Elmo P100HD User manual

INSTRUCTION MANUAL
VISUAL PRESENTER
P100HD
Please read this instruction manual carefully before using this product and
keep it for future reference
cev.fr

11
CONTENTS
IMPORTANT SAFEGUARDS ................................................................................................................................2
BEFORE YOU USE................................................................................................................................................7
CONTENTS.......................................................................................................................................................... 11
1 BUNDLED ITEMS...........................................................................................................................................13
2 BASIC OPERATIONS ....................................................................................................................................14
2-1 Document Camera.........................................................................................................................................................14
■Part Names...................................................................................................................................................................14
■Touch panel..................................................................................................................................................................15
■Rear panel and cable connection.................................................................................................................................16
■Side panel.....................................................................................................................................................................20
■Moving Parts of the Document Camera.......................................................................................................................21
2-2 Supplied Accessories.....................................................................................................................................................22
■Remote Control.............................................................................................................................................................22
■Remote Control Strap...................................................................................................................................................23
■Image Mate CD-ROM...................................................................................................................................................23
■Preparation ...................................................................................................................................................................24
2-3 Shooting Images ..........................................................................................................................................................27
■Setting up the main unit................................................................................................................................................27
■Turning the power ON/OFF..........................................................................................................................................28
■Operating the touch panel............................................................................................................................................29
■Adjusting the size..........................................................................................................................................................31
■Auto focus（AF）.........................................................................................................................................................31
■Adjusting the brightness...............................................................................................................................................32
■Turning the illumination ON/OFF..................................................................................................................................34
■Image selection.............................................................................................................................................................35
■Details of Each Function...............................................................................................................................................38
■Icon descriptions...........................................................................................................................................................45
3 ADVANCED OPERATIONS............................................................................................................................62
3-1 Using an SD card/USBflash drive .................................................................................................................................62
■Saving images ..............................................................................................................................................................64
■Displaying the stored data............................................................................................................................................69
3-2 Outputting a different image to RGB OUT and HDMI OUT...........................................................................................78
3-3 Saving data stored on an SD card to PC via USB cable...............................................................................................79
3-4 Presentation using a USB-connected PC with the supplied software...........................................................................81
3-5 Displaying the Video Image through Network Connection ............................................................................................83
3-6 Using [MIC IN] and [AUDIO IN]......................................................................................................................................88
3-7 Using the ELMO Wireless Slate/Tablet (CRA-1) with the equipment............................................................................89
■Connecting the ELMO Wireless Slate/Tablet (CRA-1).................................................................................................89
■Basic operations...........................................................................................................................................................90
■Selecting how to use the pen tablet from the tablet menu...........................................................................................92

12
■Writing to camera images.............................................................................................................................................93
■Using as a whiteboard..................................................................................................................................................97
■Using the SD card.........................................................................................................................................................99
3-8 Shooting off the stage..................................................................................................................................................105
3-9 About RS-232C............................................................................................................................................................106
4 TROUBLE SHOOTING.................................................................................................................................107
4-1 Symptoms and Confirmation........................................................................................................................................107
5 SPECIFICATIONS ........................................................................................................................................ 111
5-1 General.........................................................................................................................................................................111
5-2 Main Camera................................................................................................................................................................112
5-3 Illumination Device.......................................................................................................................................................113
5-4 Trademarks and License..............................................................................................................................................114

13
1 1 BUNDLED ITEMS
The items below are included with this product. If any item is missing, contact the
dealer from
whom you purchased this product.
USB cable
(for Connecting to PC)
AC adapter AC cord
AAA batteries
(for Remote control)
Image Mate/Instruction
Manual CD-ROM
LAN cable
Ferrite core
(for Mic IN /
AUDIO OUT cable)
Warranty
(US/JAPAN Only )
IMPORTANT
SAFEGUARDS
Image Mate
Installation Manual
P21
P23
P22
P17
P18
P27 P27
P22
P23
P18
P20
Document camera
Strap
(for Remote control) Remote control
RGB cable
P18

