Brief Operating Instructions
Soliwave FDR16/FQR16
Microwave barrier
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation:
Available for all device versions via:
• Internet: www.endress.com/deviceviewer
• Smart phone/tablet: Endress+Hauser Operations App

Soliwave FDR16/FQR16
2Endress+Hauser
Liquiphant FTL41
2 Endress+Hauser
Order code:
Ext. ord. cd.:
Ser. no.:
www.endress.com/deviceviewer Endress+Hauser
Operations App
XXXXXXXXXXXX
XXXXX-XXXXXX
XXX.XXXX.XX
Serial number
1.
3.
2.
A0023555

Soliwave FDR16/FQR16
Endress+Hauser 3
Table of contents
1 About this document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Basic safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Requirements for the personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.3 Workplace safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 Operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.5 Product safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Incoming acceptance and product identication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1 Incoming acceptance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2 Product identication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.3 Storage and transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.1 Mounting conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.2 Mounting the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.3 Post-installation check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.1 Connection requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.2 Connecting the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.3 Post-connection check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6 Operation options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.1 Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.2 Activation parameterization mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.3 Automatic adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.4 Set process window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7.5 Set switching delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7.6 Reset to factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.7 Perform function test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Table of contents

Soliwave FDR16/FQR16
4Endress+Hauser
About this document
1 About this document
1.1 Symbols
1.1.1 Safety symbols
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
serious or fatal injury.
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
This symbol contains information on procedures and other facts which do not result in perso-
nal injury.
1.1.2 Electrical symbols
Ground connection
Grounded clamp, which is grounded via a grounding system.
1.1.3 Symbols for certain types of information
Permitted
Procedures, processes or actions that are permitted.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information
Reference to documentation
Reference to another section
, , Series of steps
1.1.4 Symbols in graphics
A, B, C... View
1, 2, 3 ... Item numbers
-
Hazardous area
.
Safe area (non-hazardous area)

Soliwave FDR16/FQR16
Endress+Hauser 5
Basic safety instructions
1.1.5 Device-specic symbols
LED on
Indicates an illuminated LED
LED o
Indicates an non-illuminated LED
LED undened
Indicates an undened or arbitrary light state of the LED
Free path
Indicates the free path between FDR and FQR
Covered path
Indicates the covered path between FDR and FQR
2 Basic safety instructions
2.1 Requirements for the personnel
The personnel must fulll the following requirements to carry out the necessary tasks, e. g.,
commissioning and maintenance:
‣ Trained, qualied specialists must have a relevant qualication for the specic function and
task
‣Are authorized by the plant owner/operator
‣Are familiar with federal/national regulations
‣Must have read and understood the instructions in the manual and supplementary docu-
mentation
‣Follow instructions and comply with conditions
2.2 Designated use
Use the microwave barrier only for level detection and counting and control purposes. Impro-
per use can pose hazards. Ensure that the measuring device is free of defects while it is in
operation.
• Use the measuring device only for media to which the process-wetted materials have an
adequate level of resistance
• Do not exceed or drop below the limit values for the measuring device
 TI01564F
2.2.1 Incorrect use
The manufacturer is not liable for damage caused by improper or non-designated use.
Residual risks
Due to heat transfer from the process, the temperature of the electronics housing and the
assemblies contained therein may rise to 70 °C (158 °F) during operation.
Danger of burns from contact with surfaces!
‣If necessary, ensure protection against contact to prevent burns.

