1. GENERAL INFORMATION
Intended Use
The Emfit Nocturnal Epileptic Tonic-Clonic Seizure Monitor (device model D-1090-2G and sensor model L-4060SL) is intended to
e used for monitoring a person with epilepsy in a ed or on a chair and notifying caregiver of an over preset continued tonic-
clonic seizure, with muscle jerkings. The product consists of a ed sensor and a control unit. The control unit has an audi le
notification sound and a dry-contact output for connecting it to a nurse-call system or to a safety phone.
Control Unit
The control unit D-1090-2G activates for monitoring after it has noticed
movements or micro movements, such as caused y respiratory movements or
heart eating, for over 40 seconds. Notification is triggered if movements are
faster than preset frequency threshold (2Hz or 3 Hz) and continue over preset
delay time or all the movements disappear.
The control unit processes a low voltage (from a out 1 mV up to a out 1 V), high
impedance signal from the dynamic, quasi-piezoelectric type (i.e. self- iased)
flexi le film-like sensor.
The control unit operates with 2 pcs AA size 1.5 V alkaline atteries. An optional
AC adapter is availa le (5 VDC). AC ADAPTERS OTHER THAN ORIGINAL
ACCESSORIES FROM EMFIT MUST NOT BE USED. (MODEL: NO GTM41060-1505
AND P/N:WR9QA3000LCP-N-MNK)
The control unit has input connectors for the sensor (marked as X3) and optional
AC adapter (marked as X1). There is also a connector marked as X2 for
connecting the device to other systems for transferring the notification via dry-contact opto-coupler.
A reset switch for turning off the notification sound is to the right of the sensor input (marked as SW1).
Inside the device there is a place for 2 pcs AA size 1.5 V atteries, and mini-switches (DIP and rotary) for program settings.
Under Mattress Bed Sensor
The Emfit under mattress ed sensor model L-4060SL is a quasi-
piezoelectric, dynamic sensor that has no em edded wires or switches.
This specially formulated plastic sheet sensor is placed elow mattress,
crosswise to the ed, elow the chest area.
The sensor produces signals from even the slightest micro-movements
created when a person is in ed. When there is no movement, it
recognizes this as the individual eing a sent. When there is continued
movements with frequency from 3 Hz (or 2 Hz, see 3. DIP switch #3)
or more and up to 20 Hz, an internal time counter activates. If these
movements continue over the preset delay (10, 13, 16, or 20 seconds),
it gives a notification y sound and y dry-contact output.
There are no particular size or weight limitations, ut sensitivity and
a ility to recognize user presence as well as those movements that
should trigger notification, need to e tested in each case.
2. PACKAGE CONTENTS
- Control unit
- Bed sensor
- Wall mounting clip
- 2 screws
- 2 locking anchors
- This user’s manual
- Optionally a power supply
3. BEFORE USE SELECT THE RIGHT DIP
SWITCH SETTINGS
Inside the device there is a DIP switch with 8 small
switches. These are used for various program settings.
See the following ta le and set up the switches for
your preferred use.
To open the device cover, see the picture on right.
Open the cover y
lifting from one side

4
Table of DIP Swit h Settings
Swit h # OFF (down) ON (up)
#1 Movement continuation time delay setting, see next
chapter after volume settings
Movement continuation time delay setting, see next
chapter after volume settings
#2 Movement continuation time delay setting, see next
chapter after volume settings
Movement continuation time delay setting, see next
chapter after volume settings
#3 Movement frequency threshold 3 Hz (default) Movement frequency threshold lowered to 2 Hz. Use
only if device does not notice person’s movements
(that the caregiver should e notified of) at OFF
position.
#4 Normal sensitivity for noticing micro movements;
use when sensor is installed elow foam mattress or
mattress pad
Increased sensitivity for noticing micro movements.
Recommended use only when sensor needs to e
installed elow spring mattress (no mattress pad in
use). NOTE! Consumes more power and shortens
attery life! Blued LED light links slightly faster.
#5 “No movements” notification is ena led “No movements” notification is disa led
#6 Power switch function at SW1 is ena led (device
can e shut down and turned on y pressing SW1
for a out 3 seconds)
Power switch function at SW1 disa led (device is
always on).
#7 Notification sound volume setting, see elow Notification sound volume setting, see elow
#8 Notification sound volume setting, see elow Notification sound volume setting, see elow
Setting the Notifi ation Sound Volume
The notification sound is useful only when caregiver is in close proximity to the control unit. The volume can e adjusted at 4
levels: no sound, quiet, loud, and very loud.
Volume level Swit h # 7 Swit h #8
Very Loud OFF (down) OFF (down)
Loud ON (up) OFF (down)
Quiet OFF (down) ON (up)
No sound / mute ON (up) ON (up)
The sound stops when oth the reset switch is pressed and when the event is over. In case of person’s a sence from the ed,
the sound will stop once person has returned or reset is pressed.
