Element 1300 User manual

Dealer Name
Dealer Phone
Serial Number
9413-02 • 10/19
512 West Gorgas Street §Louisville, OH 44641-3912
www.elementvac.com
Attention Installer: Please be sure this manual and warranty information
are left with the power unit or customer when installation is complete.
Operating Instructions For
ELEMENT Central Vacuums
Inverted Filter Models:
1300, 1700 & 2300
Disposable Bag Models:
DB3000, DB5000, DB7000, DB8000 & DB9000
Read Manual Before Operating System
Read the owner’s manual thoroughly before operating to
ensure the most efficient use of the system.

ELEMENT Central Vacuum Systems
2
Models ETL File Ref. #
1300 99300
1700 99500
2300 99700
DB3000 77400
DB5000 77500
DB7000 77600
DB8000 77800
DB9000 88200

ELEMENT Central Vacuum Systems
3
TABLE OF CONTENTS:
Important Safety Instructions ....................................................................... 3
Grounding Instructions ................................................................................. 5
General Information ...................................................................................... 6
Registration ................................................................................................... 6
Operating Instructions .................................................................................. 6
General Maintenance .................................................................................... 6
Emptying the Dirt Canister and Filter Maintenance .................................... 7
Disposable Bag Maintenance, Bag Removal & Replacement ..................... 8
Troubleshooting ............................................................................................. 9
CONSIGNES DE SECURITÉ IMPORTANTES................................................. 10
INSTRUCTIONS DE MISE À LA TERRE ....................................................... 12
Warranty ........................................................................................................ 13
This manual contains canister and maintenance instructions for two (2) different
filtration methods. Please be sure to follow the appropriate instructions for your
power unit model number (found on the front of the canister).
To find links to maintenance videos, downloadable manuals,
troubleshooting and warranty information or to register your system,
please visit www.centralvacservice.com.

ELEMENT Central Vacuum Systems
4
IMPORTANT SAFETY INSTRUCTIONS
Read These Instructions Before Using This Vacuum System
Installation of this product should be made by a qualified, authorized
central vacuum dealer. Before installing, using, or servicing this product,
the installer should carefully read and fully understand the instructions
including all warnings, cautions, and safety notice statements. To
reduce the risk of personal injury, death and/or property damage, follow
all instructions for proper installation, operation and maintenance.
These instructions are not intended as a complete listing of all details
for installation, operation and maintenance. If you have any questions
concerning any of these procedures, STOP, and call an authorized central
vacuum dealer.

ELEMENT Central Vacuum Systems
5
When using an electrical appliance, basic precautions should always be
followed, including the following:
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY:
• Unplug and disconnect power before servicing.
• Do not allow to be used as a toy. Close attention is necessary when used
by or near children.
• Use only as described in this manual. Use only manufacturer’s
recommended attachments.
• Do not use with damaged cord or plug. If appliance is not working as
it should, has been dropped, damaged, left outdoors, or dropped into
water, return it to an authorized servicing dealer.
• Do not pull or carry by cord, use cord as a handle, close a door on cord,
or pull cord around sharp edges or corners.
• Do not run appliance over cord.
• Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle system or appliance with wet hands.
• Use extra care when cleaning on stairs.
• Do not use on wet surfaces.
• Do not put any object into openings. Do not use with an opening blocked.
Keep openings free of dust, lint, hair and anything that may reduce airflow.
• Keep hair, loose clothing, fingers, and all parts of body away from
openings and moving parts.
• Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
• Connect to a properly grounded outlet. See grounding instructions.
• Turn off all controls before unplugging.
• Do not use to pick up flammable or combustible liquids such as gasoline
or use in areas where they may be present.
• Do not place or store anything on top of power unit- overheating of motor
could occur.
• Any service work required under the top cover should be performed by
an authorized service representative.
• Do not operate without filter/disposable bag in place.
• Always turn off this appliance before connecting or disconnecting
motorized nozzle.

