Endress+Hauser memo-graph RSG10 User manual

Visual Data Manager
memo-graph
Operating manual
BA 153R/09/en/04.04
No.: 510 06012

Endress+Hauser

Visual Data Manager (VDM)
Betriebsanleitung
(Bitte lesen, bevor Sie das Gerät in Betrieb nehmen)
Gerätenummer:...........................
Visual Data Manager (VDM)
Operating instructions
(Please read before installing the unit)
Unit number:................................
Visual Data Manager (VDM)
Mise en service
(A lire avant de mettre l’appareil en service)
N° d’appareil:....................................
Deutsch
1 . . . 58
English
59 . . . 114
Français
115 . . .170
Visual Data Manager
59

CONTENTS Page
1. General 61
2. Check before installing! 61
3. Safety notes/correct use 62
4. Installation/connection/setting up 63
4.1 Installation 63
4.2 Ambient conditions 63
4.3 Connections/terminal layout 64
4.4 Front mounted RS 232 serial interface/
serial operating cable 67
4.5 Ethernet connection 68
5. Setting up unit 69
5.1 Setting up directly on the unit 69
- Start parameter change 69
- The main menu 69
- Selection/change push buttons 70
- Operating principle 70
5.2 Set-up by PC 70
- PC software installation 71
- Advantages of setting up using a PC 71
5.3 Set up using data carrier 71
5.4 List of operating parameters 71
- Basic settings 71
- Analogue inputs 73
- Mathematics channels (option) 77
- Digital inputs (option) 79
- Make groups 85
- Signal analysis 86
-Sundries 87
- Service 90
5.5 Programme/software update using programme diskette at the unit 92
6. Handling in operation 93
- Function keys/softkeys in normal operation 93
- Functions of the LEDs 98
- Internal memory 98
- Function of the diskette drive/data carrier change function 98
7. Serial interface/modem/Ethernet 99
7.1 RS 232 99
7.2 RS 422/RS 485 99
7.3 PROFIBUS DP 99
7.4 Setting up a modem link 100
7.5Ethernet connection(TCP/IP) 101
8. For experienced users: Serial interface
RS 232/RS422/RS 485 transmission protocols 104
8.1 Setting up commands 104
8.2 Command for measured data read out and delete 106
8.3 Read out configuration data (DK) 107
8.4 Read out actual process data 108
9. Technical data 109
10. Accessories/consumables 114
English
Contents
60

1. General
Your new Visual Data Manager (VDM) is constructed with a built-in operating manual!
The simple operating concept of the unit enables a large number of applications to be
set up easily almost without the need for paper. Your VDM displays operating hints on
screen at the touch of a button!
However, this operating manual is still important - it is an extension to the instructions
built into the unit. Here items that cannot be described on the unit in text form or
selection lists are explained.
Alterations that expand the technical capabilities are reserved. In this case details
can differ from those contained in these instructions. This is no longer a problem as
the operating manual is always included in the VDM.
Chapters 4 “INSTALLATION/CONNECTION/SETTING UP” and 5 “SETTING UP UNIT”
describe the in/output connections as well as the programming/settings and the
respective functions.
Chapter 6 “HANDLING IN OPERATION” describes how the final set up unit can be
used, what information is available and how to access this and how to get the best
results from the diskette drive.
2. Check before installing!
Transportation damage?
Attention: Please inform both your supplier and shipping agent!
The correct unit?
Please compare the order code on the legend plate (on the unit) with that on the
delivery note.
Complete delivery?
- Unit (with plug-in screw terminal blocks for power and signal connection,
dependent on the order)
- 2 jack screws for panel mounting
- 1 screw driver, blade size 2.5 mm
- PC operation and setting up software
- Delivery note
Please inform your supplier immediately if anything is missing.
English
1. General / 2. Check before installing!
61

