Enerpac EBH35 User manual

1
L4312 Rev. B 10/18 EN
1.0 SAFETY
1.1 Introduction
Read all instructions carefully. Follow all recommended
safety precautions to avoid personal injury as well
as damage to the product and/or damage to other
property. Enerpac cannot be responsible for any
damage or injury from unsafe use, lack of maintenance
or incorrect operation. Do not remove warning labels,
tags, or decals. In the event any questions or concerns
arise, contact Enerpac or a local Enerpac distributor for
clarification.
If you have never been trained on high-pressure hydraulic
tool safety, consult your distributor or service center for
information about an Enerpac hydraulic safety course.
This manual follows a system of safety alert symbols,
signal words and safety messages to warn the user of
specific hazards. Failure to comply with these warnings
could result in death or serious personal injury, as well
as damage to the equipment or other property.
The Safety Alert Symbol appears throughout
this manual. It is used to alert you to
potential physical injury hazards. Pay close
attention to Safety Alert Symbols and obey
all safety messages that follow this symbol to avoid the
possibility of death or serious personal injury.
Safety Alert Symbols are used in conjunction with certain
Signal Words that call attention to safety messages or
property damage messages and designate a degree or
level of hazard seriousness. The Signal Words used in
this manual are DANGER, WARNING, CAUTION and
NOTICE.
NOTICE:
DANGER
Indicates a hazardous situation that,
if not avoided, will result in death or
serious personal injury
NOTICE:
WARNING
Indicates a hazardous situation that,
if not avoided, could result in death
or serious personal injury.
NOTICE:
CAUTION
Indicates a hazardous situation that,
if not avoided, could result in minor
or moderate personal injury.
NOTICE
Indicates information considered
important, but not hazard related
(e.g. messages relating to property
damage). Please note that the Safety
Alert symbol will not be used with this
signal word.
1.2 Hydraulic Cutter Safety Precautions
NOTICE:
WARNING Failure to observe and comply with the
following precautions and instructions may result in
death or serious personal injury. Property damage
could also occur.
• Read and completely understand the safety
precautions and instructions in this manual. Always
follow all safety precautions and instructions,
including those that are contained within the
procedures of this manual.
• Read this manual before operating the cutter, or
before performing any adjustments, inspections,
maintenance or repairs.
• Follow all instructions and heed all precautions
stated in this manual.
• Keep this manual for future reference in a place that
is accessible to all persons operating or servicing the
cutter.
POWERFUL SOLUTIONS. GLOBAL FORCE.
Instruction Sheet
Hydraulic Bar Cutter
Model EBH35
INDEX
1.0 SAFETY .............................1
2.0 PRODUCT DATA ......................5
3.0 CONFORMANCE TO NATIONAL AND
INTERNATIONAL STANDARDS ...........6
4.0 DESCRIPTION ........................6
5.0 RECEIVING INSTRUCTIONS .............6
6.0 SET-UP .............................6
7.0 CUTTER SAFETY GUARD ...............9
8.0 CUTTER OPERATION .................10
9.0 MAINTENANCE ......................13
10.0 STORAGE .........................15
11.0 TROUBLESHOOTING ................16

