Elkay BLUBAR COUNTERTOP DSBCF180K Manual

Table of Contents
Declaraon of Conformity 2
Associaon 2
Recommendaons for Safeguarding the
Environment 3
Explanaon of Warning/Safety Icons 3
Introducon 4
Components Guide 5
Product Specicaons 6
Before You Begin –
Requirements for Installaon 7
Mounng Dimensions 7
Operang Environment 8
Water 8
Electrical 8
Tools You Will Need 9
Unpacking the Kit 9
What’s in the Kit 10
Installing the Machine 11
Operang the Touch Control
Keypad Fontemagna Compact Only 16
Programming the Touch Control
Keypad Fontemagna Compact Only 18
Roune Maintenance 19
Troubleshoong 22
Replacement Parts 25
NOTICE: Read the instrucons in this manual and retain for future reference.
Installaon and
Maintenance
Manual

2
Blubar Countertop and Fontemagna Compact
Installa on and Maintenance Manual
Declara on of Conformity
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso 032 c
Materials compliant for contact with drinking water
This unit is intended for the dispensing of drinking water, and so the materials that enter into direct contact with
water meet the criteria for food-grade components pursuant to the current legisla on. In addi on, the unit is
manufactured in compliance with Italian Ministerial Decrees 174 of 04/06/2004 and 25 of 02/07/2012.
Electrical safety
This water cooler is designed, manufactured and marketed in compliance with:
the safety objec ves of the Low Voltage Direc ve 2006/95/EC;
the protec on requirements of the Electromagne c Compa bility Direc ve 2004/108/EC.
The electrical safety of the product is ensured only when it is properly connected to an effi cient, legally
compliant grounding circuit.
UL standard for safety of drinking water coolers, ANSI/UL 399, Issued: 2008/08/22, Ed: 7, Rev: 2013/10/18
CSA standard for refrigera on equipment, CSA C22.2 No. 120, Issued: 2013/03/01, Ed: 4
Associa on
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso 032 c
Interna onal Awards
2014 – BEST PROMOTION OF HEALTH AND HYDRATION
EUROPEAN AQUA AWARDS 2014, BUDAPEST
2013 – BEST PRODUCT INNOVATION
EUROPEAN AQUA AWARDS 2013, BERLIN
2012 – BEST ENVIRONMENTALLY FRIENDLY PRACTICE
EUROPEAN AQUA AWARDS 2012, ISTANBUL
2011 – BEST PRODUCT DESIGN/INNOVATION
EUROPEAN AQUA AWARDS 2011, ODESSA
2010 – BEST ENVIRONMENTALLY FRIENDLY PRACTICE
EUROPEAN AQUA AWARD 2010, PRAGUE

3
1000002474 (Rev. D - 04/2016)
Recommenda ons for Safeguarding the Environment
Packaging materials
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso032 c
The packaging materials are 100% recyclable. Please follow the local guidelines on waste disposal.
For safety reasons keep the packaging material out of the reach and sight of children.
Scrappage
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso 032 c
The Fontemagna Compact and Blubar Countertop water coolers are made using recyclable material.
These units are marked in compliance with European Direc ve 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE). By ensuring that the product is scrapped correctly, you will help to
prevent poten al nega ve consequences for the environment and for health. This symbol indicates
that the product should not be treated as domes c waste but should be taken to a dedicated recycling
center for electrical and electronic equipment. Immediately prior to scrapping, cut o the power cable.
For more informa on on the treatment, recovery and recycling of this product, please contact
the appropriate local offi ce, the waste disposal service or the reseller from which the product was
purchased.
These products contain no CFCs or HFCs, which contribute to global warming.
They are the  rst water coolers on the American market to use natural refrigerant.
The refrigera ng system is  lled with R134a: a natural gas that does not contribute to global warming
and that allows for substan al Energy Savings.
Explana on of Warning/Safety Icons
NOTICE: Indicates an instruc on which, if not followed, could result in damage to product or property
or poor product performance.
CAUTION: Indicates an instruc on which, if not followed, could result in minor or moderate injury.
WARNING: Indicates an instruc on which, if not followed, could result in serious injury or death.

