Technical Information
RIA14
Loop powered field indicator
With explosion proof enclosure (according to Ex d)
Application
• Oil & gas
• Petrochemical industry
• System and apparatus engineering
• Outdoor applications
• Laboratory facilities
• Process data acquisition and monitoring
• Optional: stainless steel housing
Your benefits
• Loop-powered indicator in single compartment housing
• 5-digit LC display, character height 20.5 mm (0.8")
• Illuminated display, rotatable in 90° steps
• Trend bargraph in increments of 10%
• Measuring range display from -19999 to 99999
• Digital limit switch
• Freely programmable units
• 3-key operation
• Approvals: ATEX, IECEx, FM, CSA, TIIS, UL listed,
GL marine certificate
•3cableentries
• Configuration with FieldCare PC software
• Configuration without power supply using setup box

RIA14
2Endress+Hauser
Function and system design
Measuring principle
a0011145-en
Example of an application of the field indicator
The indicator records an analog measuring signal and shows this on the display. The LC display shows
the current measured value digitally and as a bargraph with limit value violation signalling. The
indicator is looped into the 4 to 20 mA circuit and obtains the required energy from there.
Measuring system Microcontroller controlled indicator in single chamber field housing with illuminated LC display. The
measuring range, decimal point and offset of the indicator can be configured comfortably by means of
three keys in the device with the housing open or by means of a PC with the FieldCare PC software.
Input
Measured variable Current
Measuring range 4 to 20 mA (reverse polarity protection)
Output
Output signal Digital limit switch
Passive, open collector:
Imax = 200 mA
Umax= 35 V
Ulow/max = < 2 V at 200 mA
Max. reaction time to limit value = 250 ms
Temperature range: -20 to +80 °C (-4 to +176 °F)
Signal on alarm • No measured value visible on the LC display, no background illumination.
• Open Collector inactive.
Transmission behavior The indicator allows the HART®transmission protocol to pass unimpeded.

RIA14
Endress+Hauser 3
Power supply
Terminal assignment
a0010946-en
Terminal assignment of the field indicator
Supply voltage Supply by means of the 4 to 20 mA current loop.
Voltage drop • Line voltage drop < 3.6 V at 3 - 22 mA
• Max. line voltage drop < 6 V at max. short-circuit current 200 mA
Terminals Cables / wires up to max. 2.5 mm2(14 AWG) plus ferrule
Cable entry The following cable entries are available:
•ThreadNPT1/2
•ThreadM20
•ThreadG1/2
• 2x gland NPT1/2 + 1x blind plug
• 2x gland M20 + 1x blind plug
Terminal Terminal assignment Input and output
+Measuring signal (+) 4 to 20 mA Signal input
-Measuring signal (-) 4 to 20 mA Signal input
1Terminal for further instrumentation Support terminal
2Digital limit switch (collector) Switch output
3Digital limit switch (emitter) Switch output

RIA14
4Endress+Hauser
Performance characteristics
Reference operating
conditions
T= 25 °C (77 °F)
Maximum measured error < 0.1% of scaled display range
Influence of ambient
temperature
Effect on the accuracy when ambient temperature changes by 1 K (1.8 °F): 0.01%
Installation
Mounting location Wall or pipe mounting (see 'Accessories')
Orientation No restrictions, the orientation is determined by the readability of the display.
Environment
Ambient temperature range -40 to +80 °C (-40 to +176 °F)
-20 to +80 °C (-4 to +176 °F) when the Open Collector output is used
Storage temperature -40 to +80 °C (-40 to +176 °F)
Electrical safety As per IEC 61010-1,
UL61010-1,
CSA C22.2 No. 1010.1-92
Climate class As per IEC 60 654-1, Class C
Degree of protection IP 67, NEMA 4X (not evaluated by UL)
Shock and vibration
resistance
3g / 2 to 150 Hz as per IEC 60 068-2-6
Condensation Permitted
Installation category 1 to IEC 61010
Pollution degree 2 to IEC 61010
Electromagnetic
compatibility (EMC)
• EN 61326 (IEC 61326):
Electromagnetic compatibility (EMC requirements)
•NAMUR(NE21):
Association for Standards for Control and Regulation in the Chemical Industry
The display can react slowly for temperatures < -20 °C (< -4 °F).
Readability of the display cannot be guaranteed at temperatures < -30 °C (-22 °F).