2
• Place the tool horizontally on a substantial work
surface. The work surface must have a rated weight
capacity that exceeds the weight of the cutter and of
the material being cut.
• Fragments and splinters may be ejected from the
cutter during normal use. The end of the material
being cut may become a projectile as it separates
during cutting. Stay clear of the cutting head and
surrounding area during operation. Always wear face
and eye protection.
• As needed, remove any foreign objects from the
cutting head that could damage the cutter and/
or injure the operator. Before removing any foreign
objects, always stop the pump, relieve hydraulic
pressure and disconnect pump from AC power
supply.
• Avoid touching the cutter's metal surfaces during
operation and after the cutter has been in use. Be
aware of the risk of burns if the cutter becomes hot.
• Do not use the cutter for activities other than those
it was approved and designed to perform. Refer to
Section 8.1 of this manual for additional information
regarding foreseen use.
• Use the cutter lifting eye and appropriately rated lifting
equipment if it is necessary to lift or suspend the tool by
mechanical means.
• Do not exceed equipment ratings. Never attempt to
cut an item that is above the maximum allowable
diameter, tensile strength or hardness for your
cutter model. Refer to the chart in Section 2.1 of this
manual. Overloading may cause equipment failure
and possible personal injury.
• Do not use the cutter in explosive atmospheres
(for example, in the presence of flammable liquids,
gasses or powders).
• Do not use the cutter on live electric lines, on
pressure vessels or ducts, or on vessels containing
corrosive and/or toxic substances.
• If the cutter malfunctions, stop use immediately.
Check for misaligned or jammed moving parts,
broken components and any other condition that
could make the tool operate incorrectly. Place the
cutter back into operation only after the fault has
been identified and the identified repairs and/or
adjustments have been performed.
• Ensure that any repairs are performed only by
trained, qualified and authorized sta using original
equipment replacement parts. For repair service,
contact the Enerpac authorized service center in
your area.
• Use only original equipment Enerpac parts. Enerpac
parts are designed to fit properly and to withstand
high loads. Non-Enerpac parts may break or cause
the product to malfunction.
• Keep cutting tools clean and replace blades when
they become dull. Suitably maintained cutting tools
with sharp edges are less likely to jam and are easier
to control.
• Always perform a visual inspection of the cutter
before placing it into operation. If any problems are
found, do not use the tool. Make repairs before using
the cutter.
• Do not use the cutter if it is leaking oil. Do not use the
cutter if damaged, altered or in need of repair.
• Do not remove or disable cutter safety devices.
Before using the cutter, make sure that all the safety
devices (guards, etc.) are in place and in good
condition.
• Do not remove the guards installed on the cutter or
on any accessories. Replace any guards immediately
if they develop faults or become damaged.
• Do not alter the calibration of the safety devices,
such as maximum pressure valves (if equipped).
• Allow only authorized, trained, and experienced
personnel to operate the cutter and supervise its use.
• Ensure that all users are trained and qualified to
operate the cutter. Operators must be aware of
all applicable occupational safety laws and must
operate the cutter in accordance with all such laws.
• Keep the work area clean and well illuminated.
• When operating the cutter, do not wear loose clothing
or jewelry. These items could get caught up in the
cutter during operation. Tie up long hair.
• Always wear and use appropriate personal protective
equipment (PPE) such as non-skid safety shoes,
hard-hat, hearing protection, and face and eye
protection. Use of these and other PPE items (used
as appropriate for the conditions) will reduce the
chance of personal injuries. The use of these items
may also be required by local regulations or laws.
• Consult your employer concerning specific safety
requirements and the safety equipment required for
use in your country or region.
• Be certain that cutter safety guard is closed before
starting the cutter.
• Always stop the cutter before opening the safety
guard. Never open the safety guard during operation.
• Before reaching inside the cutting area for any reason,
always stop the pump, relieve hydraulic pressure and
disconnect pump from AC power supply.
• Keep others clear of the work area while the tool is
in use. Be sure that all personnel not operating the
cutter remain at a safe distance when the cutter is
in operation.
• Stop the cutter if people and/or animals enter the
work area.
• Ensure that the operator is alert, observant of the
task being performed and that the work is being done
with care.
• Do not allow use of the cutter by persons that are
tired, or under the influence of drugs, alcohol or
medication.
• Do not allow children to operate the cutter or to assist
with its use. Keep children out of the work area.