4
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
Introducon
The Fontemagna Compact and Blubar Countertop coolers bring contemporary style and state-of-the-art
technology to commercial water dispensers. Fontemagna Compact combines precise pushbuon control with
a sleek, minimalist design, while Blubar Countertop puts a modern spin on the tradional appeal of the hand-
operated tap.
 Mulple dispensing opons: cold sll water, cold sparkling water, and room-temperature sll water
(Fontemagna Compact only)
 Natural materials throughout: stainless steel, aluminum, Plexiglas
 Internal components made enrely of stainless steel
 Dual cooling coil – one for cold water and one for sparkling water, with the opon for simultaneous dispensing
 High-insulaon ice bank ensures a high output of cold water, sll and sparkling
Fontemagna Compact
 Preprogrammed quanes of water to minimize overow and waste
 Electronic keypad with glass cover, easy to use and hygienic, with touch control commands
 Self-diagnosis and alarm system responds to lile or no water ow, an accidental water leak or the need for
CO2 cylinder replacement
 Energy Saving command: when selected, this feature enables standby funconality of the unit, with
consumpon reduced by 75% compared to full funconality
NOTICE: Due to rigorous tesng, product may reasonably be expected to contain traces of sanizing
soluon.

5
1000002474 (Rev. D - 04/2016)
Components Guide
Removable top cover
Lockable top cover
Touch Control
keypad
Tap – sparkling water
Tap – sll water
Drip tray
Drip tray
Ice bank inlet
Thermostat
Ice bank overow
Water inlet
Water inlet
CO2inlet
CO2inlet
Power cord
Power switch
LED alarms
No/low H20 pressure
No/low CO2 pressure
Machine stopped
Dispensing buons –
small serving
large serving
Power
buon
Energy
Saving
buon
Cold
sparkling
dispenser
Room-temperature
sll dispenser
Cold sll
dispenser
Blubar Countertop Fontemagna Compact
Fontemagna Compact
Touch Control keypad
Power cord

6
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
Product Specicaons
Specicaon Blubar Countertop Fontemagna Compact
Cooling capacity gal/h (lt/h) 20 (80) 20 (80)
Connuous supply gal (lt) 12 (45) 12 (45)
Cold water temperature 37.4°F – 50°F
(3°C – 10°C)
37.4°F – 50°F
(3°C – 10°C)
Ice bank capacity gal (lt) 3.7 (14) 3.7 (14)
Ice bank lb (kg) 11 (5) 11 (5)
Cooling technology ICE BANK single stainless steel coil ICE BANK single stainless steel coil
Condensaon Forced venlaon (fan) Forced venlaon (fan)
Adjustable thermostat Yes Yes
Refrigerant gas R134a R134a
Pump Professional booster pump Professional booster pump
Inlet water pipe ø 3/8" ø 3/8"
Power 115V - 60Hz 115V - 60Hz
Power consumpon 330W - 3.2A 330W - 3.2A
Working room temperature Min 41°F – Max 107.6°F
(Min 5°C – Max 42°C)
Min 41°F – Max 107.6°F
(Min 5°C – Max 42°C)
UNIT WEIGHT lb (kg) 77
(35)
82
(45)
SHIPPING WEIGHT lb (kg) 84
(38)
110
(50)
Dimensions W x D x H
in (mm) 14.2 x 22.6 x 22.4
(360 x 575 x 570)
18.1 x 23.2 x 20.1
(460 x 590 x 510)
Dispensing area height in (mm) 12.6 (320) 13.38 (310)
Packaging dimensions
W x D x H in (mm)
18.1 x 24.8 x 26.0
(460 x 630 x 660)
21.2 x 27.6 x 26.8
(540 x 700 x 680)
Dispensing Supply opon (sparkling, cold water) Supply opon (sparkling, cold and room
temperature water) with customizable
poron control system
Mechanical outlet taps HQ stainless steel
Push buons Electronic touch pad board
Energy Saving device Included, dedicated push buons
Display Alarms No/low water, No/low CO2, leakage
Materials All robust stainless steel parts,
Plexiglas front panel
All robust stainless steel and aluminum parts

