Enginko MCF-LW12TERWP User manual

m2m Germany GmbH | Am Kappengraben 18-20 | 61273 Wehrheim | 06081 5873860
Table of Contents
MCF-LW12TERWP Operating Manual
Important safety information
Read this manual before attempting to install the device! Failure to observe recommendations
included in this manual may be dangerous or cause a violation of the law. The manufacturer
will not be held responsible for any loss or damage resulting from not following the
instructions of this operating manual.
Do not dismantle or modify in any way.
The device is not intended to be used as a reference sensor, and enginko Srl will not be held liable for
