Brief Operating Instructions
Silopilot FMM50
Electromechanical level system
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation:
Available for all device versions via:
• Internet: www.endress.com/deviceviewer
• Smart phone/tablet: Endress+Hauser Operations App

Silopilot FMM50
2Endress+Hauser
Liquiphant FTL41
2 Endress+Hauser
Order code:
Ext. ord. cd.:
Ser. no.:
www.endress.com/deviceviewer Endress+Hauser
Operations App
XXXXXXXXXXXX
XXXXX-XXXXXX
XXX.XXXX.XX
Serial number
1.
3.
2.
A0023555

Silopilot FMM50
Endress+Hauser 3
Table of contents
1 About this document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Basic safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Requirements for the personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.3 Workplace safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.4 Operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.5 Product safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Incoming acceptance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4 Product identication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.1 Nameplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.2 Manufacturer address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5 Storage and transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5.1 Storage conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.1 Mounting conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.2 Mounting the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6.3 Post-installation check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.1 Connection requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.2 Preparing the measuring device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7.3 Connecting the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7.4 Terminal assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7.5 Ensuring the degree of protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7.6 Post-connection check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
8 Operation options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
8.1 Access to the operating menu via the local display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
9 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9.1 Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9.2 Powering up the measuring device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9.3 Conguring the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Table of contents

Silopilot FMM50
4Endress+Hauser
About this document
1 About this document
1.1 Symbols
1.1.1 Safety symbols
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
serious or fatal injury.
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
This symbol contains information on procedures and other facts which do not result in perso-
nal injury.
1.1.2 Electrical symbols
Ground connection
Grounded clamp, which is grounded via a grounding system.
1.1.3 Symbols for certain types of information
Permitted
Procedures, processes or actions that are permitted.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information
Reference to documentation
Reference to another section
, , Series of steps
1.1.4 Symbols in graphics
A, B, C... View
1, 2, 3 ... Item numbers
-
Hazardous area
.
Safe area (non-hazardous area)

Silopilot FMM50
Endress+Hauser 5
Basic safety instructions
2 Basic safety instructions
2.1 Requirements for the personnel
The personnel must fulll the following requirements to carry out the necessary tasks, e. g.,
commissioning and maintenance:
‣ Trained, qualied specialists must have a relevant qualication for the specic function and
task
‣Are authorized by the plant owner/operator
‣Are familiar with federal/national regulations
‣Must have read and understood the instructions in the manual and supplementary docu-
mentation
‣Follow instructions and comply with conditions
2.2 Designated use
Only use the meter for level measurement in bunkers or silos with dusty, ne-grain or coarse-
grain bulk solids or in tanks containing liquids. Improper use can pose hazards. Ensure that
the measuring device is free of defects while it is in operation.
• Use the measuring device only for media to which the process-wetted materials have an
adequate level of resistance
• Do not exceed or drop below the limit values for the measuring device
 TI00395F
2.2.1 Incorrect use
The manufacturer is not liable for damage caused by improper or non-designated use.
Clarication of borderline cases:
In the case of special uids and media used for cleaning, Endress+Hauser is glad to provide
assistance in verifying the corrosion resistance of wetted materials, but does not accept any
warranty or liability.
Danger of burns from contact with surfaces!
‣If necessary, ensure protection against contact to prevent burns.
2.3 Workplace safety
For work on and with the device:
‣Wear the required protective equipment according to federal/national regulations.
2.4 Operational safety
Risk of injury!
‣Operate the device in proper technical condition and fail-safe condition only.
‣The operator is responsible for interference-free operation of the device.

Silopilot FMM50
6Endress+Hauser
Incoming acceptance
2.4.1 Conversions to the device
Unauthorized modications to the device are not permitted and can lead to unforeseeable
dangers.
‣ If, despite this, modications are required, consult with Endress+Hauser.
2.4.2 Repair
To ensure continued operational safety:
‣Carry out repairs on the device only if they are expressly permitted.
‣Observe national regulations pertaining to the repair of an electrical device.
‣ Only use original spare parts and accessories from Endress+Hauser.
2.4.3 Hazardous area
To eliminate danger to persons or the facility when the device is used in the hazardous area
(e.g. explosion protection):
‣Check the nameplate to verify whether the ordered device can be used as intended in the
hazardous area.
2.5 Product safety
This state-of-the-art measuring device is designed in accordance with good engineering
practice to meet operational safety standards, has been tested, and le the factory in perfect
functioning order.
It meets general safety standards and legal requirements. It also complies with the EU direc-
tives listed in the device-specic EU Declaration of Conformity. Endress+Hauser conrms this
by axing the CE mark to the device.
3 Incoming acceptance
DELIVERY NOTE
1 = 2
A0016870
Check the following during goods acceptance:
• Are the order codes on the delivery note and the product sticker identical?
• Are the goods undamaged?
• Do the nameplate data match the ordering information on the delivery note?
• If required (see nameplate): Are the Safety Instructions, e. g. XA, provided?
• Is the device properly secured?
If one of these conditions is not met, please contact the manufacturer's sales oce.

