EP Equipment EPT20-15ET User manual

Service Manual
Electric Pallet Truck
EPT20-15ETL
EPT20-15ET

Service Manual
Electric Pallet Truck
EPT20-15ETL
EPT20-15ET

Release Date Version No. Changes (Serial number)
2016-09-27 SM-1115 09.16 New Version
This manual applies to:
Model Specifications
EPT20-15ET 1,500 kg Capacity
EPT20-15ETL 1,500 kg Capacity, Ultra-low Placement
Some sections of the manual only involve certain model, please refer to the manual
according to the actual configuration of the vehicle.
*If there are any changes, revised version will be published once every 12 months;
if there is no change, please follow the most recent version.
*Please refer to the corresponding version of the service manual against the purchase time
of your vehicle.
*If you need the latest versions of the manual, please contact our service department or
dealer to obtain.

EP Equipment Co., Ltd.
EP Industrial Park, Xiaquan Village,
Dipu Town, Anji County, Zhejiang Province
www.ep-zl.com
Safety signs and instructions:
Please strictly adhere to these safety instructions to avoid personal injury.
Please pay attention to the important safety instructions.
Instructions.
FOREWORD
This Service Manual can help readers learn more about the truck system components,
maintenance and troubleshooting, and other related information. The operation and
maintenance personnel must read this Manual carefully before using the product. And when
vehicle is in use, be sure to follow the complete operation and maintenance information in
this Manual for vehicle maintenance.
Before using, please check if the pages of the Manual are clear and complete, so as not
to affect your normal use because of incomplete information. If the contents of the Manual
have been illegible or damaged, which may affect reading, please contact our company or
dealer for replacement.
With the constant update and improvement of our products, the equipment you are using
may be slightly different from what has been described in this Manual, therefore, we must
reserve the right to modify the appearance, configuration and technical specifications. If you
have any questions, please contact our sales department or dealer.
i
Copyright
Copyright of Service Manual belongs to
EP Equipment Co., Ltd.
REV. SM-1115 09.16

REV. 09/2016
TABLE OF CONTENTS
TABLE OF CONTENTS
1. INFORMATION & SPECIFICATIONS..............................1
1.1 After-sales Service Platform .........................................3
1.2 Introduction...................................................................4
1.3 Common Tools..............................................................5
1.4 General Tightening Torques .........................................6
2. MAINTENANCE...............................................................9
2.1 Overview..................................................................... 11
2.2 Maintenance............................................................... 12
2.2.1 Cleaning ........................................................................12
2.2.2 Inspection ......................................................................12
2.2.3 Lubrication.....................................................................16
3. STRUCTURE & FUNCTIONS........................................ 19
3.1 Structure & Functions................................................. 21
3.1.1 Travel Switch .................................................................21
3.1.2 Lifting/Lowering Switch..................................................21
3.1.3 Emergency Reverse Switch ..........................................21
3.1.4 Horn Switch ...................................................................21
3.1.5 Emergency Stop Switch ................................................22
3.1.6 Key Switch.....................................................................22
3.1.7 Charge Gauge...............................................................22
3.1.8 LED Charging Indicator .................................................22
3.1.9 Buzzer ..........................................................................23
3.1.10 Fuse.............................................................................23
3.1.11 Controller .....................................................................23
3.1.12 Charger........................................................................23
3.1.13 Lifting Limit Switch.......................................................24
3.1.14 Interlock Switch ...........................................................24
3.1.15 Pump Motor.................................................................24
3.1.16 Gear Pump ..................................................................24
3.1.17 Pump Contactor...........................................................25
3.1.18 Solenoid Valve.............................................................25
4. CHASSIS SYSTEM........................................................ 27
4.1 Load Wheel ................................................................ 29
4.1.1 Removal and Installation ...............................................29
4.1.2 Faults and Causes.........................................................30
4.2 Cover.......................................................................... 30
4.2.1 Removal and Installation ...............................................30
SECTION PAGE
1-5