3. Safety notes/correct use
Please take note of
the following characters:
“Hint”: Hints for better installation/operation.
“Attention”: Ignoring this note can lead to damage of the device or faulty operation.
“Danger”: Ignoring this warning can lead to personal injury.
Correct use/
safety notes
This unit is constructed for panel and cabinet installation. It complies with the safety
requirements to EN 61010-1 / VDE 0411 Part 1 and has left our works in perfect and
safe condition.
Danger:
Safe operation can only be guaranteed if all hints and warning notes in these
operating instructions are heeded:
•The unit is only to be operated in installed condition.
•Installation and connection must only be done by skilled and qualified personnel.
Please take care of any required access protection.
•Always connect the earth (ground) protection cable before attempting to connect
any other cable. It can be dangerous if the protection cable is broken.
•Before installing please compare the supply voltage with that on the unit legend
plate.
•Combining low voltage and dangerous voltage connections on the relays is not
permitted.
•A power isolator must be installed within reach of the unit. It must also be identified
as a power isolator.
•A power fuse of <=10 Amps should be installed.
•If it is assumed that the unit cannot be safely operated (e.g. visible damage) it must
be immediately taken out of operation and secured against unintentional use.
•Repairs must only be done by trained service personnel.
Desk top version: Danger:
The power plug may only be connected to a socket with an integrated earth
protection point. This earth protection must not be broken even when operating using
an extension lead.
Relay outputs: U(max.) = 30 V (AC) / 60 V (DC)
3. Safety notes/correct use
62

4. Installation/connection/setting up
4.1 Installation
Prepare the required panel cut-out to 138+1 x 138+1 mm (to DIN 43700). Please take
note of the asymmetrical form of the unit front bezel to the casing. The unit installation
depth is approx. 211 mm.
1. Push the unit through the front of the panel cut-out. In order to avoid overheating
we recommend a spacing of > 10 mm to the rear and other units.
2. Hold the unit horizontally and fix the jackscrews into their respective slots.
(top/bottom or left/right).
3. Tighten the jackscrews evenly using a screwdriver.
Hint:
Further support is only required if the panel material is very thin.
4.2 Ambient conditionsAttention:
Distance the units from strong magnetic fields (check technical data: interference
protection). Surrounding ingress protection to classification IP 54.
Ambient temperature range: 0..50 °C, max. 57 % relative humidity without
condensation.
4. Installation/connection/setting up
63

4.3 Connections/
terminal layout
Hint:
The two central slots can be used by either 8 channel analogue or 15 channel digital
boards (incl. 6 relay outputs). Dependent on application or order.
4. Installation/connection/setting up
64

Connection plan:
Attention:
Should there be a possibility of high energy transients on long signal cables it is
recommended that an overvoltage protector be connected.
Screened signal cables are recommended on the following:
•RTDs, thermo-couples, ranges <1 V.
•When using the serial interfaces.
Power supplies:
115...230 V power supply, 50/60 Hz 24 V power supply, 0/50/60 Hz:
PE: Earth/protection cable PE: Earth/protection cable
N: Neutral N L+: + power supply
(or alternating current)
L: Phase L L-: - power supply
(or alternating current)
Analogue inputs:
The first character (x) of the three digit terminal number is the respective channel
number (1.. to 8..: channels 1 to 8, or A.. to H..: channels 9 to 16).
Current Voltage/thermo-couple RTD
x11 A
x12 +
a
Sense
compensation
x13 --B
x14 +
Digital inputs on the power supply board:
91 Digital input 1
92 Digital input 2
93 Digital input 3
94 Digital input 4
95 Digital input 5
96 Digital input 6
97 Digital input 7
Digital inputs on the digital board (s)
Digital board I Digital board II
191 Digital input 8 391 Digital input 23
192 Digital input 9 392 Digital input 24
193 Digital input 10 393 Digital input 25
4. Installation/connection/setting up
65