Silopilot FMM50
Endress+Hauser 7
Storage and transport
4 Product identication
The measuring device can be identied in the following ways:
• Nameplate data
• Extended order code with breakdown of the device features on the delivery note
• Enter serial number from nameplates in W@M Device Viewer (www.endress.com/devicevie-
wer): All of the information on the measuring device is displayed along with an overview of
the scope of technical documentation provided
• Enter the serial number on the nameplate into the Endress+Hauser Operations App or use
the Endress+Hauser Operations App to scan the 2-D matrix code (QR Code) on the name-
plate
4.1 Nameplate
The nameplate displays the legally required and device-relevant information, for example:
• Manufacturer identication
• Order number, external order code, serial number
• Technical data, degree of protection
• Firmware version, hardware version
• Information relevant to approval, reference to safety instructions (XA)
• DataMatrix code (information about the device)
4.2 Manufacturer address
Endress+Hauser SE+Co. KG
Hauptstraße 1
79689 Maulburg, Germany
5 Storage and transport
5.1 Storage conditions
Use original packaging.
5.1.1 Storage temperature
-40 to +80 °C (-40 to +176 °F)
5.1.2 Transporting the device
Transport the device to the measuring point in the original packaging.

Silopilot FMM50
8Endress+Hauser
Mounting
6 Mounting
6.1 Mounting conditions
A A
Ta
Tp
0000000255
1 Installation position
A Distance to the filling stream, internals, struts or cornices
Ta Ambient temperature
Tp Process temperature
Installation position
• Protect sensing weight from spillage.
• Protect measuring tape from damage.
• Select an installation position with as free a measuring path as possible.
• Select wiper length so that the sensing weight can move freely during the entire measuring
process.
Mounting
• Mounting on counter ange DN100 PN16 (hole dimensions according to EN 1092-1)
• Maximum angle of inclination 2°
• Use weather protection cover or weather protection roof for outdoor installation.
• Use accessories to adapt the device to the installation situation.
• Observe maximum ambient and process conditions!

Silopilot FMM50
Endress+Hauser 9
Mounting
• Maximum temperature from lower edge of process adapter: +70 °C (+158 °F)
• Accessories →  TI00395F
6.2 Mounting the device
6.2.1 Required tool
• To open the device: Allen key 5 mm 5 mm
• For the process connection: Appropriate installation tool
• For the sensing weight: Open-end wrench 10 mm 10 mm
6.2.2 Preparing the measuring device
• Remove all remaining transport packaging.
• For devices with an extended wiper (500/1000 mm):
Mount the wiper according to the enclosed instructions
• Removing the transportation lock
21
0000000256
2 Removing the transportation lock
1 Wiperextension
2 Transportationlock

Silopilot FMM50
10 Endress+Hauser
Mounting
• For large sensing weight (cage, bell or oval oat):
Use or create structural support measures and lower the tape border an appropriate distance
before mounting.
0000000257
3 Mounting the sensing weight
6.2.3 Mounting the device
Fit the measuring device on the process connection and align it in such a way that
• the housing is horizontal (maximum angle of inclination 2°),
• the cable entries (and the external start button where applicable) are accessible, and
• the display is directed towards the user.
Fix the measuring device with four suitable screws.
Mounting the sensing weight.
• Do not crease the measuring tape (reduced service life).
• Seal: to be provided by the customer
• Mounting with accessories →  TI00395F
• In case of heavy dust generation in the process: Create slight overpressure to the
mounting ange (air volume as required, G¼ female connection).

Silopilot FMM50
Endress+Hauser 11
Mounting
6.2.4 Mounting dimensions
98
(3.86)
L
349
(13.74)
305 (12.01)
339 (13.35)
D
260 (10.24)
L
0000000249
4 Mounting dimensions. Unit of measurement mm (in)
The wiper length (L) depends on the selected maximum nozzle height:
• 225 mm (8.86 in), Ordering code "maximum connection height; wiper", option Aor B
• 515 mm (20.28 in), Ordering code "maximum connection height; wiper", option Cor D
• 1015 mm (39.96 in), Ordering code "maximum connection height; wiper", option Eor F
The housing depth (D) depends on the selected process pressure:
• 196 mm (7.72 in), Ordering code "process pressure", option 1
• 211 mm (8.31 in), Ordering code "process pressure", option 2