14
2 2 BASIC OPERATIONS
2-1 Document Camera
■Part Names
Operation of the main unit:
Name
①Upper light
②Remote control sensor
③Side panel
④Built-in mic
⑤Touch panel
⑥Main switch
⑦Rear panel
⑧Base light
P21
P34
P22
P20
P29
P28
P16
P34
Front
⑧⑤
①
②
④
③⑥⑦
②
Rear/Side

15
■Touch panel
Name Function
①Touch panel Output image and icons are displayed. With these
icons, various settings can be made.
CAUTION
•Do not press the panel strongly by finger or sharp objects.
This can cause damage or malfunction.
•To prevent damage during transport, a protection sheet has been put on the touch
panel screen. Please be sure to remove it before use.
The touch panel is made of glass. Pay attention to the followings to avoid
glass breakage and injury.
•Do not rub or press the panel with a sharp object such as a knife.
•Do not press the panel strongly by finger or do not apply weight to the panel.
•Do not rub the panel with a hard object.
•Do not hit the panel with a hard object or do not drop it onto the panel.
•Do not put an object on the panel.
•Gently wipe the surface with a soft cloth to remove dirt.
Pay attention to the followings in order to maintain the performance of the
touch panel.
•Do not stick adhesive tape on the panel.
•A protection sheet is attached to the surface of the touch panel to avoid
scratches during transportation. Remove the sheet gently before use.
P29

16
■Rear panel and cable connection
Name Function
①HDMI IN 1
HDMI IN 2
To input HDMI images and audio. (HDMI cable is not supplied
with the product.)
②RGB IN 1
RGB IN 2
To input RGB image. (RGB cable is supplied with this product.)
In the stand-by mode, the image input to the [RGB IN 1] terminal
is output from the [RGB OUT] terminal.
③AUDIO IN 1
AUDIO IN 2
To input audio line .(An audio cable is not supplied with this
product.)
④Resolution
To change the display resolution of output terminal.
Select the display resolution with the switch.
⑤Ethernet terminal
[100BASE/10BASE]
To enable the image transfer or the main unit control over the
LAN. (LAN cable is supplied with this product.)
Resolution Left
switch
Right
switch
1080P（1920 × 1080）
720P（1280 × 720）
SXGA（1280 × 1024）
WXGA（1280 × 800）
XGA（1024 × 768）
⑩⑪⑨⑧⑦⑥⑤
④③②③②
①

17
Name Function
⑥USB To connect to a PC. (USB cable is supplied with this product.)
⑦RS-232C To control the unit from a PC through an RS-232C cable.
(RS-232C cable is not supplied with this product.)
⑧AUDIO OUT To output audio line. (Audio cable is not supplied with this product.)
⑨RGB OUT To output analog RGB images. (Analog RGB cable is supplied with
this product.)
⑩HDMI OUT To output digital images. (HDMI cable is not supplied with this
product.)
⑪DC IN 12V Plug-in for the AC adapter. (A cable is supplied with this product.)
①To connect the product to a device with an HDMI output terminal.
Connect a commercially available HDMI cable to the [HDMI IN] terminal on the rear panel.
②To connect the product to a device with an analog RGB output terminal.
Connect the RGB cable to the [RGB IN] terminal on the rear panel.
Only 1 RGB cable is supplied with the product.
■Specifications of the [RGB IN] terminal
Signal allocation
N o t e
•Cable must conform to the HDMI standard.
•Elmo does not guarantee operation for all HDMI-compatible monitors.
DSUB 15P shrink terminal
Video signal Analog 0.7V (p-p) 75Ω terminated
Horizontal synchronized signal TTL level (Positive/negative polarity)
Vertical synchronized signal TTL level (Positive/negative polarity)