Setting the Movement Notifi ations
Continued Faster Movements Notification Time Delay Setting
This notification is triggered when the device senses movements in frequency range etween 3 Hz – 20 Hz (or 2 – 20 Hz if
switch #3 is ON) that continue longer than the preset delay. The alarm delay can e set at 10, 13, 16 or 20 seconds.
Set the preferred delay according to the following ta le. If false alarms ecome a pro lem, extend the delay.
Movements to ontinue
to trigger a notifi ation
Swit h # 1 Swit h #2
10 seconds ON(up) ON (up)
13 seconds (default) OFF (down) OFF (down)
16 seconds ON (up) OFF (down)
20 seconds OFF (down) ON (up)

5
No Movements Notification / Switch #5
The device can e set to trigger notification when system does not notice any movements or micro movements (for example
when person leaves the ed). As factory default this switch is at OFF position ie. notification is ena led.
ALWAYS REMOVE BATTERIES AND UNPLUG THE AC ADAPTER (IF IN USE) BEFORE MAKING CHANGES TO THE DIP
SWITCH POSITIONS. OTHERWISE THE NEW SETTINGS WILL NOT TAKE EFFECT.
4. SETTING THE SENSITIVITY
Sensitivity can e adjusted with 10 position rotary switch inside. Factory default setting is the pointer
pointing to #3. In case device does not notice individual’s micro movements, adjust sensitivity higher y
turning the pointer clock-wise one position per time. If the device notices movements even though no
one is in ed, lower sensitivity y turning the screw counter-clockwise one position per time. Always test
after every change efore putting into use.
5. INSTALLING THE BED SENSOR BELOW MATTRESS
ALWAYS INSTALL THE SENSOR CROSSWISE TO THE BED AT THE POSITION BELOW THE
CHEST.
CHECK THE CORRECT PLACEMENT OF THE SENSOR AT LEAST ONCE A WEEK.
IF YOU USE THE SENSOR ON A SPRING MATTRESS, PLACE THE SENSOR BETWEEN THE
MATTRESS PAD AND THE SPRING MATTRESS!
IF THE BED HAS A SPRING MATTRESS, WITHOUT MATTRESS PAD, AND A BOX-SPRING
BELOW SPRING MATTRESS, SENSOR CAN BE INSTALLED BETWEEN THE SPRING MATTRESS
AND THE BOX. IN THAT CASE INSTALL SOME DURABLE (ABOUT 2-3 MM), THICK PLASTIC OR
PLYWOOD SHEET ON TOP AND BELOW OF THE SENSOR TO AVOID SPRINGS DAMAGING THE
SENSOR. THIN SOFT CUSHION BETWEEN THE SHEETS AND SENSOR IS PREFERRED. SET THE
DIP SWITCH #4 UP.
THE SENSOR MUST ALWAYS BE PLACED BENEATH A MATTRESS OR MATTRESS PAD. THE
SENSOR MUST NOT BE IN DIRECT CONTACT WITH A PERSON!
THE EMFIT BED SENSOR IS DESIGNED TO WITHSTAND USE BELOW THE MATTRESS, AGAINST
A HARD BED BOTTOM FOR 4 – 5 YEARS OF USE. MANUFACTURER RECOMMENDS REPLACING
IT AFTER 6 YEARS FROM MANUFACTURING DATE OR AFTER 5 YEARS OF USE, WHICHEVER COMES FIRST.
WHEN USED ON TOP OF A SPRING MATTRESS, THE USE TIME IS MUCH SHORTER DUE TO MORE WEAR AND TEAR
CAUSED WHEN PERSON IS IN BED. THIS WEAR AND TEAR CAUSES THE SENSOR TO WRINKLE. WITH SPRING
MATTRESSES, A PERSON’S WEIGHT AND RESTLESSNESS CAN AFFECT THE USE TIME. THE ESTIMATED USE TIME IN A
SPRING MATTRESS BED IS 1–2 YEARS. IF USED IN SUCH CIRCUMSTANCES, MANUFACTURER RECOMMENDS REPLACING
THE SENSOR WHEN IT LOOKS WEAR OUT AND LATEST AFTER 3 YEARS OF USE. WARRANTY DOES NOT APPLY IF BED
SENSOR IS DAMAGED DUE TO NORMAL WEAR AND TEAR!
DO NOT USE WITH ANTI-DECUBITUS MATTRESS (USED FOR PREVENTING BED-SORES), WHERE AIR PRESSURE IS
CONTROLLED WITH COMPRESSOR.
6. CONNECTORS AND WIRING
Connectors are marked with X1, X2 and X3. These are:
X1 - Power supply connector. Use only Glo Tek Inc. power supply, model no:
GTM41060-1505 and P/N:WR9QA3000LCP-N-MNK, availa le as original
acessory from Emfit.