Soliwave FDR16/FQR16
6Endress+Hauser
Incoming acceptance and product identication
2.3 Workplace safety
For work on and with the device:
‣Wear the required protective equipment according to federal/national regulations.
2.4 Operational safety
Risk of injury!
‣Operate the device in proper technical condition and fail-safe condition only.
‣The operator is responsible for interference-free operation of the device.
2.5 Product safety
The devices of the microwave barrier are designed in accordance with good engineering
practice to meet state-of-the-art safety requirements, has been tested, and le the factory in a
condition in which it is safe to operate.
They meet general safety standards and legal requirements. They also complies with the EU
directives listed in the device-specic EU Declaration of Conformity. Endress+Hauser conrms
this by axing the CE mark to the devices.
3 Incoming acceptance and product identication
3.1 Incoming acceptance
Check the following during goods acceptance:
Are the order codes on the delivery note and the product sticker identical?
Are the goods undamaged?
Do the nameplate data match the ordering information on the delivery note?
 If required (see nameplate): Are the Safety Instructions, e. g. XA, provided?
Is the device properly secured?
If one of these conditions is not met, please contact the manufacturer's sales oce.
3.2 Product identication
The measuring device can be identied in the following ways:
• Nameplate data
• Extended order code with breakdown of the device features on the delivery note
• Enter serial number from nameplates in W@M Device Viewer (www.endress.com/
deviceviewer): All of the information on the measuring device is displayed along with an
overview of the scope of technical documentation provided
• Enter the serial number on the nameplate into the Endress+Hauser Operations App or use
the Endress+Hauser Operations App to scan the 2-D matrix code (QR Code) on the name-
plate

Soliwave FDR16/FQR16
Endress+Hauser 7
Incoming acceptance and product identication
3.2.1 Nameplate
Soliwave 1
Order code:
2
Ext. ord. cd.:
Ser.-No.:
3

3
4
1 Nameplate data
1 Manufactureraddress
2 Order number, external order code, serial number
3 Technical data
4 Approval-specificinformation
3.2.2 Manufacturer address
Endress+Hauser SE+Co. KG
Hauptstraße 1
79689 Maulburg, Germany
3.3 Storage and transport
3.3.1 Storage conditions
Use original packaging.
3.3.2 Storage temperature
→ 10
3.3.3 Transporting the device
Transport the device to the measuring point in the original packaging.

Soliwave FDR16/FQR16
8Endress+Hauser
Mounting
4 Mounting
4.1 Mounting conditions
Minimization of application-specic inuences
→  TI01564F "Performance characteristics"
4.1.1 Mounting position
Checking the alignment → Position of potential equalization terminal
(A= same direction for both devices; B= one device rotated by 90°)
β
BA
α
0000000005
2 Mounting position
A Detectionrange0.5to20m(19.7to787.4in)
B Detectionrange0.12to0.5m(4.7to19.7in)
α Antennaopeningangleapprox.12°
β 90°
4.1.2 Reector operation
Arrange devices symmetrically to the reector (entrance angle = exit angle).
Range reduction per reector: 10 %

Soliwave FDR16/FQR16
Endress+Hauser 9
Mounting
4.1.3 Optimization of the signal quality
It is possible to optimize the signal quality by moving FQR16 and FDR16 on their longitudinal
axis by a, b = ±10 mm (±0.4 in) aer an automatic adjustment has been performed.
a
b
FQR16 FDR16
0000000003
3 Optimizationofthesignalquality
4.1.4 Parallel operation
αα
A
D
0000000009
4 Parallel operation
A Distance between microwave barriers
D Detection range
α 90°

Soliwave FDR16/FQR16
10 Endress+Hauser
Mounting
• Recommendation under ideal conditions: A ≥ D/2
• Stronger reections → increase A
4.1.5 Operating temperature range
-20 to +60 °C (-4 to +140 °F)
4.1.6 Process adapter
→  TI01564F "Accessories"
• Weld-in or screw-in adapter type FAR52
• Welding sleeve, counternuts and mounting bracket
• Plug made of PTFE or aluminum oxide ceramics type FAR54
• Sight glass fitting
• Process nozzle type FAR50
• Insertion adapter type FAR51 for process nozzles
• High pressure and high temperature adapter
4.1.7 Mounting dimensions
20 (0.79) 55 (2.17)40 (1.57)
28 (1.10)
A
70  (2.76)
90 (3.54)
60

(2.36)
110 (4.33)
110 (4.33)
G1
G1½
1½NPT
0000000012
5 Mountingdimensions.Unitofmeasurementmm(in)
A 2³⁄₈"(60.325mm/2.375in)

Soliwave FDR16/FQR16
Endress+Hauser 11
Mounting
4.2 Mounting the device
4.2.1 Mounting with connection thread
A B
2 ³⁄₈"55
2
0000000061
6 Mounting with connection thread
A 1½NPT
B G1/G1½
Screw in conical (A) or cylindrical (B) connection thread.
Align the housing of the electronics (potential equalization terminal of both devices must
point in the same direction).
Fix the housing in place.
Seal: to be provided by the customer