Silopilot FMM50
12 Endress+Hauser
Electrical connection
6.3 Post-installation check
Is the device undamaged (visual inspection)?
 Does the device conform to the measuring point specications?
For example:
• Process temperature
• Process pressure
• Ambient temperature
Are the measuring point number and labeling correct (visual inspection)?
Is the device adequately protected against precipitation and direct sunlight?
Is the device properly secured?
7 Electrical connection
For a device for the hazardous area:
Observe the instructions in the Ex documentation (XA).
7.1 Connection requirements
7.1.1 Required tool
• To open the device: Allen key 5 mm
5 mm
• For the sensing weight: Open-end wrench 30 mm
30 mm
• For the terminals: Slotted screwdriver 0.6x3.5mm
0,6x3,5mm
• For potential equalization: Slotted screwdriver 1.0x6.5mm
1,0x6,5mm
7.1.2 Connecting cable requirements
The connecting cables provided by the customer must meet the following requirements:
• Permissible temperature range:
- FMM50-*******A/C****: -20 to +70 °C (-4 to +158 °F)
- FMM50-*******B/D****: -40 to +70 °C (-40 to +158 °F)
• Protection: IP67
• Normal installation cable sucient
• ⌀ 10 to 17 mm (0.39 to 0.67 in)
• Observe the maximum thermal load of the cables and lines introduced.
• The gland is only admissible for the connection of xed-installation lines and cables. Appro-
priate strain relief must be ensured by the operator.
• Mount the cable gland so that it is protected against mechanical damage ("low" degree of
mechanical risk – impact energy: 4 Joule).

Silopilot FMM50
Endress+Hauser 13
Electrical connection
7.2 Preparing the measuring device
Remove the dummy plug if present.
Housing not sealed tight!
• Operational reliability of the measuring device could be compromised. Use suitable cable
glands that match the degree of protection.
• If the measuring device is supplied with cable glands: Observe the cable specications
7.3 Connecting the device
7.3.1 Connect potential equalization
The potential equalization for the device must be integrated into the existing potential equali-
zation on site.
1
0000000258
5 Connect potential equalization
1 Externalgroundterminal
Requirements:
• The potential equalization must be connected to the external ground terminal on the device.
• For optimum electromagnetic compatibility, keep the potential equalization line as short as
possible.
• The recommended cable cross-section is 2.5 mm2.
• The potential equalization of the FMM50 must be included in the local potential equaliza-
tion.

Silopilot FMM50
14 Endress+Hauser
Electrical connection
7.3.2 Connecting the device
KL1
KL2 KL3
0000000222
6 Terminal assignment
Unscrew the housing cover on the electronics side (large cover).
Push the cable through the cable entry. To ensure tight sealing, do not remove the sealing
ring from the cable entry.
Strip the cable and cable ends. In the case of stranded cables, also t ferrules.
Connect the cable in accordance with the terminal assignment.
Firmly tighten the cable glands.
Reverse the procedure to reassemble the device.
7.4 Terminal assignment
7.4.1 Supply voltage
• Terminal assignment: 1.1 (L1) / 1.2 (N) / 1.3 (PE)
• Voltage range
- FMM50-*****1******: 180 to 253 V AC, 50/60 Hz
- FMM50-*****2******: 90 to 127 V AC, 50/60 Hz
• Ie = 8 A (115 V) for 40 ms / 4.4 A (230 V) for 20 ms
• In accordance with IEC/EN61010 a suitable circuit breaker must be provided for the measu-
ring device.
• Overcurrent protection device: maximum 16 A

Silopilot FMM50
Endress+Hauser 15
Electrical connection
7.4.2 Signal input
Order code Terminal assignment
Without Input 1 (active) Input 2 (active)
3.1 3.3 (+)
3.2 3.4 (‒)
Input 1 (passive) Input 2 (passive)
3.5 3.7
3.6 3.8
• Contact load:
- active: 12 to 24 V
- passive: switching contact max. 30 V DC / 300 mW
• The signal inputs (active/passive) can only be used alternatively. An input can only be
assigned as either active or passive.
• In the case of the device version with an external start button, this button is connected
to the passive signal input 1. Only signal input 2 (active or passive) is then available.
• A start pulse must be present for at least 200 ms for it to be evaluated.
7.4.3 Current output
• Terminal assignment: 3.9 (+) / 3.10 (‒)
• Current output: 0 - 20 mA or 4 - 20 mA, active
• Load: max. 600 Ω
7.4.4 Relay output
Order code Terminal assignment
Output
option A, B
Relay 1 Relay 2
2.1 2.4
2.2 2.5
2.3 2.6
Output
option B
Relay 3 Relay 4 Relay 5 Relay 6
2.7 2.10 2.13 2.16
2.8 2.11 2.14 2.17
2.9 2.12 2.15 2.18
• Contact load: max. 250 V AC / 6 A

