Emotron DSV15-35 User guide
Control unit
For Emotron DSV15-35 AC drives
Mounting instruction
4
1 General information
First read, then start
1General information
1.1 First read, then start
Information
and tools with regard to the Emotron products can be found on the Internet:
http://www.emotron.com
à File-archive
You will
find
information
on wiring and commissioning in the
mounting
and switch-on
instructions
of the inverter.
Read this
documentation
thoroughly before carrying out the
installation
and commissioning.
Please observe the safety
instructions!
5
Mounting 2
Important notes
2Mounting
2.1 Important notes
Dangerous electrical voltage
Possible consequence: death or severe injuries
▶All works on the inverter must only be carried out in the deenergised state.
▶After switching off the mains voltage, wait for at least 3 minutes before you start working.
DANGER!
6
2 Mounting
Mounting steps
2.2 Mounting steps
You need:
• Torx screwdriver TX20
1. Preparation:
1. Insert the shield sheet into the slot on the back side until it engages.
2. Mounting:
1. Hook the control unit into the upper mounting slots.
2. Turn it downwards until it engages into the lower mounting slots.
7
Mounting 2
Mounting steps
3. Fix it with a securing screw.
The control unit is mounted.
© 01/2016 | 13492598 | 1.0 / 01-6409-01R1