Soliwave FDR16/FQR16
12 Endress+Hauser
Mounting
4.2.2 Mounting alternatives G thread
• Mounting with welding (A): Screw in the device as far as it will go.
• Mounting in existing thread (B): Screw in the device flush with the inner wall and lock it
with a counternut.
A B
1 2
0000000014
7 Mounting alternatives G thread
1 WeldingsleeveG1
2 CounternutG1½
Seal: to be provided by the customer

Soliwave FDR16/FQR16
Endress+Hauser 13
Mounting
4.2.3 Mounting without contact with the process
• Risk of condensate formation on the inner process wall → plug 2
• A minimize → minimize signal attenuation
• Observe maximum temperature T
D
1 2
A
T
0000000021
8 Mountinginfrontofmicrowave-impermeableprocesswall
1 Microwave-permeableplug
2 Microwave-permeableplugincaseofcondensateformationontheinnerprocesswall
4.2.4 Mounting with accessories
→  TI01564F "Accessories"
Observe the enclosed instructions enclosed with the accessories!
4.3 Post-installation check
Is the device undamaged (visual inspection)?
 Does the device conform to the measuring point specications?
For example:
• Process temperature
• Process pressure
• Ambient temperature
Are the measuring point number and labeling correct (visual inspection)?
Is the device adequately protected against precipitation and direct sunlight?
Is the device properly secured?

Soliwave FDR16/FQR16
14 Endress+Hauser
Electrical connection
5 Electrical connection
For a device for the hazardous area:
Observe the instructions in the Ex documentation (XA).
5.1 Connection requirements
5.1.1 Connect potential equalization
• The potential equalization must be connected to the external ground terminal on the device.
• For optimum electromagnetic compatibility, keep the potential equalization line as short as
possible.
• The recommended cable cross-section is 2.5 mm2.
• The potential equalization of the FDR16/FQR16 must be included in the local potential
equalization.
5.1.2 Connecting cable requirements
• Permissible temperature range → 10
• .IP69 / -IP67
• Connection cable FQR16 max. 2.5 Ω/core / Connecting cable FDR16 with FQR16 max. 5 Ω/
core
• Total capacity < 100 nF
• Pre-fabricated connection and interconnection cables →  TI01564F "Accessories"
5.2 Connecting the device
5.2.1 Wiring
A→1 2
FQR16 FDR16
0000000004
9 Wiring
A Supplyandsignalcircuit
1 ConnectioncablewithM12right-anglesocket
2 ConnectingcablewithM12right-angleplugandM12right-anglesocket

Soliwave FDR16/FQR16
Endress+Hauser 15
Electrical connection
Supply voltage
• U = 18 to 30 V DC
• In accordance with IEC/EN61010 a suitable circuit breaker must be provided for the measu-
ring device.
• Voltage source: Non-hazardous contact voltage or Class 2 circuit (North America).
Power consumption
P ≤ 2.4 W
Current consumption
I ≤ 120 mA (without load)
Load
Max. 200 mA
Switching output
• 3-wire DC-PNP (positive voltage signal at the switching output of the electronics)
• 2 DC-PNP outputs, antivalent switched
The devices are internally equipped with a ne-wire fuse 500 mA (slow-blow) according
to IEC 60127-2, this cannot be changed by the user in the event of a fault.
5.2.2 Pin assignment
FQR16
K
1 K2
3 2
4 1
L- L+
0000000006
10 Pinassignmentforsupplyvoltageandoutputcircuit
Kx External load
Switching output
Point level Signal strength (LED
white) Sensor state Switching output
MAX safety MIN safety
LED on or ashing fast
(approx. 9 to 15 Hz)
1 2
41
LED o or ashing slowly
(approx. 2 to 8 Hz)
21
1 4

Soliwave FDR16/FQR16
16 Endress+Hauser
Electrical connection
Function test
Point level Sensor state Error/Warning Switching output
Warning
LED ashing
1 2
41
21
1 4
/
Error
LED lights up permanently
21
41
5.3 Post-connection check
Is the device or cable undamaged?
Do the cables used comply with the requirements?
Do the mounted cables have adequate strain relief?
 Are the connectors rmly tightened?
 Does the supply voltage match the specications on the nameplate?
No reverse polarity, is terminal assignment correct?
If supply voltage is present, is the green LED lit?

