Description of Device Parameters
Proline Promag 300
Modbus RS485
Electromagnetic flowmeter
Menu/Variable
Proline Device
Access status tooling:
Operation
Setup
Diagnostics
Locking status:
Access status tooling:
Enter access code:
System
Sensor
Input
Output
Communication
Application
Diagnostics
P
P
P
P
Expert
GP01053D/06/EN/02.17
71376176
Valid as of version
01.01.zz (Device firmware)

Proline Promag 300 Modbus RS485 Table of contents
Endress+Hauser 3
Table of contents
1 About this document ................ 4
1.1 Document function ..................... 4
1.2 Target group .......................... 4
1.3 Using this document .................... 4
1.3.1 Information on the document
structure ....................... 4
1.3.2 Structure of a parameter
description ..................... 6
1.4 Symbols used .......................... 6
1.4.1 Symbols for certain types of
information .................... 6
1.4.2 Symbols in graphics ............... 7
1.5 Documentation ........................ 7
1.5.1 Standard documentation ........... 7
1.5.2 Supplementary device-dependent
documentation .................. 7
2 Overview of the Expert operating
menu .............................. 8
3 Description of device parameters ... 11
3.1 "System" submenu ..................... 14
3.1.1 "Display" submenu ............... 14
3.1.2 "Configuration backup" submenu .... 28
3.1.3 "Diagn. handling" submenu ......... 31
3.1.4 "Administration" submenu ......... 39
3.2 "Sensor" submenu ...................... 44
3.2.1 "Measured val." submenu .......... 44
3.2.2 "System units" submenu ........... 55
3.2.3 "Process param." submenu ......... 70
3.2.4 "External comp." submenu ......... 83
3.2.5 "Sensor adjustment" submenu ....... 88
3.2.6 "Calibration" submenu ............ 95
3.3 "I/O configuration" submenu .............. 96
3.4 "Input" submenu ....................... 99
3.4.1 "Current input 1 to n" submenu ...... 99
3.4.2 "Status input 1 to n" submenu ...... 102
3.5 "Output" submenu ..................... 104
3.5.1 "Current output 1 to n" submenu .... 104
3.5.2 "Pulse/frequency/switch output
1 to n" submenu ............... 118
3.5.3 "Relay output 1 to n" submenu ..... 138
3.5.4 "Double pulse output" submenu ..... 145
3.6 "Communication" submenu .............. 149
3.6.1 "Modbus config." submenu ........ 150
3.6.2 "Modbus info" submenu .......... 155
3.6.3 "Modbus data map" submenu ...... 156
3.6.4 "Web server" submenu ........... 156
3.6.5 "WLAN settings" submenu ........ 159
3.7 "Application" submenu ................. 166
3.7.1 "Totalizer 1 to n" submenu ........ 167
3.7.2 "Custody transfer" submenu ....... 171
3.8 "Diagnostics" submenu ................. 171
3.8.1 "Diagnostic list" submenu ......... 174
3.8.2 "Event logbook" submenu ......... 179
3.8.3 "Custody transfer logbook" submenu 181
3.8.4 "Device information" submenu ..... 181
3.8.5 "Mainboard module" submenu ..... 185
3.8.6 "Sens. electronic" submenu ........ 186
3.8.7 "I/O module 1" submenu .......... 187
3.8.8 "I/O module 2" submenu .......... 187
3.8.9 "I/O module 3" submenu .......... 189
3.8.10 "Display module" submenu ........ 190
3.8.11 "Data logging" submenu .......... 191
3.8.12 "Min/max val." submenu ......... 199
3.8.13 "Heartbeat" submenu ............ 201
3.8.14 "Simulation" submenu ........... 201
4 Country-specific factory settings .. 212
4.1 SI units ............................ 212
4.1.1 System units .................. 212
4.1.2 Full scale values ............... 212
4.1.3 Output current span ............ 213
4.1.4 Pulse value ................... 213
4.1.5 On value low flow cut off ......... 213
4.2 US units ........................... 214
4.2.1 System units .................. 214
4.2.2 Full scale values ............... 214
4.2.3 Output current span ............ 215
4.2.4 Pulse value ................... 215
4.2.5 On value low flow cut off ........ 216
5 Explanation of abbreviated units .. 217
5.1 SI units ............................ 217
5.2 US units ........................... 217
5.3 Imperial units ....................... 218
6 Modbus RS485 Register
Information ...................... 219
6.1 Notes ............................. 219
6.1.1 Structure of the register
information .................. 219
6.1.2 Address model ................ 219
6.2 Overview of the Expert operating menu .... 220
6.3 Register information .................. 232
6.3.1 "System" submenu .............. 233
6.3.2 "Sensor" submenu .............. 237
6.3.3 "I/O config." submenu ............ 246
6.3.4 "Input" submenu ................ 247
6.3.5 "Output" submenu .............. 248
6.3.6 "Communication" submenu ........ 253
6.3.7 "Application" submenu ........... 255
6.3.8 "Diagnostics" submenu ........... 257
Index ................................. 262