X2 - Aux connector for connecting the device to some other system (ca le not
included) for transferring the notification via a dry-contact opto-coupler.
DRY-CONTACT OUTPUT OF THE X2 (AUX) CONNECTOR CAN ONLY BE
CONNECTED TO A SYSTEM SAFETY VOLTAGE INPUT WITH MAX VOLTAGE
BELOW 25V (AC) / 60V (DC), WHERE BOTH POLES HAVE BEEN SEPARATED FROM THE ELECTRICAL NETWORK (SO
CALLED FLOATING APPLIED PART). MAX LOAD CURRENT 100 mA!
X3 - Sensor connector (use only Emfit ed sensor model L-4060SL)

6
Connect the under mattress sensor, optional AC adapter and possi le connection wire to other system as follows:
X2 (AUX) Conne tor Pin Order
From left to right
Pin #1 Common return
Pin #2 Normally Open (NO) send
Pin #3 Normally Closed (NC) send
Pin #4 Low Battery send
Pin #5 Not in use, do not connect
Pin #6 Not in use, do not connect
Pin #7 Not in use, do not connect
Pin #8 Not in use, do not connect
DRY-CONTACT OUTPUT OF THE X2 (AUX) CONNECTOR CAN ONLY BE CONNECTED TO A SYSTEM SAFETY VOLTAGE
INPUT WITH MAX VOLTAGE BELOW 25V (AC) / 60V (DC), WHERE BOTH POLES HAVE BEEN SEPARATED FROM THE
ELECTRICAL NETWORK (SO CALLED FLOATING APPLIED PART). MAX LOAD CURRENT 100 mA!
7. INSTALLING THE WALL MOUNT AND DEVICE
Connect the sensor wire plug to
the control unit X3 marked
connector.
If you need to connect the dry-
contact output to another system,
plug the suita le connection wire to
the X2 marked connector
Connect the optional AC adapter
cord to the X1 marked connector
Attach the wall mount with the
included two anchors and screws
Slide the device into the mount Press the device downwards so
you hear a “click” sound

7
8. INSTALLING BATTERIES AND BATTERY CONSUMPTION
Product operates with 2 pcs AA size 1.5 V atteries. Install and remove the atteries as follows:
Estimated attery life is 6 months, when using high quality alkaline atteries, with 2800 mAh capacity (2pcs). Estimation is
ased on measured attery consumption in various conditions and then a calculation where device is on 50% of time (shut down
50% of time) and of that 50% of time there is someone in ed 75% of that time, there are two notifications per day and sound
notification is on 30 seconds each time.
WHEN THE BATTERIES ARE GETTING LOW, THE RED LED BEGINS TO FLASH SLOWLY, A “BEEP” SOUND WILL BE HEARD
AFTER EVERY 1,5 HOURS AND THE DRY-CONTACT OUTPUT GIVES LOW BATTERY NOTIFICATION AFTER EVERY 3 HOURS.
9. ABOUT THE OPTIONAL 5V AC ADAPTER
For preparing the optional power supply for use, do the following:
THE EMFIT EPILEPTIC TONIC-CLONIC SEIZURE ALARM IS DESIGNED AND TESTED TO BE USED ONLY WITH GLOBTEK
INC. POWER SUPPLY MODEL: NO GTM41060-1505 AND P/N:WR9QA3000LCP-N-MNK. ANY OTHER TYPE OF AC ADAPTER
MAY AFFECT THE PRODUCT’S SAFETY.
The power supply is equipped with a lue indicator light; when the light is on the power supply is in use. If the light is off and
the power supply is connected to the mains outlet, the power supply is pro a ly damaged and should e replaced.
WHEN THE AC ADAPTER IS CONNECTED TO THE POWER INPUT, THE BATTERIES ARE ELECTRICALLY DISCONNECTED.
IN CASE OF NO MAINS POWER AND AC ADAPTER CORD IS CONNECTED TO X1, THE BATTERIES INSIDE WILL NOT
OPERATE AS BACK UP POWER SUPPLY.
Open the cover y lifting from
one side
Install 2 pcs good quality alkaline
AA size 1,5 V alkaline atteries
according the polarity drawings
on the circuit oard
When removing old atteries,
they are easiest to remove y
lifting from + ends
Remove the plastic cover Pick up suita le adapter from the
included 4 pcs
Install the adapter and make
sure it stays in place

8
10. LED-LIGHT INDICATORS
1. Green LED / Presence
- The green light starts linking slowly (half the speed of lue light) when the
device notices micro or other movements (person goes to ed)
- The green light starts linking same speed with lue light when the device
has noticed micro and/or other movements (person in ed) for 40 seconds
and it activates for presence monitoring.