3
• Always be certain that hydraulic pressure is fully
relieved before disconnecting hydraulic hoses,
loosening hydraulic fittings, or performing any tool
disassembly or repair procedures.
CAUTION
Failure to observe and comply with the
following precautions and instructions could result
in minor or moderate personal injury. Property
damage could also occur.
• To help ensure proper operation and best
performance, use only Enerpac HF hydraulic oil. Use
of any other oil may result in unsafe operation and /or
damage to tool. The Enerpac product warranty may
also be invalidated.
• Be careful to avoid damaging hydraulic hoses. Avoid
sharp bends and kinks when routing hydraulic hoses.
Do not exceed the minimum bend radius specified
by the hose manufacturer. Using a bent or kinked
hose will cause severe back-pressure. Sharp bends
and kinks will internally damage the hose, leading to
premature hose failure.
• Do not drop heavy objects on hoses. A sharp impact
may cause internal damage to hose wire strands.
Applying pressure to a damaged hose may cause it
to rupture.
• Do not lift hydraulic equipment by the hoses or couplers.
Use the equipment handle(s) or lifting eye(s) (if equipped)
and appropriately rated lifting equipment.
• Keep hydraulic equipment away from flames and
heat. Excessive heat will soften packings and seals,
resulting in fluid leaks. Heat also weakens hose
materials and packings.
• Protect all hydraulic equipment from weld spatter.
1.4 Safety Symbols (on cutter)
WARNING
Failure to observe and comply with the
safety symbols axed to the cutter housing could
result in death or serious personal injury.
WARNING
Make sure the safety symbols (decals,
labels, etc.) are securely axed to the tool and that
they are legible. If not, obtain replacements from
Enerpac. Refer to tool repair parts sheet for locations
and part numbers. Failure to maintain safety symbols
on tool could result in death or serious personal
injury.
The following safety symbols are axed to the cutter
housing:
Crush hazard: Keep hands, fingers and other
body parts away from the cutting head during
operation.
Projectile hazard: Objects may be ejected
from the cutter during operation. Stay clear of
cutting area. Wear eye and face protection.
1.3 General Hydraulic Tool Safety Precautions
(Tools with external hydraulic pumps)
NOTICE:
WARNING
Failure to observe and comply with the
following precautions and instructions could result
in death or serious personal injury. Property damage
could also occur.
• Always read, follow and completely understand
all manufacturer's instructions when operating
pumps, valves and all other devices used with the
tool. Follow all safety precautions contained in the
manufacturer's manuals.
• Use the tool only with a compatible Enerpac pump.
Use of a non-compatible pump may result in erratic
and/or unsafe operation.
• The tool is designed for a maximum working pressure
of 10,150 psi [700 bar]. Do not connect the tool to a
pump with a higher pressure rating. Be certain that all
hydraulic hoses and fittings are properly connected
and that they are rated at 10,150 psi [700 bar] or
higher.
• Never set a relief valve to a higher pressure than
the maximum rated pressure of the pump and tool.
If ratings are dierent, relief valve setting should not
exceed the setting of the lowest rated component
(pump or tool).
• Perform cleaning, maintenance and repair operations
only after disconnecting the tool from the hydraulic
pump.
• Wear suitable personal protective equipment (PPE)
such as goggles, gloves and protective clothing
when checking hoses and fittings.
• Do not leave the tool unattended in the workplace
when it is connected to the hydraulic pump.
• The tool is designed for noncontinuous use. Allow
suciently long pauses to allow the oil to cool.
Consult Enerpac if prolonged and/or interrupted use
is required.
• Do not expose tool to temperatures in excess of
158°F [70°C]. Allow tool to cool or remove heat
source.
• Be aware of hot metal components. Avoid contact
with these components to prevent burns.
• Do not handle pressurized hoses. Escaping oil under
pressure can penetrate the skin. If oil is injected
under the skin, see a doctor immediately.
• Do not pressurize disconnected couplers.
• Never use a hydraulic cylinder or tool with uncoupled
couplers.
• Do not remove or disable the pump relief valve.
Do not remove or disable the tool relief valve (if
equipped).
• Monitor the system hydraulic pressure gauge (or
digital pressure readout). It is your window to see
what is happening in the system.

4
PPE Alert: Wear personal
protective equipment
(PPE) when using or
servicing equipment.
Instruction Manual Alert: Read the
instruction manual before using or servicing
equipment.
1.5 Disconnecting Pump AC Power
WARNING
Pump MUST be disconnected from the
AC power supply before performing cutter
maintenance, repair or cleaning procedures, or
before allowing persons to reach inside the cutting
head for any reason. Failure to observe this
precaution may result in serious personal injury.
• Cutter will operate immediately when pump motor
is running, and either of the cutter push buttons is
depressed.
• If it is not possible to unplug the pump power cord
from the AC power outlet, turn o and lock out
power at the AC power supply and disconnect the
hydraulic hoses.
• Refer to the separate pump instruction sheet
(provided with the pump) for detailed pump safety,
operation and maintenance instructions.
1.6 Crush Hazard
DANGER
Cutter will start immediately when
pump motor is ON and cutter advance or retract
button is depressed.
DO NOT place hands, fingers or other parts of
your body inside the cutting head unless pump
is disconnected from AC power supply. Death or
serious personal injury will result if cutter is operated
while persons are working inside the cutting head.
• Never reach into the cutting head while cutter is in
operation.
• Before reaching inside the cutting head for any
reason, always stop the pump, relieve hydraulic
pressure, and disconnect pump from AC power
supply.
CRUSH HAZARD
Do not reach inside cutting head
unless pump is disconnected from AC
power supply.

