Elkay EDF14C Installation manual

97256C Rev. A 4/05
EDF14C
Installation/Care/UseManual
Toassureyouinstallthismodeleasilyandcorrectly,PLEASEREADTHESESIMPLE
INSTRUCTIONSBEFORESTARTINGTHEINSTALLATION.CHECKYOURINSTALLA-
TIONFORCOMPLIANCEWITHPLUMBING,ELECTRICALANDOTHERAPPLICABLE
CODES.Afterinstallation,leavetheseinstructionsinsidethefountainforfuturereference.
15
SEE FIG. 2
INSTALLATION INSTRUCTIONS
1. Wall should already be framed for the fountain using the positioning dimensions shown in Figure 1. Shown dimensions pertain to
installation location (framing must support up to 150 lbs. weight).
2. Install rough-in plumbing as shown in Figure 1. Waste line should extend a minimum of 2" (51mm) through the back panel. Connect
ing lines to be copper and thoroughly flushed to remove all foreign matter before connection to fountain. Run the supply water inlet
line through the back panel. Install a service stop (not provided). Turn on supply water and flush thoroughly.
3. Secure the fountain to the wall using (6) bolts and washers (not provided). Tighten securely.
4. Remove elbow from end of p-trap and attach it to drain tube. Reattach elbow to p-trap and cut waste tube to required length
using plumbing hardware and trap as a guide.
5. Make water supply connections from service stop to the fountain. Turn on water supply and check for leaks. Newly installed
water supply line should be insulated after leak check is completed.
6. These products are designed to operate on 20-105 PSIG supply line pressure. If inlet pressure is above 105 PSIG, a pressure
regulator must be installed in the supply line. Any damage caused by reason of connecting these products to supply line pres
sures lower than 20 PSIG or higher than 105 PSIG is not covered by warranty.
7. Check stream height from bubbler. Stream height is factory set at 35 PSI. If supply pressure varies greatly from this, turn
adjustment screw on the regulator (Item 5). Clockwise adjustment will raise stream height and counter-clockwise will lower stream
height. For best adjustment stream should hit basin approximately 6-1/2" (165mm) from bubbler.
TROUBLESHOOTINGANDMAINTENANCE
1. Orifice Assy: Mineral deposits on orifice can cause water flow to spurt or not regulate. Mineral deposits may be removed from
orifice with a small round file not over 1/8" diameter or a small diameter wire. CAUTION: Do not file or cut orifice materials.
IMPORTANT
ALLSERVICETOBEPERFORMEDBYANAUTHORIZED SERVICE PERSON
IMPORTANT! INSTALLER PLEASE NOTE.
THEGROUNDINGOF ELECTRICALEQUIPMENTSUCHAS TELEPHONE,COMPUTERS,ETC.TO
WATER LINES ISACOMMONPROCEDURE.THISGROUNDINGMAYBEINTHE BUILDING OR MAY
OCCURAWAYFROMTHEBUILDING.THISGROUNDINGCANCAUSEELECTRICALFEEDBACKINTOA
FOUNTAIN, CREATINGANELECTROLYSISWHICHCAUSESAMETALLICTASTE ORANINCREASEIN
THEMETALCONTENTOFTHE WATER.THISCONDITIONISAVOIDABLEBYUSINGTHEPROPER
MATERIALSASINDICATED.ANYDRAINFITTINGSPROVIDEDBYTHEINSTALLER SHOULDBEMADE
OFPLASTICTOELECTRICALLYISOLATETHEFOUNTAIN FROMTHE BUILDINGPLUMBINGSYSTEM.
Installer

97256C Rev. A 4/05
EDF14C
PAGE 2
LEGEND
A= RECOMMENDED WATER SUPPLY LOCATION 3/8 O.D.TUBE CONNECT
STUBBED 1" (25mm)FROM WALL SHUT OFF BY OTHERS
B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4" O.D. DRAIN
STUBBED 6-5/8" (168mm) FROM WALL
C = 1-1/4" TRAP FURNISHED
D = 1/4" (6mm) DIA. HOLES FOR SECURING FOUNTAIN TO WALL
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
ELKAY MANUFACTURING COMPANY • 2222 CAMDEN COURT • OAK BROOK, IL 60523 • 630.574.8484
PARTNO.ITEMNO. PARTSLIST
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
NS
DESCRIPTION
BUBBLERASSY
COVERNUT
BUTTON
RETAININGNUT
REGULATOR
O-RING
ORIFICEFITTING
ORIFICEFLOWSTRAIGHTNER
BUBBLERBODY
NIPPLE
GASKET
SCREEN
WASHER
LOCKNUT - 3/8 - 18
FOUNTAINBODY
DRAIN
LK142
40089C
40048C
10031C
61313C
A52919
40319C
50314C
45675C
A54800
100322740560
A54888
72460042
70012C
28577C
LK464
1
FIG. 2
FLOORLINE
FIG. 1
3
4
6, 7, 8
10,11
12
5
9
13
14
2
PRINTED IN U.S.A
