PACSystemsTM RX3i
CEP CARRIER
(IC695CEP001 & IC694CEE001)

GFK-2884K Feb 2022
i
Warnings and Caution Notes as Used in this Publication
WARNING
Warning notices are used in this publication to emphasize that hazardous voltages, currents, temperatures, or
other conditions that could cause personal injury exist in this equipment or may be associated with its use.
In situations where inattention could cause either personal injury or damage to equipment, a Warning notice is
used.
CAUTION
Caution notices are used where equipment might be damaged if care is not taken.
Note: Notes merely call attention to information that is especially significant to understanding and operating
the equipment.
These instructions do not purport to cover all details or variations in equipment, nor to provide for every possible
contingency to be met during installation, operation, and maintenance. The information is supplied for
informational purposes only, and Emerson makes no warranty as to the accuracy of the information included herein.
Changes, modifications, and/or improvements to equipment and specifications are made periodically and these
changes may or may not be reflected herein. It is understood that Emerson may make changes, modifications, or
improvements to the equipment referenced herein or to the document itself at any time. This document is intended
for trained personnel familiar with the Emerson products referenced herein.
Emerson may have patents or pending patent applications covering subject matter in this document. The furnishing
of this document does not provide any license whatsoever to any of these patents.
Emerson provides the following document and the information included therein as-is and without warranty of any
kind, expressed or implied, including but not limited to any implied statutory warranty of merchantability or fitness
for particular purpose.

GFK-2884K Feb 2022
2
Introduction
The PACSystems RX3i Carrier IC695CEP001 interfaces a remote node, consisting of one RX3i I/O module, to a PROFINET
I/O Local Area Network (LAN).
The optional RX3i Expansion Carrier IC694CEE001 attaches to the RX3i CEP001 Carrier and provides the ability to add
one additional RX3i IC694 I/O module to the remote node.
The RX3i CEP001 Carrier functions as a PROFINET IO-Device. The RX3i CEP001 Carrier’s main Remote I/O functions
include:
•Scanning all the modules within the remote node (input and output scan)
•Publishing data on the PROFINET network to a PROFINET IO-Controller at a user-specified production period
•Receiving data from a PROFINET IO-Controller on the PROFINET network at a customer-specified production period
•Managing PROFINET communication and module configuration between a PROFINET IO-Controller and modules
within the remote node
•Managing the state of the I/O when communications is lost
•Publishing fault information (alarms, diagnostics, and such) to the PROFINET IO-Controller
•Provides power to the CEE001 Expansion Carrier
The insertion and removal of I/O modules is the same as in an RX3i Universal Backplane. Refer to GFK-2314, PACSystems
RX3i System Manual.
The RX3i CEP001 Carrier provides two RJ-45 Ethernet receptacles. It supports 10/100BASE-TX Ethernet standard
interface.
Features
•Full programming and configuration services for all supported RX3i I/O Modules using PAC Machine Edition. Refer
to the section, Supported I/O modules
•Support daisy-chain/line, star, or ring (redundant media) network topologies
•Two switched Ethernet ports: two eight-conductor RJ-45 shielded-twisted pair 10/100 Mbps copper interfaces
•USB port for field updates of firmware using Win Loader
•Supports Hot-standby CPU Redundancy using PROFINET I/O: requires RX3i CEP001 2.01 GSDML version 2.3 or later
•Supports HART® Pass Through using PROFINET
Note: The USB port is for firmware upgrades only. It is not intended for permanent connection.
The CEP001 Carrier requires a user-supplied +24 Vdc power source.
Ordering Information
CAT Number
Description
IC695CEP001
RX3i CEP001 Carrier with RJ-45 Copper Ethernet Interface
IC694CEE001
RX3i CEE001 Expansion Carrier

