Fisher™LCP100 Local Control Panel
Contents
Introduction 1.................................
Scope of Manual 1.............................
Description 2.................................
Specifications 2...............................
Educational Services 2...........................
Installation 5..................................
Hazardous Area Classifications and Special
Instructions for “Safe Use” and Installation
in Hazardous Areas 5........................
Mounting 5..................................
Electrical Connections 5........................
Pre‐Setup Testing 24............................
Setup 25......................................
Principle of Operation 25........................
Maintenance 26................................
Troubleshooting 26............................
Parts Ordering 27...............................
Parts List 27...................................
Common Parts 27.............................
Figure 1. Fisher LCP100 Local Control Panel, with
FIELDVUE DVC6200 SIS Digital Valve Controller
and Bettis™Actuator
X0247
Introduction
Scope of Manual
This instruction manual includes installation and maintenance information for the Fisher LCP100 local control panel
(figure 1). This device is used with Fisher FIELDVUE™ instruments in Safety Instrumented Systems (SIS). Refer to the
DVC6200 SIS Digital Valve Controllers for Safety Instrumented System (SIS) Solutions instruction manual
(D103557X012) or the DVC6000 SIS Digital Valve Controllers for Safety Instrumented System (SIS) Solutions
instruction manual (D103230X012) for additional information.
Unless otherwise noted, the information in this instruction manual applies to both DVC6200 SIS and DVC6000 SIS
digital valve controllers. For simplicity, the DVC6200 SIS model name will be used throughout.
Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
2
Do not install, operate, or maintain an LCP100 local control panel without being fully trained and qualified in valve,
actuator, and accessory installation, operation, and maintenance. To avoid personal injury or property damage, it is
important to carefully read, understand, and follow all of the contents of this manual, includingall safety cautions and
warnings. If you have any questions about these instructions, contact your Emerson sales office or Local Business
Partner.
Description
The LCP100 local control panel is used with the HARTrcommunicating DVC6200 SIS digital valve controller. This panel
is used to manually open and close a safety shutdown valve. The LCP100 also provides a manual reset feature as well as
a button for initiating a partial stroke test.
Specifications
Typical specifications for the LCP100 local control panel are shown in table 1.
Educational Services
For information on available courses contact:
Emerson Automation Solutions
Educational Services - Registration
Phone: [phone] or [phone]
e‐mail: [email protected]
emerson.com/fishervalvetraining

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
3
Table 1. Specifications
Power Options (switch selectable)
JExternal: 24 VDC +/- 10% @ 50 mA maximum
continuous current (100 mA maximum inrush)
JLoop: 8‐20 mA (LCP100 and DVC6200 SIS
combined)
Power Consumption
External: 1.32 W max continuous
Loop (Point-to-Point): 0.042 W max continuous
Loop (Multi-Drop): 0.126 W max continuous
Temperature Limits(1)
-40 to 65_C (-40 to 149_F)
Maximum distance between LCP100 and DVC6200
SIS digital valve controller
Cable length is limited by maximum cable
capacitance of 100,000 pF(2). Typical 314 meters
(1030 feet) with 18 AWG shielded Audio, Control and
Instrumentation Cable.
Electrical Classification
CSA (C/US)
AEx ia IIB T4 Ga(3) – Zone 0, 1, 2
AEx e mb [ib] IIC T4 Gb – Zone 1, 2
AEx ic IIC T4 Gc – Zone 2
Class I Division 2 Groups ABCD T4
ATEX
Ex ia IIB T4 Ga(3) – Zone 0, 1, 2
Ex e mb [ib] IIC T4 Gb – Zone 1, 2
Ex ic IIC T4 Gc – Zone 2
IECEx
Ex ia IIB T4 Ga(3) – Zone 0, 1, 2
Ex e mb [ib] IIC T4 Gb – Zone 1, 2
Ex ic IIC T4 Gc – Zone 2
Ex tb IIIC T71°C Db – Zone 21, 22
CUTR
Ex em[ib] IIC – Zone 1, 2
Ex ic IIC – Zone 2
Electrical Housing
IP66
Electromagnetic Interference (EMI)
Meets EN 61326-1:2013
Immunity—Industrial locations per Table 2 of
EN 61326-1 Standard. Performance is
shown in table 2 below.
Emissions—Class A
ISM equipment rating: Group 1, Class A
Connections
Conduit: 3/4 NPT or M20
Wiring
14 to 26 AWG
Torque Specifications
Wiring terminals: 0.5 NSm (4.5 inSlbs)
Electrical Installation
Wire connections are polarity sensitive
Compatibility
DVC6200 SIS with Firmware revision 3 or later
DVC6000 SIS with Firmware revision 7 or later
Installation Orientation
Wiring entrance must be facing down
Dimensions
253.1 mm (10 inches) long by 109.5 mm (4.3 inches)
wide by 127.8 mm 5 inches) deep. See figure 2.
Construction Materials
Housing material: filled polyester
Approximate Weight
2.2 kg (4.9 lb)
1. The pressure/temperature limits in this document and any applicable standard or code limitation should not be exceeded.
2. DVC6000 SIS: Cable length is limited by maximum cable capacitance of 18000 pF.
3. LOOP Powered only.