5
2.0 PRODUCT DATA
2.1 Cutter Maximum Capacities
Cutter
Model
No.
Material to be Cut
Material Maximum
Diameter
Material Maximum
Tensile Strength
Material Maximum
Hardness
in mm psi daN/mm2Rockwell C
EBH35 Round, square or
flat metal bars 1.38 35 89,900 62 43
NOTICE
Material to be cut must not exceed any of the stated maximum limits shown above.
Cutter may stall during operation if one or more of the maximum limits is exceeded.
2.2 Specifications
Cutter
Model
No.
Max. Cutting
Force Weight
Max. Hyd.
Operating
Pressure
Ambient
Operating Temp
Hyd.
Pump*
Tons kN lb Kg psi bar ˚F ˚C
EBH35 68 606 106 48 10,150 700
-40
to
+122
-40
to
+50
External
Notes:
* Hydraulic pump sold separately. Special Enerpac pump required. Refer to Section 6.1 for additional information.
2.3 External Dimensions
Dimension in mm
A
CB
A 22.3 566
B 8.4 213
C 10.2 259
Product specifications are subject to change without notice.

6
See Figure 1 for a description of cutter major features
and typical items included in the shipment. Refer to
Section 2.0 for maximum cutting capacities,
specifications and dimensions.
5.0 RECEIVING INSTRUCTIONS
Visually inspect all components for shipping damage.
Shipping damage is not covered by warranty. If shipping
damage is found, notify carrier at once. The carrier is
responsible for all repair and replacement costs resulting
from damage in shipment.
6.0 SET-UP
6.1 Hydraulic Pump Requirements
The cutter must be used in conjunction with a specially
designed hydraulic pump (sold separately). This pump
contains unique valving and controls that are specific to
the cutter.
Refer to the pump instruction sheet for detailed
pump setup and operation instructions. Also refer to
Section 6.4 of this manual for additional details.
3.0 CONFORMANCE TO NATIONAL AND
INTERNATIONAL STANDARDS
Enerpac declares that this product has been
tested and conforms to applicable
standards and is compatible with all CE
requirements. A copy of an EU Declaration
of Conformity is enclosed with each shipment of this
product.
4.0 DESCRIPTION
The Enerpac model EBH35 is a fixed-head hydraulic
cutter designed to cut round, square or flat metal bars
and other similar items.
The cutter contains two blades, one fixed and one
moving. The moving blade is actuated by an integral
double-acting hydraulic cylinder. The double-acting
design ensures positive blade return and also helps
prevent jamming or sticking.
Hydraulic power is supplied by an Enerpac hydraulic
pump, which is sold separately from the cutter. Refer to
Section 6.1 for additional pump information.
Figure 1, Features and Components
3
4
6
7
8
9
1
2
5
Key:
1. Safety Guard
2. Cutting Head
3. Lifting Eye
4. Positioning Handle #2
5. Push Buttons (advance - retract)
6. Positioning Handle #1
7. Hydraulic Hoses and Electrical Cable (short length)
8. Hydraulic Cylinder
9. Support Bolt

7
6.2 Hydraulic Connections
A high pressure twin hydraulic hose assembly connects
the pump control valve to the cutter. The hoses are
included as part of a hose subassembly that also
contains an electrical cable for the cutter controls. This
subassembly is not included with the cutter and must be
purchased separately.
To facilitate connections, quick-disconnect hydraulic
couplers are present on the hoses, the cutter, and on the
pump control valve.
NOTICE:
WARNING
Hydraulic oil can reach very high
temperatures even when the cutter is idle and cutting
force is not being applied. To prevent burns, always
use suitable personal protective equipment when
connecting or disconnecting couplers on a cutter
that has been in operation.
NOTICE:
WARNING
Never use any hydraulic component
that contains damaged hydraulic couplers. Never
connect or disconnect a hydraulic coupler if the
hydraulic circuit is pressurized. Failure to observe
these instructions may result in the uncontrolled
release of pressurized hydraulic oil. Skin penetration
may occur. Death or serious personal injury could
result.
NOTICE
All hydraulic hoses and fittings used with the
cutter must be rated at 10,150 psi [700 bar] or above.
6.2.1 Connecting the Hydraulic Couplers
1. Be sure that pump motor is stopped.
2. Be certain there is no residual pressure in the
hydraulic circuit. If pressure is present, discharge the
pressure in accordance with the instructions in the
pump instruction sheet.
Repeat steps 3 through 6 for each hydraulic connection.
See Figures 2 and 3 for hookup details.
NOTICE
Before connecting hydraulic hoses, be certain
that the electrical cable (included in hose and cable
subassembly) is properly oriented. Note that electrical
connectors are dierent on cutter and pump ends.
3. Remove the coupler dust caps.
4. Inspect the couplers after removing the dust caps.
Remove any oil, dust or dirt.
5. Push the male and female couplers firmly together
until engagement occurs.
6. Screw the threaded collar of the female coupler fully
onto the threaded flange of the male coupler. Be sure
that no threads are visible.
6.2.2 Disconnecting the Hydraulic Couplers
1. Be sure that pump motor is stopped.
2. Be certain there is no residual pressure in the
hydraulic circuit. If pressure is present, discharge the
pressure in accordance with the instructions in the
pump instruction sheet.
Figure 2, Hydraulic and Electrical Connections at Cutter (typical)
2
1
Connected View
Key:
1. Hydraulic Hoses and Couplers
2. Electrical Connectors and Cable

