Elenco Electronics Space Battle SCP-05 User manual

The Snap Circuits Kit uses electronic blocks that snap onto a clear plastic base grid to build different
circuits. These blocks have different colors and numbers on them so that you can easily identify them.
Build the circuit shown by placing all the parts with a black 1next to them on the clear plastic base grid
first. Then, assemble parts marked with a 2. Install two (2) “AA” batteries (not included) into the battery
holder (B1).
Turn on the slide switch (S1). Activate the circuit by pressing the press switch (S2) or waving your hand
just above the photoresistor (RP), do both several times and in combination. You will hear an exciting
range of sounds, as if a space battle is raging!
The space war IC is a super-miniaturized electronic circuit that can play a variety of cool sounds stored
in it by using just a few extra components. In movie studios, technicians are paid to insert sounds like
these at the precise instant a gun is fired. Try making your sound occur at the same time an object hits
the floor. It is not as easy as it sounds.