Digital board I Digital board II
194 Digital input 11 394 Digital input 26
195 Digital input 12 395 Digital input 27
196 Digital input 13 396 Digital input 28
197 Digital input 14 397 Digital input 29
198 Digital input 15 398 Digital input 30
199 Digital input 16 399 Digital input 31
291 Digital input 17 491 Digital input 32
292 Digital input 18 492 Digital input 33
293 Digital input 19 493 Digital input 34
294 Digital input 20 494 Digital input 35
295 Digital input 21 495 Digital input 36
296 Digital input 22 496 Digital input 37
- Ground digital board I - Ground digital board II
Hint: If the auxiliary power supply is to be used for the digital inputs of the digital
boards, auxiliary power “-” must be connected to the “-” on the digital boards.
Auxiliary voltage for the digital inputs, not stabilised, max. 150 mA:
+ Auxiliary voltage approx. +24 V
- Auxiliary voltage ground
Relay outputs on power supply board:
(Factory settings, can be changed, see “Setting up unit - setting up parameter list -
service")
41 Relay 1, normally closed
42 Relay 1, common
44 Relay 1, normally open
53 Relay 2, Contact 1
54 Relay 2, Contact 2
63 Relay 3, Contact 1
64 Relay 3, Contact 2
73 Relay 4, Contact 1
74 Relay 4, Contact 2
83 Relay 5, Contact 1
84 Relay 5, Contact 2
Open collector output (NPN transistor):
98 Collector
99 Emitter
Relay outputs on digital board (s)
Digital board I Digital board II
151 Relay 6, Contact 1 751 Relay 12, Contact 1
152 Relay 6, Contact 2 752 Relay 12, Contact 2
251 Relay 7, Contact 1 851 Relay 13, Contact 1
252 Relay 7, Contact 2 852 Relay 13, Contact 2
351 Relay 8, Contact 1 951 Relay 14, Contact 1
352 Relay 8, Contact 2 952 Relay 14, Contact 2
4. Installation/connection/setting up
66

Digital board I Digital board II
451 Relay 9, Contact 1 A51 Relay 15, Contact 1
452 Relay 9, Contact 2 A52 Relay 15, Contact 2
551 Relay 10, Contact 1 B51 Relay 16, Contact 1
552 Relay 10, Contact 2 B52 Relay 16, Contact 2
651 Relay 11, Contact 1 C51 Relay 17, Contact 1
652 Relay 11, Contact 2 C52 Relay 17, Contact 2
Interfaces (rear mounted):
Sub-D connector to DIN 41652, socket, 9 pin
Hint: Do not connect unused pins.
Pin RS 232 RS 422 RS 485
PROFIBUS
DP
‘Monitor’
PROFIBUS
DP ‘Slave’
2TxD TxD
3RxDTxD(+)
RxD/TxD
(+)
RXD/TXD
(+) RxD
4 RxD (+)
5 GND GND GND
8 TxD (-) RxD/TxD
(+) RxD/TxD (-)
9 RxD (-)
Housing Screen Screen Screen Screen
Pin layout for cable connection from the rear mounted RS232 interface to a PC or
modem:
Signal
9pin
RS232 at
unit
9pin
RS232 at
PC
25 pin
RS232 at
PC
9pin
RS232 at
modem
25 pin
RS232 at
modem
TxD22332
RxD33223
GND55757
Screen Housing (Housing) (Housing) (Housing) (Housing)
4.4 Front mounted
RS 232 serial
interface/serial
operating cable
4. Installation/connection/setting up
67

4.5 Ethernet connection An IEEE 802.3 compatible connector on a screened RJ45 plug on the rear side of the
device is available as a network connection. The device can be connected to a hub
or switch via this connection. The pin assignment corresponds to a standard MDI
interface (AT&T258), so that a 1:1 cable with a maximum length of 100 metres can be
used here.
LED description
There are three LEDs next to the Ethernet connections. These indicate the status of
the Ethernet interface.
Yellow LED: When the device is transmitting data it flashes irregularly,
otherwise is continuously on.
Green LED: When the device is receiving data it flashes irregularly, otherwise is
continuously on.
Red LED: Is on when the device is connected to a network. If this LED is not
illuminated then communication is impossible.
RJ45 socket (pin assignment AT&T256)
4. Installation/connection/setting up
68

5. Set-up unit
5.1 Set-up direct on
the unit:
The push button functions are displayed on screen directly above the respective
push button.
•Using “ð....” and “...ï” push buttons, other functions of these push buttons can be
selected.
•Free fields mean that the push button has no function at the moment.
Starting parameter changes (from normal operation):
•Operate “....ð”: the push button function changes.
•Operate “Set-up”: the main menu is displayed.
•Select the required chapter by operating the “ñ”or“ò” push buttons.
•Acknowledge the selection by operating “Ô.
•Using the “Help” push button the integrated operating manual (help text in yellow
windows) can be switched on and off.
The main menu:
Individual parameters are shown in chapters in the main menu:
Basic settings General parameters (date, time, setting up release code ...)
Analogue inputs All channel or measurement point specific parameters of the analogue inputs (input
signal, measurement point identifier, limit values, ...)
Mathematics channels
(Option) Parameters for combining analogue channels
Digital inputs
(Option)
All channel specific parameters for the digital channels on the power suply board.
(function, identifiers, limit values, ...)
Digital board(s)
(Option)
All channel specific parameters for the digital channels on the digital input board(s).
(function, identifiers, limit values, ...)
Digital channel
Combination
Only if the digital channels are available. Combines one or more digital channels in a
“virtual channel”. Is handled the same as real inputs
Hint:
If individual chapters are missing
then the unit is not fitted with these
options.
5. Set-up unit
69