Silopilot FMM50
16 Endress+Hauser
Electrical connection
7.5 Ensuring the degree of protection
Check that the housing seals are clean and tted correctly. Dry, clean or replace the seals if
necessary.
Tighten all housing screws.
Firmly tighten the cable glands.
Unused cable entries must be sealed with suitable blanking plugs.
7.6 Post-connection check
Is the device or cable undamaged (visual inspection)?
Do the cables used comply with the requirements?
Do the mounted cables have adequate strain relief?
 Are the connectors rmly tightened?
 Does the supply voltage match the specications on the nameplate?
No reverse polarity, is terminal assignment correct?
If supply voltage is present, is the green LED lit?

Silopilot FMM50
Endress+Hauser 17
Operation options
8 Operation options
3
2
1
0000000221
7 Operation options
1 Operatingkeysforconfiguration
2 Buttontostartameasurementmanually
3 Externalbuttontostartameasurementmanually

Silopilot FMM50
18 Endress+Hauser
Operation options
8.1 Access to the operating menu via the local display
8.1.1 Operational display
measured valuemeasured value 
6633..4422%%
________________________−−−−−−−−−−−−−−−−
  
1
3
4
6
2
5
8 Operationaldisplay
1 Name of function
2 Functionnumber
3 Displaysymbols
4 Measuredvalueandunit
5 Bargraphofmeasuredvalue
6 Operatingelements
Operating options
Key Meaning
FSwitch to group selection 00, 01, ...
O /S Not used
• The operational display essentially corresponds to the measured value display (func-
tion 000).
• The operational display appears automatically aer the start-up procedure. Only then
can a measurement operation commence.
• During initial commissioning, function 060 "language" and function 083 "distance unit"
appear once only. Aerwards, the measured value display appears.
• The default values are always shown in bold in the following chapters, unless they are
explicitly mentioned.
Display symbols
Symbol Meaning
This lock symbol is displayed when the measuring device is locked and no entries
can be made.
This alarm symbol is shown when the device is in an alarm condition (error
condition). A ashing symbol indicates that a fault has occurred.
This symbol ashes when the device is in the "manual" measurement mode.
When the button is pressed, the symbol disappears and the direction selected
(run up ↑ run down ↓) is shown.

Silopilot FMM50
Endress+Hauser 19
Operation options
8.1.2 Navigation view
group selectiongroup selection →→
basic setupbasic setup
inputs and outputsinputs and outputs
measurement param.measurement param.
  
1
2
9 Navigation view
1 Functiongroups
2 Operatingelements
The active selection of the function group (here "basic setup") is indicated by a check mark in
front of the menu text.
Operating options
Key Meaning
SMoves the active function group down
OMoves the active function group up
FSwitches to the active function group
8.1.3 Edit view
Entering a value Selecting a value
empty calibr.empty calibr. 
33mm
distance flange todistance flange to
min. fillingmin. filling
  
1
3
4
5
2input input  
not usednot used
boltingbolting
start measurementstart measurement
  
1
3
5
2
10 Edit view
1 Nameoffunction
2 Functionnumber
3 Numericalvalueorselection
4 Helptext
5 Operatingelements

Silopilot FMM50
20 Endress+Hauser
Operation options
Operating options
Key Meaning
SEntering a value
• Activates the edit mode
• Changes the displayed character (9, 8, 7, ... , Z, Y, X, ...)
Selecting a value
Moves the active option down
OEntering a value
• Activates the edit mode
• Changes the displayed character (0, 1, 2, ... , A, B, C, ...)
Selecting a value
Moves the active option up
F• Navigation to the right within a function group
• In edit mode:
- Change to the next character
- At the end, accept the entry by switching to the next function
Editing options
The following characters are available for selection when editing:
• Numerical values: 0 to 9 and "." (period) as the separator in the unit selected
• Tag number (function 080): additionally letters A to Z and "-" (minus)
• Navigation characters:
- "←" goes one or more spaces to the le
- "→" goes one or more spaces to the right
8.1.4 Operating elements
Key Meaning
SEntering a value
Activates the edit mode and reduces the value
Selecting a function group or a value
Moves the active option down
OEntering a value
Activates the edit mode and increases the value
Selecting a function group or a value
Moves the active option up
F• Navigation to the right within a function group
• In edit mode: Accept the value entered
S +O Navigation to the le within a function group
O +F Increases the contrast of the liquid crystal display
S +F Decreases the contrast of the liquid crystal display
S +O +F • Enables or disables hardware locking
• Operating keys have no function on their own
• "man. start" and external start button are not locked