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
4
Table 2. Electromagnetic Immunity Performance Criteria
Port Phenomenon Basic Standard Test Level Performance
Criteria(1)
Enclosure
Electrostatic discharge (ESD) IEC 61000‐4‐2 $4 kV contact
$8 kV air A
Radiated EM field IEC 61000‐4‐3
80 to 1000 MHz @ 10V/m with 1 kHz AM at 80%
1400 to 2000 MHz @ 3V/m with 1 kHz AM at 80%
2000 to 2700 MHz @ 1V/m with 1 kHz AM at 80%
A
I/O signal/control
Burst (fast transients) IEC 61000‐4‐4 $1 kV, I/O lines
$2 kV, DC power lines A
Surge IEC 61000‐4‐5 $1 kV, I/O lines
$2 kV, DC power lines) A
Conducted RF IEC 61000‐4‐6 150 kHz to 80 MHz at 3 Vrms with 1 kHz AM at 80% A
Specification limit = ±1% of span
1. A = No degradation during testing. B = Temporary degradation during testing, but is self‐recovering.
Figure 2. Fisher LCP100 Local Control Panel Dimensions
129
(5.1)
94
(3.7)
110
(4.3)
194
(7.6) 257
(10.1)
mm
(INCH)
E1077‐1

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
5
Installation
WARNING
Electrostatic charge hazard. Do not rub or clean the LCP100 with solvents if a flammable vapor is present. To do so could
result in an explosion.
Note
Direct all wiring to the left side inside the LPC100 compartment, away from the buttons.
Hazardous Area Classifications and Special Instructions for “Safe Use” and
Installation in Hazardous Locations
Refer to the following instruction manual supplements for approval information.
D CSA (C/US) Hazardous Area Approvals - LCP100 Local Control Panel (D104236X012)
D ATEX Hazardous Area Approvals - DVC2000 Digital Valve Controllers (D104237X012)
D IECEx Hazardous Area Approvals - DVC2000 Digital Valve Controllers (D104238X012)
All documents are available from your Emerson sales office, Local Business Partner, or Fisher.com. Contact your
Emerson sales office or Local Business Partner for all other approval/certification information.
Mounting
Refer to figure 2 for dimensional information. The LCP100 local control panel has four (4) mounting holes for on‐site
mounting of the device. The LCP100 must be installed so that the wiring connections are on the bottom to prevent
accumulation of moisture inside the box.
Electrical Connections
WARNING
Select wiring and/or cable glands that are rated for the environment of use (such as hazardous location, ingress protection,
and temperature). Failure to use properly rated wiring and/or cable glands can result in personal injury or property damage
from fire or explosion.
Wiring connections must be in accordance with local, regional, and national codes for any given hazardous area approval.
Failure to follow the local, regional, and national codes could result in personal injury or property damage from fire or
explosion.
Refer to the appropriate wiring diagram, as defined in table 3, based on your protection method and installation
requirements. Also refer to figure 4 for LCP100 switch setting, terminal connections, and label details and information,
as well as DVC6200 SIS terminal box details.

