Emerson SA1-2 Series Installation instructions

1(4)
Emerson Automation Solutions | AVENTICS
cad_re-ass_sak-rtc-1_v02.docx
CAD Re-assembly instructions
for our neutral CAD file formats
Product: Shock absorber unit, Series SA1-2
Parts assembled: 2 (5)
Consists of following parts: 6 pcs
Parts assembled: 2 (5)

2(4)
Emerson Automation Solutions | AVENTICS
cad_re-ass_sak-rtc-1_v02.docx
Mate instructions, step by step for easy handling
Constraint 1(2): Insert
Constraint 2(2): Mate
2 –Assemble Impacted Ring. Parts assembled: 3(6)
Constraint 2(2): Align
1–Assemble Shock Absorber Body & Pin. Parts assembled: 2(6)
Constraint 1(2): Insert

3(4)
Emerson Automation Solutions | AVENTICS
cad_re-ass_sak-rtc-1_v02.docx
Mate instructions, step by step for easy handling
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 2(2): Align (“X “mm)
Note:
* The X dimension is free adjusted upon using
purposes
3 –Assemble Shock Absorber Nut. Parts assembled: 4(6)
Constraint 1(2): Insert
Constraint 2(2): Align (“Y”mm)
Note:
* The Y dimension is free adjusted upon using
purposes
4 –Assemble Adjustable Screw. Parts assembled: 5(6)
Constraint 1(2): Insert

4(4)
Emerson Automation Solutions | AVENTICS
cad_re-ass_sak-rtc-1_v02.docx
Mate instructions, step by step for easy handling
Constraint 2(3) : Insert
Constraint 3(3) : Mat
Constraint 2(2): Align (“Z”mm)
Note:
* The Z dimension is free adjusted upon using
purposes
5 –Assemble Adjustable Nut. Parts assembled: 6(6)
Constraint 1(2): Insert