ELEMENT Central Vacuum Systems
6
GROUNDING
INSTRUCTIONS
This appliance must be grounded.
If it should malfunction or break
down, grounding provides a path of
least resistance for electric current
to reduce the risk of electric shock.
This appliance is equipped with a
cord having an equipment-grounding
conductor and grounding plug.
The plug must be plugged into an
appropriate outlet that is properly
installed and grounded in accordance
with all local codes and ordinances.
WARNING
Improper connection of the
equipment-grounding conductor
can result in a risk of electric
shock. Check with a qualified
electrician or service person if
you are in doubt as to whether the
outlet is properly grounded. Do not
modify the plug provided with the
appliance. If it will not fit the outlet,
have a proper outlet installed by a
qualified electrician.
Models 1300, 1700, 2300, DB3000,
DB5000, DB7000 and DB8000 are
for use on a nominal 120 volt circuit
and have a grounding plug that
looks like the plug in Fig. A.
Model DB9000 dual motor unit is
for use on a nominal 240 volt circuit
and has a grounding plug that looks
like the plug in Fig. B.
Make sure that the appliance is
connected to an outlet having the
same configuration as the plug. No
adapter should be used with this
appliance.
CONNECT TO A PROPERLY GROUNDED OUTLET ONLY.
SAVE THESE SAFETY INSTRUCTIONS
Intended For Household and Light Commercial Use. Do not vent into a
wall, a ceiling, or concealed space of a building or structure.
WARNING:
Electric shock could occur
if used on wet surfaces.
CAUTION:
Do not use on a wet
rug or floor.

ELEMENT Central Vacuum Systems
7
GENERAL INFORMATION
The central vacuum is designed to vacuum ordinary household dirt and
dust. The system is designed for dry pickup.
The central vacuum system is a network of inlet valves, 2” PVC tubing,
and low voltage wiring installed in the walls of your home. The dirt is
transported through the in-wall tube system back to the dirt canister
(removable lower portion of the power unit).
REGISTRATION
To register your Element Central
Vacuum System warranty in the
United States and Canada, register
online at www.cvacregistration.com
or fill out and mail the warranty
card located with this manual.
Proof of purchase or registration
of your Element Central Vacuum
System is required before any
warranty work will be performed
by an authorized Element Central
Vacuum dealer. Registration
ensures a fast and easy resolution
to your warranty requirements.
OPERATING INSTRUCTIONS
Using the central vacuum system
is easy. For standard systems,
simply raise the inlet valve lid,
insert the hose end and attach the
desired cleaning tool to the hose
wand. The power unit is activated
when the hose is inserted into the
valve. Please refer to accessory
instructions for further specifics on
usage.
When using the inlet valve on the
power unit (models 1300, 1700 and
2300 ONLY), the ON/OFF switch
must be in the ON position.
GENERAL POWER UNIT MAINTENANCE
The simple care and maintenance instructions included here will help
ensure trouble-free use of your central vacuum system.
• Do not place objects on top of the power unit. The motor could overheat.
• Do not allow the motor to remain ON unless a hose is connected or an
inlet valve is open. If airflow is not permitted to flow through fan blades,
motor damage could occur.
• Do not operate without a disposable bag in place in models DB3000,
DB5000, DB7000, DB8000 & DB9000. Use disposable bag 9637 in model
DB3000 and 9520 in models DB5000, DB7000, DB8000 & DB9000.
• Empty the dirt canister/disposable bag when it is 2/3 full.
• The power unit does not require any lubrication.
• The exterior of the power unit can be wiped with a clean, dry cloth. Do
not use liquid cleaners or water as an electrical shock may occur.
• For additional service contact the qualified servicing dealer written on
the front of this manual or locate an authorized dealer online at
www.elementvac.com.

ELEMENT Central Vacuum Systems
8
EMPTYING THE DIRT CANISTER & FILTER
MAINTENANCE
For Inverted Bag Models: 1300, 1700 & 2300
The dirt canister is the removable lower portion of the power unit.
Follow These Steps (Refer to figures 1-4)
Make sure the power unit is OFF.
FIG. 3
FIG. 1
FIG. 4
FIG. 2
1. Unlatch and remove the dirt canister. Latches are located on opposite
sides of the power unit. When the dirt canister is removed the
permanent inverted filter will be visible. (Fig. 1)
2. Hold a large disposable bag around the bottom portion of the power
unit. (Fig. 2)
3. Take hold of the sewn-in weight located at the bottom of the permanent
filter, now inside the disposable bag and shake the weight. NOTE:
Shaking the weight of the permanent filter will be sufficient for
cleaning. DO NOT vacuum, brush or scrape the filter as it will cause
damage. (Fig. 3)
4. Carefully remove the disposable bag and empty the dirt and debris in
the dirt canister into the bag, close and dispose of.
5. Raise the dirt canister to the base of the power unit and engage the
latches. Be certain the dirt canister is seated properly to the gasket on
the base of the power unit. (Fig. 4)
8