RIA14
Endress+Hauser 5
Mechanical construction
Design, dimensions Die cast aluminum housing for general purpose or as option stainless steel housing
a0011152
Data in mm (data in inches in brackets)
• Electronics compartment and connection compartment together in the single chamber housing
• Display can be rotated in 90°-stages
Weight • Approx. 1.6 kg (3.53 lb) (aluminium housing)
• Approx. 4.2 kg (9.26 lb) (stainless steel housing)
Material Housing Nameplate
Die-cast aluminum AlSi10Mg with powder coating on
polyester basis
Aluminum AlMgl, anodized in black
Stainless steel 1.4435 (AISI 316L), as an option 1.4401 (AISI 316)

RIA14
6Endress+Hauser
Operability
Local operation
a0011157
LC display of the field indicator (illuminated, pluggable in 90° stages)
Item 1: bargraph display in increments of 10% with indicators for measuring range undershoot (item 1a)/overshoot (item 1b)
Item 2: measured value display, character height 20.5 mm (0.8")
Item 3: 14-segment display for units and information messages
Item 4: symbol "programming disabled"
Item 5: unit "%"
Item 6: warning symbol "failure"
•Displayrange
-19999 to +99999
•Offset
-19999 to +99999
• Signalling
Measuring range overshoot/undershoot
• Limit value violation
Lower/upper limit value exceeded
Operating elements
3-key operation (-/+/E) integrated in device, access with housing open
Remote operation Configuration
The device is configured with the FieldCare PC operating software. FieldCare Device Setup forms part
of the scope of supply of Commubox FXA291 or TXU10-AC (see ‘Accessories’) or can be downloaded
free of charge from the Internet at www.endress.com.
Interface
Configuration interface at device; connection to PC via configuration cable (see "Accessories").
Configurable device parameters (selection)
Measuring dimension, measuring ranges (linear/square), setup block using user code, failsafe mode,
digital filter (damping), offset, limit value (min/max/alarm), alarm limit values freely adjustable.

RIA14
Endress+Hauser 7
a0011146-en
Configuration with PC operating software.
Certificates and approvals
CE mark The device complies with the legal requirements of the EC directives. Endress+Hauser confirms that
the device has been successfully tested by affixing to it the CE mark.
Ex approvals Information about currently available Ex versions (ATEX, FM, CSA, etc.) can be supplied by your E+H
Sales Center on request. All explosion protection data are given in a separate documentation which is
available upon request.
Marine approval Germanischer Lloyd marine certificate
Other standards and
guidelines
• IEC 60529: Degree of protection by housing (IP-Code)
• IEC 61010-1: Safety requirements for electrical measurement, control and laboratory
instrumentation.
• IEC 61326-series: Electrical equipment for measurement, control and laboratory use - EMC
requirements.
• NAMUR: User association of automation technology in process industries (www.namur.de)
• NEMA: Standardization association for the electrical industry in North America.
UL Recognized component to UL 3111-1
CSA GP CSA General Purpose

RIA14
8Endress+Hauser
Ordering information
Detailed ordering information is available from the following sources:
• In the Product Configurator on the Endress+Hauser website: www.endress.com É Select
country É Instruments É Select device É Product page function: Configure this product
• From your Endress+Hauser Sales Center: www.endress.com/worldwide
Product Configurator - the tool for individual product configuration
• Up-to-the-minute configuration data
• Depending on the device: Direct input of measuring point-specific information such as measuring
range or operating language
• Automatic verification of exclusion criteria
• Automatic creation of the order code and its breakdown in PDF or Excel output format
• Ability to order directly in the Endress+Hauser Online Shop

RIA14
Endress+Hauser 9
Accessories
Accessories
Documentation
• Overview brochure: System components: FA00016K/09
• Operating Instructions for 'RIA14 field indicator': BA00278R/09
• Supplementary Ex documentation:
ATEX II2(1)G EX ib[ia] IIC T6/T5/T4: XA090R/09/a3
ATEX II2G Ex d IIC T6/T5/T4: XA091R/09/a3
ATEX 2D Ex tD A21 IP67 T110°C: XA092R/09/a3
Order No. Name
FXA291 Commubox FXA291 incl. FieldCare Device Setup and DTM library
TXU10-AC Commubox TXU10 incl. FieldCare Device Setup and DTM library