8
Repeat steps 3 through 5 for each hydraulic connection:
3. Unscrew the threaded collar of the female coupler
from the threaded flange of the male coupler.
4. Disconnect the couplers. Remove any oil, dust or dirt.
5. Reinstall the coupler dust caps.
6.3 Electrical Connections
An electrical cable connects the pump electrical circuits
to the push button controls mounted on the cutter. This
cable is included as part of the hydraulic hose and
electrical cable subassembly. See Figure 3.
Connect the electrical cable as described in the following
steps. Refer to Figures 2 and 3.
1. Be sure that pump is disconnected from AC power
supply.
2. Connect one end of the electrical cable to the
electrical connector at the pump electrical control
box.
3. Connect the other end of the electrical cable to the
electrical connector at the cutter.
To Pump
2
1
1
6.4 Pump Setup
Prepare the pump for operation as described in the
pump instruction sheet.
Before connecting the pump to the cutter, verify that the
pump relief valve is set at 10,150 psi [700 bar].
If the pump and/or cutter is being used for the first time,
be certain to bleed air from the hydraulic system as
described in Section 8.4 before using the cutter.
Verify that pump oil level is correct and that there are no
oil leaks or other obvious problems.
Figure 3, Hydraulic and Electrical Connections at Pump
Key:
1. Hydraulic Hoses and Couplers
2. Electrical Connectors and Cable

9
• Before reaching inside the cutting head to clear
jams or for any other reason, always stop the pump,
relieve hydraulic pressure and disconnect pump
from AC power supply.
• Always reinstall safety guard after performing any
adjustments, maintenance or repairs. Never operate
the cutter with safety guard removed.
• Be certain that safety guard is in good condition
and secured by both screws. Replace guard if worn,
damaged or missing. Tighten or replace screws if
loose.
• Replace inspection window if it is damaged or if it
becomes scratched or dicult to see through.
7.2 Opening and Closing the Safety Guard
The safety guard contains a U-shaped handle at the
hinged end. Use this handle to open and close the
guard.
Open the safety guard as shown in Figure 5.
Close the safety guard as shown in Figure 6.
7.0 CUTTER SAFETY GUARD
7.1 Description
When closed, the safety guard prevents hand contact
with the moving piston and blade. See Figure 4.
The safety guard is manufactured from steel and
contains a clear polycarbonate inspection window. Two
screws secure the guard to the cutting head.
NOTICE:
WARNING Failure to observe and comply with the
following precautions and instructions could result
in serious personal injury.
• Always close the safety guard before beginning the
cutting process. Cutting head must be shielded by
guard during cutter operation.
• Never operate cutter with safety guard open.
• Never open guard and reach into the cutting head
while cutter is operating. Guard must remain closed
until cutter is stopped.
Figure 4, Safety Guard with Inspection Window
12
Figure 5, Opening the Safety Guard Figure 6, Closing the Safety Guard
Key:
1. Safety Guard
2. Inspection Window