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
6
Table 3. Wiring Configurations with DVC6200 SIS Digital Valve Controller
LCP100 Protection Method LCP100 Power Source Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage) Refer to figure
Ex e mb [ib] IIC
Ex tb IIIC
LOOP
DVC6200 SIS then LCP100 Point-to-Point 5
Multi-Drop 6
LCP100 then DVC6200 SIS Point-to-Point 7
Multi-Drop 8
24 VDC DVC6200 SIS then LCP100 Point-to-Point 9
Multi-Drop 10
Ex ic IIC
Ex tb IIIC
LOOP
DVC6200 SIS then LCP100 Point-to-Point 11
Multi-Drop 12
LCP100 then DVC6200 SIS Point-to-Point 13
Multi-Drop 14
24 VDC DVC6200 SIS then LCP100 Point-to-Point 15
Multi-Drop 16
Ex ia IIB
Ex tb IIIC LOOP
DVC6200 SIS then LCP100 Point-to-Point 17
Multi-Drop 18
LCP100 then DVC6200 SIS Point-to-Point 19
Multi-Drop 20
Note
For intrinsically safe applications, the LCP100 forms an intrinsically safe explosion protection system when used with intrinsically
safe associated apparatus (a barrier) or with any other intrinsically safe devices.
The following requirements must be met: Uo ≤ Ui , Io ≤ Ii, Po ≤ Pi , Co ≥ Ci + Cc, Lo ≥ Li + Lc.
When installing the cover, tighten the screws evenly in a criss‐cross pattern such as the one indicated in figure 3, to a
torque of 2.82 N•m (25 lbf•in), to help ensure the cover is properly installed.
Figure 3. Proper Cover Installation
NOTE: TIGHTEN THE SCREWS IN A CRISS‐CROSS PATTERN
TO HELP ENSURE PROPER COVER INSTALLATION.
1
2
3
4

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
7
POWER SELECTOR
SWITCH (FACTORY
DEFAULT IS 24VDC)
Figure 4. Interior Details of Fisher LCP100 and FIELDVUE DVC6200 SIS
LABEL IDENTIFIES TERMINALS USED WHEN
POWER SELECTOR SWITCH IS SET TO LOOP
TERMINAL CONNECTIONS: USED FOR BOTH 24VDC
AND LOOP POWER SWITCH SELECTION. REFER TO
WIRING DIAGRAMS IN THE FOLLOWING FIGURES
FOR CORRECT WIRING CONNECTIONS
LABEL IDENTIFIES TERMINALS USED WHEN POWER
SELECTOR SWITCH IS SET TO 24VDC. NOTE THAT
MIDDLE TERMINAL IS NOT USED WITH THIS SETTING
TERMINAL CONNECTIONS:
USED WHEN 24VDC POWER
SWITCH IS SELECTED
LABEL IDENTIFIES
POWER SELECTOR
SWITCH SETTING:
LEFT = 24VDC
RIGHT = LOOP
ELECTRICAL ENTRY
3/4 NPT OR M20
LCP100 INTERIOR
DVC6200 SIS
TERMINAL BOX INTERIOR
TALK +
TALK -
LOOP +
LOOP -
AUX -
AUX +
EARTH GROUND
SAFETY
GROUND
GE26881-Sheet 2

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
8
Figure 5. Ex e mb [ib] IIC or Ex tb IIIC Wiring Diagram 1
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex e mb [ib] IIC
Ex tb IIIC LOOP DVC6200 SIS then LCP100 Point-to-Point
2
LOGIC SOLVER
OUTPUT
8 - 20 mA
(USER SUPPLIED)
1
NOTES:
1 THE LOGIC SOLVER MINIMUM OUTPUT MUST BE 8 mA. THE LCP100 WHEN
POWERED BY THE LOOP CONSUMES APPROXIMATELY 4 mA.
2 FOR FLAMEPROOF/EXPLOSION-PROOF APPROVED DIGITAL VALVE CONTROLLERS,
INSTALL CONDUIT SEALS OR FLAMEPROOF CABLE GLANDS AS REQUIRED TO MAINTAIN
THE FLAMEPROOF/EXPLOSION-PROOF INTEGRITY OF THE DEVICE.
GE26881-Sheet 3
2

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
9
Figure 6. Ex e mb [ib] IIC or Ex tb IIIC Wiring Diagram 2
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex e mb [ib] IIC
Ex tb IIIC LOOP DVC6200 SIS then LCP100 Multi-Drop
LOGIC SOLVER
OUTPUT
24VDC
(USER SUPPLIED)
NOTES:
1 THE LCP100 WHEN POWERED BY THE LOOP CONSUMES APPROXIMATELY 4 mA.
2 FOR FLAMEPROOF/EXPLOSION-PROOF APPROVED DIGITAL VALVE
CONTROLLERS, INSTALL CONDUIT SEALS OR FLAMEPROOF CABLE GLANDS AS
REQUIRED TO MAINTAIN THE FLAMEPROOF/EXPLOSION-PROOF INTEGRITY OF THE
DEVICE.
LC340 LINE
CONDITIONER
FLD
SYS
GE26881-Sheet 4
1
2
2

