EPIX360™ Electrostatic Sprayer
User Guide
Ver. 042520
Thank you for choosing the EMist EPIX360™ Electrostatic Sprayer.
We’ve created an easy-to-use system that combines advanced liquid application technologies with improved
mobility. The result is superior application and enhanced disinfection, as well as a convenient design for users.
We recommend you read through this entire instruction manual before beginning.
Included are assembly, operating, and safety instructions. Following these manufacturer guidelines will help
the system perform at peak eectiveness, extend the life of the product, and ensure operator safety.
Questions?
Each component has been inspected prior to your purchase. However, in the event that there is a problem,
please contact our customer support center at Emist.com.
EPIX360™ Electrostatic Sprayer User Guide
2©2020 EMist®is a registered trademark of SanoTech 360, LLC. All rights reserved.
EMist-00055-20-EPIX360 User Guide - Ver. 042520
3
©2020 EMist®is a registered trademark of SanoTech 360, LLC. All rights reserved.
EMist-00055-20-EPIX360 User Guide - Ver. 042520
1. General Precautions & Safety Warnings
The EMist EPIX360™ electrostatic sprayer is a
battery-powered liquid spray system designed to
improve the performance of water soluble or water
based solutions used on touchable and other exposed
surfaces. This is accomplished by applying an
electrostatic charge to the surface of the liquid
droplets as they leave the spray head. This unique
process improves liquid adhesion to targeted surfaces.
The hazards associated with the liquids you choose to
apply represent their own unique and important safety
requirements. Refer to each chemical manufacturer’s
documentation to establish best use steps and any
need for personal protective equipment (PPE).
Never point the spray applicator at another person
and never touch or handle the charging area within
the applicator (front end) during spraying. This will help
avoid chemical splash and other possibly unsafe
spraying conditions.
DO NOT USE LIQUIDS THAT ARE NOT
WATER SOLUBLE OR WATER BASED
WITHIN THE SPRAYER. HIGH ALCOHOL
CONTENT LIQUIDS MUST NEVER BE
SPRAYED NEAR AN OPEN FLAME OR
OTHER POSSIBLE IGNITION SOURCES.
• Read the User Guide thoroughly. Failure to read the
guide is considered misuse of the equipment.
• Use the sprayer only for its intended use as directed
in this guide.
• Familiarize yourself with all components, including
caution and warning labels.
• Only trained and qualied personnel should operate
the sprayer.
• Do not use the equipment while under the inuence
of drugs or alcohol.
• Remove the battery when leaving the equipment
unattended.
• Store the system in a cool, dry place. Do not expose
to extreme temperatures.
• Flush the system before storing.
Lack of attention to safety can result in reduced
eciency, accident(s), or personal injury. Use the following
safety precautions as a guide when using this machine:
• Do not place body parts or any foreign object into
any opening of the sprayer.
• Never reach inside of the sprayer while the
system is powered on.
• Never place equipment in standing water or liquid.
• Never operate the sprayer if it has been damaged
or if it is not working properly.
Safety Warning:
Do not use the electrostatic sprayer if you have a
pacemaker or an Implantable Cardioverter Debrillator
(ICD) or stand within 10 feet if you use such devices,
as this product contains an electrostatic device that
may interfere with these type of devices. Contact your
physician prior to operation if you are unsure if this
system will interfere with your implant.
Safety Notes:
Users are required to read this User Guide,
understand the safe and correct operating procedures
that pertain to the operation of the sprayer, and
maintain the product according to the User Guide. It
is the operator’s responsibility to ensure that any
person who uses this equipment has read this guide.
To reduce the risk of electrical shock or injury, follow
these guidelines:
Electrical Warning
4©2020 EMist®is a registered trademark of SanoTech 360, LLC. All rights reserved.
EMist-00055-20-EPIX360 User Guide - Ver. 042520
2. Initial Inspection & Set Up - Inventory
1. Electrostatic Sprayer
2. Tank
3. Tank Liners (qty. 5)
4. Tank Cap Assembly
5. Tank Cap Cover
6. 14.4v Battery
7. 14.4v Battery Charger
FG.2009 -
FG.2010 -
FG. 2014 -
FG.2011 -
FG.2012 -
SA.2011.1 -
MD.03.053 -
MD.03.049 -
Battery
Battery Charger (US)
Battery Charger (EU)
Tank
Tank Liners (qty. 5)
Tank Cap Assembly
Tank Cap Cover
Nozzle Tip
Items Included: Accessories & Parts Sold Separately:
3. Assembly & Operating Instructions
Electrostatic Sprayer
8 oz Liquid Tank
8 oz Liquid Tank Liners (qty. 5)
Tank Cap Assembly
Tank Cap Cover
Rechargeable Battery
Battery Charger
1.
2.
3.
4.
5.
6.
7.