REV. 09/2016
TABLE OF CONTENTS
4.3 Lifting Mechanism....................................................... 31
4.3.1 Fork Inspection..............................................................31
4.3.2 Connecting Rod Adjustment ..........................................31
4.3.3 Removal and Installation ...............................................32
5. DRIVE SYSTEM............................................................. 33
5.1 Drive Assembly........................................................... 36
5.1.1 Removal and Installation ...............................................36
5.2 Electromagnetic Brakes.............................................. 36
5.2.1 Removal and Installation ...............................................37
5.2.2 Faults and Causes.........................................................37
5.2.3 Checking and Testing ....................................................38
5.2.4 Control Circuit Troubleshooting .....................................39
5.3 Drive Wheel................................................................ 40
5.3.1 Removal and Installation ...............................................40
5.3.2 Faults and Causes.........................................................40
5.4 Drive Motor................................................................. 41
5.4.1 Removal and Installation ...............................................41
5.4.2 Faults and Causes.........................................................41
5.4.3 Checking and Testing ....................................................42
5.5 Gearbox...................................................................... 43
5.5.1 Removal and Installation ...............................................43
5.5.2 Faults and Causes.........................................................43
6. OPERATING SYSTEM................................................... 45
6.1 Control Lever.............................................................. 47
6.2 Button Switch.............................................................. 47
6.2.1 Removal and Installation ...............................................47
6.2.2 Faults and Causes.........................................................48
6.2.3 Checking and Testing ....................................................48
6.2.4 Control Circuit Troubleshooting .....................................49
6.3 Travel Switch .............................................................. 51
6.3.1 Removal and Installation ...............................................51
6.3.2 Faults and Causes.........................................................51
6.3.3 Checking and Testing ....................................................51
6.3.4 Control Circuit Troubleshooting .....................................52
7. HYDRAULIC SYSTEM................................................... 53
7.1 Overview..................................................................... 55
7.1.1 Hydraulic Schematic Diagram ......................................56
2-5
TABLE OF CONTENTS
SECTION PAGE

REV. 09/2016
TABLE OF CONTENTS
7.2 Pump and Motor Assembly......................................... 57
7.2.1 Removal and Installation ...............................................57
7.2.2 Component....................................................................58
7.3 Pump Motor................................................................ 58
7.3.1 Removal and Installation ...............................................58
7.3.2 Faults and Causes.........................................................59
7.3.3 Checking and Testing ....................................................59
7.4 Pump Contactor.......................................................... 60
7.4.1 Faults and Causes.........................................................60
7.4.2 Checking and Testing ....................................................61
7.4.3 Control Circuit Troubleshooting .....................................61
7.5 Solenoid Valve ........................................................... 62
7.5.1 Faults and Causes.........................................................62
7.5.2 Checking and Testing ....................................................62
7.5.3 Control Circuit Troubleshooting .....................................63
7.6 Reach Cylinder........................................................... 64
7.6.1 Cylinder Removal Precautions ......................................64
7.6.2 Cylinder Installation Precautions ...................................65
7.6.3 Removal and Installation ...............................................66
7.7 Hydraulic Troubleshooting .......................................... 68
7.8 Hydraulic Symbol........................................................ 69
8. ELECTRICAL SYSTEM................................................. 71
8.1 Controller.................................................................... 73
8.1.1 Removal and Installation ...............................................73
8.1.2 Controller Interface Function .........................................73
8.2 Fuse............................................................................ 75
8.2.1 Location of Fuses ..........................................................75
8.2.2 Checking and Testing ....................................................76
8.3 Key Switch.................................................................. 77
8.3.1 Removal and Installation ...............................................77
8.3.2 Faults and Causes.........................................................77
8.3.3 Checking and Testing ....................................................77
8.3.4 Control Circuit Troubleshooting .....................................77
8.4 Charge Gauge............................................................ 78
8.4.1 Removal and Installation ...............................................78
8.4.2 Faults and Causes.........................................................78
8.4.3 Checking and Testing ....................................................78
8.4.4 Control Circuit Troubleshooting .....................................78
8.5 LED Charging Indicator .............................................. 79
8.5.1 Removal and Installation ...............................................79
3-5
TABLE OF CONTENTS
SECTION PAGE

REV. 09/2016
TABLE OF CONTENTS
8.5.2 Faults and Causes.........................................................79
8.5.3 Checking and Testing ....................................................79
8.5.4 Control Circuit Troubleshooting .....................................79
8.6 Lifting Limit Switch...................................................... 80
8.6.1 Removal and Installation ...............................................80
8.6.2 Faults and Causes.........................................................80
8.6.3 Checking and Testing ....................................................80
8.6.4 Control Circuit Troubleshooting .....................................80
8.7 Interlock Switch .......................................................... 81
8.7.1 Removal and Installation ...............................................81
8.7.2 Faults and Causes.........................................................81
8.7.3 Checking and Testing ....................................................81
8.7.4 Control Circuit Troubleshooting .....................................81
8.8 Speed Mode Switch (Optional)................................... 82
8.8.1 Removal and Installation ...............................................82
8.8.2 Connection Mode ..........................................................82
8.8.3 Faults and Causes.........................................................82
8.8.4 Checking and Testing ....................................................82
8.8.5 Control Circuit Troubleshooting .....................................83
8.9 Handheld Unit (Optional)............................................ 84
8.9.1 Handheld Unit Connection.............................................84
8.9.2 Handheld Unit Main Menu.............................................84
8.9.3 Parameter Settings........................................................85
8.9.4 TESTER Menu ..............................................................87
8.10 Controller Error Message ......................................... 88
8.10.1 Traction Controller .......................................................88
8.11 Electrical Schematic Diagrams ................................. 91
8.12 Cable Wiring Diagrams............................................. 94
8.13 Wiring Harness and Connectors............................... 95
9. TROUBLESHOOTING................................................... 97
9.1 Preparation Before Troubleshooting........................... 99
9.1.1 Check the Voltage of Battery.........................................99
9.2 Troubleshooting Solutions of Common Faults.......... 100
APPENDIX ................................................................ 103
B SERVICE MANUAL - BATTERY................................. 105
B1 Lead-acid Battery...................................................... 107
B1-1 Safety and Warnings.............................................. 107
4-5
TABLE OF CONTENTS
SECTION PAGE

