Eminent EM6025 User manual

E
EM6025 Outdoor camera with Infrared function

2 | ENGLISH
EM6025 Outdoor camera with Infrared
function
Warnings and points of attention
Opening of the product and/or products can lead to severe injuries! Repairing of the
product should be done by qualified Eminent staff!
Table of contents
1.0 Warranty conditions...............................................................................................2
2.0 Introduction ...........................................................................................................2
2.1 Functions and features ......................................................................................3
2.2 Package contents..............................................................................................3
3.0 Mounting the camera.............................................................................................3
4.0 Service and support...............................................................................................4
1.0 Warranty conditions
The five-year Eminent warranty applies for all Eminent products unless mentioned
otherwise before or during the moment of purchase. When having bought a second-
hand Eminent product the remaining period of warranty is measured from the moment
of purchase by the product’s first owner. The Eminent warranty applies to all Eminent
products and parts indissolubly connected to and/or mounted on the main product.
Power supply adapters, batteries, antennas and all other products not integrated in or
directly connected to the main product and/or products of which, without reasonable
doubt, can be assumed that wear and tear show a different pattern than the main
product are not covered by the Eminent warranty. Products are not covered by the
Eminent warranty when exposed to incorrect/improper use, external influences and/or
when opened by parties other than Eminent.
2.0 Introduction
Congratulations on your purchase of this high-quality Eminent product! This product
has undergone extensive testing by Eminent’s technical experts. Should you
experience any problems with this product, you are covered by a five-year Eminent
warranty. Please keep this manual and the receipt in a safe place.
Register this product now on www.eminent-online.com and receive product updates!

3 | ENGLISH
2.1 Functions and features
The EM6025 is a compact outdoor camera with infrared function. This camera
conforms to the IP68 standard, meaning that the camera is water and dust proof. This
makes the camera perfectly capable of observing objects in the outdoors, such as the
entrance of an office building, a parking lot or a cycle shed.
Thanks to the built-in infrared function you can realize up to 15 meters of sight under
bad lighting situations.
2.2 Package contents
The following parts need to be present in the packing:
1. EM6025 Camera
2. Mounting set, consisting of 1 mounting stand, 3 screws and 3 plugs.
Note: Connecting the EM6010 DVR unit requires a combined Coax/power cable, type
EM6040. You can order the EM6040 from your Eminent-dealer.
3.0 Mounting the camera
The EM6025 is meant to be mounted to the wall or ceiling. Follow the instructions
below to be able to use the camera in combination with the Eminent EM6010 DVR
unit:
1. Remove both the camera and the mounting stand from the package.
2. Use the mounting stand to mark three holes on the location where you wish to
mount the camera (You can temporarily mount the camera to the stand to
pinpoint the best location).
3. Drill three holes and fill them with three mounting plugs.
4. Mount the camera stand to the wall using three screws.
5. Adjust the camera so that the location you wish to observe is clearly visible.
6. After the camera has been adjusted you can fasten the clamp to the stand.
7. If the view of the camera is hindered by sunlight, you can slide the plastic sun
cover back or forth.
8. Connect a video cable (BNC) and power cable to the camera.
9. Connect the other end of the video cable to your EM6010.
10. The video cable needs to be connected directly to one of the four ports of the
EM6010.
11. The power cable needs to be connected to the distribution block (supplied with
the EM6010) supplying the camera with 12 Volts AC.
12. Setup your EM6010 DVR for using this camera (consult the manual of the
EM6010 for details).
13. The camera is now ready for use.

4 | ENGLISH
Hint: The EM6025 itself is water and dust proof, but the plugs that connect to the
camera are not. Make sure these do not get wet. Hide and protect them using, for
instance, isolation materials.
4.0 Service and support
This manual has been carefully written by Eminent’s technical experts. If you have
problems installing or using the product, please contact [e-mail].

Declaration of Conformity
To ensure your safety and compliance of the product with the directives and laws
created by the European Commission you can obtain a copy of the Declaration of
Conformity concerning your product by sending an e-mail message to: info@eminent-
online.com. You can also send a letter to:
Eminent Computer Supplies
P.O. Box 276
6160 AG Geleen
The Netherlands
Clearly state ‘Declaration of Conformity’ and the article code of the product of which
you would like to obtain a copy of the Declaration of Conformity.
EM6025 | 10-2007
