Emerson AVENTICS GPC Series Installation instructions

1(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_gpc-e-sb-1_v02.docx
CAD Re-assembly instructions
for our neutral CAD file formats
Product: Guide cylinder, Series GPC
Parts assembled: 2 (5)
Consists of following parts: 7 pcs
Parts assembled: 2 (5)

2(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_gpc-e-sb-1_v02.docx
Mate instructions, step by step for easy handling
I. Instruction for main assembly:
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 2(3) : Insert
Constraint 1(3): Insert
Constraint 2(3): Insert
Constraint 3(3): Mate
1 - Assemble A & B part. Parts assembled: 2 (5)
Constraint 1(2): Insert
Constraint 2(2): Mate
2 - Assemble 1st PLUG. Parts assembled: 3 (5)

3(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_gpc-e-sb-1_v02.docx
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 1(2): Insert
Constraint 2(2): Mate
3 - Assemble 2nd PLUG. Parts assembled: 4 (5)
Constraint 1(2): Insert
Constraint 2(2): Mate
4 - Assemble Shock Absorber. Parts assembled: 5 (5)

4(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_gpc-e-sb-1_v02.docx
II. Instruction for shock absorber assembly:
Constraint 2(2): Mate
1 - Assemble A & B part. Parts assembled: 2 (3)
Constraint 1(2): Insert
Consists of following parts: 3 pcs
Parts assembled: 2 (5)

5(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_gpc-e-sb-1_v02.docx
Constraint 2(2): Align (Suitable value)
2- Assemble Nut. Parts assembled: 3 (3)
Constraint 1(2): Insert
