Press ENTER,1.
2. Enter User Code 1; all communication buffers are cleared and all communications
stop immediately.
Zone Chime On/Off
The keypad can be set to chime when Perimeter With Delay or Perimeter zones are
opened or closed. This feature only functions when the system is disarmed.
To toggle the zone chime On or Off:
•Press Q, 6 while the system is disarmed.
The keypad will sound a continuous tone to indicate “Zone Chime ON” or two short
beeps to indicate “Zone Chime OFF”.
Keypad Backlight On/Off
To toggle the backlight of any keypad On or Off:
•Press and hold down #for more than 2 seconds.

-17-
Chapter Four: Programming
4.1: General
The Penta control panel may be programmed using either the LED keypad or
Electronics Line’s Remote Programmer. If using the Remote Programmer, refer to the
instructions provided with the software.
4.2: Guide to Programming
The control panel has 61 parameter addresses allowing precise custom configuration of
the system to suit the user’s needs. The options for each address are listed in section
4.3: Programming Parameters. All of the programming parameters are stored in the
Penta’s non-volatile EEPROM memory which stores the data in the event that power is
disconnected. Before programming directly after installing the system, restore the
default parameters as explained in 2.5: Turning on the System.
To program the system:
1. Make sure the system is disarmed.
2. Press Q, 7.
3. Enter the Installer Code (the default installer code is 1234); the Armed LED lights
up and the System LED flashes.
4. Enter the two-digit parameter number to be programmed; the Ready LED lights up
and the Armed LED turns off.
5. Enter a new value or press #to cancel; if the value has been successfully changed,
the keypad sounds an acknowledge tone to confirm and the Ready LED turns off.
6. Press # to exit programming mode.
Note: The default Installer Code should be changed immediately after installing
the system.
Hexadecimal Data
Some of the programming parameters require a hexadecimal value to be entered. To
enter hexadecimal data, use the following combination of digits for hexadecimal
numbers greater than 9.
Q, 0= AQ, 1= B Q, 2= CQ, 3 = DQ, 4 = EQ, 5 = F
Keypad Tones
The keypad sounds a series of tones to aid programming. These tones offer the
installer status indication during programming. The following is a summary of the
keypad programming tones.
Short Beep =Confirmation of each keystroke
Long Beep =Acknowledgment of a successful entry
Low Beeps =Error, illegal entry
Continuous Beeps = Entry/Exit delay

-18-
4.3: Programming Parameters
The following section lists the Penta’s programming parameters which are used to
configure the system. For a listing of the default parameters please contact your local
dealer.
Address 00: Communication Attempts
The control panel’s attempts to communicate with the central station are organized in
rounds. A communication round is a set of dialing attempts. If the panel does not
succeed in sending the event message to the primary number within this number of
attempts, the backup number is dialed the same number of times. A new round will
begin 30 minutes after the last dialing attempt. The number of communication rounds is
defined in the first digit of this address. The number of dialing attempts in each round is
defined in the second digit. Note: To Disable Communications, enter 00 at this
address.
First Digit: Communication Rounds
Enter a value between 1 – F
(F = Unlimited rounds until
communication is established)
Second Digit: Dialing Attempts
Enter a value between 1 – F
Address 01: Miscellaneous
This address offers a number of options for the system’s setup. Enter 5 digits at this
address according to the following:
Fifth Digit: P Key Alarm
0 - Audible
1 - Silent
First Digit: Keypads
0 - No Keypads
1 - One Keypad
2 - Two Keypads
3 - Three Keypads
Third Digit: Tamper Zone Definition
0 - Arm/Disarm Keyswitch
1 - Tamper Zone
Second Digit: Keyswitch Function
0 - Latching
1 - Momentary
Fourth Digit: E Key Alarm
0 - Audible
1 - Silent

-19-
Address 02: Communication Options
This address consists of the various options used in communication and/or remote
programming. Enter five digits according to the following.
Fifth Digit: Dialing
0 - Pulse
1 - DTMF
First Digit: Protocol
0 - 20pps 4/2 no parity
1 - Follow Me
2 - Contact ID
3 - Voice Message (3601)
4 - 10pps 3/1 no parity
Fourth Digit: Handshake
0 - 1400Hz Handshake
1 - 2300Hz Handshake
Second Digit: RP Access Type
0 - Passcode
1 - Callback
Third Digit: RP Access
0 - Disable RP Access
1 - Enable RP Access
Address 03: Zone 1 Definition
One of six response types can be assigned to zone 1. Each zone type can be
programmed as ‘Silent’ or ‘Audible’. A ‘Silent’ zone will not activate a siren or bell when
the zone is tripped.
00 - Perimeter zone with delay (Silent)
10 - Perimeter zone with delay (Audible)
01 - Perimeter zone (Silent)
11 - Perimeter zone (Audible)
02 - Conditional zone (Silent)
12 - Conditional zone(Audible)
03 - Interior zone (Silent)
13 - Interior zone (Audible)
04 - 24hr zone (Silent)
14 - 24hr zone (Audible)
05 - Fast Loop Perimeter Zone (Silent)
15 - Fast Loop Perimeter Zone (Audible)
Address 04: Zone 2 Definition
Same as above for zone 2.
Address 05: Zone 3 Definition
Same as above for zone 3.
Address 06: Zone 4 Definition
Same as above for zone 4.

-20-
Address 07: Entry Delay Time
The entry delay timer determines the amount of time the user has to disarm the system
before an alarm is activated. The entry delay is only initiated if the premises are entered
through a zone defined as ‘perimeter with delay’. Enter a hexadecimal value between 1 and
255 seconds at this address using the hexadecimal conversion chart in Appendix A.
Address 08: Exit Delay Time
The amount of time the user has to leave the premises after arming is determined by
the exit delay timer. An open zone will not activate an alarm during this period. Enter a
hexadecimal value between 1 and 255 seconds at this address using the hexadecimal
conversion chart in Appendix A.
Address 09: Bell Cut-Off Time
The bell cut-off is the period of time that the bell or siren will be activated after an alarm
has occurred. Enter a value between 1 and 5 minutes at this address.
Address 10: PGM Options
The PGM (Programmable Output) can be used for indication of certain status or trouble
conditions. When the PGM output is activated terminal 9 switches to ground. Choose
the PGM output setting from the following table.
Value Name Activated By Deactivated By
00 PGM Disabled --- ---
01 Arm/Disarm System Armed System Disarmed
02 Entry/Exit Entry/Exit Tone Follower Entry/Exit Tone Follower
04 Communication System in Communication End of Communication
08 AC Loss AC Loss AC Restore
10 Bell Follower Bell Follower Bell Follower
20 Duress Duress Code (deactivated after 2 seconds)
40 Alarm System in alarm Arming/Disarming/View log†
80 Chime Follower Keypad Chime Follower Keypad Chime Follower
Event Codes
All events can be programmed to transmit a two digit event code message to the
central station. These codes are usually assigned by the central station - consult the
central station operator/owner for a listing of the different event codes. To disable an
event code program the code as 00.
Address 11: Alarm from Zone 1*
Address 12: Alarm from Zone 2*
Address 13: Alarm from Zone 3*
Address 14: Alarm from Zone 4*
Address 15: Alarm from Tamper Zone*
†To deactivate the PGM output, the relevant log must be viewed.
*When using the Follow-me feature, program these addresses with a value greater than 00.