10
8.0 CUTTER OPERATION
8.1 Foreseen Use and Residual Risks
NOTICE:
WARNING
Failure to observe and comply with the
instructions and precautions contained in the
following paragraphs could result in death or serious
personal injury.
1. The cutter is designed for cutting round, flat or square
metal bars within the designated range as specified
by the manufacturer. Material maximum diameter,
tensile strength and hardness must not exceed the
maximum allowable values shown in Section 2.1 of
this manual.
2. The cutter may be used only when connected to a
compatible Enerpac hydraulic pump.
3. Operators must observe the instructions in this
manual in order to minimize the risk of accidents.
In particular, operators must pay attention when
working in conditions that could cause:
• Possible burns from overheated metal parts.
• Injury due to incorrect positioning or inadequate lifting
or moving.
• Injury caused by splinters discharged from the bar or
other work piece.
NOTICE:
WARNING
People remaining in the vicinity of the
cutter while it is working are subject to the risk of
flying debris (dangerous objects, etc.). Serious
personal injury could result.
4. Incorrect Uses:
• Cutter must not be used for purposes other than
those indicated in this document.
• Cutters must not be used in areas subject to the risk
of explosion.
8.2 Positioning and Transporting the Cutter
• Before inserting material to be cut inside the cutting
head, be certain that the cutter is positioned on a solid
and stable work surface of sucient weight rating
capacity. Refer to Section 2.2 for cutter weight.
• Position the cutter as needed using the positioning
handles located at the front and rear of the cutter
hydraulic cylinder.
• If it is necessary to move or transport the cutter, use
only the supplied lifting eyebolt. See Figure 7. Use
appropriately rated lifting equipment.
NOTICE:
WARNING
Because the cutter components are
very heavy, there is a risk of cuts, crushing or broken
bones. To avoid accidents, use care when working
with the cutter. Serious personal injury may result if
the cutter is not properly supported and handled in
an appropriate way.
Figure 7, Cutter Lifting Location
8.3 Operating Precautions
NOTICE:
WARNING
Failure to observe the following
precautions and instructions could result in death or
serious personal injury.
• Keep fingers, hands and other body parts clear of
the cutting head. Be certain that safety guard is
closed. View cutting only through the inspection
window in the safety guard.
• Do not attempt to reposition the item being cut as
the cutter is in operation. Always stop the cutter and
then move the piston to the “home” (fully retracted)
position before repositioning the item.
• Dangerous projectiles could occur at any time
during cutting. Always wear face and eye protection.
Keep persons away from cutting area.
• Cutter surfaces can become very hot. To prevent
burns, avoid contact with cutter components and
wear appropriate personal protective equipment.
• Refer to additional safety precautions in Section 1.0
of this manual before using the cutter or performing
any maintenance or repair activities.
8.4 Trapped Air Removal
Before placing a new cutter into operation, cycle the
piston several times without load to remove any trapped
air in the hydraulic circuit. The tool should also be placed
below the pump so the air can escape to the pump
reservoir.
Air is completely purged when the piston advances and
retracts smoothly in both directions, from fully extended
to fully retracted.
This procedure may also be performed after the cutter
has been serviced.
Refer to the cutter controls information in Section 8.6 of
this manual when performing the air removal procedure.

11
8.5 Positioning Material
Always be sure that the piston and
moving blade are in the fully retracted
“home” position before placing any
material inside the cutting head. See
Figure 8.
Position the material to be cut between the
cutter blades, so that it is perpendicular
to the piston axis, as shown in Figure 9.
This will provide the best quality cut while
placing the least amount of load on the
cutter.
Adjust the support bolt as needed. Head
of support bolt should just touch the
surface of the material to be cut, when
the item is positioned against the fixed
blade of the cutter.
After adjusting the support bolt, be sure
that the support bolt retaining nut is snug
tight against the support bolt mounting
ear. This will help prevent support bolt
movement during cutting.
NOTICE
Be certain that the hardness,
tensile strength and diameter of the
material to be cut are within allowable
limits. Refer to the chart in Section 2.1 of
this manual for additional information.
Failure to observe this instruction may
result in poor cutting performance and/or
damage to the cutter.
90°
90°
Figure 10, Adjusting the Support Bolt
Figure 8, Piston and Blade in Home Position (fully retracted)
Figure 9, Positioning Material in the Cutting Head

12
8.6 Cutter Controls
Two push buttons control cutter operation. One push
button is for the advance function and the other push
button is for the retract function.
With the pump motor ON:
• Press and hold the advance push button to advance
the piston and slide the moving blade forward. See
Figure 11.
• Press and hold the retract push button to retract the
piston and slide the moving blade backward. See
Figure 12.
• Release either push button at any time to stop
movement of the piston and moving blade. Be advised
that there may be a brief delay for the piston and blade
to make a complete stop.
8.7 Cutting Procedure (typical)
1. Make sure that diameter, tensile strength and
hardness of the material to be cut falls within the
allowable ranges for your cutter model. Refer to the
chart in Section 2.1 of this manual.
1
Figure 11, Operation - Advance/Cut
2
2. Be sure that the piston is in the “home” (fully retracted)
position. See Figure 8.
3. Open the safety guard. Refer to Section 7.2 for
additional information.
4. Place the material to be cut between the fixed and
moving blades. Be sure that it is perpendicular to the
piston axis, as shown in Figure 9. Refer to instructions
in Section 8.5 for additional information.
NOTICE
Failure to properly position the material in
the cutting head may result in blade breakage and
reduced cutting eciency.
5. Adjust the support bolt.
6. Close the safety guard. Refer to Section 7.2 for
additional information.
7. Start the pump motor.
8. Press and hold down the advance push button until
the item has been fully cut.
9. Press and hold down the retract push button until
the moving blade moves fully rearward and is in the
“home” (fully retracted) position.
Figure 12, Operation - Retract