After unpacking, inspect components for any
damage or missing hardware pieces, etc. The
following should be included in your bundle package: Plug cord into the wall outlet.
Install battery into charger.
Reference power indicator (3
bars = full charge).
1.
2.
3.
Charge the Battery First:
Initial Set Up
1
65
42 3
7
Assembled
Unit
Storage Case with Sprayer
and Accessories
5
©2020 EMist®is a registered trademark of SanoTech 360, LLC. All rights reserved.
EMist-00055-20-EPIX360 User Guide - Ver. 042520
Battery Management
•
•
•
•
Fully charge each battery before use.
Always keep connectors clean and dry.
Do not expose batteries to standing liquid or
excessive heat.
Only charge battery packs with an EMist charger.
4. Spray Application
Begin at the farthest point from the doorway, work
toward the doorway so you can step out when
application is complete.
Aim the electrostatic sprayer 36” to 48” from the
surface target area, begin with a smooth gure “S”
movement aiming below, at, and above the surface
target area while walking at an average pace
continuously moving.
Make sure you are working in a methodical “S” pattern
and let your passes overlap when moving to the next
surface target area.
Allow treated area to set for contact time as
recommended by the chemical manufacturer’s
label before re-entry into the area.
1.
2.
3.
4.
Spray Application Process
TIP: IF THE APPLICATOR BECOMES WET OR
BEGINS TO DRIP, YOU ARE MOVING TOO SLOW
OVER THE SURFACE TARGET AREA AND NEED TO
SPEED UP THE APPLICATION PROCESS. DO NOT
OVER-SATURATE THE SURFACE. IF YOU SEE RUNS
OR PUDDLES, YOU ARE APPLYING TOO MUCH
CHEMICAL. THE GOAL IS TO ACHIEVE EVEN
COVERAGE OVER THE TARGET SURFACE AREA.
Fluid Management
•
•
•
Stay in motion. Electrostatically charged droplets will
accumulate in higher levels at the tip of the applicator
if you move too slowly while the device is in use.
Do not over apply. The tendency to “paint the fence”
is an over usage of chemical.
In between chemical changes, press the trigger while
pointing to the oor or other safe target area for four
to ve seconds to clear the remaining chemical in the
system.
The sprayer is designed for single or multiple application
environments. Please use the multiple tank applications
carefully by marking tanks with your chemical identiers
when necessary.
Tips:
Special note:
Always mark and save one tank liner exclusively for
clean water. This will be used to ush the system
at the end of daily use or when ushing the system
between switching to dierent chemicals for use in
disinfecting.
6©2020 EMist®is a registered trademark of SanoTech 360, LLC. All rights reserved.
EMist-00055-20-EPIX360 User Guide - Ver. 042520
5. Maintenance & Cleaning
TIP: DO NOT STORE CHEMICALS IN THE
RESERVOIR WHILE THE SYSTEM IS NOT IN
USE FOR GREATER THAN A 24-HOUR PERIOD.
TIP: IT’S IMPORTANT TO FLUSH THE SYSTEM IN
BETWEEN USE OR WHEN SWITCHING CHEMICALS
TO PREVENT RESIDUAL BUILD UP AND TO AVOID
MIXING CHEMICALS.
Flushing the Electrostatic Sprayer
•
•
Clear the system at least once a day by spraying
clean water through the sprayer for at least 10-15
seconds. Use the tank liner marked for clean water.
This tank liner should be stored with the sprayer’s
accessories and equipment and should be rinsed
after each use.
Keep batteries fully charged.
The sprayer is designed to require minimal maintenance
and cleaning.
Tips:
Storage
•
•
•
Empty uid or run until empty.
Remove batteries and re-charge by placing on the
charger.
Wipe down exterior with water or alcohol for removing
dirt and soil.
Battery Removal
•Place batteries into charger to fully charge for next
usage. Each battery takes approximately 45 minutes
to fully charge.
Changing Chemicals
•
•
•
To ush the system, ll the tank liner marked for clean
water with water.
Spray for at least 10-15 seconds to ush the previous
uid from the system.
When nished, rinse the clean water tank liner and
properly store it with the sprayer’s accessories and
equipment. Do not discard unless damaged or aged
from use.
CAUTION: TO PREVENT CROSS CONTAMINATION
OF CHEMICALS, YOU MUST PERFORM A FLUSH
ANY TIME YOU CHANGE THE TYPE OF CHEMICALS
BEING USED.
CAUTION: DO NOT STORE THE SPRAYER IN AN
AREA THAT MAY FREEZE (TO AVOID DAMAGE FROM
LIQUID REMAINING IN THE SYSTEM AND LINES).
THIS WILL VOID THE WARRANTY.
Tips:
Tips:
Tips:
1000 Forest Park Blvd. Ste 402
Fort Worth, TX 76110
Emist.com •888.534.7001