- The green light links rapidly when device notices movements with
frequency etween 3-20 Hz (2-20 Hz if DIP switch #3 is ON)
- The green light links every 4
th
time of the lue light after device has
triggered no movement notification, until SW1 is pressed shortly or there is
movements or micro movements (person has returned to the ed) for at least 40
seconds.
2. Blue LED / Power ON - Stand y
- The lue light links slowly when the device is ON
- The lue light links fast for a short moment when the device triggers a notification
3. Red LED / Fault
- The red light linking quickly means the sensor is not connected or sensor is roken. A notification sound is heard first
time 10 seconds after device notices sensor fault, and then after every 45 seconds. Dry-contact output gives notification
first time after 30 seconds and then after every 30 minutes, until proper sensor is plugged.
- The red light linking slowly means replace the atteries. A notification sound is after every 1 ½ hours and dry-contact
output gives low attery notification after every 3 hours until atteries are replaced.
11. SW1 - RESET SWITCH / ON-OFF SWITCH / BY-PASS SWITCH
SW1 As a Reset Swit h
When the notification sound is activated, it can e silenced y riefly pressing the
the SW1 switch (see picture). A eep- eep sound is also heard.
In case of faster continued movements, when the faster movements have stopped
the sound will also stop.
In case of no movement notification, when person returns to the ed the sound will
stop after a out 40 seconds.
SW1 As a On-Off Swit h
When the ON-OFF switch function is ena led from DIP-switch #5, the SW1 switch functions also as ON-OFF switch. To turn the
device ON or OFF, just press the SW1 switch for a out 3 seconds. A “ eep” sound is heard when turning the device ON. A eep-
eep- uup sound is heard when turning the device OFF.
SW1 As a No Movement Notifi ation By-Pass Swit h
The no movement notification can e ypassed if a person wants to leave the ed without causing a notification. This means
that the person can e away from the ed without time limits. Exit-delay will not e activated until the person is ack on the ed
and then leaves again.
When the no movement notification is ena led from DIP-switch #4, to ypass the notification, press the SW1 switch efore the
exit-delay time is up. Control-unit informs of a successful y-pass y eep- eep sound. The SW1 switch can also e pressed
just efore getting up off the ed to y-pass the notification.
After pressing the SW1 switch, person has 20 seconds to completely exit the ed. If this is not done, device re-activates
automatically.
12. TESTING AND INSPECTIONS
Weekly Inspe tion
1. Inspect that all wires are in good condition.
2. Check that the sensor is positioned correctly elow chest position, across the ed.
1. Green
2. Blue
3. Red

9
Tests When Taking into Use and Every Month
Do the following tests at least once a month and when putting into use, to ensure the system’s proper operation!
Testing the “no movements” notification
1. Check to see if system is turned on. If disa led, set on the “no movement” notification function (DIP switch 5 at OFF
position). Check that the device is ON ( lue LED-light is linking slowly).
2. Have the person lay still on the ed on his/her right side for at least 2 minutes. System should notice person’s micro
movements immediately, and the green occupancy LED indicator will start to link slowly, every second time the lue
LED links. Green LED should link continuously the entire time person is in ed. System activates after noticing
movements or micro movements for 40 seconds. At that time the green LED starts linking at same time with lue
LED. If the device won’t detect the presence of a person (green LED light is not linking) move to chapter 12
trou leshooting. If the green light goes off for long periods of time and the no movement notification is triggered,
adjust sensitivity higher (see 4, setting the sensitivity). If the green light links continuously, while the person is laying
still on their right side, the sensitivity level is correct.
3. Now ask the person to leave the ed. The no movement notification should e triggered after a out 5 - 10 seconds,
when person has left the ed and no one is touching the ed, sensor or wires. If the notification doesn’t work and the
green light continues linking, see chapter 13 trou leshooting.
Testing the faster movements notification
1. Simulate continued fast movements, for example, y tapping the mattress just a ove the sensor.
2. During the tapping, the green light should start linking faster.
3. The device should make the notification sound after the delay time (10, 13 16 or 20 sec) has passed.
13. TROUBLESHOOTING
ALWAYS CHECK FIRST THAT INSTALLATION IS CORRECT AND TEST THE DEVICE PROPERLY AFTER EVERY ADJUSTMENT.
Notification is not getting forward via the other system the device is connected to;
•Check that the connection ca le is connected correctly and it is in good condition. Often the wire uses at oth ends same
connector ut wiring order is not the same. Make sure it is connected the right way!
Notification sound does not operate;
•Check the volume level.
False notifications without reason:
•Check the condition, positioning and connection of the ed sensor.
•Is the no movement notification in use? If yes, check the sensitivity according to chapters 4 and 11. It may e that
sensitivity is not set properly and device cannot occasionally detect any micro-movements.
