Emerson AS3-ACD Series User manual

1(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as3-acd-4_v02.docx
CAD Re-assembly instructions
for our neutral CAD file formats
Product: Maintenance unit, Series AS3-ACD
Parts assembled: 2 (5)
Consists of following parts: 3 pcs
Parts assembled: 2 (5)

2(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as3-acd-4_v02.docx
Mate instructions, step by step for easy handling
I. Assemble main parts
Constraint 1(3): Mate
Constraint 2(3): Insert
Constraint 3(3): Insert
1 –Assemble Filter pressure regulator & Block assembly kit Parts assembled: 2(3)
Constraint 1(3): Align
Constraint 2(3): Align
Constraint 3(3): Mate
2–Assemble Lubricator Parts assembled: 3(3)

3(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as3-acd-4_v02.docx
Mate instructions, step by step for easy handling
II. Assemble sub parts: Filter pressure regulator
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 1(2): Insert
Constraint 2(2): Mate
1 –Assemble Pressure regulator & Reservoir Parts assembled: 2(3)
Consists of following parts: 3 pcs
Parts assembled: 2 (5)

4(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as3-acd-4_v02.docx
Mate instructions, step by step for easy handling
III. Assemble sub parts: Lubricator
IV.
V.
VI.
VII.
Constraint 1(2): Insert
2 –Assemble Pressure gauge Parts assembled: 3 (3)
Consists of following parts: 2 pcs
Parts assembled: 2 (5)
Constraint 2(2): Mate

5(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as3-acd-4_v02.docx
Mate instructions, step by step for easy handling
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 1(2): Insert
Constraint 2(2): Mate
1 –Assemble Lubricator body & Lubricator reservoir Parts assembled: 2 (2)