About this document Proline Promag 300 Modbus RS485
4 Endress+Hauser
1 About this document
1.1 Document function
The document is part of the Operating Instructions and serves as a reference for
parameters, providing a detailed explanation of each individual parameter of the Expert
operating menu.
It is used to perform tasks that require detailed knowledge of the function of the device:
• Commissioning measurements under difficult conditions
• Optimal adaptation of the measurement to difficult conditions
• Detailed configuration of the communication interface
• Error diagnostics in difficult cases
1.2 Target group
The document is aimed at specialists who work with the device over the entire life cycle
and perform specific configurations.
1.3 Using this document
1.3.1 Information on the document structure
The document lists the submenus and their parameters according to the structure from the
Expert menu (→  8), which is displayed when the "Maintenance" user role is
enabled.

Proline Promag 300 Modbus RS485 About this document
Endress+Hauser 5
!
Expert
System
Sensor
Communication
Application
Diagnostics
Access status display
Output
Operating menu for experts
Language
Operatation Language
Parameter 1
Setup
Submenu 1
Submenu n
Device tag
Advanced setup Enter access code
Parameter 1
Parameter n
Submenu 1
Submenu n
Diagnostics Parameter 1
Parameter n
Submenu 1
Submenu n
Operating menu for operators and maintenances
Parameter n
Operator
Maintenance
Task-oriented
Function-oriented
Expert
Wizard 1 / Parameter 1
Wizard n / Parameter n
Parameter n
Input
A0029160-EN
 1 Sample graphic for the schematic layout of the operating menu
Detailed information concerning:
• Arrangement of the parameters according to the menu structure of the Operation
menu, Setup menu, Diagnostics menu along with a brief description, see the
Operating Instructions for the device →  7
• Operating philosophy of the operating menu: "Operating philosophy" chapter of the
Operating Instructions for the device →  7

About this document Proline Promag 300 Modbus RS485
6 Endress+Hauser
1.3.2 Structure of a parameter description
The individual parts of a parameter description are described in the following section:
Complete parameter name Write-protected parameter =
Navigation Navigation path to the parameter via the local display (direct access code) or web browser
Navigation path to the parameter via the operating tool
The names of the menus, submenus and parameters are abbreviated to the form in which they appear on
the display and in the operating tool.
Prerequisite The parameter is only available under these specific conditions
Description Description of the parameter function
Selection List of the individual options for the parameter
• Option 1
• Option 2
User entry Input range for the parameter
User interface Display value/data for the parameter
Factory setting Default setting ex works
Additional information Additional explanations (e.g. in examples):
• On individual options
• On display values/data
• On the input range
• On the factory setting
• On the parameter function
1.4 Symbols used
1.4.1 Symbols for certain types of information
Symbol Meaning
Tip
Indicates additional information.
Reference to documentation
A
Reference to page
Reference to graphic
Operation via local display
Operation via operating tool
Write-protected parameter

Proline Promag 300 Modbus RS485 About this document
Endress+Hauser 7
1.4.2 Symbols in graphics
Symbol Meaning Symbol Meaning
1, 2, 3 ... Item numbers A, B, C, ... Views
A-A, B-B, C-C, ... Sections
1.5 Documentation
1.5.1 Standard documentation
Operating Instructions
Measuring device Documentation code
Promag H 300 BA01394D
Promag P 300 BA01395D
1.5.2 Supplementary device-dependent documentation
Special Documentation
Contents Documentation code
Information on the Pressure Equipment Directive SD01614D
Radio approvals for WLAN interface for A309/A310 display module SD01793D
Remote display and operating module DKX001 SD01763D
Contents Documentation code
Heartbeat Technology SD01743D
Web server SD01655D