REV. 09/2016
TABLE OF CONTENTS
B1-2 Use of Battery ........................................................ 107
B1-2.1 Pre-use Checks ........................................................107
B1-2.2 Discharging...............................................................107
B1-2.3 Charging ...................................................................108
B1-2.4 Temperature..............................................................108
B1-3 Maintenance & Care ............................................. 108
B1-3.1 Daily Maintenance ....................................................108
B1-3.2 Weekly Maintenance.................................................108
B1-3.3 Monthly Maintenance................................................109
B1-3.4 Care ..........................................................................109
B1-4 Storage .................................................................. 110
B1-5 Troubleshooting ..................................................... 110
B2 Maintenance-free Battery......................................... 113
B2-1 Safety and Warnings.............................................. 113
B2-2 Use of Battery ........................................................ 113
B2-2.1 Pre-use Checks ........................................................ 113
B2-2.2 Discharging............................................................... 113
B2-2.3 Charging ................................................................... 114
B2-3 Maintenance & Care .............................................. 114
C SCHEDULE................................................................. 115
5-5
TABLE OF CONTENTS
SECTION PAGE

REV. 09/2016
TABLE OF CONTENTS

SAFETY WARNING
For your own safety and that of others, please observe the following safety instructions:
Thorough and normative maintenance is one of the most important prerequisites to ensure
stable and reliable operation of truck. Neglecting regular maintenance could easily lead
to the truck malfunction and failure, and potential threats to staff and operational safety.
Therefore, there must be adequate maintenance equipment, professional maintenance
personnel and a comprehensive maintenance plan in place.
Please perform the maintenance and inspections according to the following provisions:
To strictly enforce the truck maintenance, lubrication and inspection plans.
Truck maintenance, lubrication and inspection personnel must be approved by accredited
certification or evaluation agency.
The following operations shall be performed before you leave the truck:
- No parking on slopes.
- Fully lower the forks.
- Cut off the power supply.
- Turn the switch lock to “STOP” and remove the key.
Prior to truck maintenance:
- Raise the drive wheel off the ground, or cut off the power supply connection.
- Use wooden wedges or other effective fixtures.
- When performing maintenance underneath the vehicle, make sure that the lifting device
or jack leg is secure.
- Park your vehicle in a safe and secure area.
Never use an open flame to check level of electrolyte, other oils or fluids for leaks.
Keep the parking lot clean, well-ventilated and dry.
Regular checks and maintenance should be conducted to braking, steering, control, warning
and safety devices to keep them in good condition.
All nameplates and safety signs on the truck should be cleaned regularly to make them
clearly visible.
Regular checks and maintenance should be conducted to all the devices of lifting system to
ensure them to be safe for use.
The hydraulic system should be checked regularly based on usage. Hydraulic cylinders,
hydraulic valves and other hydraulic components should be ensured to be without leakage.
Regular checks and maintenance should be conducted to batteries, motors, controllers,
limit switches, protective devices, wires and connectors, and so on. Please pay particular
attention to the electrical insulation.
Park the truck in a clean environment to minimize the risk of fire.
Without the permission of the manufacturer, users are not allowed to change or increase
the capacity of the truck. After having been changed under permission, the nameplates and
safety signs on the truck should also be changed accordingly.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.

1
1
1. INFORMATION & SPECIFICATIONS

2
NOTE:

3
REV. 09/2016
INFORMATION & SPECIFICATIONS
1
1.1 After-sales Service Platform
Claims/Replacement Parts Service Platform:
In order to provide you with a fast and efficient
after-sales service, when you claim / order spare
parts or after-sales service upon maintenance,
please provide accurate truck model, vehicle
body serial number and part number.
After-sales Maintenance Service Platform:
Customer
[email protected]
Customer
Components
Warehouse
Customer service to input
into After-sales System.
After-sale Engineer to
call back to confirm the
accuracy of the information
about the components.
Shipped within
24 hours
Claim Form
Customer service to input
into After-sales System.
After-sale Engineer to call
back to confirm about the
specific fault information.
Within two business
days after the mainten-
ance, customer service
will call back and close
the claim.
Maintenance service
specialist will provide
on-site service at the
appointed time.
iNOTE
Customer
[email protected]
Claim Form
Customer

