Em-Trak B400 User manual

ICertified high powered AIS Class B (5W SOTDMA)
IHigh performance latest generation GPS
IRuggedized and impervious to extreme environments
– water (IPx6, IPx7), damp, shock, vibration, temperatures
ISuitable internal or permanent external installation
IRobust ergonomic button and rotary-knob user
interfaces with configurable multi-lingual menu options
IIntegrated high definition colour display with night mode
IENC chart (C-MAP) with configurable AIS target overlay
IMultiple functionality – collision, CPA, MOB, SAR,
vessel lists, text messaging, weather, active
monitoring, silent mode, plus much more
IProfessional live AIS AtoN information display
IPlug & play connectivity - integrated WiFi,
NMEA 0183 & NMEA 2000
IEnhanced RF screening to protect against
electromagnetic interference
IBuilt-in power surge protection
The B400 is a certified high powered, priority
transmission, Class B AIS transceiver. As a single
integrated unit with high definition colour display,
and IPx6 and IPx7 weather and waterproofing,
the B400 can be permanently installed in any
external or internal location and is easy to
configure, install, operate and connect to your
existing navigation displays.
B400 incorporates a range of enhanced
functionality which includes vessel display filters,
colour ENC (C-MAP), MOB and SART alerts and
WiFi connectivity.
DESCRIPTION
B400 CLASS B |AIS Transceiver
HIGH TRANSMIT POWER (5W SOTDMA)
FEATURES
EM-TRAK.COM
Product Code: 427-0003
5W/SO
TRANSMIT & RECEIVE
NMEA 0183 & 2000
IPx7
WATERPROOF
WiFi
5W

EM-TRAK.COM
HEAD OFFICE
em-trak Marine Electronics Ltd
Wireless House
Westfield Industrial Estate
Midsomer Norton
Bath BA3 4BS
United Kingdom
T+44 (0)1761 409 559
F [phone]
E [e-mail]
Wwww.em-trak.com
PHYSICAL & ENVIRONMENTAL SPECIFICATION
Size (H x W x D) 152 x 165 x 95mm
Weight 1.1kg
Operating temperature -25°C to +55°C
Storage temperature -25°C to +70°C
Ingress protection IPx6 and IPx7
ELECTRICAL SPECIFICATION
Supply voltage 12V or 24V DC
Supply voltage range 9.6V - 31.2V DC
Average current (at 12V) 480mA
Peak current 4A
Average power consumption
(at 12V) 5.8W
Galvanic isolation NMEA 0183, NMEA 2000, power
supply, VHF antenna port
CONNECTORS
VHF antenna SO-239
GNSS TNC
Power 2 way circular multipole
NMEA 0183/Silent mode 14 way circular multipole
NMEA 0183/alarm relay 18 way circular multipole
NMEA 2000 5 way Micro-C connector
DATA INTERFACES
NMEA 0183 3 x input ports
3 x bi-directional ports
NMEA 2000 NMEA 2000 Ed 3.101, LEN=1
WiFi
IEEE 802.11 (a/b/g), client
mode and access point mode
supported. (5 connections in
access point mode)
STANDARDS COMPLIANCE
AIS standards IEC 62287-2 Ed. 2
ITU-R M.1371.5
Product safety standards EN60950-1 2006 +A11:2009
+A1:2010 +A12:2011 +A2:2013
Environmental standards IEC 60945 Ed. 4
Serial data interface standards IEC 61162-1 Ed 5.0
IEC 61162-2 Ed 1.0
NMEA 2000 NMEA 2000 Ed 3.101
GNSS performance standards IEC 61108-1 Ed 2.0
IEC 61108-02 Ed 1.0
GNSS
Systems supported
GPS, GLONASS, BeiDou, Galileo
(two of any combination, three
including GPS, Galileo)
Channels 72
Internal/external antenna External only
Time to first fix from cold start 26s
VHF TRANSCEIVER
VDL access scheme SOTDMA
Operating frequency 156.025MHz - 162.025MHz
Channel bandwidth 25kHz
Receivers/transmitters 3 x receivers, 1 x transmitter
AIS receiver sensitivity (20% PER) -111dBm
AIS transmitter power 5W (+37dBm)
USER INTERFACE
Screens 5” 800 x 480 full colour LCD
Buttons
Rotary encoder for selection and entry,
4 menu keys and 4 direction keys
SD card interface
Micro SD card interface for logging and
chart cards (not available from em-trak)
GNSS ANTENNA
Size 85 x 70mm
Weight 470g
Ingress protection IPx6 and IPx7
Mounting 1 inch 14 TPI pole mount required
GNSS systems supported GPS, GLONASS, Galileo, BeiDou
IN THE BOX
1 x AIS transceiver
1 x Mounting bracket & fixings pack
1 x Product manual and document pack
1 x Power cable
1 x Data accessory cable
WARRANTY
With em-trak you can buy with confidence. If you are unhappy with your new
product for any reason, within two days of receipt and subject to the product
and packaging being complete and undamaged, you may return it to us for a full
refund. We are sorry, but we cannot accept the return of any product if you have
not advised us in writing within 48 hours of receiving your em-trak product,
or if it has been used and or damaged or if any of the package is incomplete.
All em-trak products benefit from our three year global warranty. In the unlikely
event of a problem, please contact our Customer Support department (24/7) at
[e-mail] and one of our experts will work with you to resolve your
issue or arrange the repair or replacement of your em-trak product. The warranty
is invalidated if the product has been incorrectly used, damaged or tampered.