Overview of the Expert operating menu Proline Promag 300 Modbus RS485
8 Endress+Hauser
2 Overview of the Expert operating menu
The following table provides an overview of the menu structure of the expert operating
menu and its parameters. The page reference indicates where the associated description of
the submenu or parameter can be found.
Expert
Direct access (0106) →  11
Locking status (0004) →  12
Access status (0005) →  13
Ent. access code (0003) →  13
‣System →  14
‣Display →  14
‣Config. backup →  28
‣Diagn. handling →  31
‣Administration →  39
‣Sensor →  44
‣Measured val. →  44
‣System units →  55
‣Process param. →  70
‣External comp. →  83
‣Sensor adjustm. →  88
‣Calibration →  95
‣I/O config. →  96
I/O 1 to n terminals (3902–1 to n) →  97
I/O 1 to n info (3906–1 to n) →  97
I/O 1 to n type (3901–1 to n) →  98

Proline Promag 300 Modbus RS485 Overview of the Expert operating menu
Endress+Hauser 9
Apply I/O config (3907) →  98
Alteration code (2762) →  98
‣Input →  99
‣Current input 1 to n →  99
‣Status input 1 to n →  102
‣Output →  104
‣Curr.output 1 to n →  104
‣PFS output 1 to n →  118
‣Relay output 1 to n →  138
‣Double pulse out →  145
‣Communication →  149
‣Modbus config. →  150
‣Modbus info →  155
‣Modbus data map →  156
‣Web server →  156
‣WLAN settings →  159
‣Application →  166
Reset all tot. (2806) →  166
‣Totalizer 1 to n →  167
‣Custody transfer →  171
‣Diagnostics →  171
Actual diagnos. (0691) →  172
Prev.diagnostics (0690) →  173
Time fr. restart (0653) →  174
Operating time (0652) →  174

Overview of the Expert operating menu Proline Promag 300 Modbus RS485
10 Endress+Hauser
‣Diagnostic list →  174
‣Event logbook →  179
‣Cust.transf.log. →  181
‣Device info →  181
‣Mainboard module →  185
‣Sens. electronic →  186
‣I/O module 1 →  187
‣I/O module 2 →  187
‣I/O module 3 →  189
‣Display module →  190
‣Min/max val. →  199
‣Data logging →  191
‣Heartbeat →  201
‣Simulation →  201

Proline Promag 300 Modbus RS485 Description of device parameters
Endress+Hauser 11
3 Description of device parameters
In the following section, the parameters are listed according to the menu structure of the
local display. Specific parameters for the operating tools are included at the appropriate
points in the menu structure.
Expert
Direct access (0106) →  11
Locking status (0004) →  12
Access status (0005) →  13
Ent. access code (0003) →  13
‣System →  14
‣Sensor →  44
‣I/O config. →  96
‣Input →  99
‣Output →  104
‣Communication →  149
‣Application →  166
‣Diagnostics →  171
Direct access 
Navigation  Expert → Direct access (0106)
Description Use this function to enter the access code to enable direct access to the desired parameter
via the local display. A parameter number is assigned to each parameter for this purpose.
User entry 0 to 65 535
Additional information User entry
The direct access code consists of a 5-digit number (at maximum) and the channel
number, which identifies the channel of a process variable: e.g. 00914-2. In the navigation
view, this appears on the right-hand side in the header of the selected parameter.

Description of device parameters Proline Promag 300 Modbus RS485
12 Endress+Hauser
1
00914-2
A0029414
1 Direct access code
Note the following when entering the direct access code:
• The leading zeros in the direct access code do not have to be entered.
Example: Enter "914" instead of "00914"
• If no channel number is entered, channel 1 is accessed automatically.
Example: Enter 00914 → Assign variable parameter
• If a different channel is accessed: Enter the direct access code with the corresponding
channel number.
Example: Enter 00914-2 → Assign variable parameter
Locking status
Navigation  Expert → Locking status (0004)
Description Displays the active write protection.
User interface • Hardware locked
• CT act.-def.par.
• CT act.-all par.
• Temp. locked
Additional information User interface
If two or more types of write protection are active, the write protection with the highest
priority is shown on the local display. In the operating tool all active types of write
protection are displayed.
Detailed information on access authorization is provided in the "User roles and
associated access authorization" and "Operating concept" sections of the Operations
Instructions for the device →  7
Selection
Options Description
None The access status displayed in the Access status parameter (→  13) applies .
Only appears on local display.
Hardware locked
(priority 1)
The DIP switch for hardware locking is activated on the PCB board. This locks write
access to the parameters (e.g. via local display or operating tool) .
Cust.trans. act.
(priority 2) Only available for Promag H.
The DIP switch for custody transfer mode is activated on the PCB board. This locks
write access to all the parameters (e.g. via local display or operating tool).
For detailed information on custody transfer mode, see the Special
Documentation for the device →  7

