Section 1: General Specifications and Installation
Name
Description
Supply Input
24V + / - 10%, DC, 30mA
RS485 Signal
Industry standard 2-wire +5V differential
Environmental
Operational: -10 … 50°C
Storage: -40°C … 60°C
Relative Humidity
< 95% (non condensing)
Protection Rating
IP55
Max Cable Length
25m / 82.5ft shielded twisted pair
Mechanical Installation
Figure 1: Dimensions

PACMotion™ VFD External Keypad User Guide Section 1
GFK-3246A April 2022
2
Through Panel Mount
Figure 2: Through Panel Mount
Electrical Installation
Figure 3: Cable Requirements
CAUTION
Incorrect cable connection may damage the drive. Extra careshould be taken when using third party
cable.

PACMotion™ VFD External Keypad User Guide Section 1
GFK-3246A April 2022
3
Allowed System Configurations
Different drive models can be used on the same PACMotion VFD External Keypad network provided a
unique communications address is assigned to each.
Note: Cannot be used with Master –Slave or Cascade Control
Figure 4: Supported Configurations

PACMotion™ VFD External Keypad User Guide Section 2
GFK-3246A April 2022
4
Section 2: Easy Startup
To Setup The PACMotion VFD External Keypad
Communication Address
By default, the PACMotion VFD External Keypad (IC866-EKPD) will try to communicate with the drive
that has Address1 in the network after powering up for the first time.
The PACMotion VFD External Keypad will display Scanning for Drive 01 after power up, which indicates
that the PACMotion VFD External Keypad is searching for the drive with the correct drive addressin the
network. Once the drive has been found, the message Load... will be displayed on the PACMotion VFD,
which indicates that the PACMotion VFD External Keypad is reading the configuration information from
the drive. Usually it will take 1~2 seconds for the PACMotion VFD External Keypad to read this
information. After the data has been loaded, the PACMotion VFD External Keypad willdisplay the drive
real time status.
NOTE In the case where the keypad is connected to a drive where the networkaddress is not 1, the
following steps can be used to set the address of the drive.
Figure 5: Select Drive Address

PACMotion™ VFD External Keypad User Guide Section 2
GFK-3246A April 2022
5
Working with Multiple Drive Networks
When the PACMotion VFD External Keypad is used on networks with multiple drives, the user can
change the drive address to set up communication with another drive in the same dive network at any
time.
Figure 6: Set Drive Address
Networks with Two PACMotion VFDs Connected
A maximum of two PACMotion VFD External Keypads can be connected within the same drive network
to communicate with the same drive or different drives.
When using two PACMotion VFD External Keypads simultaneously on a network, the user must change
the PACMotion VFD External Keypads Device Number on the second PACMotion VFD External Keypads
to ensure correct operation. All PACMotion VFD External Keypads units are set to Device Number 1 by
default.
Figure 7: Select PACMotion VFD External Keypad ID
Note: Once the user has set the PACMotion VFD External Keypad as Device Number 2, PACMotion VFD
Studio software cannot be used on the same drive network. The PACMotion VFD External Keypad
device address should only be changed to 2 if two PACMotion VFD External Keypad units are connected
on a network. A PACMotion VFD External Keypad with Device Number 1 must always be present for the
network to function correctly.

PACMotion™ VFD External Keypad User Guide Section 2
GFK-3246A April 2022
6
Changing the Display Language
Figure 8: Select Language
Drive Fault Message and Trip Codes
See the PACMotion VFD Advanced User Manual (GFK-3112) for further information.

PACMotion™ VFD External Keypad User Guide Section 2
GFK-3246A April 2022
7
PACMotion VFD External Keypad Display Messages
The PACMotion VFD External Keypad uses various display messages to indicate different working
statuses.
Status
Description
Scanning for Drive xx
The PACMotion VFD External Keypad is searching for the drive
with address ‘xx’ in the network.
Load…
The PACMotion VFD External Keypad has found the drive in
the network andis loading the initialisation information
from the drive.
SC-OBS
The communication link between the PACMotion VFD and
PACMotion VFD External Keypad has failed.
Select Language
Displayed in the language selection screen, with a list of
available languages. Press the Navigate keyto select a
language
Select drive address xx
Displayed when selecting the address of the PACMotion VFD
that the PACMotion VFD External Keypad should try to
communicatewith. Press the Stop key to select the drive
address.
Select PACMotion VFD External
Keypad ID
Displayed when selecting the PACMotion VFD External
Keypad ID (1 or 2) so that two PACMotion VFD External
Keypads can be connected to a singledrive, or network of
multiple drives.

PACMotion™ VFD External Keypad User Guide Section 3
GFK-3246A April 2022
8
Section 3: Troubleshooting
Status
Description
Select Drive Address XX
Displayed After SCAN . .
message
The PACMotion VFD External Keypad failed to successfully
communicate with the specified drive address in the network.
Check that the RJ45 data cable connection is correct. Check that the
drive with address XX is available in the network.
If XX > 1 and only one PACMotion VFD External Keypad is connected,
then check the PACMotion VFD External Keypad device number, make
sure the number is 1.
Display Err-id on power up
This status normally occurs when there are two PACMotion VFD
External Keypad units in the same drive network and both of them have
the same device number. Check and change the device number of one
PACMotion VFD External Keypad.
Display Err-id on normal
operation
This status normally occurs when the user plugs a second PACMotion
VFD External Keypad into the drive network. Change the device number
of one of the PACMotion VFD External Keypad units.
Display SC-OBS
The Communication link between the PACMotion VFD External Keypad
and PACMotion VFD has failed during operation.
Check the electrical connection, and make sure the cable is connected
correctly between the PACMotion VFD External Keypad and the drive.
Press STOP button to enable the PACMotion VFD External Keypad to
search for the drive again.
