Eluktronics MECH-15 G2 User manual
User Manual
Eluktronics MECH-15G2
The information in this user’s manual is protected by copyright
laws, all parts of this manual, including the products and software
described in it, can not be reproduced, transmitted, transcribed,
stored in a retrieval system, nor translated into any language.
THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE
FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL
AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL
DAMAGES, WHICH MAY RESULT FROM THE PERFORMANCE
OR USE OF THIS MANUAL.
The illustrations in this user’s manual are for reference only.
The information in this user’s manual is subject to change without
notice.
Notice
TABLE OF CONTENTS
Notice ...................................................................................................... 2
Preface .................................................................................................... 5
1.1 Regulation Information....................................................................... 6
1.2 Safety Instructions............................................................................. 7
1.3 Warranty Void Warning..................................................................... 8
1.4 Release History ................................................................................. 9
Get to Know the Basics ..........................................................................10
fs.......................................................................11
2.2 Preparing Your Computer ............................................................... 15
2.3 Product Overview ............................................................................16
Getting Started.......................................................................................
3.1 AC Adapter ....................................................................................... 26
3.2 Understanding the Keyboard ...........................................................27
3.2.1 Keyboard Shorcuts ...................................................................... 28
3.3 Using the Touchpad / Clickpad..........................................................31
BIOS Setup ............................................................................................ 32
4.1 About BIOS Setup ........................................................................... 33
4.1.1 When to Use BIOS Setup............................................................. 33
4.1.2 How to Run BIOS Setup............................................................... 33
4.2 BIOS Setup Menu............................................................................ 35
4.2.1 Main Menu.................................................................................... 35
4.2.2 Advanced Menu ........................................................................... 37
4.2.3 Security Menu............................................................................... 39
4.2.4 Boot Menu .................................................................................... 40
4.2.5 Exit Menu...................................................................................... 42
Notebook Manual 5
English
Preface
Chapter 1
6 Notebook Manual English
1.1 Regulation Information
CE compliance
This device is classed as a technical information equipment (ITE) in
Do not subject the unit to temperatures below 5°C (41°F) or
above 40°C (104 °F).
BY AN INCORRECT TYPE DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
extended durations can damage one’s hearing. In
order to reduce the risk of damage to hearing, one
should lower the volume to a safe, comfortable level,
and reduce the amount of time listening at high
requirements.
Notebook Manual 7
English
1.2 Safety Instructions
Do not apply heavy pressure to the computer or subject it to any form of
strong impact as this can damage the computer's components or otherwise
cause it to malfunction.
Never cover or block the air vents including those located at the base of the
computer. Never cover your computer or AC adapter with any object.
To keep your computer in prime operating condition, protect your work area
from direct sunlight.
Do NOT expose to or use near liquid, rain, or moisture.
Do NOT use the modem during electrical storms.
NOT
1
2
3
4
5
1
52
3
4
100kg
8 Notebook Manual English
1.3 Warranty Void Warning
WARNING:The thermal system is not meant to be tampered with. Any
adjustment or modification to the thermals on this PC will void your warranty.
If you're encountering an issue with heat or believe your PC is running
warmer than it should, please contact technical support. We are here to assist you.
Notebook Manual 9
English
1.4 Release History
1.0 04/2018
Date Revision
Initial release
10 Notebook Manual English
Chapter 2
Get to Know the Basics
Notebook Manual 11
English
2.1 Product Specication
This User’s Manual provides technical information of instructions
and illustrations on how to operate this notebook. Please read
this manual carefully before using this notebook.
・CPU
Supported Processor
Intel CFL-H
・Memory
DDR Memory Type
DDR4 2400MHz to 2666MHz
・Physical Characteristic
Dimension
359* 242* 19~(23)mm
2.1kg+/- 5%
・GPU
Supported Graphics Card
NVIDIA GTX 1060
12 Notebook Manual English
・I/O Port
USB
RJ45
Card Reader
HDMI
x 1
x 1
x 1
・Audio
Audio Codec
Azalia standard support, D3 mode support, 2.1 Channels support
Speaker/MIC
x 2
x 2
Mini DP
t
Digital Microphone support w/ Camera
Sound Baster Cinema
Notebook Manual 13
English
・Input
Keyboard
Mechanical Keyboard with RGB Backlight Support
Pointing Device
Touchpad 104*72
LCD
, (Narrow border)
・Display
LAN
Supports 10/100/1000 MB/Sec
Wireless LAN
*IEEE802.11b/g/n support; AC mode support
・Communication Port
HD webcam
・Webcam
14 Notebook Manual English
・Power
AC Adapter
Automatic voltage adjustment between 100 and 240VAC 50/60Hz,
1. 150 Watts (19V/7.89A), 3 Pins
2. 180 Watts (19.5V/9.23A), 3 Pins (Option)
3 cells (3s1p 4100mAh) 46.74Wh
Battery
D
19.5V/9.23A (Option) or 19V/7.89A
・Storage
HDD
7mm height
SSD
*M.2 2280, PCIE/SATA*1
*RAID 0/1 support
Notebook Manual 15
English
2.2 Preparing your Computer
Connect the AC adapter’s DC output plug to the DC IN jack.
A
BThe display panel can be opened to a wide range of angles for
optimal viewing. Please be careful not to bend the panel back too far to
avoid potential damage to the hinges or display.
CPress the power button to turn on your notebook computer.
16 Notebook Manual English
Top-Open View
2.3 Product Overview
Please become familiar with each component before
you operate the computer.
NOTE: The product’s color/LED color, I/O port, indicator location
& specification will depend upon the advertised product you purchased.
Note: When you are not using the computer, please keep
the LCD-screen closed to protect it from dust.
1
2
5
6
3
7
4
8
9
Notebook Manual 17
English
1
3
2
4
5
Webcam
A device which allows you to record video or take photographs with
your computer.
Camera Status LED
The camera status LED
indicates if the camera is active .
Microphone
LCD screen
Internal d isplay /panel of your notebook computer.
Caps Lock Status LED
Charging & Battery Indicator
Power Indicator
n
No Lightff
Power Button
s
NOTE: Holding the power button for 4-5 seconds will hard power the
PC down.
6
18 Notebook Manual English
7 Quick Launch Button
Fan full speed On/Off
9
8Keyboard
Full 15.6" KB with RGB backlight support.
Touchpad/Clickpad
Tochpad LED indicator/ Touchpad switch