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
10
Figure 7. Ex e mb [ib] IIC or Ex tb IIIC Wiring Diagram 3
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex e mb [ib] IIC
Ex tb IIIC LOOP LCP100 then DVC6200 SIS Point-to-Point
LOGIC SOLVER
OUTPUT
8 - 20 mA
(USER SUPPLIED)
NOTES:
1 THE LOGIC SOLVER MINIMUM OUTPUT MUST BE 8 mA. THE LCP100 WHEN
POWERED BY THE LOOP CONSUMES APPROXIMATELY 4 mA.
2 FOR FLAMEPROOF/EXPLOSION-PROOF APPROVED DIGITAL VALVE CONTROLLERS,
INSTALL CONDUIT SEALS OR FLAMEPROOF CABLE GLANDS AS REQUIRED TO MAINTAIN
THE FLAMEPROOF/EXPLOSION-PROOF INTEGRITY OF THE DEVICE
GE26881-Sheet 5
2
1

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
11
Figure 8. Ex e mb [ib] IIC or Ex tb IIIC Wiring Diagram 4
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex e mb [ib] IIC
Ex tb IIIC LOOP LCP100 then DVC6200 SIS Multi-Drop
LOGIC SOLVER
OUTPUT
24VDC
(USER SUPPLIED)
NOTES:
1 THE LCP100 WHEN POWERED BY THE LOOP CONSUMES APPROXIMATELY 4 mA.
2 FOR FLAMEPROOF/EXPLOSION-PROOF APPROVED DIGITAL VALVE CONTROLLERS,
INSTALL CONDUIT SEALS OR FLAMEPROOF CABLE GLANDS AS REQUIRED TO MAINTAIN
THE FLAMEPROOF/EXPLOSION-PROOF INTEGRITY OF THE DEVICE.
LC340 LINE
CONDITIONER
FLD
SYS
GE26881-Sheet 6
2
1

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
12
Figure 9. Ex e mb [ib] IIC or Ex tb IIIC Wiring Diagram 5
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex e mb [ib] IIC
Ex tb IIIC 24VDC DVC6200 SIS then LCP100 Point-to-Point
NOTES:
1 WHEN 24VDC POWER IS AVAILABLE FOR THE LCP100, IT IS NOT NECESSARY TO
CONNECT THE LOOP + OF THE DIGITAL VALVE CONTROLLER TO THE LOOP + OF THE
LCP100. DOING SO WILL CAUSE THE LCP100 TO UNNECESSARILY CONSUME 4 mA AT
THE EXPENSE OF THE DIGITAL VALVE CONTROLLER
2 FOR FLAMEPROOF/EXPLOSION-PROOF APPROVED DIGITAL VALVE CONTROLLERS,
INSTALL CONDUIT SEALS OR FLAMEPROOF CABLE GLANDS AS REQUIRED TO MAINTAIN
THE FLAMEPROOF/EXPLOSION-PROOF INTEGRITY OF THE DEVICE.
LOGIC SOLVER
OUTPUT
4 - 20 mA
(USER SUPPLIED)
(USER SUPPLIED)
24 VDC
SOURCE
GE26881-Sheet 7
2
1
2

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
13
Figure 10. Ex e mb [ib] IIC or Ex tb IIIC Wiring Diagram 6
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex e mb [ib] IIC
Ex tb IIIC 24VDC DVC6200 SIS then LCP100 Multi-Drop
NOTES:
1 WHEN 24VDC POWER IS AVAILABLE FOR THE LCP100, IT IS NOT NECESSARY TO
CONNECT THE LOOP + OF THE DIGITAL VALVE CONTROLLER TO THE LOOP + OF THE
LCP100. DOING SO WILL CAUSE THE LCP100 TO UNNECESSARILY CONSUME 4 mA AT
THE EXPENSE OF THE DIGITAL VALVE CONTROLLER
2 FOR FLAMEPROOF/EXPLOSION-PROOF APPROVED DIGITAL VALVE CONTROLLERS,
INSTALL CONDUIT SEALS OR FLAMEPROOF CABLE GLANDS AS REQUIRED TO MAINTAIN
THE FLAMEPROOF/EXPLOSION-PROOF INTEGRITY OF THE DEVICE.
LOGIC SOLVER
OUTPUT
24VDC
(USER SUPPLIED)
(USER SUPPLIED)
24 VDC
SOURCE
LC340 LINE
CONDITIONER
FLD
SYS
GE26881-Sheet 8
2
2
1