7
1000002474 (Rev. D - 04/2016)
Before You Begin – Requirements for Installaon
Mounng Dimensions
Width
22.2"(564mm)
Width
26.1"(663mm)
Depth
26.6" (678mm)
Depth
27.2" (691mm)
Height
34.4" (874mm)
Height
34.4" (874mm)
Height
28" (711mm)
Height
12.75"
(324mm)
Depth
3.88" (99mm)
Diameter
8" (203mm)
Width
3.25" (83mm)
Footprint:
14.2” wide x 22.6" deep
363mm x 574mm
Footprint:
18.1" wide x 23.2" deep
460mm x 589mm
Blubar Countertop
Over counter (includes 4" clearance on sides and back)
Under counter
Water lter
CO2 cylinder (typical, 20 pound)
Fontemagna Compact

8
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
Operang Environment
 Install the machine in a clean, dry, well-venlated room. It is designed to funcon correctly in environments
with a temperature of 16°C to 32°C – Climac Class N, (between 61°F and 90°F).
 Check that the water cooler is level, that it is on a surface that can support its weight and in an environment
suitable for its size and use.
 Do not place the machine near a source of heat.
 To guarantee adequate venlaon, leave at least 4" (100 mm) of space around the unit.
 Take care not to damage the cooling uid circuit. It is essenal to ensure that the tubes of the refrigerant
circuit are not damaged.
 The unit is not intended for use by children.
 Keep the areas surrounding the unit dry to avoid the risk of people slipping.
 The unit must not be cleaned with a water jet.
Water
 Always connect the water cooler to a water main that supplies drinking water only.
 Use of 3/8" diameter connecons is recommended.
 Turn o the main water inlet tap if the unit is not to be used for a long period.
Electrical
 Check that the voltage shown on the serial number plate corresponds to the voltage being
supplied at the installaon site.
 Do not use extension cables or mulple-power sockets. The machine must be located
close enough to a standard power socket that the supplied power cable reaches without
stretching.
 Aer installaon, check that the machine is not standing on its power supply cable.
 Ensure that it is possible to disconnect the power supply either by removing the plug or via a two-pole circuit
breaker placed upstream of the plug.
 Before any maintenance or cleaning operaon is carried out, remove the plug from the socket or disconnect
the power supply.
 If the power cable is damaged, it must be replaced by the manufacturer, by its technical support service or by
a qualied technician.
 Do not posion other electrical equipment in the immediate vicinity of the water cooler.

9
1000002474 (Rev. D - 04/2016)
Tools You Will Need
Unpacking the Kit
Remove the front panel (labeled FRONT) and cover of the
wooden packing case.
Remove the cardboard box and the internal protecve
packaging by sliding them up and over the top.
Once you have unpacked the machine, check all components
to ensure that they are not damaged. Contact the carrier
immediately if there has been any damage during shipping.
NOTICE: Ensure that your machine is installed by a
qualied technician in compliance with the
manufacturer’s instrucons and the local safety
guidelines.
NOTICE: Only qualied technicians should access the internal components of your machine, other than
to ll the ice bank.
(2) 8" adjustable wrenches
(1) 10" adjustable pliers
(1) 12" adjustable wrench
(1) universal screwdriver
(1) 12" pipe cuer
(1) wire cung pliers

10
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
What’s in the Kit
NOTICE: CO2 source is not included and must be supplied separately.
(1) Blubar Countertop or Fontemagna
Compact water cooler
(1) CO2
regulator
(1) external
water lter
Top panel
keys
(2) 3/8"–quick
connect connector
(1) supply hose 1/2 ips x 3/8
tube x 12” long
(1) water
shuto valve
(1) water
pressure
regulator
(1) 10' coil CO2
tubing 1/4” OD
(natural)
(1) 3/8” x 1/4”
quick connect
connector
(1) 4” piece of
1/4” OD tubing
(1) 10' coil
water tubing
3/8” OD (blue)
PLUS