Notice! Any movements that are etween 3 Hz (or 2 Hz if ena led) and 20 Hz frequency and have continued over preset delay
time will trigger the notification.
The device does not trigger no movements notification and the green light is linking even if there is no one on the ed
•Check for possi le external distur ances on the ed sensor and its ca le. Remove any external distur ances causing
vi rations.
•Check the sensor and its ca le. A roken sensor or ca le may cause distur ances to the signal so that the green light links
all the time. Usually this is detected y the device itself and red light starts linking. Also, sensor ca le should e away from
any main outlet ca les and should not e hooked to the AC adapter ca le.
•If the ca le and the sensor seem to e in order, try reducing the sensitivity as some external vi rations may cause this. See
also chapters 4 and 11.
The device does not trigger no movement notification and the green light is off when there is no one on the ed:
•Is the green light linking when there is someone in ed? If not, check the sensor and its ca le.
•Check that the device is switched ON. It is ON if the lue LED light is linking slowly. If it is not linking, press the SW1
switch for a out 4 seconds.
•Check the sensitivity setting of the device when a person remains still on the ed. Green light should e linking and
system activate after person has een in ed for 40 seconds. If necessary increase the sensitivity.
Please never hesitate to contact manufacturer for any pro lems with use! All feed ack is highly appreciated!

10
14. CLEANING
The ed sensor can e cleaned with water and, when necessary, neutral general-purpose or mild antiseptic detergents. Always
dry the sensor after cleaning. Use a moist cloth for cleaning the control unit.
THE CONTROL UNIT MUST NOT GET WET! DO NOT CLEAN THE AC ADAPTER OR THE CONTROL UNIT WHEN IT IS
CONNECTED TO THE MAINS OUTLET. ALWAYS DRY IT WELL AFTER CLEANING.
15. IMPORTANT SAFETY PRECAUTIONS
TO AVOID POSSIBLE INJURY OR DEATH:
- READ INSTRUCTIONS PRIOR TO USE
- ALWAYS TEST THE SYSTEM PER INSTRUCTIONS PRIOR TO USE
- THIS PRODUCT MAY NOT BE SUITABLE FOR ALL PERSONS
- THIS PRODUCT SHOULD NOT BE A SUBSTITUTE FOR MAINTAINING THE ROUTINE VISUAL MONITORING PROTOCOL BY
CAREGIVER.
- MUST NOT BE USED IN SITUATIONS WHERE A DELAY IN THE ARRIVAL OF APPROPRIATE MEDICAL CARE COULD LEAD TO A
POTENTIALLY LIFE-THREATENING SITUATION.
- NEVER USE EMFIT SENSOR WITH OTHER MANUFACTURERS’ DEVICES.
- THE NOTIFICATION MAY FAIL TO SOUND IF THE SENSOR OR ITS WIRE IS DAMAGED OR IMPROPERLY POSITIONED.
- PETS CAN CAUSE FALSE NOTIFICATIONS OR MAY CAUSE THE DEVICE NOT TO TRIGGER NOTIFICATION.
- SENSOR MUST NOT BE SCRATCHED, SLIT OR CUT.
- CHECK SENSOR AND WIRES CONDITION AND IN USE TIME AT LEAST WEEKLY AND REPLACE WHEN NECESSARY.
- DO NOT INTEGRATE TO OTHER SYSTEM OTHERWISE THAN SPECIFIED IN THIS MANUAL.
- TO AVOID RISK OF ELECTRICAL SHOCK, AVOID GETTING THE SENSOR SYSTEM GET WET.
- DO NOT OPEN THE PARTS OR ATTEMPT TO REPAIR IT YOURSELF.
- ALWAYS KEEP THE CONTROL UNIT AND SENSOR DRY. EXPOSURE TO EXCESSIVE MOISTURE CAN CAUSE IT TO
MALFUNCTION.
- THE PRODUCT FULLFILLS THE REQUIREMENTS OF THE EMC-DIRECTIVE FOR MEDICAL DEVICES- IT DOES NOT CAUSE ANY
ELECTROMAGNETIC DISTURBANCE IN NORMAL WORKING CONDITIONS.
- THE PRODUCT CAN BE STACKED OR PLACED NEAR OTHER PRODUCTS OR DEVICES AS LONG AS MECHANICAL VIBRATION IS
NOT PRESENT.
- ALWAYS CHECK THE FUNCTION OF THE PRODUCT AFTER MAKING ADJUSTMENTS.
ACCIDENTIAL OR INTENTIONAL ADJUSTMENT OF KNOBS AND SWITCHES BY THE USER OR SUBJECT MAY CAUSE:
- THE NOTIFICATION SOUND TO NOT ACTIVATE WHEN ADJUSTING THE VOLUME CONTROL TO THE OFF POSITION.