Proline Promag 300 Modbus RS485 Description of device parameters
Endress+Hauser 13
Options Description
CT act.-def.par.
(priority 3) Only available for Promag H.
The DIP switch for custody transfer mode is activated on the PCB board. This locks
write access to the defined parameters (e.g. via local display or operating tool).
For detailed information on custody transfer mode, see the Special
Documentation for the device →  7
Temp. locked
(Priority 4)
Write access to the parameters is temporarily locked on account of internal
processes running in the device (e.g. data upload/download, reset etc.). Once the
internal processing has been completed, the parameters can be changed once
again.
Access status
Navigation  Expert → Access status (0005)
Description Displays the access authorization to the parameters via the local display, Web browser or
operating tool.
User interface • Operator
• Maintenance
Factory setting Maintenance
Additional information Description
Access authorization can be modified via the Ent. access code parameter
(→  13).
If additional write protection is active, this restricts the current access authorization
even further.
Display
Detailed information on access authorization is provided in the "User roles and
associated access authorization" and "Operating concept" sections of the Operations
Instructions for the device →  7
Ent. access code
Navigation  Expert → Ent. access code (0003)
Description Use this function to enter the user-specific release code to remove parameter write
protection.
User entry 0 to 9 999

Description of device parameters Proline Promag 300 Modbus RS485
14 Endress+Hauser
3.1 "System" submenu
Navigation  Expert → System
‣System
‣Display →  14
‣Config. backup →  28
‣Diagn. handling →  31
‣Administration →  39
3.1.1 "Display" submenu
Navigation  Expert → System → Display
‣Display
Display language (0104) →  15
Format display (0098) →  16
Value 1 display (0107) →  18
0% bargraph 1 (0123) →  18
100% bargraph 1 (0125) →  19
Decimal places 1 (0095) →  19
Value 2 display (0108) →  20
Decimal places 2 (0117) →  21
Value 3 display (0110) →  21
0% bargraph 3 (0124) →  22
100% bargraph 3 (0126) →  22
Decimal places 3 (0118) →  23
Value 4 display (0109) →  23
Decimal places 4 (0119) →  24

Proline Promag 300 Modbus RS485 Description of device parameters
Endress+Hauser 15
Display interval (0096) →  24
Display damping (0094) →  25
Header (0097) →  26
Header text (0112) →  26
Separator (0101) →  27
Contrast display (0105) →  27
Backlight (0111) →  28
Display language
Navigation  Expert → System → Display → Display language (0104)
Prerequisite A local display is provided.
Description Use this function to select the configured language on the local display.
Selection • English
• Deutsch *
• Français *
• Español *
• Italiano *
• Nederlands *
• Portuguesa *
• Polski *
• русский язык(Ru) *
• Svenska *
• Türkçe *
•中文 (Chinese) *
•日本語 (Japanese) *
•한국어 (Korean) *
•ةّيبَرَعْلا(Ara) *
• Bahasa Indonesia *
•ภาษาไทย (Thai) *
• tiếng Việt (Vit) *
• čeština (Czech) *
Factory setting English (alternatively, the ordered language is preset in the device)
* Visibility depends on order options or device settings

Description of device parameters Proline Promag 300 Modbus RS485
16 Endress+Hauser
Format display
Navigation  Expert → System → Display → Format display (0098)
Prerequisite A local display is provided.
Description Use this function to select how the measured value is shown on the local display.
Selection • 1 value, max.
• Bargr. + 1 value
• 2 values
• Val. large+2val.
• 4 values
Factory setting 1 value, max.
Additional information Description
The display format (size, bar graph etc.) and number of measured values displayed
simultaneously (1 to 4) can be configured. This setting only applies to normal operation.
• The Value 1 display parameter (→  18) to Value 4 display parameter
(→  23) are used to specify which measured values are shown on the local
display and in what order.
• If more measured values are specified than the display mode selected permits, then
the values alternate on the device display. The display time until the next change is
configured via the Display interval parameter (→  24).
Custody transfer mode
Only available for Promag H.
• Once the measuring device has been enabled for custody transfer mode, depending on
the custody transfer approval selected the display can switch between showing the
relevant information and the custody transfer counter.
• In addition, a padlock symbol appears in the header of the display ().
For detailed information on custody transfer mode, see the Special Documentation for
the device →  7