Selection/change push button functions:
•“Ô: Start change, acknowledge selection.
•“ñ” or. “ò”: Select parameters.
•“ï“ or. ”ð“: Move cursor - change to next line.
•“ESC”: Abort last operating step; return to previous screen.
Operating principle:
1. Start parameter change with “Ô.
2. Using “ñ”or“ò” scroll values, characters, selection lists.
3. If the parameter is set up correctly acknowledge using “Ô.
Hints:
-Any parameter displayed in grey cannot be selected or changed (only hints or not
available/active option).
-Set-up is always possible using the “0000” setting (as delivered). Set-up can be
protected from unauthorised manipulation by entering a 4 digit secret code. This
code must then be entered whenever setting up changes are done using the front
mounted push buttons.
Tip: Note the secret code. Keep it away from unauthorised personnel.
-Changed settings are only operational when the unit is returned to normal operation
by operating the “ESC” push button a number of times followed by the push button.
Up to this time the unit continues to operate using the previously set parameters.
Attention: Change the diskette/ATA flash card if the old measured data is to be
used again, when new setting up parameters are stored old measured data on both
the diskette/ATA flash card and the internal memory is deleted.
5.2 Set-up by PC The Visual Data Manager can also be set up using a PC. In order to do this the
following is available:
-Front mounted RS 232 operating interface (3.5 mm stereo socket, protected behind
the diskette drive cover)
-Rear mounted RS 232 or RS 422/485 system interfaces.
Make groups
Parameters, for combining/displaying single channels into groups.
Hint: Only channels that are allocated to a group can be displayed or saved,
(internal memory and on diskette).
Channels that are not allocated to groups can however be monitored for limit
infringements or be automatically analysed (select this in order to utilise the
memory to its best).
Signal analysis
All settings required so that the signals can be automatically analysed.
Hint: The signal analysis is stored and can be used on a PC later. This means that
for example daily minima, maxima and averages of a few measurement points can
be read out front end and then displayed as a table or even graphically as a curve.
Helps to optimise memory capacity.
Sundries Interface parameters, memory capacity, simulation, ...
Service General service functions, relay operating modes -
ONLY FOR SERVICE PERSONNEL !!
5. Set-up unit
70

PC software installation
1.Install the PC software delivered with the unit on the computer.
If required the programme operating instructions can be printed out after installation.
2.Initiate the programme.
3.Attention: First connect the stereo plug to the socket on the unit then connect the
interface plug to the PC. When disconnecting do this in the reverse order.
4.Now the unit can be set up using the PC. Please note the operating hints/help
built into the programme.
Advantages of setting up using a PC:
•Unit data is stored in a data base and can be recalled at any time.
•Text input from a keyboard is easier and quicker.
•Using the programme measured values can be read out, archived and displayed
on the PC screen.
Attention:
-The front mounted RS 232 interface has priority over the rear mounted interface (the
rear mounted RS 232 interface is switched off when the stereo plug is inserted).
-Only one interface (RS 232 or RS 422 or RS 485) can be used at any time for setting
up.
5.3 Set up using
data carrier
1. The unit set-up can be copied to a data carrier. First select menu point in the
PC-Software “Display unit set up/add new unit” Select the unit from the list. Then
select menu point “Finished -> Create set-up data carrier (diskette/ATA flash card”.
Now select the required drive in which the data carrier is placed. Once this has been
acknowledged with OK the set-up file (*.rpd) will be generated.
Hint: In order to use this function the unit must already be available in the PC data
bank.
2. Place the parameter diskette into your unit(s), select “Diskette/Set up from diskette”
After a few minutes the unit is available with the new set up installed.
Attention: Once the transfer has been completed remove the set up diskette and
replacethiswithanewdatadiskette.
5.4 List of operating
parameters:
Basic settings:
•Set-ups that are generally valid to the unit, e.g. date, time etc.:
Unit identifierDescription of where the unit is installed (important when using more than one unit).
20 characters.
Hint: This is stored on the data carrier. Graphics and tables in the PC are identified
with this text (important fo example when more than one unit is in operation). The unit
identifier is also available when exporting data into other spread sheet programmes.
5. Set-up unit
71