- FALSE NOTIFICATIONS (INCREASE) OR MALFUCTION (DECREASE) WHEN ADJUSTING THE SENSITIVITY.
- THE PRODUCT MAY NOT GIVE NOTIFICATION WHEN NECESSARY WHEN PRESSING THE ON/OFF/RESET SWITCH.
- THE PRODUCT MAY NOT GIVE NOTIFICATION WHEN NECESSARY WHEN SWITCHING DIP SWITCHES.
16. MATERIALS DISPOSAL
At the end of the product’s use life, please dispose of it at appropriate collection points provided in your country.
For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance
(EIA, www.eiae.org).
In the European Union, this la el indicates that this product should not e disposed of with household waste. It
should e deposited at an appropriate facility to ena le recovery and recycling.
17. EU / DECLARATION OF CONFORMITY
Emfit Epileptic Seizure Alarm (device model D-1090-2G and ed sensor model L-4060SL) complies with the
essential requirements of EMC directive 2004/108/EC, CE mark directive 93/68/EEC and Medical Device Directive
93/42/EC and carries the CE marking accordingly.

11
18. EMFIT LIMITED WARRANTY STATEMENT
In the unlikely event that your product needs guarantee service, please contact your dealer, distri utor or manufacturer. To
avoid any unnecessary inconvenience on your part, we recommend you read this instruction manual carefully efore seeking
guarantee service.
YOUR GUARANTEE
By this Guarantee, Emfit guarantees the product to e free from defects in materials and workmanship at the date of original
purchase for a period of two (2) years from that date.
If within the guarantee period the product is determined to e defective (at the date of original purchase) due to improper
materials or workmanship, Emfit will, without charge for la our or parts, repair or (at Emfit's discretion) replace the product or
its defective parts su ject to the terms and limitations elow. Emfit may replace defective products or parts with new or
refur ished products or parts. All products and parts replaced ecome the property of Emfit.
TERMS
Guarantee services will e provided only if the original invoice or sales receipt (indicating the date of purchase, model name and
dealer's name) is presented with the defective product within the guarantee period. Emfit may refuse free-of-charge guarantee
service if these documents are not presented or if they are incomplete or illegi le. This Guarantee will not apply if the model
name or serial num er on the product has een altered, deleted, removed or made illegi le.
This Guarantee does not cover transport costs and risks associated with transport of your product to and from Emfit.
This Guarantee does not cover:
a) periodic maintenance and repair or parts replacement due to wear and tear. Notice! Emfit ed-sensor wears and tears
significantly faster when installed on soft ase like spring mattress.
) consuma les (components that are expected to require periodic replacement during the lifetime of a product such as non-
rechargea le atteries)
c) damage or defects caused y use, operation or treatment of the product inconsistent with normal use
d) damage or changes to the product as a result of:
i. misuse, including:
- treatment resulting in physical, cosmetic or surface damage or changes to the product
- failure to install or use the product for its normal purpose or in accordance with Emfit’s instructions on installation or use
- failure to maintain the product in accordance with Emfit’s instructions on proper maintenance
- installation or use of the product in a manner inconsistent with the technical or safety laws or standards in the country where it
is installed or used
ii. the condition of or defects in systems with which the product is used or incorporated except other Emfit’s products designed
to e used with the product
iii. use of the product with accessories, peripheral equipment and other products of a type, condition and standard other than
prescri ed y Emfit
iv. repair or attempted repair y persons who are not Emfit employees
v. adjustments or adaptations without Emfit’s prior written consent, including:
- upgrading the product eyond specifications or features descri ed in the instruction manual, or
- modifications to the product to conform it to national or local technical or safety standards in countries other than those for
which the product was specifically designed and manufactured
vi. neglect
vii. accidents, fire, liquids, chemicals, other su stances, flooding, vi rations, excessive heat, improper ventilation, power surges,
excess or incorrect supply or input voltage, radiation, electrostatic discharges including lighting, other external forces and
impacts.
This guarantee covers only hardware components of the product.
EXCLUSIONS AND LIMITATIONS
EXCEPT AS STATED ABOVE, EMFIT MAKES NO WARRANTIES (EXPRESS, IMPLIED, STATUTORY OR OTHERWISE) REGARDING
PRODUCT OR ACCOMPANYING OR CONSTITUENT SOFTWARE QUALITY, PERFORMANCE, ACCURACY, RELIABILITY, FITNESS FOR
A PARTICULAR PURPOSE, OR OTHERWISE. If this exclusion is not permitted or fully permitted y applica le law, Emfit excludes
or limits its warranties only to the maximum extent permitted y applica le law. Any warranty that cannot e fully excluded will
e limited (as far as permitted y applica le law) to the duration of this Guarantee .