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
14
Figure 11. Ex ic IIC or Ex tb IIIC Wiring Diagram 1
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex ic IIC
Ex tb IIIC LOOP DVC6200 SIS then LCP100 Point-to-Point
LOGIC SOLVER
OUTPUT
8 - 20 mA
(USER SUPPLIED)
INTRINSICALLY
SAFE
BARRIER
NOTES:
1 THE LOGIC SOLVER MINIMUM OUTPUT MUST BE 8 mA. THE LCP100 WHEN
POWERED BY THE LOOP CONSUMES APPROXIMATELY 4 mA.
2 REFER TO THE DVC6200 SERIES QUICK START GUIDE (D103556X012) FOR
SCHEMATICS AND ENTITY PARAMETERS.
LOOP
TERMINALS:
Ui = 27 VDC
Ii = N/A
Pi = N/A
Ci = 1.1 nF
Li = 0 mH
GE26881-Sheet 9
2
1

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
15
Figure 12. Ex ic IIC or Ex tb IIIC Wiring Diagram 2
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex ic IIC
Ex tb IIIC LOOP DVC6200 SIS then LCP100 Multi-Drop
LOGIC SOLVER
OUTPUT
24 VDC
(USER SUPPLIED)
INTRINSICALLY
SAFE
BARRIER
NOTES:
1 THE LCP100 WHEN POWERED BY THE LOOP CONSUMES APPROXIMATELY 4 mA.
2 REFER TO THE DVC6200 SERIES QUICK START GUIDE (D103556X012) FOR
SCHEMATICS AND ENTITY PARAMETERS.
LOOP
TERMINALS:
Ui = 27 VDC
Ii = N/A
Pi = N/A
Ci = 1.1 nF
Li = 0 mH
LC340 LINE
CONDITIONER
FLD
SYS
GE26881-Sheet 10
2
1

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
16
Figure 13. Ex ic IIC or Ex tb IIIC Wiring Diagram 3
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex ic IIC
Ex tb IIIC LOOP LCP100 then DVC6200 SIS Point-to-Point
NOTES:
1 THE LOGIC SOLVER MINIMUM OUTPUT MUST BE 8 mA. THE LCP100
WHEN POWERED BY THE LOOP CONSUMES APPROXIMATELY 4 mA.
2 REFER TO THE DVC6200 SERIES QUICK START GUIDE (D103556X012)
FOR SCHEMATICS AND ENTITY PARAMETERS.
(USER SUPPLIED)
INTRINSICALLY
SAFE
BARRIER
LOOP
TERMINALS:
Ui = 27 VDC
Ii = N/A
Pi = N/A
Ci = 1.1 nF
Li = 0 mH
LOGIC SOLVER
OUTPUT
8 - 20 mA
GE26881-Sheet 11
2
1

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
17
Figure 14. Ex ic IIC or Ex tb IIIC Wiring Diagram 4
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex ic IIC
Ex tb IIIC LOOP LCP100 then DVC6200 SIS Multi-Drop
INTRINSICALLY
SAFE
BARRIER
NOTES:
1 THE LCP100 WHEN POWERED BY THE LOOP CONSUMES APPROXIMATELY 4 mA.
2 REFER TO THE DVC6200 SERIES QUICK START GUIDE (D103556X012) FOR
SCHEMATICS AND ENTITY PARAMETERS.
LOOP
TERMINALS:
Ui = 27 VDC
Ii = N/A
Pi = N/A
Ci = 1.1 nF
Li = 0 mH LOGIC SOLVER
OUTPUT
24 VDC
(USER SUPPLIED)
LC340 LINE
CONDITIONER
FLD
SYS
GE26881-Sheet 12
2
1