Soliwave FDR16/FQR16
Endress+Hauser 17
Operation options
6 Operation options
5
4
3
2
16
7
8
0000000010
11 DisplayandoperatingelementsoftheFDR16
1 Signalstrength(LEDwhite)
2 Onlyforparameterization:LEDyellow
3 Sensorstate(LEDyellow)
4 Operation(LEDgreen)
5 Error/warning(LEDred)
6 Parameterizationpointautomaticadjustment
7 Parameterizationpointprocesswindow
8 Parameterizationpointswitchdelay

Soliwave FDR16/FQR16
18 Endress+Hauser
Operation options
Light signals (LEDs)
Display Meaning
Operation
LED lights up: Device is ready for operation (supply voltage is applied)
LED ashes: Device is in parameterization mode (→ 19)
Error/Warning
LED lights up: Error/device failure (unrecoverable error)
LED ashes: Warning/maintenance required (recoverable error)
Sensor state
LED o: Free path
LED on: Covered path
For parameterization only
Signal strength
Light state (o, 2 to 15 Hz or permanently lit) is proportional to the
strength of the signal
On-site operation
0000000011
12 On-site operation
Place the operating magnet on the marked surfaces of the FDR16 for operation (north pole
visible as shown).

Soliwave FDR16/FQR16
Endress+Hauser 19
Commissioning
7 Commissioning
The microwave barrier is ready for operation a maximum of 3 s aer the supply voltage is
applied.
Initial setup → 7.2 ... 7.5
7.1 Function check
Function check
• "Post-installation check" checklist
• "Post-connection check" checklist
7.2 Activation parameterization mode
Setting options only available with activated parameterization mode (7.3 ... 7.5)
Activation parameterization mode
Power supply o: Operating magnet on "Auto Span", "Process Window" or "Switch Delay"
Power supply on: Initialization → green LED (operation) ashes slowly
Remove operating magnet → parameterization mode (green LED continues to ash slowly)
• The device continues to operate normally in the background depending on the current
settings, so that, for example, exceeding the point level leads to a switchover of the signal
output.
• 10 minutes no action → parameterization mode is terminated (device switches to normal
operation)
• The parameterization mode can also be terminated by a voltage reset.
7.3 Automatic adjustment
• Automatic adjustment of the process-dependent detection range.
• To be performed once during commissioning with free path
Perform automatic adjustment
Operating magnet on "Auto Span" → green LED ashes quickly
Remove the operating magnet within 10 seconds:
→ green LED lights up for 2 s
→ automatic adjustment successfully performed
• Automatic adjustment not feasible (for example, with covered path) → warning
• After an automatic adjustment, the white LED (signal strength) lights up permanently if the
signal strength is sufficiently high and there is a free path.
• When the path is covered, the yellow LED (sensor status) indicates the covered path, and
the white LED is off or flashing at a low frequency. If this is not the case, the process win-
dow must then be adjusted.

Soliwave FDR16/FQR16
20 Endress+Hauser
Commissioning
7.4 Set process window
• If the point level cannot be reliably detected after an automatic adjustment because the
medium to be detected does not dampen sufficiently, the process window must reduced step
by step.
• An enlargement of the process window is also possible. This is useful if, for example, ma-
terial is conveyed through the detection range of the microwave barrier due to the process,
which leads to attenuation of the microwave.
Customize process window
Operating magnet on "Process Window":
→ green LED ashes quickly
→ display (5 s) current process window
Continue to stop operating magnet → every 5 s change to next process window
Remove operating magnet → last displayed process window selected
Display Meaning
100 % (for very good damping media)
70 % (for good damping media)
50 % (factory setting)
30 % (for smaller damping media)
15 % (for small damping media)
7.5 Set switching delay
A switching delay is helpful, for example, if the signal strength uctuates strongly, so that the
outputs only switch when the switching point is exceeded or undershot for a correspondingly
long time.
Set switching delay
Operating magnet on "Switch Delay":
→ green LED ashes quickly
→ display (5 s) current switching delay
Continue to stop operating magnet → every 5 s change to next switching delay
Remove operating magnet → last displayed switching delay selected