Actual date Format: DD.MM.YY
Actual time Format: hh:mm, 24 h display
Summer time change
over mode
Function of the summer/normal time change over.
“Automatic”: Changeover to valid EU recommendations.
“Manual”: Changeover times can be set up in the following addresses.
“OFF”: No changeover.
NT/ST region In Europe the summer/normal time changeover occurs at a different time to that in the
USA.Selecttheregioninwhichtheunitistobeinstalled.
Date NT->ST Day on which changeover from normal to summer time occurs. Format: DD.MM.YY
Time NT->ST Time at which the clock increases by 1 hour on changeover from normal to summer
time. Format: hh:mm
Date ST->NT Day on which changeover from summer to normal time occurs. Format: DD.MM.YY
Time ST->NT Time at which the clock decreased by 1 hour on changeover from summer to normal
time. Format: hh:mm
Release code Factory default: “0000”, this means changes possible without security code.
Set individual code: Further setting up changes are only possible after entering
this code.
Tip: Note the code and store out of reach of unauthorised personnel.
Temp. units Selection of temperature units. All directly connected temperature measurement
using thermocouples or RTDs are displayed in the units selected.
ATA operating mode •Barrel memory: Once the ATA flash card is full no further data is stored on the ATA
flash.
Ring memory: The oldest data is always deleted in order to make room for more
up-to-date information.
Pen size normal/wide •Determines with which pen size the analogue signal is drawn (normal = 1 dot using
thin pen, wide (fat) = 2 dots with wide pen)
Warning message at xx
min without ATA flash
•A warning message can be displayed after a preset tme of 1 - 999 minutes after the
ATA flash card has been removed from the unit.
Warning message at
xx %
•Warns, before diskette is 100 % full. The internal (ring) memory continues to be
used during diskette change or when the diskette is full. The new data is then
written on the new diskette after diskette change (important for complete data
archiving).
5. Set-up unit
72

Switch outputWhen warning message “Change diskette” is displayed a relay or open collector
output can be switched. The respective terminal numbers are indicated in brackets.
See “Installation/connection/set-up”.
Acknowledge message“Yes”: The warning message “Change diskette” remains actively displayed until it is
acknowledged by push button.
“No”: The message is not displayed.
Hint: The percentage of diskette space used is always displayed in normal operation
(top right hand of the screen). The same functionality with ATA flash memory card.
Rear illumination
“Screen saver”
Set-up for switching off the screen rear illumination. (Screen saver switching off
increases the life of the rear illumination).
Illumination off after ...Switches the display off xxxx minutes after the last time a push button was used (rear
illumination is switched off). All further functions of the unit continue (green LED is on).
Operating any push button switches the illumination back on. “0000 min” = no switch
off.
Analogue inputs:
•Set-up/limits of analogue values for the measurement points connected.
SignalEach channel selectable. See “Connections/terminal layout”.
Channel identifierIdentifier of the measurement point connected to this channel.
10 character.
Engineering unitsInput of the engineering units used by the measurement point connected to this input
(e.g. bar, °C, m³/h, ...). 5 character.
Decimal pointSelection of the number of decimal points required for the 4 digit measurement value
display.
Range starting pointTransmitters change the measured value into a standard signal.
Example: 0-14 pH from the sensor is changed to 4-20 mA. The range starting point fo
0 - 14 pH is therefore “0“.
5. Set-up unit
73