ELEMENT Central Vacuum Systems
9
DISPOSABLE BAG MAINTENANCE
BAG REMOVAL & REPLACEMENT
For Disposable Bag Models: DB3000, DB5000, DB7000, DB8000 & DB9000
The dirt canister is the removable lower portion of the power unit.
Follow These Steps (Refer to figures 1-4)
Make sure the power unit is OFF.
1. Unlatch and remove the dirt canister. Latches are located on opposite
sides of the power unit. (Fig. 1)
2. Remove the used bag by rotating the cardboard header and pulling
down from the plastic bag adapter. (Fig. 2)
3. Pull off reorder information and seal the bag opening with adhesive
flap. Discard used bag. (Fig. 3)
4. Install new bag by folding over the flap, exposing the hole in cardboard
header. Do not remove reorder information from flap until ready for
disposal. Align the slots in the cardboard header with the tabs on the
plastic bag adapter. Push the cardboard header firmly onto the adapter
and rotate 45° to ensure that the slots are no longer aligned with the
tabs. (Fig. 2)
5. Raise the dirt canister to the base of the power unit and engage the
latches. Be certain the dirt canister is seated properly to the gasket on
the body of the power unit. (Fig. 4)
FIG. 3
FIG. 1
FIG. 4
FIG. 2

ELEMENT Central Vacuum Systems
10
TROUBLESHOOTING THE SYSTEM
Motor Fails to Turn on:
If the system fails to turn on when engaged, check the following:
• Check the main fuse or circuit breaker at the main power supply panel of
your home. Reset breaker or replace fuses if necessary.
• Check the power unit reset button located about the power cord.
Pressing the button should restore operation.
• If the circuit protector continues to trip after a short period of time the
motor brushes may be worn out. Contact the qualified servicing dealer
written on the front of this manual or locate an authorized dealer online
at www.elementvac.com for service.
• On Models 1300, 1700 & 2300 ONLY: Turn the power switch on the
power unit to ON. If the power unit starts, the low voltage wiring, relay
or the hose could be causing the issue. If the power unit does not come
on, but the light on the power switch is on, you may be experiencing a
problem with the motor. Contact your servicing dealer written on the
front of this manual or locate an authorized dealer online at
www.elementvac.com.
Loss of Vacuum
If the system shows a loss of vacuum power, check the following:
• The dirt canister may need emptied or the bag may need replaced—
follow instructions in this guide, depending on unit type.
• The hose may be clogged- To check if there is an obstruction, unplug the
hose and insert an object that is smaller than the diameter of the hose (a
butter knife works well). Pass the object completely through the hose, if
it stops, that will indicate where the obstruction is located. A dry garden
hose can be inserted into the hose to help push the obstruction through.
• The dirt canister may not be property seated to the gasket- Follow
instructions in this guide for replacing the dirt canister.
• Tube lines may be obstructed- First check the 90° elbow located directly
behind the inlet valves, if an obstruction occurs it will usually not make
it past this elbow. If the obstruction is not visible at the elbow, attempt to
purge the tubing at each inlet valve. To do this, connect the hose and use
your hand to stop airflow at the end of the hose for a couple seconds, let
airflow resume. Repeat if necessary.
• If necessary, contact the qualified servicing dealer written on the front
of this manual to perform required maintenance or locate an authorized
dealer online at www.elementvac.com.
Obtaining Service Under Warranty: To obtain repair on warranted
parts, contact the seller of the system with the power unit serial
number located on the power unit.

ELEMENT Central Vacuum Systems
11
CONSIGNES DE SÉCURITÉ IMPORTANTES
Lisez ces instructions avant d'utiliser ce système de vide
L'installation de ce produit doit être effectuée par un concessionnaire
agréé et agréé. Avant d'installer, d'utiliser ou d'entretenir ce produit,
l'installateur doit lire attentivement et comprendre complètement
les instructions, y compris tous les avertissements, mises en garde
et déclarations de sécurité. Pour réduire le risque ou les blessures
corporelles, le décès et/ou les dommages matériels, respectez toutes les
instructions pour une installation, un fonctionnement et une maintenance
appropriés. Ces instructions ne sont pas une liste complète de tous les
détails pour l'installation, l'exploitation et la maintenance. Si vous avez des
questions concernant l'une de ces procédures, arrêtez-la et appelez un
revendeur autorisé de l'aspirateur central.