13
9.0 MAINTENANCE
9.1 Periodic Maintenance Table
Refer to the Periodic Maintenance Chart (Table 1) for a
list of various routine checks and procedures.
9.2 Cleaning
• Clean the cutter using a dry cloth or compressed air.
For plastic surfaces, use a cloth slightly dampened
with water.
NOTICE:
CAUTION To prevent possible injury, always wear
safety glasses or face mask when using compressed
air.
• Be sure there are no traces of oil, grease or corrosive
substances on the tool, especially on the grips.
• Use a damp cloth and soapy water to clean plastic
components.
• Do not use gasoline or thinner to clean the tool.
9.3 Fasteners
Periodically check all screws, nuts and other fasteners
for proper tightness. Tighten any loose fasteners.
Replace any worn or damaged fasteners. This should
be performed periodically or every day in the event of
frequent or prolonged cutter operation.
NOTICE
Failure to check and tighten fasteners as
required may result in serious damage to the cutter.
9.4 Preparation for Maintenance
All cutter maintenance procedures must be performed
under the following conditions:
• All hydraulic pressure must be relieved. Refer to the
pump instruction sheet for pressure relief procedure.
• The pump must be disconnected from the AC power
supply.
• The cutter must be given time to cool to prevent burns.
• Procedures must be performed in a suitable work
environment in accordance with all current safety
regulations and/or laws in your country or region.
• The cutter must be cleaned thoroughly before
maintenance procedures are performed.
• Suitable personal protective equipment (PPE) must be
used and/or worn while performing any work.
NOTICE:
WARNING
Ensure that any guards or shields (if
present) have been correctly reinstalled before
placing the cutter back into service after maintenance
procedures are completed. Failure to reinstall these
devices could result in serious personal injury.
Table 1 - Periodic Maintenance Chart
Time Interval Maintenance Operation Method To be performed by:
Every 8 hours of
operation:
Check the cutter for loose,
damaged or worn parts.
Check for oil leaks. Tighten,
replace or repair as required.
Visual Operator
Clean the cutter. (Refer to instructions in
Section 9.2)
Operator
Check that screws and bolts are
properly tightened. Replace any
missing screws or bolts.
(Refer to instructions in
Section 9.3)
Operator
As required: Replace fixed blade. (Refer to instructions in
Section 9.5.1)
Operator
Replace moving blade. (Refer to instructions in
Section 9.5.2)
Operator

14
NOTICE:
WARNING
Always disconnect pump from AC
power supply before beginning cutter blade
replacement procedures. Failure to observe this
precaution could result in accidental startup as
procedures are being performed. Serious personal
injury could result.
4. Place the cutter horizontally on a stable work surface.
5. Open the safety guard. Refer to Section 7.2 for
additional information.
6. Remove the two fixed blade screws (Figure 13, item 1).
7. Remove the worn fixed blade (Figure 13, item 2) and
replace it with the new fixed blade.
8. Install two NEW fixed blade screws (Figure 13, item 1).
New fixed blade screws are included with the new blade.
Torque to 18 ft-lb [25 Nm]. Also apply Loctite 243 or
equivalent.
9. Close the safety guard. Refer to Section 7.2 for
additional information.
10. Test for proper operation before placing the cutter
back into service.
9.5.2 Moving Blade Replacement
Replace the moving blade as described in the following
steps:
1. Start the pump. Extend the piston to allow access to
the moving blade and screws. See Figure 14.
2. Stop the pump. Be sure that hydraulic pressure is
completely relieved.
3. Disconnect pump from AC power supply.
9.5 Blade Replacement
The use of worn blades decreases the eectiveness of
the cutter and can also side load the cylinder, possibly
damaging the tool. Pump overheating may also occur.
Replace blades immediately when it is noticed that
they are worn and/or damaged, or if there has been a
noticeable decrease in cutting performance.
The cutter contains a fixed blade and a moving blade.
Refer to Section 9.5.1 for fixed blade replacement
instructions and to Section 9.5.2 for moving blade
replacement procedures.
NOTICE:
CAUTION
Use extreme caution when removing
and installing blades. Blades may be sharp even
when worn. To avoid hand injury, wear appropriate
hand protection and avoid contact with blade cutting
edges.
NOTICE
To help ensure even blade wear and optimum
cutting performance, it is recommended that both the
fixed blade and the moving blade be replaced at the
same time.
9.5.1 Fixed Blade Replacement
Replace the fixed blade as described in the following
steps. Refer to Figure 13, items 1 and 2.
1. Start the pump. Move the piston to the “home”
position (fully retracted). See Figure 8.
2. Stop the pump. Be sure that hydraulic pressure is
completely relieved.
3. Disconnect pump from AC power supply.
1
2
Figure 13, Fixed Blade Replacement
Key:
1. Fixed Blade Screws
2. Fixed Blade