11
1000002474 (Rev. D - 04/2016)
Installing the Machine
CAUTION: Wear safety gloves when handling the machine. Metal edges are sharp, and touching them
could result in minor or moderate injury.
CAUTION: Machine weighs more than 100 lbs (45 kg) when the ice bank is lled. Liing without proper
support could result in minor or moderate injury.
1. Install external water lter and CO2 cylinder.
1. Use (2) Phillips head screws to mount bracket to under-counter wall.
2. User (4) Phillips head screws to mount lter head to bracket.
3. Remove cap from lter. Insert lter into lter head and turn clockwise (right) unl it stops.
NOTICE: Install CO2 source per manufacturer’s recommendaons.
1. 2. 3.

12
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
2. Cut, size and connect water and CO2 piping to t your installaon.
NOTICE: The water pressure entering the machine must be between 14.5 psi (0.10 MPa) minimum and
51 psi (0.35 MPa) maximum. If the inlet water pressure is higher than 51 psi, the water pressure regulator
supplied must be used.
NOTICE: An incoming ow rate of >1.0 gallon/minute is recommended for opmal quality of sparkling
water.
NOTICE: Check all input piping and connecons for leaks before connecng to the machine.
Water source:
threaded
ng
Water
source: open
3/8" pipe
Water lter
3/8"–quick
connect
adapter
3/8"–quick
connect
adapter
Water
shuto
valve
Water pressure
regulator
Water
piping cut
to size
3/8” water
tubing cut
to size
Water piping
cut to size
To water
cooler
Short
3/8"– 3/8" pipe
Using the quick connect ngs
To connect:
1. Make clean, 90° cut to
piping end.
2. Push piping straight into
ng unl it stops.
3. Pull back to check that
connecon is secture.
To disconnect:
1. Press in the end tab.
2. Pull piping out.
3. Release tab.
1/4” Gas tubing
cut to size
Regulator
CO2source
3/8” x 3/8”
quick connect
3/8” x 1/4”
quick connect
connector
1/4” tubing
4” long
Recommended total
lenght 6 feet
Use one of two
connecon
methods

13
1000002474 (Rev. D - 04/2016)
3. Fill the ice bank in your machine.
Blubar Countertop
1. Insert piping from water supply (A) into ice bank
inlet quick connect (B).
2. Fill slowly unl water reaches the maximum ll
line on the overow tube on the back side of the
machine (C).
3. If water exceeds this level, water will ow from
the drip tray on the front.
4. If you have to move the unit, remember to empty
the ice bank rst.
5. Turn o water supply and remove piping from ice
bank inlet.
Fontemagna Compact
1. Unlock and open the top cover using the
supplied key (A).
E
2. Look for the bright yellow label with the arrow
(B), which points to the ice bank inlet hole (C).
3. Insert piping from water supply (D) directly into
the ice bank inlet.
BC
D
4. Fill slowly unl water appears in drip tray (E).
5. If you have to move the unit, remember to empty
the ice bank rst.
6. Turn o water supply and remove piping from ice
bank inlet.

14
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
4. Place the machine in its operang locaon.
NOTICE: Ensure machine remains level while being lied into place to prevent spillage from ice bank.
5. Connect external water and CO2 piping.
6. Plug the machine into the wall socket and turn it on.
1. Connect the power cable to the nearest socket.
2. On the Blubar Countertop, ip the power switch at the rear of the machine to the "I" posion. On the
Fontemagna Compact, press the power buon at the top right of the Touch Control keypad. Refer to
Components Guide on page 5.
NOTICE: Chilling of the ice bank begins immediately when unit is turned on. Complete chilling of ice
bank will require 1-3 hours. The machine should not be used as a water dispenser unl chilling is complete.
Water input
CO2 input
Blubar Countertop Fontemagna Compact
Water input
Drip tray
waste water CO2 input

