Mounting of WS1 Style 1
Mounting of WS1 Style • Version: 30.06.2020 • Technical changes and errors excepted. • Elsner Elektronik GmbH • Sohlengrund 16 • 75395 Ostelsheim • Germany • www.elsner-elektronik.de • Technical Service: +49 (0) 7033 / 30945-250
Brief Instruction
Mounting of WS1 Style
Item numbers 60180-60189 (WS1 Style), 60194 (WS1 Style-4 PF)
Warning, mains voltage! National legal regulations are to be
observed. Installation, inspection, commissioning and
troubleshooting of the device must only be carried out by a
competent electrician.
Notes on wireless equipment
When planning facilities with devices that communicate via radio, adequate radio
reception must be guaranteed. The range will be limited by legal regulation and
structural circumstances. Avoid sources of interference and obstacles between re-
ceiver and transmitter, that could disturb the wireless communication. Those
would be for example:
• Walls and ceilings (especially concrete and solar protection glazing).
• Metal surfaces next to the wireless participants (e. g. aluminium
construction of a conservatory).
• Other wireless devices and powerful local transmitters (e.g. wireless
headphones), which transmit on the same frequency. Please maintain a
minimum distance of 30 cm between wireless transmitters for that reason.
Preparing the installation location
The device must only be installed and used in dry, interior
spaces. Avoid condensation.
The device is to be installed flush to the wall surface. When selecting an installation
location, please ensure that the measurement results of the integrated temperatu-
re/humidity sensor are affected as little as possible by external influences. Possible
sources of interference include:
• Direct sunlight
• Drafts from windows and doors
• Draft from ducts which lead from other rooms to the concealed box
• Warming or cooling of the building structure on which the device is
mounted, e.g. due to sunlight, heating or cold water pipes
• Connection lines which lead from warmer or colder areas to the device
Cut-out dimensions for concealed box:
W = 166 mm +1 -0 | H = 116 mm +1 -0 | D = 80 mm
An external antenna can be connected in order to improve wireless communicati-
ons. During installation, a conduit 50 cm in length should be placed beneath the
recessed housing, in which the external antenna can be mounted (antenna dimen-
sions approx. 565 x 8 x 5, L × W × H in mm):
Preparing for installation
Wall-fitting
Cavity wall fitting
Assembling the control unit with concealed box
During electrical installation, please introduce all connection cables into the con-
cealed box through the lower or upper side wall. In the process, keep the individual
connection wires short to prevent long reserve loops.
After connecting the cables screw the security covering onto the concealed box.
The security covering must be fixed before the control is put
into operation! It prevents contact with current-carrying parts
in the concealed box.
By adjusting the mounting screws, the display unit will rest flat on the wall later
and be held by the magnets safely.
Connect the flat ribbon cable to the display and place the display unit on the con-
cealed box. The magnets must be attracted by the mounting screws considerably
and the display unit must rest tightly on the concealed box.
Structure of the connector board WS1 Style
Structure of the connector board WS1 Style-PF
The manual with additional information about commissioning,
functions and use of the controls WS1 Style can be download-
ed from www.elsner-elektronik.de in the menu area "Service/
Downloads".
Conduit angled diagonally dow-
nwards (for cable access from
above or below)
Conduit angled vertically downwards (only
for cable access from above!)
concealed concealed
45°
cable
cable
box box
M16 conduit, 50 cm in length M16 conduit,
50 cm in length
The display unit is held by magnets. Re-
move the front part from the concealed
box.
Caution: The display is connected
with a flat-ribbon cable to the circuit
board in the concealed box.
Loosen the plug so that the display unit
can be removed.
Remove all parts of the transportation
lock/packing.
The security covering in the concealed
box is attached with four screws: Loosen
the screws and take off the security cover-
ing.
Remove the circuit board from the con-
cealed box to be installed a keep it in a
place where it is protected from dirt. It
may never be exposed to dust or mo-
isture!
Place the concealed box in the wall so
that the arrows point upwards.
For fitting, screw the cover (board) on to
the concealed box with the enclosed
screws.
Clamp the concealed box to the wall with
the four enclosed screws.
Upon delivery, the pouch containing the
assembly screws can be found in the con-
trol unit’s concealed box.
or
Adjust the screws of the magnetic moun-
ting with the enclosed template. Each of
the four screws must be adjusted individi-
ally in height.
When the edge of the template rests on
the wall surface (1), the template must
rest on the mounting screws as well (2).
