Elite Screens VMAX2 (Plus) Series Guide

VMAX2/Spectrum Vertical Limit Switch Adjustment Instructions
Caution: The screen’s Top Black Drop is already set to its maximum drop distance. There is NO extra
black top drop in the roller. Attempting to increase the drop will damage the motor and VOID your
warranty with Elite Screens. Do not use these instructions to try and get more out of your standard
black masking drop. Please contact Elite Screens before making any adjustments.
1. Allen Wrench
Fig. 1
2. Limit Ad ustment Switches
Fig. 2
(Note: When turning the limit switches, bear in mind that one full-circle turn in either direction will create a one
inch adjustment)
/32” Allen Wrench
UP adjustment switch
DOWN adjust
ment switch

3. Ad usting Retraction Position (shown in Fig. 3 – Fig. 7)
Fig. 3
Fig. 4
Fig.
If the screen will not retract
completely (as shown in Fig.
3), use the following steps.
Use remote to retract screen
as much as possible.
Use your allen
-
wrench to turn the
UP switch counter-clockwise.
Note: Adjustment should be made
while facing the back of the screen.

Fig. 6
Fig. 7
4. Ad usting the Top Black Masking (shown in Fig. 8 – Fig. 12)
Note: All electric screens come with standard top black masking and they cannot be dropped further. DO NOT
use these instructions to try to get more out of your standard black masking drop.
Fig. 8
One full turn will retract your screen by 1”. In
order to see adjustment, deploy and retract
the screen. (Warning: If you continue to rotate
the switch once the weight bar fits flush with
the casing, the screen will attempt to retract
further, causing damage to the unit. DO OT
over turn the switch).
If the screen retracts too far, just rotate
the UP adjustment switch 2-3 turns
clockwise, and the screen will lower.
If you need to decrease
the amount
of top black masking, refer to the
following steps.
Note: Adjustment should be made
while facing the back of the screen.

Fig. 9
Fig. 10
Fig. 11
Note: As a rule, Elite Screens does not recommend making unnecessary adjustments to
the screen, as improper adjustments will damage the unit.
Please contact Technical Support for assistance [phone]
Use your remote t
o fully lower
the screen.
Use your allen
-
wrench
to turn the
DOWN switch clockwise
One full turn equals 1” of decreased
drop. In order to notice the
adjustment, retract and deploy the
screen. Warning: Over adjusting the
switch will damage the motor and
void the warranty.
Note: Adjustment should be made
while facing the back of the screen.