GFK-2884K Feb 2022
3
Specifications
Specification
Description
PROFINET support
PROFINET Version 2.3 Class A IO-Device
RX3i Controller version
required
CPU320/CPU315 Primary Firmware Release 8.95 or later
CPU320/CPU315 Boot Firmware Release 5.10 or later
CPE310/CPE305 Primary Firmware Release 8.95 or later
CPE310/CPE305 Boot Firmware Release 7. 10 or later
CRU320 Primary Firmware Release 8.95
CRU320 Boot Firmware Release 5.10 or laterIC69PNC001 PROFINET IO-controller with firmware
version 2.26 or later
RXi Controller version
required
RXi Controller, ICRXICTL000, with firmware version 7.80 or later is compatible with CEP001 up to
version 2.01 but is not compatible with CEP001 version 2.30.
PAC Machine Edition version
required
Version 8.6 with SIM 3 or later
Power requirements1
IC695CEP001: 5.25W (0.22 A) at 24 Vdc with or without Expansion Carrier (IC694CEE001)
DC power supply input range: 19.2 to 30 Vdc
Module dimensions
177.2 x 51 x 35 mm (6.98” x 2.01” x 1.38”). Same for CEP001 and CEE001.
Operating temperature
0°C to 60 °C (32°F to 140 °F) maximum surrounding air temperature
Number of Ethernet port
connectors
IC695CEP001: Two RJ-45 10/100Base-TX receptacles
IC694CEE001: None
USB connector (for firmware
upgrades)
IC695CEP001: One Micro-B connector. USB 2.0 compliant running at full-speed (12 MHz) in device
mode
IC694CEE001: None
PNS status and control bits
32 input status bits and 32 output control bits
I/O data update on the
PROFINET LAN
Configurable: 1 ms, 2 ms, 4 ms, 8 ms, 16 ms, 32 ms, 64 ms, 128 ms, 256 ms and 512 ms
Number of IP addresses
One; supports Classless Inter-Domain Routing (CIDR)
Number of MAC addresses
Three; one per external port and one internal. External MAC addresses are only used for specialized
Ethernet protocols such as MRP or LLDP.
I/O station maximum limits
Number of I/O modules per station
IC695CEP001:
One
IC695CEP001 with IC694CEE001:
Two
I/O data per station
1024 bytes total
512 bytes of input data
512 bytes of output data
Configuration
Configured using PAC Machine Edition when used with a PACSystems RX3i PROFINET Controller
module as part of an RX3i High-speed I/O LAN system.
V2.3 GSDML file available for import into 3rd-Party tools.
Note: For product standards, general operating specifications, and installation requirements, refer to GFK-2314, PACSystems RX3i System
Manual.
_________________________
1
Value does not include the power consumption of the installed I/O modules. When calculating the total power requirements, add the power consumption of
the I/O modules according to the I/O module datasheet.

GFK-2884K Feb 2022
4
Installation Location
This product is intended for use with the RX3i system. Its components are considered open equipment (having live
electrical parts that may be accessible to users) and must be installed in an ultimate enclosure that is manufactured to
provide safety. At a minimum, the enclosure shall provide a degree of protection against solid objects as small as 12mm
(fingers, for example). This equates to a NEMA/UL Type 1 enclosure or an IEC60529 IP20 rating providing at least a
pollution degree 2 environment. For details about installing RX3i rack systems, refer to PACSystems RX3i System
Manual, GFK-2314.
Installation in Hazardous Areas
The following information is for products bearing the UL marking for Hazardous Areas or ATEX marking for explosive
atmospheres:
CLASS 1 DIVISION 2 GROUPS ABCD
WARNING
•This equipment is an open-type device and is meant to be installed in an enclosure suitable for the environment
that is only accessible with the use of a tool.
•Suitable for use in Class I, Division 2, Groups A, B, C and D Hazardous Locations, or nonhazardous locations only.
•Explosion hazard - substitution of components may impair suitability for Class I, Division 2.
•When in hazardous locations, turn off power before replacing or wiring modules
ATEX Zone 2
This module must be mounted in an enclosure certified in accordance with EN60079-15 for use in Zone 2, Group IIC and
rated IP54. The enclosure shall only be able to be opened with the use of a tool.
Normal Operation of Individual LEDs
Power LEDs
The RX3i CEP001 Carrier has two Power LEDs, PWR1 and PWR2 that indicate whether the power is applied and is within
range corresponding to the two power sources.
Green, ON
Power is applied at the minimum specified level
OFF
The power supply does not have power or has failed.
OK LED
The OK LED indicates whether the CEP001 Carrier can perform normal operation.
Green, ON
RX3i CEP001 is OK
Amber, ON
Either the RX3i CEP001 Carrier or IO module has a fault
Amber, blink pattern
Fatal error. Flashes once between error codes.
Fast blinking
CEP001 has no valid MAC addresses
OFF
CEP001 has an unrecoverable fault