REV. 09/2016
INFORMATION & SPECIFICATIONS
1
4
No. Name
1 Control Lever
2 Emergency Stop Switch
3 Charge Gauge
4 LED Charging Indicator
5 Key Switch
6 Upper Cover
7 Charging Plug
No. Name
8 Battery
9 Chassis
10 Balance Stand / Caster Wheel
11 Drive Wheel
12 Lower Cover
13 Lift Cylinder
1.2 Introduction

5
REV. 09/2016
INFORMATION & SPECIFICATIONS
1
This series are electric pallet trucks. Its import-
ant structure is as shown in Figure 10001.
-Please refer to the nameplate for rated load
capacity of the vehicle.
- The vehicle can only be used on the level gro-
und indoors, never use it on mezzanine or
balcony area.
WARNING
Truck can only be operated by single operator;
other personnel is forbidden from riding.
1.3 Common Tools
No. Name Remark
1 Hex Wrench 2#~14# One Set
2 Hex Head Socket Wrench 10#~27# One Set
3 Phillips Screwdriver 2# One Piece
4 Slotted Screwdriver 2# One Piece
5 Circlip Pliers One for holes and one for shaft
6 Hammer One Piece
7 Spreader, Crane One Pair
8 Cylinder Wrenches For removal and installation of cylinders
9 Diagonal Pliers One Piece
10 Cylinder Pliers One Piece
11 Grease Gun One Piece
12 Tiger Tooth Wrench 22#/27# One of Each
WARNING

REV. 09/2016
INFORMATION & SPECIFICATIONS
1
6
Table 1.4.1 Screws/Bolts Performance Levels
Performance Level Material Specification (mm)
5.8 grade Low carbon steel M6 ~ M48
8.8 grade Quenched and tempered medium
carbon steel M6 ~ M48
10.9 grade Quenched and tempered medium
carbon alloy steel M6 ~ M48
12.9 grade Quenched and tempered medium
carbon alloy steel M6 ~ M48
12.9
10.9
8.8
5.8
1.4 General Tightening Torques
Screws or bolts used on the truck are of 8.8
grade or higher performance level.
When you are conducting truck maintenance,
you can refer to Table 1.4.1 and Table 1.4.2 to
select the suitable screws or bolts for replace-
ment.
-
-
CAUTION
The performance levels of screws or bolts are
marked on the heads of the screws or bolts.
If you find the screws or bolts used on certain
position are not marked with performance
level, please select spare parts with perform-
ance level of at least 8.8 grade or higher level
forreplacement.

7
REV. 09/2016
INFORMATION & SPECIFICATIONS
1
Table 1.4.2 Metric Screws/Bolts Tightening Torque Table (n•m)
Nominal Diameter
(mm)
Performance Level
5.8 8.8 10.9 12.9
Proof Stress (MPa)
380 600 830 970
M6 7~8 10~12 14~17 17~20
M8 16~18 25~30 34~41 41~48
M8×1 17~20 27~32 37~43 43~52
M10 31~36 49~59 68~81 81~96
M10×1 35~41 55~66 76~90 90~106
M12 55~64 86~103 119~141 141~167
M12×1.5 57~67 90~108 124~147 147~174
M14 87~103 137~164 189~224 224~265
M14×1.5 144~170 149~179 206~243 243~289
M16 136~160 214~256 295~350 350~414
M16×1.5 144~170 228~273 314~372 372~441
M18 186~219 294~353 406~481 481~570
M18×1.5 210~247 331~397 457~541 541~641
M20 264~312 417~500 576~683 683~808
M20×1.5 294~345 463~555 640~758 758~897
M22 360~431 568~680 786~941 918~1099
M22×1.5 395~473 624~747 803~1034 1009~1208
M24 457~547 722~864 998~1195 1167~1397
M24×2 497~595 785~940 1086~1300 1269~1520
M27 669~801 1056~1264 1461~1749 1707~2044
M27×2 723~865 1141~1366 1578~1890 1845~2208
M30 908~1087 1437~1717 1984~2375 2318~2775
M30×2 1005~1203 1587~1900 2196~2629 2566~3072
M36 1587~1900 2506~3000 3466~4150 4051~4850
M36×3 1680~2011 2653~3176 3670~4394 4289~5135
M42 2538~3039 4088~4798 5544~6637 6479~7757
M42×3 2731~3269 4312~5162 5965~7141 6921~8345
M48 3813~4564 6020~7207 8327~9969 9732~11651
M48×3 4152~4970 6556~7848 9069~10857 10598~12688

REV. 09/2016
INFORMATION & SPECIFICATIONS
1
8

9
2
2. MAINTENANCE