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
18
Figure 15. Ex ic IIC or Ex tb IIIC Wiring Diagram 5
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex ic IIC
Ex tb IIIC 24VDC DVC6200 SIS then LCP100 Point-to-Point
INTRINSICALLY
SAFE
BARRIER
NOTES:
1 WHEN 24 VDC POWER IS AVAILABLE FOR THE LCP100, IT IS NOT NECESSARY TO
CONNECT THE LOOP + OF THE DIGITAL VALVE CONTROLLER TO THE LOOP + OF THE
LCP100. DOING SO WILL CAUSE THE LCP100 TO UNNECESSESARILY CONSUME 4 mA AT
THE EXPENSE OF THE DIGITAL VALVE CONTROLLER.
2 REFER TO THE DVC6200 SERIES QUICK START GUIDE (D103556X012) FOR
SCHEMATICS AND ENTITY PARAMETERS.
LOOP
TERMINALS:
Ui = 27 VDC
Ii = N/A
Pi = N/A
Ci = 1.1 nF
Li = 0 mH
INTRINSICALLY
SAFE
BARRIER
24 VDC
TERMINALS:
Ui = 27 VDC
Ii = N/A
Pi = N/A
Ci = 1.1 nF
Li = 0 mH
AUX +
AUX -
LOGIC SOLVER
OUTPUT
4 - 20 mA
(USER SUPPLIED)
(USER SUPPLIED)
24 VDC
SOURCE
GE26881-Sheet 13
2
1

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
19
Figure 16. Ex ic IIC or Ex tb IIIC Wiring Diagram 6
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex ic IIC
Ex tb IIIC 24VDC DVC6200 SIS then LCP100 Multi-Drop
INTRINSICALLY
SAFE
BARRIER
NOTES:
1 WHEN 24 VDC POWER IS AVAILABLE FOR THE LCP100, IT IS NOT NECESSARY
TO CONNECT THE LOOP + OF THE DIGITAL VALVE CONTROLLER TO THE LOOP +
OF THE LCP100. DOING SO WILL CAUSE THE LCP100 TO UNNECESSESARILY
CONSUME 4 mA AT THE EXPENSE OF THE DIGITAL VALVE CONTROLLER.
2 REFER TO THE DVC6200 SERIES QUICK START GUIDE (D103556X012) FOR
SCHEMATICS AND ENTITY PARAMETERS.
LOOP
TERMINALS:
Ui = 27 VDC
Ii = N/A
Pi = N/A
Ci = 1.1 nF
Li = 0 mH
24 VDC
TERMINALS:
Ui = 27 VDC
Ii = N/A
Pi = N/A
Ci = 1.1 nF
Li = 0 mH
AUX +
AUX -
INTRINSICALLY
SAFE
BARRIER
LOGIC SOLVER
OUTPUT
24 VDC
(USER SUPPLIED)
LC340 LINE
CONDITIONER
FLD
SYS
24 VDC
SOURCE
(USER SUPPLIED)
GE26881-Sheet 14
2
1

Instruction Manual
D103272X012
LCP100 Local Control Panel
August 2017
20
Figure 17. Ex ia IIB or Ex tb IIIC Wiring Diagram 1
LCP100
Protection Method
LCP100
Power Source
Wiring Order from
Logic Solver
DVC6200 SIS Mode
(Current or Voltage)
Ex ia IIB
Ex tb IIIC LOOP DVC6200 SIS then LCP100 Point-to-Point
INTRINSICALLY
SAFE
BARRIER
NOTES:
1 THE LOGIC SOLVER MINIMUM OUTPUT MUST BE 8 mA. THE LCP100
WHEN POWERED BY THE LOOP CONSUMES APPROXIMATELY 4 mA.
2 REFER TO THE DVC6200 SERIES QUICK START GUIDE (D103556X012)
FOR SCHEMATICS AND ENTITY PARAMETERS.
LOOP
TERMINALS:
Ui = 30 VDC
Ii = 226 mA
Pi = 1.4 W
Ci = 0.22 mF
Li = 16.0 mH
AUX
TERMINALS:
Ui = 30 VDC
Ii = 452 mA
Pi = 1.4 W
Ci = 0 mF
Li = 0 mH
(USER SUPPLIED)
LOGIC SOLVER
OUTPUT
8 - 20 mA
GE26881-Sheet 15
2
1