18
Pin No. Name Pin No. Name Pin No. Name
1 Video signal (Red) ６GND (Red) １１ GND
2 Video signal (Green) ７GND (Green) １２ N.C
3 Video signal (Blue) ８GND (Blue) １３ Horizontal
synchronized signal
4 N.C ９N.C １４ Vertical
synchronized signal
5 GND １０ GND １５ N.C
③To connect the unit to a device (audio amplifier etc) with an audio line output
terminal.
Connect a commercially available audio cable to the [AUDIO IN] terminal on the rear panel.
④To switch the output image type.
Change the output image type.
⑤To connect the unit to a device with Ethernet terminal.
Connect the supplied LAN cable to the [Ethernet terminal] terminal on the rear panel.
Explanation of the Ethernet terminal LED
⑥To connect a PC with the USB cable.
Connect the supplied USB cable to the [USB] terminal on the rear panel.
⑦To connect the unit to a device with an RS-232C port.
The unit can be controlled from a PC through an RS-232C cable by using [RS-232C] terminal on
the rear panel.
⑧To connect the unit to a device (speaker with amplifier etc) with an audio line
input terminal.
Connect a commercially available audio cable to the [AUDIO OUT] terminal on the rear panel
after looping the audio cable 2 times around the ferrite core that is supplied with this product.
⑨To connect the unit to a device with an analog RGB input terminal.
Connect the RGB cable to the [RGB OUT] terminal on the rear panel.
Only 1 RGB cable is supplied with the product.
Orange…Blinking: Access
Green … ON: Link OK

19
⑩To connect the unit to a device with an HDMI input terminal.
Connect a commercially available HDMI cable to the [HDMI OUT] terminal on the rear
panel.
⑪To connect the AC adapter.
Before inserting the AC adapter in an outlet, connect the DC plug of the supplied AC adapter to
the [DC IN 12V] terminal on the rear panel.
N o t e
N o t e
• If the displayed image is off-center, adjustment of the horizontal and vertical position should be
made from the connected device.
• In some cases, vertical stripes may appear on the display device. This can be reduced by
adjusting the “clock phase” function of the connected device.
• When using a PC with external output mode switching, tap [ (Signal select)] > []
on the touch panel after setting the PC to the external output mode.
•When selecting the image in [ Signal select (Normal)], output same image (resolution) to
[RGB OUT] and [HDMI OUT].
• When the HDMI monitor is connected, the output image (resolution) is automatically changed
based on information from the connected monitor. Even if [RGB OUT] is selected, it is not
reflected.
• We recommend that you change the output image (resolution) with the power supply turned off
(standby status).
We do not guarantee proper operation when the output image (resolution) was changed in any
other condition than specified above.
•We recommend using a USB 2.0 compliant USB cable.
• If you plug into the USB cable with the power on, the PC may not recognize the device.
• Depending on the PC’s USB environment or the peripheral equipment using the USB 2.0
compliant cable, image transfer may be disrupted.
• Operation is not guaranteed for all environments.
• Please use the monitor corresponding to the input of the image (resolution) or 720p or more.
It will not operate with a cable that doesn’t conform to the HDMI standard.
• Elmo does not guarantee operation for all HDMI-compatible monitors.

20
■Side panel
Mark Function
①To insert an SD card (commercially available).
Push the card again to remove the SD card.
②To connect a wireless pen Tablet (commercially available) or a
USB flash drive (commercially available).
③MIC IN
To connect an audio line-output device after looping the cable 3 times
around the ferrite core that is supplied with this product. Audio input is a
dual purpose port (microphone/line-in). When using a microphone, make
sure to connect a commercially available electret condenser microphone.
④MIC OUT To output audio signal input to the “MIC IN” terminal. (An audio cable is not
supplied with this product.)
N o t e
• Connecting microphones other than electret condenser microphones (microphones for PCs
and so on) could cause a malfunction to occur.
P89
P62
①
②
③
④

21
■Moving Parts of the Document Camera
This unit can be moved as shown below.