Range end point The same as range starting point. Here, however, the end value of the range must be
set up e.g. “14“ on a transmitter with 0-14 pH.
Zoom start If the total range of the transmitter is not to be displayed the lower starting value of the
“Zoomed” section can be set in this address (higher resolution is achieved using this
feature).
Example: Transmitter 0-14 pH, required display section 5-9 pH. Set up “5".
Zoom end The same as in “Zoom start”. Here the upper value of the “Zoomed” section is set up.
Example: Transmitter 0-14 pH, required display section 5-9 pH. Set up “9".
Offset Factory default “0". The preset value is added to the real measured value for further
use (display, storage, alarm set point monitor).
Damping/filter The more unwanted interference on the input signal, the higher the value should be
set. Result: fast changes are suppressed (for experts: “low pass 1").
Cold junction
compensation
Only used on direct connection of thermocouples. “Internal”: Compensation of the
error voltage occurring on the connection terminals by measuring the rear panel
temperature. “External x °C/ °F”: Compensation of the error voltage by using
thermostat controlled external comparison points. Recommendation when using
thermocouple type B (Pt30Rh-Pt6Rh): Even without an external comparitor always
set “External (0 °C / 32 °F)” when connecting directly.
Reason: non-linear trace of this thermocouple in the ranges < 50 °C / < 122 °F.
Copy set up Copies the settings of the actual channel to the selected channel (including alarm set
points). The last two characters of the channel identifier of the target channel are
substituted by the channel number.
Integration Set-up only required if this analogue measurement point is to be integrated, e.g. for
quantity measurement. For analysis cycles see “Signal analysis”.
Integration base By using the integration feature quantities (in m³) can be calculated from analogue
signals (e.g. flow in m³/h). Here the required time base must be selected.
Example: ml/s -> time base seconds (s); m³/h -> time base hours (h).
Integration engineering
units
Set up the engineering unit of the value calculated by the integration feature (e.g. m³).
Scrolled display Selection if and with which counter value the instantaneous value is to be alternately
displayed. The analogue value is then displayed for approx. 6 s alternating with the
counter value for approx. 4 s.
Calc. factor It offers the option to convert the integrated values easily. For example, if the
transmitter delivers l/s and the required unit is m³ the integrated value will be
converted to m³ by adjusting the conversion factor to 0.001.
5. Set-up unit
74

Option: Profibus DP
(Monitor)
Set-up only required if a PROFIBUS measurement point is to be used by this channel.
•Slave address
Select the address of the respective sensor. Every sensor “slave” must have an
individual address. The measured value (the digital bus signal) is handled the same
as any conventional analogue measurement point.
Hint: If the slave supplies more than one set of measurements (“Input Index Data” on
multiparameter sensors), each measurement requires an individual channel.
•Index Input _Data
Position, where the measured value information starts in the PROFIBUS transmitter
data set. On single channel units: “000". Please also note details in the sensor
operating manual.
•Data type
Mostly “Floating Point”. Please note the details in the sensor operating manual.
Option: Profibus DP
(Slave)
Using the point Miscelaneous/Interface/Communication the external DP-Slave module
can be selected. This includes Slave address, Baudrate, time out and data
construction (see additional documetation: ZBA117ren).
Hint: Select a slave address smaller than 126.
5. Set-up unit
75

Limits Set-up only required if limits are to be monitored on this channel. It is also possible to
see if the alarm set point is active without haveing to open this menu point (“Limit X
active u“).
Type Select set point type.
Analogue signals: “LV high”: Signal exceeds the preset alarm set point. “LV low”:
Signal falls below the preset alarm set point. “Gradient”: Signal changes too fast.
For quantities (calculated from the analogue using the integration feature): The
counter alarm set point is exceeded within the preset time cycle.
Hint: In order to monitor counter values for alarm conditions the necessary signal
analysis must be active (see chapter “Signal analysis”).
Alarm set point, high/low Analogue alarm set point value in preset engineering units, e.g. in °C, bar, ... .
Alarm set point,
integration
Quantity alarm set point (integrated analogue channel) in the engineering units set up
under “Integration”.
Gradient dy/dt Alarm set point when the signal changes too fast (the signal changes by a value of dy
withinatimeofdt).
Signal change dy Value by which the signal must change within the preset time span in order to be
recognised as an alarm.
Time span dt Time span, within which the signal must change by the preset value in order to be
recognised as an alarm.
Hysteresis type “Percentage %”: set up hysteresis in %. “Absolute”: Hysteresis set up in the preset
engineering units (e.g. in °C, bar, ...).
Hysteresis value The alarm condition is only deleted when the signal has returned to the normal range
by the preset value.
Time delay The signal must have infringed the preset value for, at least, this amount of time
before it can be seen as an alarm condition.
5. Set-up unit
76