EMFIT’S ONLY OBLIGATION UNDER THIS GUARANTEE IS TO REPAIR OR REPLACE PRODUCTS SUBJECT TO THESE GUARANTEE
TERMS AND CONDITIONS. EMFIT IS NOT LIABLE FOR ANY LOSS OR DAMAGE RELATING TO PRODUCTS, SERVICE, THIS
GUARANTEE OR OTHERWISE, INCLUDING - ECONOMIC OR INTANGIBLE LOSSES - THE PRICE PAID FOR THE PRODUCT - LOSS
OF PROFITS, REVENUE, DATA, ENJOYMENT OR USE OF THE PRODUCT OR ANY ASSOCIATED PRODUCTS - INDIRECT,
INCIDENTAL OR CONSEQUENTIAL LOSS OR DAMAGE. THIS APPLIES WHETHER THAT LOSS OR DAMAGE RELATES TO: IMPAIRED
OR NON-OPERATION OF THE PRODUCT OR ASSOCIATED PRODUCTS THROUGH DEFECTS OR UNAVAILABILITY WHILE WITH
EMFIT, WHICH CAUSED DOWNTIME, LOSS OF USER TIME OR BUSINESS INTERRUPTION INACCURACY OF OUTPUT FROM THE
PRODUCT OR ASSOCIATED PRODUCTS .
THIS APPLIES TO LOSS AND DAMAGES UNDER ANY LEGAL THEORY, INCLUDING NEGLIGENCE AND OTHER TORTS, BREACH OF
CONTRACT, EXPRESS OR IMPLIED WARRANTY, AND STRICT LIABILITY (EVEN WHERE EMFIT HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES).
Where applica le law prohi its or limits these lia ility exclusions, Emfit excludes or limits its lia ility only to the maximum extent
permitted y applica le law. For example, some countries prohi it the exclusion or limitation of damages resulting from
negligence, gross negligence, wilful misconduct, deceit and similar acts. Emfit’s lia ility under this guarantee will in no case
exceed the price paid for the product, ut if applica le law permits only higher lia ility limitations, the higher limitations apply.

12
YOUR LEGAL RIGHTS RESERVED
Consumers have legal (statutory) rights under applica le national laws relating to the sale of consumer products. This guarantee
does not affect statutory rights you may have nor those rights that cannot e excluded or limited, nor rights against the person
from whom you purchased the product. You may assert any rights you have at your sole discretion.
19. TECHNICAL SPECIFICATIONS
Control Unit
Model: D-1090-2G
Operating voltage: 5 V DC
Input / output connectors: Power, AUX and Sensor
Dry-contact outputs: Max. 100 mA A, <60 V DC, <25 V AC
Switches and controls: SW1 (On/Off/Reset switch), 8 DIP switches for program settings, 1 pcs 10 position rotary switch
for sensitivity adjustment
Light indicators: 3 LEDs, green, lue and red
Notification delays: Faster movements threshold delay adjusta le: 10, 13, 16 or 20 sec; no movement notification
threshold delay a out 5 seconds
Mounting: On the wall with included racket or on the ta le
Dimensions mm 96 x 127 x 34 mm
Weight: 110 g
Color: White
Enclosure protection: IP20
Case: Plastic
Bed Sensor
Model: L-4060SL
Type: Bed sensor
Placing: Under the mattress
Porta ility: Yes
Dimension mm (L x W): 400 x 580 mm
Thickness: 0,4 mm
Weight: 110 g
Color: Blue
Surface material: Polyester
Ca le length: 3m
Environment onditions
Operating temperature: 10°C TO 40°C
Storage and transportation
temperature: -30°C TO 50°C
Humidity: 20%… 75% Relative humidity
Produ t lassifi ation
93/42/EEC Medical device class 1
Electrical safety: Class II equipment
Enclosure protection: IP20

13
20. ELECTROMAGNETIC CONDITIONS
System specification:
- D-1090-2G monitor
- L-4060SL ed sensor
- Glo Tek power supply model: no GTM41060-1505 and P/N:WR9QA3000LCP-N-MNK.
Ca le specification:
- Power ca le (non shielded) max. Length 2 m
- Sensor ca le (shielded) max. length 3 m
Note! RF communications equipment can effect medical electrical equipment!
Electromagnetic emissions
The Emfit Emfit Nocturnal Epileptic Tonic-Clonic Seizure Monitor is intended for use in the electromagnetic environment specified
below. The customer or the user of the equipment should assure that it is used in such an environment.
RF emissions
CISPR 11
Group 1
The Emfit Nocturnal Epileptic Tonic-Clonic
Seizure Monitor uses RF energy only for
its internal function. Therefore, its RF
emissions are very low and are not likely to
cause any interference in nearby electronic
equipment.