22
2-2 Supplied Accessories
■Remote Control
Preparation of Remote Control
Remove the battery case cover at the back of the remote control and install 2 batteries. (TYPE
AAA)
Operation of the remote control
When a camera image is displayed
When data in an SD card/USB flash drive is displayed
Receiving signal from the remote control
Point the infrared light emitting part of the remote control at the infrared
sensor, and press the button of the desired function.
Receivable range
Distance: Within approx. 7m from the front of the infrared
sensor
Angle: Within 30° up, down, left, and right of the infrared
sensor
WARNING
Children may ingest small batteries;
always keep batteries safe and out
of reach.
If a battery is swallowed, consult
a doctor immediately as this could
result in asphyxiation or be an
obstacle to digestion, etc.
N o t e
The receivable range may be reduced when the main
unit is placed in direct sunlight, near an inverter
fluorescent light or in any other unfavorable conditions.
Depending on the light source conditions, the sensor
may fail to receive any infrared light. In such cases,
relocate the main unit or shield the light source.
P31
P62
Within 7m
sensor

23
■Remote Control Strap
The strap can be fastened to the remote control as shown below.
■Image Mate CD-ROM
The CD-ROM contains the software for connecting to a PC and the Instruction Manual. For
software installation, follow the instructions of the Image Mate Installation Manual.

24
■Preparation
Setting Up
①Release the camera column lock by turning the security lock knob.
②As shown in the right figure, hold the setup grip
and raise the camera column. At this time, the camera
head slides up in conjunction with the rise of the camera
column. The lamp column will also rise.
③If necessary, move the lamp column and the lamp head
to an appropriate position as shown in the right figure.
N o t e
When using a glossy paper, the document could reflect the
illumination to disable normal display. In this case, adjust the
lamp position to a position in which such reflection can be
avoided.
Setup grip
Locked
Unlock
③

25
(1) Fold the camera column on the stage. When the camera
column is folded in the storage position, the camera
position is initialized.
(2)Then, raise the camera column.
N o t e
If the camera column is pulled or pushed forcedly, the camera
might be pushed out of position, and the camera image might
be displaced from the display center. In this case, initialize the
camera position as follows:
Setup grip

26
STORING
①Return the lamp to the original position. Then,
hold the setup grip of the camera column and fold
the camera column. At this time, the camera head
slides down and the lamp column also folds.
②Lock the camera column and the lamp column by
turning the security lock.
N o t e
N o t e
N o t e
Turn OFF the power switch before the storing.
Do not force down the camera column
and the lamp column when folding them.
N o t e
Do not fold the camera column when the
close-up lens holder remains open, or the
close-up lens could be damaged.
When this camera system is not in use,
unplug the power cord and the AC adapter
from the plug socket.
Locked Unlocked
②
Close-up
lens holder

27
2-3 Shooting Images
■Setting up the main unit
Set up the main unit as shown in the figure above. Then connect the main unit to a projector or a
PC monitor, and turn on the power of the main unit.
Connecting the AC cord
Connect the AC cord and the AC adapter. Then connect the AC adapter to the [ DC IN 12V ]
terminal at the rear panel of the document camera, and insert the AC cord into an outlet.
AC adapter
AC cord
Camera
Power button
P28
P28
Cable
To main unit
AC adapter
AC cord
Connect
To wall outlet

28
Connecting the video cable
Connect the document camera to the display device with a video cable corresponding to the
display device.
■Turning the power ON/OFF
•Press the [ ] button on the main unit or the [ ]
button on the remote control to turn the power ON.
(After the [ ] button flashes blue, it is illuminated a few
seconds later.)
•Press the [ ] button on the main unit or the [ ]
button on the remote control to turn the power OFF.
You need to hold down the button for two seconds or more for
the button on the main unit.
(The LED of the [ ] button is illuminated in red.)
N o t e
CAUTION
Before connecting the main unit to other devices, be sure to turn OFF the
power for all of the devices.
Set the resolution corresponding to the display device.
•Do not operate this device while it is flashing.

29
■Operating the touch panel
You can control the unit with the touch panel..
Startup screen
The startup screen will appear on the touch panel
when the product is turned on.
Main menu
The main menu is displayed by tapping the menu
icon at the top right of the startup screen
How to operate the touch panel
①Tap
By tapping an icon on the touch panel,
you can select a function and operate.