1
1
2
1 Mains connection
L/N/PE 230 V/50 Hz
2 Drive group 1
3 Drive group 2
4 Drive group 3
5 Drive group 4
6 Outer conductor L1
7 Multifunctional output 1
(potential-free)
8 MF output 2 (potential-free)
9 Wall button 1
(terminal 1: +12 V | 2: Up | 3: Down)
10 Wall button 2
(4: +12 V | 5: Up | 6: Down)
11 Wall button 3
(7: +12 V | 8: Up | 9: Down)
12 Wall button 4
(10:+12V|11:Up|12:Down)
13 Weather station (terminals 1-2)
Wire assignment: red = 1, black = 2,
yellow and white = not connected
14*Multifunctional input 1
(terminal 3: +12 V | 4: GND | 5: IN)
15*MF input 2 (6: +12 V | 7: GND | 8: IN)
16 Connector for flat-ribbon cable to
front board
17 Microfuse T6,3 A
* Supply voltage e. g. indoor sensor
possible via MF inputs
(No. 14, terminal 3(+), 4(-) and
No. 15, terminal 6(+), 7(-)),
max. 50 mA altogether.
12
3
4
5
6
7
89
10
11
12
13
14
15
16
17
1 Mains connection
L/N/PE 230 V/50 Hz
2 Drive group 1
3 Drive group 2
4 Drive group 3
5 Drive group 4
6 Multifunctional output 1
(potential-free)
7 MF output 2 (potential-free)
8 Microfuse T630 mA
9 Wall button 1
(terminal 1: +12 V | 2: Up | 3: Down)
10 Wall button 2
(4: +12 V | 5: Up | 6: Down)
11 Wall button 3
(7: +12 V | 8: Up | 9: Down)
12 Wall button 4
(10:+12V|11:Up|12:Down)
13 Weather station (terminals 1-2)
Wire assignment: red = 1, black = 2,
yellow and white = not connected
14*Multifunctional input 1
(terminal 3: +12 V | 4: GND | 5: IN)
15*MF input 2 (6: +12 V | 7: GND | 8: IN)
16 Connector for flat-ribbon cable to
front board
* Supply voltage e. g. indoor sensor
possible via MF inputs
(No. 14, terminal 3(+), 4(-) and
No. 15, terminal 6(+), 7(-)),
max. 50 mA altogether.
12
3
4
5
6
7
8
9
10
11
12
13
14
15
16
EN

Mounting of WS1 Style 2
Mounting of WS1 Style • Version: 30.06.2020 • Technical changes and errors excepted. • Elsner Elektronik GmbH • Sohlengrund 16 • 75395 Ostelsheim • Germany • www.elsner-elektronik.de • Technical Service: +49 (0) 7033 / 30945-250
Connection diagrams
Drive and MF outputs WS1 Style (60180-60189):
max. 400 W per motor output,
total max. 1.5 kW for all motor outputs
Drive and MF outputs WS1 Style-PF (60194):
per motor output max. 5 A / 230 V
Inputs WS1:
Connection examples for multifunctional outputs
Connecting 230 V consumers to MF outputs
Connecting low-voltage consumers and potential-free contacts to MF
outputs
Technical specifications Control Unit WS1 Style
The product conforms with the provisions of EU directives.
There are no drive outputs available with the model WS1-0.
multifunctional outputs 1-4 WS1000 Color/Style
multifunctional outputs 1-2 WS1 Color/Style
MF output 1 MF output 2 MF output 3
neutral conductor
heating valve 230 V
lamp 230 V
Contactor / Relay (on-site)
MF output 4
L1 / L1connector
ventilator 230 V
F1 6,3A slow-blow
radiant heater
Housing Glass, plastic material
Colours • White/grey
• Dark grey/black
Mounting Flush/cavity wall
Dimensions Display front approx. 181 × 131 (W × H, mm),
mounting depth approx. 8 mm,
concealed box approx. 172 × 122 × 81 (W × H
× D, mm)
Ambient temperature Operation 0…+55°C, Storage -30…+70°C
Ambient humidity 5...95% RH, avoid bedewing
Operating voltage 230 V AC, 50 Hz
Power consumption Stand-by max. 11 W
Loading capacity
drive outputs
per drive output max. 400 W,
total max. 1.5 kW
Frequency
wireless channels
868.2 MHz
Protection category IP 20
Measurement range
temperature
0…+55°C
Resolution (tempera-
ture)
0.1°C
Measurement range
humidity
5…95% RH
Resolution (humidity) 0.1% RH
multifunctional outputs 1-4 WS1000 Color/Style
multifunctional outputs 1-2 WS1 Color/Style
MF output 1 MF output 2 MF output 3 MF output 4
e.g. 24 V (ext.power supply)
heating valve 24 V other consumers 24 V
signal contact for e.g.
rain / wind / frost /
smoke detector / alarm
thermostat
(on-site)