GFK-2884K Feb 2022
5
Connect LED
The CONN LED indicates the status of PROFINET connections.
Green, ON
At least one PROFINET connection (AR) exists with an IO-Controller
Amber, blink pattern
Fatal error. Flashes once between error codes blinked on the OK LED
Amber, blink in 1Hz
No device name configured
OFF
No PROFINET connection (AR) exists
Port LEDs
The RX3i CEP001 has two Port LEDs, PRT1 and PRT2 that indicate link speed, link connection and link activity
corresponding to the two external Ethernet ports.
Green, ON
Link connected, 100 Mbps
Green, blinking
Port active, 100 Mbps
Amber, ON
Link connected, 10 Mbps
Amber, blinking
Port active, 10 Mbps
Amber, blink pattern
Fatal error. Flashes once between error codes blinked on the OK LED
OFF
The associated Ethernet port is not connected to an active link (can be disabled by
configuration)
Note: Multiple LEDs can blink in patterns that indicate special conditions, such as a request for module identification. Refer to PACSystems
RX3i PROFINET Scanner IC695CEP001 User Manual, GFK-2883.
Power LED (IC694CEE001)
The RX3i Expansion Carrier CEE001 has one PWR LED to indicate whether the power provided by the RX3i CEP001 Carrier
is within range.
Green, ON
OK
Amber, ON
Power 24Vdc and/or 5Vdc is not in specified range
OFF
No power

GFK-2884K Feb 2022
6
Quick Start
Carrier Installation Requirements
The CEP001 Carrier and optional Expansion Carrier CEE001 can be mounted on a DIN-rail
or on a panel.
Adequate installation space is required for:
1. Clearance for communications port cables.
2. Power wiring.
3. Operating the DIN latch.
The RX3i CEP001 Carrier with an I/O module attached requires an enclosure with minimum
depth of 165 mm.
Rated thermal specifications are based on a clearance of 5.1 cm (2”) above and below the
equipment and 2.54 cm (1”) to the left of the RX3i CEP001 Carrier.
Figure 2: Connecting Expansion Carrier
Connecting the CEE001 Expansion Carrier to the CEP001 Carrier
1. Open the connector cap on the RX3i CEP001 Carrier.
2. Slide and install the RX3i CEE001 Expansion Carrier along the guide slots on the RX3i CEP001 Carrier.
3. When the Expansion Carrier is aligned with the CEP001 Carrier, engage the expansion connectors.
4. Close the connector cap.
5. Secure the Expansion Carrier to the DIN rail or panel. Refer to Installing an RX3i CEP001 Carrier on a DIN-rail or Panel
Mounting.
6. Connect the grounding hole on the CEE001 to the panel or enclosure as described in grounding.
Figure 1: Dimension

GFK-2884K Feb 2022
7
Installing an RX3i CEP001 Carrier on a DIN-rail
The carrier mounts on a standard EN 50022, 35 x 7.5 mm DIN-rail.
Conductive (unpainted) finish is required for proper grounding.
For best resistance to vibration, the DIN-rail should be installed
horizontally on a panel using screws spaced approximately 15 cm
(6”) apart.
1. With a small flathead screwdriver, pull out the two DIN-rail
latches and stand the carrier on the DIN-rail.
2. Push in the two DIN-rail latches so that the latches hold the DIN-
rail.
Panel Mounting
For applications requiring maximum or long-term resistance to mechanical vibration and shock, the panel-mounting
method is strongly recommended. A minimum panel thickness of 2.4 mm (.093”) is required. The mounting diagram
below applies to both the CEP001 Carrier and CEE001 Expansion Carrier.
Note:
•Tolerances on all dimensions are ±0.2 mm (0.078”) non-cumulative.
•Apply 1.1 to1.4 Nm (10 to12 in/lbs.) of torque to M3.5 (#6-32) steel screws threaded into tapped holes in the panel.
Figure 4: Panel Mounting
Figure 3: Installing on DIN Rail