15
1000002474 (Rev. D - 04/2016)
7. Purge the water lines.
1. Place receptacle beneath tap to catch dispensed water. Discard water as necessary.
2. Allow water to run connuously unl ow is clear of air.
3. Repeat for all taps.
NOTICE: The "No/low CO2" error LED will ash on the Fontemagna Compact when dispensing begins. This is
correct, as the CO2 connecon has not been acvated yet. This alarm can be ignored during this step.
8. Open the CO2 valve.
4. Using a screwdriver slowly turn valve screw counterclockwise
(le) to open valve.
5. Connue unl pressure reads 55 to 60 psi max.
9. Re-purge the line for sparkling water.
NOTICE: The water will ow at at rst, then gradually
become more sparkling as the line is purged of sll water.
NOTICE: If the "No/low CO2" error LED on the Fontemagna Compact ashes during this step, there is a
problem with the connecon to the CO2 source. Check all components in the gas system before
proceeding.
10. Allow machine to complete inial chilldown.
NOTICE: Complete chilling of ice bank will require 1-3 hours. The machine should not be used as a water
dispenser unl chilling is complete.
Open both
taps Press and hold
dispensing buon
Blubar Countertop Fontemagna Compact

16
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
Operang the Touch Control Keypad
Fontemagna Compact Only
To turn on the machine
Press the power buon.
Note: The power buon and dispensing buon LEDs turn on.
To turn o the machine
Press the power buon a second me.
Note: The power buon and dispensing buon LEDs turn o.
To dispense a small, single serving size of your
water selecon
Press the upper buon for that dispenser.
Note: The buon LED turns o while the machine is dispensing.
To dispense a large serving size of your water
selecon
Press the lower buon for that dispenser.
Note: The buon LED turns o while the machine is dispensing.
To stop dispensing before your serving is complete
Press the buon a second me.
Note: The water ow stops and the LED turns on.
To turn on Energy Saving mode
Press and release the Energy Saving buon.
Note: The LED on the Energy Saving buon turns on and all
other LEDs turn o.
NOTICE: E nergy Saving mode slows down the acvaon
me of the compression. This mode should only be used
when the machine will not be operated, such as when
the business has closed for the day.
To turn o Energy Saving mode
Press the Energy Saving buon or any of the dispensing buons.
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER

17
1000002474 (Rev. D - 04/2016)
To turn on Key Lock
Press and hold the Energy Saving buon for more than
4 seconds, unl the machine beeps once.
Note: All of the buon LEDs ash.
NOTICE: Key lock deacvates all the buons on the
keypad. It should be acvated before the keypad is
cleaned.
To turn o Key Lock
Press and hold the Energy Saving buon for more than
4 seconds, unl the buon LEDs stop ashing.
Note: All LEDs return to their default appearance.
To reset an alarm
Turn the machine o, then on again.
NOTICE: Alarms indicate a problem with the water, CO2,
or electrical system of the machine. Do not operate the
machine unl the problem has been located and xed.
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER

18
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
Programming the Touch Control Keypad
Fontemagna Compact Only
By default, the Fontemagna Compact dispenses a single 7 oz (0.2 liter) serving when the upper dispensing buon
is pressed, and a 34 oz (1 liter) serving when the lower dispensing buon is pressed. You can change the default
serving size by entering Programming Mode.
To enter programming mode
Press and hold the Energy Saving buon, plus the two Room
Temperature dispensing buons, unl the machine beeps
three mes.
Note: The LEDs in all dispensing buons ash to indicate they
are ready to be programmed.
To reset the serving size for a buon
1. Place a correctly sized cup or bole beneath the dispenser.
2. Press the buon to start dispensing. Water ows and the LED for that buon shuts o.
NOTICE: Water will connue to ow unl you press the buon a second me.
3. When water has reached to desired level, press the buon a second me to stop dispensing. The water ow
stops and the LED for that buons turns back on.
NOTICE: The maximum serving size you can set is 101 oz (3 liters). This volume would require a
65-second dispensing session.
4. Repeat these steps for any other buons you wish to reset.
To reset all buons to factory defaults while in
programming mode
Press the Energy Saving buon.
To exit programming mode
Press and hold the Energy Saving buon, plus the two Room
Temperature dispensing buons, unl the machine beeps
three mes.
Note: All LEDs return to their default appearance.
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER
SPARKLING
H2O
CO2
STOP
MESSAGE
ROOM
TEMPERATURE COLD
ENERGY
SAVING
POWER