ELEMENT Central Vacuum Systems
12
Lors de l'utilisation d'un appareil électrique, les précautions de base
doivent toujours être suivies, y compris les suivantes:
AVERTISSEMENT: POUR RÉDUIRE LE RISQUE
D'INCENDIE, D'ÉLECTROCUTION OU DE BLESSURE:
• Débranchez et débranchez l'alimentation avant de procéder à l'entretien.
• Ne laissez pas être utilisé comme un jouet. Une attention particulière est
nécessaire lorsqu'ils sont utilisés par des enfants ou à proximité d'enfants.
• Utilisez uniquement comme décrit dans ce manuel. Utilisez uniquement
les pièces jointes recommandées par le fabricant.
• Ne pas utiliser avec un cordon ou une fiche endommagés. Si
l'appareil ne fonctionne pas comme il se doit, il a été abandonné,
endommagé, laissé à l'extérieur ou tombé dans l'eau, renvoyez-le à un
concessionnaire agréé.
• Ne tirez ni ne le transportez par cordon, utilisez le cordon comme
poignée, fermez une porte sur le cordon ou tirez le cordon autour des
arêtes vives ou des coins.
• Ne coulez pas l'appareil sur le cordon.
• Tenir le cordon éloigné des surfaces chauffées.
• Ne débranchez pas en tirant sur le cordon. Pour débrancher, saisissez
la fiche, pas le cordon.
• Ne manipulez pas le système ou l'appareil avec les mains humides.
• Faites attention en cas de nettoyage sur les escaliers.
• Ne pas utiliser sur des surfaces humides.
• Ne placez aucun objet dans les ouvertures. Ne pas utiliser avec une
ouverture bloquée. Gardez les ouvertures sans poussière, peluches,
cheveux et tout ce qui peut réduire le débit d'air.
• Gardez les cheveux, les vêtements lâches, les doigts et toutes les parties
du corps loin des ouvertures et des pièces en mouvement.
• Ne retirez rien qui brûle ou fume, comme les cigarettes, les allumettes
ou les cendres chaudes.
• Connectez-vous à une prise de courant correctement mise à la terre.
Voir les instructions de mise à la terre.
• Éteignez toutes les commandes avant de débrancher.
• Ne pas utiliser pour retirer des liquides inflammables ou combustibles tels
que de l'essence ou utiliser dans les endroits où ils peuvent être présents.
• Ne placez ni ne stockez rien au dessus de l'unité de puissance - une
surchauffe du moteur pourrait se produire.
• Tout service de travail requis sous la couverture supérieure doit être
effectué par un représentant agréé.
• Ne pas utiliser sans filtre/sac jetable en place (le cas échéant).
• Toujours éteindre cet appareil avant de brancher ou de débrancher la
buse motorisée.

ELEMENT Central Vacuum Systems
13
CONNECTEZ-VOUS À UNE PRISE CORRECTEMENT
MISE À LA TERRE UNIQUEMENT.
INSTRUCTIONS DE MISE À LA TERRE
Cet appareil doit être mis à la terre. En cas de
dysfonctionnement ou de panne, la mise à la
terre offre un chemin de résistance au courant
électrique pour réduire le risque de choc
électrique. Cet appareil est équipé d'un cordon
doté d'un conducteur de mise à la terre et
d'une fiche de mise à la terre. La fiche doit être
branchée sur une prise appropriée correctement
installée et mise à la terre conformément à tous
les codes et ordonnances locaux.
AVERTISSEMENT
Un branchement incorrect
de l’équipement de mise a la
terre peut causer un risque
d’électrocution. Si vous avez un
doute concernant la mise a la terre
de votre prise, veuillez faire vérifier
votre installation par un électricien
qualifie ou une personne du service
après-vente. Ne pas modifier la
fiche fournie avec l’appareil- si la
fiche ne se branche pas a la prise,
faites installer une prise adéquate
par un électricien qualifie.
Les modèles 1300, 1700, 2300,
DB3000, DB5000, DB7000 et DB8000
sont destinés à être utilisés sur
un circuit nominal de 120 volts et
ont une fiche de mise à la terre qui
ressemble à la fiche de la Fig. A.
Les modèles DB9000 sont destinés
à être utilisés sur un circuit nominal
de 240 volts et ont une fiche de mise
à la terre qui ressemble à la fiche
illustrée à la Fig. B.
Assurez-vous que l'appareil est
connecté à une prise de courant
ayant la même configuration que la
fiche. Aucun adaptateur ne doit être
utilisé avec cet appareil.
Enregistrer ces consignes de sécurité
Destiné à l'usage domestique et léger.
Ne pas évacuer dans un mur, un
plafond ou un espace dissimulé
d'un bâtiment ou d'une structure.
ATTENTION:
Un choc électrique pourrait survenir
si utilisé sur des surfaces humides.
MISE EN GARDE:
Ne pas utiliser sur un tapis ou
un plancher humide.