GFK-2884K Feb 2022
8
Grounding
The RX3i CEP001 Carrier and CEE001 Expansion Carrier each provide two grounding connection contacts:
•Grounding clips at the back of the carrier, which require DIN-rail installation
•Grounding screw hole at bottom-left of the carrier
Note: When the Carrier is mounted on a DIN-rail, the grounding clips on the back of the Carrier do not provide an adequate ground
connection. The Carrier’s metal back must also be grounded using a separate conductor. The star lock washer method is suitable for
a shield ground, but not suitable for a safety ground.
Ground each Carrier to the panel or enclosure using a minimum AWG #12 (3.3 mm2) wire with ring terminals. Use an
M3 screw, star lock washer and a flat washer to connect the wire at the Carrier’s grounding hole. Connect the other end
of the ground wire to a tapped hole in the grounded mounting panel or enclosure, using a machine screw, star lock
washer and flat washer. Alternately, if the panel has a ground stud, use a nut and star lock washer for each wire on the
ground stud to ensure adequate grounding. Where connections are made to a painted panel, the paint should be
removed so clean, bare metal is exposed at the connection point. Terminals and hardware used should be rated to work
with the aluminum carrier material.
Figure 5: Ground Shield Connection
WARNING
All CEP001 Carriers in a system must be grounded to minimize electrical shock hazard. Failure to do so can result in
severe personal injury.
Installing Modules on the Carrier
The insertion and removal of I/O modules is the same as in an RX3i Universal Backplane. For details, refer to GFK-2314,
PACSystems RX3i System Manual.
Failure to do so Do not install a Power Supply module on the CEP001 or CEE001 Carrier. Attempting to do so could
damage the module and/or the Carrier.
Caution

GFK-2884K Feb 2022
9
Unsupported Modules
If an unsupported module is inserted in the CEP001 or CEE001 Carrier, the module will not be recognized correctly and
could cause damage to the Carrier or the module.
When an unsupported I/O module is inserted into either the RX3i CEP001 Carrier or RX3i CEE001 Expansion Carrier, no
alarm is reported to indicate this.
For the latest updated list of supported I/O modules, refer to the section, Supported I/O Modules.
Some unsupported I/O modules have the same Distinguishing Class (for example, IC694MDL740 has the same
Distinguishing Class as IC694MDL742).
Connecting Power Supplies
You will need:
•One 24 Vdc power supply which provides a low voltage/limited current (LVLC) power source. (For example, the
combination of an isolated DC supply and a fuse, listed 30 Vdc minimum and 3 A maximum, connected in series
with the input.)
•Power cord with 28 to16 AWG / 0.08 to1.32 mm2 wires
•Ferrules for 28 to16 AWG wires (optional)
•Frame ground wire, 28 to16 AWG
•Input power terminal block; provided (Dinkle Part Number 0156-2B-B3269806BK)
•Small flathead screwdriver (jeweler’s size 14)
Note:Two power supplies are required if using redundant power supplies.
Before inserting the wires into the power connector terminal block, use a small flathead screwdriver to press the spring
on the terminal block.
1. Using the power cord, attach the power supply to the power terminal block as displayed in the following figure.
Recommended wire stripping length is 6 to7 mm (0.25”).
2. If using redundant power supplies, connect the second power supply to the input power terminal block.
3. Insert the input power terminal block into the Input Power connector.
Note:For CE Mark purposes, input power lines to the CEP001 Carrier should be limited 30 m (98 ft) or less. There are no user-serviceable
fuses in the CEP001 Carrier.
Caution