19
1000002474 (Rev. D - 04/2016)
Roune Maintenance
Daily
 Clean all external surfaces of the machine, the drip tray and the dispensing nozzles.
NOTICE: It is recommended that all external components of the product be cleaned daily.
It is recommended that you use dish soap, warm water and a clean, so cloth to clean the product.
DO NOT USE THE FOLLOWING PRODUCTS:
Do not use ... chlorine bleach soluons on the product. Chlorides found in most soaps, detergents, bleaches and
cleaners can aack stainless steel. These products can cause surface-ping.
Do not use ... metal bers to clean the product. Metal bers have a tendency to disintegrate and release small
metal parcles that are embedded in the surface. Metal parcles oxidize and give the impression that the
surface of the product is rusng.
Do not use ... abrasive cleaners or abrasive pads, as these will scratch the surface of the product.
Do not use ... a water jet.
 The Plexiglas facing on the Blubar Countertop may be cleaned with mul-use cleaners or dedicated glass
cleaners.
 To remove limescale, use a slightly acidic product (e.g. citric acid) that has been heavily diluted – excessive
acidity may damage the surface of the steel.
 To clean the drip tray, use a diluted limescale cleaner such as citric acid. The drip tray may also be washed in
the dishwasher.
 Before cleaning the keypad, turn on Key Lock to prevent accidentally dispensing water. Refer to To turn on Key
Lock on page 17.
Weekly
 Use a vacuum to clean out all vents.

20
Blubar Countertop and Fontemagna Compact
Installaon and Maintenance Manual
Twice a Year
 Replace the water lter aer 6000 gallons or 6 months, or earlier depending on water quality.
NOTICE: The lter head has an internal shuto valve that stops the ow of water when the lter is
removed. It is not necessary to shut o the water supply.
1. Turn used lter counterclockwise (to the le) 1/4 turn to remove from lter head. Pull lter away from head
and remove.
2. Remove the cap from the new lter. Place the cap on the used lter to seal it.
3. Insert the new lter into the lter head and turn the lter clockwise (to the right) unl it stops.
4. Place a receptacle under the sll water dispenser and dispense connuously for a minimum of two gallons to
purge air and ne carbon parcles from lter.
 Sanize the machine
NOTICE: This operaon must be carried out by your ELKAY reseller or by a qualied technician.
When required
 Replace the UV lamp (Fontemagna Compact only)
CAUTION: The light emied by the ultra-violet lamp may cause serious burns to the eyes and skin.
Disconnect the electrical source of supply of the UV radiaon before opening the machine.
1. Disconnect the unit from its electrical source.
2. Once the unit is shut down, open the top panel with the key provided in the kit.
3. Loosen the screws of each dispensing valve in order to remove the UV lamps from their dedicated slot.
Disconnect the electrical connector of the UV OUT lamp. Pull the lamp removing it from its ng holder —
handling it carefully.
4. Insert the new lamp and reconnect the connector — handling it carefully.
5. Repeat the procedure for all the dispensing valves.
6. The used UV lamps can be disposed at your local waste management site.
NOTICE: This operaon must be carried out by your ELKAY reseller or by a qualied technician.
NOTICE: For the replacement of UV OUT pipe is not necessary to turn water o.