RF emissions
CISPR 11
Class B
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations/
flicker emissions
IEC 61000-3-3
Complies
The Emfit Emfit Nocturnal Epileptic Tonic-
Clonic Seizure Monitor is suitable for use in
all establishments, including domestic
establishments and those directly
connected to the public low-voltage
power supply network that supplies
buildings used for domestic purposes.
Electromagnetic immunity
Immunity test IEC 60601
test level
Compliance level Electromagnetic environment
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
IEC-60601-1-2 test level Floors should be wood,
concrete or ceramic tile. If floors
are covered with synthetic
material, the relative humidity
should be at least 30 %.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply lines
±1 kV for input/output lines
IEC-60601-1-2 test level Mains power quality should be
that of a typical commercial or
hospital environment.
Surge
IEC 61000-4-5
±1 kV line(s) to line(s)
IEC-60601-1-2 test level Mains power quality should be
that of a typical commercial or
hospital environment
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
<5 % U T
(>95 % dip in U T )
for 0,5 cycle
40 % U T
(60 % dip in U T )
for 5 cycles
70 % U T
(30 % dip in U T )
for 25 cycles
<5 % U T
(>95 % dip in U T )
for 5 sec
IEC-60601-1-2 test level Mains power quality should be
that of a typical commercial or
hospital environment. If the user
of the The Emfit epileptic
seizure alarm enquires
continued operation during
power mains interruptions, it is
recommended that the Emfit
Nocturnal Epileptic Tonic-Clonic
Seizure Monitor be powered
from an uninterruptible power
supply or battery
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m
IEC-60601-1-2 test level Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical commercial
or hospital environment.
NOTE U T is the a.c. mains voltage prior to application of the test level.

14
Electromagnetic immunity
Immunity test IEC 60601 test
level
Compliance
level
Electromagnetic environment – guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
3 Vrms
150 kHz to 80 MHz
3 V/m
80 MHz to 2,5 GHz
[V 1 ] = 3 V
150 kHz to 80 MHz
[E 1 ] = 3 V/m
80 MHz to 2,5 GHz
Portable and mobile RF communications equipment
should be used no closer to any part of the
The Emfit Nocturnal Epileptic Tonic-Clonic Seizure Monitor ,
including cables, than the recommended separation distance
calculated from the equation applicable to the frequency of the
transmitter.
Recommended separation distance
where P is the maximum output power rating of the
transmitter in watts (W) according to the transmitter
manufacturer and d is the recommended separation
distance in metres (m).
Field strengths from fixed RF transmitters, as determined
by an electromagnetic site survey, should be
less than the compliance level in each frequency
range.
Interference may occur in the vicinity of equipment
marked with the following symbol:
NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically
with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site
survey should be considered. If the measured field strength in the location in which the [ EQUIPMENT or SYSTEM ] is
used exceeds the applicable RF compliance level above, the [ EQUIPMENT or SYSTEM ] should be observed to verify
normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting
or relocating the [ EQUIPMENT or SYSTEM ].
b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than [V 1 ] V/m.

15
Recommended separation distances between
portable and mobile RF communications equipment and the [ EQUIPMENT or SYSTEM ]
The Emfit Nocturnal Epileptic Tonic-Clonic Seizure Monitor is intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled. The customer or the user of the Emfit epileptic seizure alarm can help prevent electromagnetic interference
by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the Emfit Nocturnal
Epileptic Tonic-Clonic Seizure Monitor alarm as recommended below, according to the maximum output power of the communications
equipment.
Rated maximum
output power
of transmitter
W
Separation distance according to frequency of transmitter
0,01
0,12 m 0,12 m 0,23 m
0,1
0,37 m 0,37 m 0,73 m
1 1,17 m 1,17 m 2,33 m
10 3,69 m 3,69 m 7,38 m
100 11,67 m 11,67 m 23,33 m
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in metres (m)
can be determined using the equation applicable to the frequency of the transmitter, where P is the maximum output
power rating of the transmitter in watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 The ISM (industrial, scientific and medical) bands between 150 kHz and 80 MHz are 6,765 MHz to 6,795 MHz;
13,553 MHz to 13,567 MHz; 26,957 MHz to 27,283 MHz; and 40,66 MHz to 40,70 MHz.
NOTE 3 An additional factor of 10/3 is used in calculating the recommended separation distance for transmitters in the
ISM frequency bands between 150 kHz and 80 MHz and in the frequency range 80 MHz to 2,5 GHz to decrease the
likelihood that mobile/portable communications equipment could cause interference if it is inadvertently brought into
patient areas.
NOTE 4 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
21. MANUFACTURER´S CONTACT INFORMATION
Manufa turer:
Emfit Ltd
Konttisentie 8
FI-40800 VAAJAKOSKI
FINLAND
Phone: [phone]
Fax: [phone]
Email: in[email protected]
Internet: www.emfit.com