ELEMENT Central Vacuum Systems
14
The Element Central Vacuum System (the “Element System”) is manufactured by H-P Products, Inc. (“H-
P”), 512 W. Gorgas Street, Louisville, Ohio, 44641. The following is the exclusive limited warranty (“Limited
Warranty”) provided by H-P with respect to the Element System:
Permanently Installed Components
All permanently installed components of the Element System are warranted to be free from defects in
material and workmanship under normal use and care as long as the original purchaser (“you”) owns
the home of the original installation or until the system is removed from its original installation location,
whichever occurs first. In the event of a defect in a permanently installed component of the Element
System, contact an authorized Element dealer (an “Authorized Dealer”) to ensure the best quality repair
and servicing. Upon determination of a defect with the permanently installed product, H-P will provide
any replacement parts to the Authorized Dealer at no cost to you. For a period of one (1) year from the
date of original installation, the Authorized Dealer will repair or replace, at H-P’s option, any permanently
installed defective part or parts at your location at no labor cost. Thereafter, repair or replacement of any
permanently installed defective part or parts shall be at the labor cost billed to you by the Authorized Dealer.
Attachments
Element System cleaning attachments including: turbine power brushes, non-electric hoses, wands, tools
and tool caddies are warranted to be free from defects in material and workmanship under normal use
and care for three (3) years from original date of consumer purchase. Electric powerheads and hoses are
warranted to be free from defects in material and workmanship under normal use and care for one (1) year
from original date of purchase, as more fully set forth in the electric powerhead manual. In the event of a
defect in an Element cleaning attachment, the attachment will be repaired or replaced, at H-P’s option, at an
Authorized Dealer’s location at no cost to you.
Limitations for Non-Residential Applications
In non-residential applications (a) permanently installed components of the Element System are warranted
to be free from defects in material and workmanship for one (1) year from date of original installation, and (b)
Element System cleaning attachments will be free from defects in material and workmanship for ninety (90)
days from the original date of purchase.
Limitations of Warranty
In addition to any limitations set forth above, this Limited Lifetime Warranty does not extend to (a) any
power unit purchased from someone other than an Authorized Dealer; (b) any Element System which has
not been installed in accordance with manufacturer-recommended instructions; (c) any Element System or
attachment which has been altered or modified in any way; (d) any Element System or attachment which has
been damaged due to misuse, negligence, accident, or improper operation; (e) any damage due to shipping
and handling; (f) any damage due to installation or faulty installation; (g) any Element System or attachment
upon which an unauthorized repair or service has been performed; (h) any damage to a permanently
installed component as a result of or relating to consumable items such as motor brushes, disposable bags,
or filters; or (i) any Vroom product or Chameleon Adaptable Hose System product as they carry their own
respective warranties. Purchase of products and services from unauthorized sources does not void your
original warranty on the Element System or attachments purchased through H-P or an Authorized Dealer.
You are responsible for securing additional and separate warranties on parts and services purchased from
someone other than an Authorized Dealer as H-P does not offer warranty coverage on products and services
purchased through unauthorized sources. There is NO warranty for consumable items such as light bulbs,
belts, beater brushes, motor brushes, disposable bags and filters.
AS A CONDITION PRECEDENT TO WARRANTY COVERAGE HEREUNDER, YOU MUST PROVIDE PROOF OF
PURCHASE OR HAVE REGISTERED THE ELEMENT CENTRAL VACUUM POWER UNIT BY TELEPHONE
AT 1-800-822-8356, ONLINE AT www.cvacregistration.com OR BY COMPLETING AND MAILING THE
WARRANTY REGISTRATION CARD.
THIS WARRANTY IS A SOLE AND EXCLUSIVE WARRANTY. ALL OTHER WARRANTIES INCLUDING IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXCLUDED. THIS
WARRANTY COVERS ONLY LIABILITY AND RESPONSIBILITY DESCRIBED HEREIN AND THERE IS NO
LIABILTY FOR ANY CONSEQUENTIAL, INCIDENTAL OR SPECIAL DAMAGES ARISING FROM THE USE OF
THIS SYSTEM.
Some states do not allow exclusion or limitation or warranties or limitation of incidental or consequential
damages, so the above exclusion may not apply to you. This warranty gives you specific legal rights and
you may have other rights that vary from state to state.
LIFETIME PLUS 1 RESIDENTIAL
LIMITED WARRANTY

ELEMENT Central Vacuum Systems

512 W. Gorgas St., Louisville, Ohio 44641
www.elementvac.com