Proline Promag 300 Modbus RS485 Description of device parameters
Endress+Hauser 17
Possible measured values shown on the local display:
"1 value, max." option
X X X X X X XX X
l/h
900.00
A0016529
"Bargr. + 1 value" option
X X X X X X XX X
900.00
900.00 kg/h
l/h
A0013098
"2 values" option
X X X X X X XX X
kg/h
900.00
l/h
900.00
A0013100
"Val. large+2val." option
X X X X X X XX X
kg/h
900.00
1.00 kg/l
900.00 l/h
A0013102
"4 values" option
X X X X X X XX X
900.00 kg/h
900.00 l/h
1.0 kg/l
213.94 kg
A0013103

Description of device parameters Proline Promag 300 Modbus RS485
18 Endress+Hauser
Value 1 display 
Navigation  Expert → System → Display → Value 1 display (0107)
Prerequisite A local display is provided.
Description Use this function to select one of the measured values to be shown on the local display.
Selection • Volume flow
• Mass flow
• Correct.vol.flow
• Flow velocity
• Conductivity *
• CorrConductivity *
• Totalizer 1
• Totalizer 2
• Totalizer 3
• Curr.output 1
• Curr.output 2 *
• Temperature *
• Electronic temp.
Factory setting Volume flow
Additional information Description
If several measured values are displayed at once, the measured value selected here will be
the first value to be displayed. The value is only displayed during normal operation.
The Format display parameter (→  16) is used to specify how many measured
values are displayed simultaneously and how.
Custody transfer mode
Only available for Promag H.
Once the measuring device has been enabled for custody transfer mode, depending on the
custody transfer approval selected the display can switch to show the relevant information.
For detailed information on custody transfer mode, see the Special Documentation for
the device →  7
Dependency
The unit of the displayed measured value is taken from the System units submenu
(→  55).
0% bargraph 1 
Navigation  Expert → System → Display → 0% bargraph 1 (0123)
Prerequisite A local display is provided.
* Visibility depends on order options or device settings

Proline Promag 300 Modbus RS485 Description of device parameters
Endress+Hauser 19
Description Use this function to enter the 0% bar graph value to be shown on the display for the
measured value 1.
User entry Signed floating-point number
Factory setting Country-specific:
• 0 l/h
• 0 gal/min (us)
Additional information Description
The Format display parameter (→  16) is used to specify that the measured value
is to be displayed as a bar graph.
User entry
The unit of the displayed measured value is taken from the System units submenu
(→  55).
100% bargraph 1 
Navigation  Expert → System → Display → 100% bargraph 1 (0125)
Prerequisite A local display is provided.
Description Use this function to enter the 100% bar graph value to be shown on the display for the
measured value 1.
User entry Signed floating-point number
Factory setting Depends on country and nominal diameter →  212
Additional information Description
The Format display parameter (→  16) is used to specify that the measured value
is to be displayed as a bar graph.
User entry
The unit of the displayed measured value is taken from the System units submenu
(→  55).
Decimal places 1 
Navigation  Expert → System → Display → Decimal places 1 (0095)
Prerequisite A measured value is specified in the Value 1 display parameter (→  18).
Description Use this function to select the number of decimal places for measured value 1.

Description of device parameters Proline Promag 300 Modbus RS485
20 Endress+Hauser
Selection • x
• x.x
• x.xx
• x.xxx
• x.xxxx
Factory setting x.xx
Additional information Description
This setting does not affect the measuring or computational accuracy of the device.
The arrow displayed between the measured value and the unit indicates that the
device computes with more digits than are shown on the local display.
Value 2 display 
Navigation  Expert → System → Display → Value 2 display (0108)
Prerequisite A local display is provided.
Description Use this function to select one of the measured values to be shown on the local display.
Selection • None
• Volume flow
• Mass flow
• Correct.vol.flow
• Flow velocity
• Conductivity *
• CorrConductivity *
• Temperature *
• Electronic temp.
• Totalizer 1
• Totalizer 2
• Totalizer 3
• Curr.output 1
• Curr.output 2 *
• Curr.output 3 *
• Curr.output 4 *
• Cust.trans.count *
Factory setting None
Additional information Description
If several measured values are displayed at once, the measured value selected here will be
the second value to be displayed. The value is only displayed during normal operation.
The Format display parameter (→  16) is used to specify how many measured
values are displayed simultaneously and how.
Dependency
The unit of the displayed measured value is taken from the System units submenu
(→  55).
* Visibility depends on order options or device settings
