Elmo TT-02S User manual

Document Camera
Shenendehowa Central
Schools
Pieces, Parts and Setup
VGA Connection (Option 1)
The TT-02s Document Camera (“Elmo”) includes the following parts:
Always use the Elmo on a flat, stable surface. When carrying, be sure
to hold the lower part of the main unit. Never hold the Elmo by the
neck or camera head.
The Elmo must used in conjunction with an LCD projector. There are
several ways to connect the Elmo to a projector.
VGA cable: A VGA connection will provide slightly higher quality
than an RCA connection. However, it will require some cable
reconfiguration (plugging/unplugging). This option may work well when
the Elmo is in one location (e.g. library) for an extended period of time.
RCA cable: While an RCA connection may appear slightly
“jittery,” it is a very simple setup for teachers who have ceiling-
mounted projectors. This option is recommended if the Elmo will be
moved frequently between rooms with projectors. The Elmo does NOT
come with an RCA cable. However, every room with a ceiling-mounted
projector has an RCA cable coming down from the ceiling (RCA cables
can also be purchased in many lengths from places like Radio Shack).
If using with a computer already connected to a projector:
1. Unplug VGA cable going to the #2 end of the “Y” cable at the back
of the computer and plug it into the RGB Out port on the Elmo.
2. Use VGA cable supplied with Elmo to connect from the #2 end of
“Y” cable (on back of computer) to the RGB In port on the Elmo.
[If using with just a projector (no computer), simply connect a
VGA cable from the projector to the RGB Out port on the Elmo.]
3. Make sure both DIP switches are in the UP position.
4. Connect the power adapter to the Elmo and a power source.
DIP Switch Settings
Output
(DIP switch)
in UP position
RCA Connection (Option 2)
The second port from the right on the back of the Elmo is a DIP
switch. Different DIP switch positions are required, depending on
whether the Elmo is connected with a VGA or RCA cable. Use a small
screw driver or pen to carefully adjust the left switch according to the
diagrams below.
document
camera
anti-glare sheet
power adapter
usb cable (6’)
VGA cable (6.5’)
stage
OR
RGB/VGA
setting (default)
Video (RCA)
setting
This setup uses one RCA cable (not supplied with Elmo, but every new
projector installation has one). RCA cables usually have yellow, red and
white plugs on the end –only the yellow (video) plug is needed.
1. In classrooms with ceiling-mounted projectors, locate the yellow
RCA plug dangling from the ceiling near the computer. Plug it into
the yellow Video Out port on the back of the Elmo.
2. Make sure the left DIP switch is in the DOWN position.
3. Connect the power adapter to the Elmo and a power source.
Use COMPUTER
mode on
projector
remote.
RGB Out
RGB In
Output
(DIP Switch)
Use VIDEO
mode on
projector
remote.
Output
(DIP switch)
Put left switch
in DOWN position
Video Out
OPTIONAL USB CONNECTION IN VGA MODE: When a USB cable is
connected, images from the Elmo can be “scanned” and pasted into
documents. See reverse for details.

Functions and Settings
Function buttons on the base of the unit include:
Power: Turn Elmo ON or OFF (keep Power button
held down for 2-3 seconds to turn OFF).
PC: Display computer image on projector
(if using a VGA connection)
Camera: Display Elmo image on projector
Brightness: Brighten or darken the camera image
Save image to SD card
Switch output image to SD mode
Display Print or 3-D Objects…Endless Possibilities
After connecting the appropriate cables and turning the power ON,
place a print or 3-D object beneath the camera. Objects may be placed
on the stage or the stage may be removed. Use the zoom and auto-
focus features (and lamp, if needed) to project a clear, sharp image.
Tip: To reduce glare when displaying glossy objects, place the supplied
anti-glare sheet over the area where the glare is occurring.
Ways to use the Elmo for instruction in your classroom:
Read a book for all to see
Demonstrate with manipulatives (coins, blocks, letters), tools such as
a clock or ruler or any “show and tell” object.
Display and discuss artwork, primary source documents, newspapers,
maps, graphs, nutrition labels and other print or graphic objects.
Mark-up/edit writing pieces by overlaying with acetate.
Demonstrate a process such as a science dissection or art technique.
Rather than projecting onto a screen, tape a large sheet of paper to
the wall when displaying a graphic organizer, venn diagram or blank
map and have students filling in the necessary information.
RGB Out
RGB In
Video Out
Power
USB
SD Card Options
zoom dial
rotate dial to
zoom in or out
auto-focus
press once to focus automatically
lamp switch
illuminate objects
POWER
PC
CAMERA
BRIGHTNESS
Capture Images with TWAIN software
camera head
Camera head folds
down 90˚for storage
SD (Secure Digital) is a type of memory card commonly used in digital
cameras and other devices. If you choose to use the optional SD slot,
you must supply your own SD card (it does not come with the Elmo).
Display images from an SD card:
1. Insert an SD card into the slot on the side panel (push the card
again to remove it).
2. Press the button to display images saved on the SD card.
3. Press or to advance to the next image. Press or to
display the previous image.
The zoom feature can be used with SD card images.
Save images to an SD card:
1. Press the
button to switch to camera mode.
2. Press the
button to save whatever image is being displayed.
When the
mark lights up on the screen, the saving is in
process. When the mark goes out, the saving process is complete.
Capturing images is only possible when using a VGA connection.
To “scan” or capture images displayed via the Elmo you must first
install the Elmo TWAIN software. Use the Start menu to select My
Computer. Navigate to S:\Software\Elmo. Double-click the Setup
icon and follow the prompts.
After the software is installed, use the supplied USB cable to connect
the Elmo to the computer. Once the software is installed and the USB
cable is connected, images from the Elmo can be “scanned” into
programs such as Powerpoint or Word.
1. Open the program in which you wish to insert an image.
2. Use the Insert menu to select Picture… From
Scanner or Camera. Click the Custom Insert button.
3. Click the Still button to preview the image. When ready,
click the Transfer button and the image will be
transferred to the open document.
