Emerson NL4-FLC Series Installation instructions

1(3)
Emerson Automation Solutions | AVENTICS
cad_re-ass_nl4-flc-5_v02.docx
CAD Re-assembly instructions
for our neutral CAD file formats
Product: Microfilter, Series NL4-FLC
Parts assembled: 2 (5)
Consists of following parts: 5 pcs
Parts assembled: 2 (5)

2(3)
Emerson Automation Solutions | AVENTICS
cad_re-ass_nl4-flc-5_v02.docx
Mate instructions, step by step for easy handling
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 2(3) : Insert
Constraint 3(3) : Mate
”Apply the same to assemble ” 2nd Cap” with Filter body”
Constraint 1(2) : Insert
Constraint 2(2) : Mate
1 –Assemble Filter Body & Reservoir. Parts assembled: 2(5)
Constraint 1(1) : Insert
Constraint 1(3) : Insert
Constraint 2(3) : Align
Constraint 3(3) : Mate
2 –Assemble Filter Body & Caps Parts assembled: 4(5)

3(3)
Emerson Automation Solutions | AVENTICS
cad_re-ass_nl4-flc-5_v02.docx
Mate instructions, step by step for easy handling
Constraint 2(3) : Insert
Constraint 1(1) : Insert
Constraint 1(2) : Insert
Constraint 2(2) : Mate
3 –Assemble Filter Body & Protective Guard Parts assembled: 5(5)