15
10.0 STORAGE
10.1 Storage Guidelines
If the cutter will be stored for an extended period of time:
• Disconnect hydraulic hoses from cutter. Be sure that
dust caps are installed on hydraulic couplers.
• Thoroughly clean the cutter.
• Lubricate the cutter metal surfaces with a thin layer
of oil.
• Store the cutter in a clean and dry place, accessible
only to authorized personnel.
10.2 Return to Use (after storage)
Before using the cutter after an extended period of
storage or inactivity, perform the following steps:
• Remove protective oil coating (applied before storage)
from cutter surfaces.
• Check for oil leaks. Make repairs as required.
• Check that the tool hydraulic hoses and electrical
cable are intact and undamaged.
• Check for any missing, worn or improperly installed
parts.
• Check that all screws, nuts, bolts and other fasteners
are tight.
• Replace, repair or tighten components as needed.
NOTICE:
WARNING
Always disconnect pump from AC
power supply before beginning cutter blade
replacement procedures. Failure to observe this
precaution could result in accidental startup as
procedures are being performed. Serious personal
injury could result.
4. Open the safety guard. Refer to Section 7.2 for
additional information.
5. Loosen and remove the moving blade screws
(Figure 14, item 1).
6. Remove the worn moving blade (Figure 14, item 2).
7. Install new moving blade (Figure 14, item 2) onto the
piston.
NOTICE
A screwdriver or small pry bar may be needed
to pry the blade from the mating surface of the piston.
8. Install the new moving blade screws (Figure 14,
item 1). Torque to 91 in-lb [10 Nm]. Apply Loctite 243
or equivalent.
9. Close the safety guard. Refer to Section 7.2 for
additional information.
10. Test for proper operation before placing the cutter
back into service.
Figure 14, Moving Blade Replacement
1
2
Key:
1. Moving Blade Screws
2. Moving Blade

16
11.0 TROUBLESHOOTING
Refer to the Cutter Troubleshooting Chart (Table 2) for
a list of common hydraulic cutter symptoms, possible
causes and solutions.
For repair service, contact an Enerpac authorized
service center. Inspection and repairs should be
performed only by an Enerpac authorized service center
or other qualified hydraulic tool service facility.
Table 2 - Cutter Troubleshooting Chart
Symptom Possible Cause Solution Maint. Level
1. Piston moves
slowly and/or has
diculty cutting
the material.
Blocked or restricted hydraulic oil
flow.
Check for incomplete
hydraulic connections,
blocked hydraulic hoses or
other similar problems.
Operator
Low hydraulic oil level. Check oil level. Add oil if low. Operator
Material being cut is outside of
acceptable specifications.
Material properties must not
exceed stated maximum
limits. Refer to Section 2.1.
Operator
Low hydraulic oil pressure or flow. Check pump relief valve
setting. Troubleshoot and
repair pump and solenoid
control valve (as required).
Service Center
Cutter seal wear and/or internal
damage.
Repair cutter as required. Service Center
2. Cutter vibrates
during operation.
Loose or missing screws or bolts. Verify screws and bolts are
properly tightened. Replace
any missing screws or bolts.
Operator
3. Piston does not
advance or retract
when pump motor
is ON and cutter
push buttons are
pressed.
Pump not connected to electrical
power.
Check that pump is connected
to AC power supply. Be sure
that pump is on.
Operator
Electrical cable disconnected at
pump or at cutter.
Connect electrical cable. Operator
Cutter push button switches and/or
wiring defective.
Repair or replace cutter
electrical components as
required.
Service Center
Pump solenoid control valve
components defective.
Repair or replace control valve
components as required.
Service Center
4. External oil leaks. Loose hydraulic fittings. Tighten loose fittings. Operator
Damaged hydraulic hoses. Replace hoses. Operator
Damaged hydraulic couplers. Replace couplers. Service Center
Worn or damaged cutter
components.
Repair cutter as required. Service Center

Notes:

Notes:

Notes:

WWW.ENERPAC.COM
