Epiroc FlexiROC T20 R Specifications

PM No. 9852 2467 01i
Epiroc
FlexiROC T20 R
Operator's instructions

2
SAFETY INSTRUCTIONS

Before starting, read all instructions carefully.
Special attention must be paid to
information alongside this symbol.
Only use genuine Epiroc parts.
© Copyright 2017, Epiroc Stonetec S.r.l.
Any unauthorized use or copying of the contents or any part thereof is prohibited.
This applies in particular to trademarks, model denominations, part numbers and drawings.
Epiroc Stonetec S.r.l.
12031 Bagnolo Piemonte (CN), Italy

3
Safety
Safety
Reference
………………………………………………………………………………………………………5

4
Safety

5
Safety
Reference
Note
Always read the information in the Safety document before starting to use the rig or
starting maintenance work.

6
Safety

7
Operator's instructions
Operator's instructions
1. General .....................................................................................................................................11
Foreword...................................................................................................................................11
Principal components................................................................................................................12
General system description........................................................................................................13
General description of the drill rig.........................................................................................13
Hydraulic pumps...................................................................................................................17
Hydraulic pump 1..............................................................................................................17
Hydraulic pump 2..............................................................................................................17
Hydraulic pump 3..............................................................................................................17
Hydraulic pump 4..............................................................................................................17
Air system.............................................................................................................................17
2.Technical data............................................................................................................................18
FlexiROC T20 R.......................................................................................................................18
Dimensions...............................................................................................................................20
Dimensions ...........................................................................................................................20
Transport dimensions ........................................................................................................20
Coverage area...................................................................................................................21
Danger zone ......................................................................................................................21
3. Daily checks..............................................................................................................................22
Foreword...................................................................................................................................22
Extra safety check.....................................................................................................................22
Safety....................................................................................................................................22
Check points..........................................................................................................................23
Before starting...........................................................................................................................25
Safety....................................................................................................................................25
Checks ..................................................................................................................................25
Functionality test after start.......................................................................................................26
Checks ..................................................................................................................................26
Function test while drilling........................................................................................................27
Checks ..................................................................................................................................27
4.Controls .....................................................................................................................................28
Controls ....................................................................................................................................28
General..................................................................................................................................28
Remote control box...............................................................................................................29
Pressure gauge panel .............................................................................................................30
Operator panel.......................................................................................................................31
Menu views...........................................................................................................................33
Settings submenus.............................................................................................................33
Diagnostics submenus .......................................................................................................34
Options submenus .............................................................................................................35
Shortcuts menus ................................................................................................................36
Gradient meter...................................................................................................................38
Control panel for diesel engine..........................................................................................39
5. Radio box..................................................................................................................................42
Safety....................................................................................................................................42
Controls ....................................................................................................................................43
Left-hand multifunction lever................................................................................................44
Right-hand multifunction lever..............................................................................................45
Right-hand multifunction lever-proportional function............................................................46

8
Touch buttons ...........................................................................................................................47
Menu views...........................................................................................................................48
Navigation.........................................................................................................................48
Menu description...............................................................................................................49
Menus for testing...............................................................................................................51
Error messages..................................................................................................................53
Function................................................................................................................................56
Time-out function..............................................................................................................56
Start-up .............................................................................................................................56
Stops.................................................................................................................................57
Drilling..............................................................................................................................57
Display heater....................................................................................................................58
Replacing the box..............................................................................................................59
Learn-link..........................................................................................................................59
6. Operating ..................................................................................................................................61
Activating the remote control box .............................................................................................61
Diesel engine starting................................................................................................................64
Stopping the diesel engine.........................................................................................................65
Feed Rotation............................................................................................................................66
General..................................................................................................................................66
Upward and horizontal drilling..........................................................................................66
Maintenance for drilling upwards ......................................................................................67
Hydraulic feed rotation..........................................................................................................68
Safety................................................................................................................................68
Operation ..........................................................................................................................68
Tramming .................................................................................................................................69
Operation ..............................................................................................................................69
Checking after tramming...........................................................................................................71
Tramming - General principles..................................................................................................71
Tramming, general................................................................................................................71
Maximum permitted inclination angles during setting- up for drilling........................................72
Setting-up for drilling with the feeder in vertical position and centered between the wheels...72
Setting-up for drilling with the feeder in vertical position and swung max to left...................72
Setting-up for drilling with the feeder in vertical position and swung max to right.................73
Setting-up for drilling with the feeder top in extreme position forwards, the feeder laterally
vertical and centred between the wheels ................................................................................73
Setting-up for drilling with the feeder top in extreme position rearwards, the feeder laterally
vertical and centered between the wheels...............................................................................73
Using the winch when tramming...............................................................................................74
General..................................................................................................................................75
Action before winching.........................................................................................................75
Checking the attachment of the winch cable..........................................................................75
Correct assembly...................................................................................................................76
Tramming uphill....................................................................................................................77
Tramming downhill...............................................................................................................79
7. Before drilling...........................................................................................................................80
Safety........................................................................................................................................80
Setting up for drilling................................................................................................................80
Setup for drilling - General principles........................................................................................82
General setup ........................................................................................................................82
Uphill setup...........................................................................................................................82
Downhill setup......................................................................................................................82
Setup - Transverse incline .....................................................................................................83

9
8. Drilling .....................................................................................................................................84
Start of manual drilling..............................................................................................................84
Feeder adjustment during drilling..........................................................................................86
Checks during drilling...............................................................................................................87
Break loose ...........................................................................................................................87
Break loose (applies to extension drilling).............................................................................87
Rod adding................................................................................................................................88
Threading..................................................................................................................................90
Unthreading and extracting .......................................................................................................91
Changing drill bit ......................................................................................................................93
Action in case of drilling problems............................................................................................93
Drilling problems ..................................................................................................................93
High coupling sleeve temperature..........................................................................................94
Difficulties in loosening the coupling sleeve..........................................................................94
Hole deflection......................................................................................................................94
8. Options .....................................................................................................................................95
Electric filler pump ...................................................................................................................95
Water flush / Water mist............................................................................................................96
Water flushing.......................................................................................................................96
Water mist.............................................................................................................................98
Auxiliary hydraulic fittings .......................................................................................................99
RAS........................................................................................................................................100
Rod adding with RAS..........................................................................................................100
Unthreading and extracting with RAS .................................................................................102
Filter with Pre-Cat...................................................................................................................103
Use and maintenance...........................................................................................................104
System status.......................................................................................................................104
Scheduled maintenance .......................................................................................................105

10

11
Operator's instructions
1. General
1. General
Foreword
This instruction manual is part of the complete delivery of the drill rig. It provides
information on the design and operation of the drill rig and contains advice and the
measures necessary to keep the rig operational. This instruction manual is no replace-
ment for thorough training on the drill rig.
This instruction manual should be read in advance by all persons who are to operate or
repair the drill rig or carry out maintenance on it.
See separate instructions for documentation on the rock drill/rotation unit, the diesel
engine and certain other components.
For other questions refer to the local Epiroc company office. Addresses and tel-
ephone numbers are in the Maintenance instructions.

12
Operator's instructions
1. General
Principal components
Figure: Principal components
1Feeder 7Dust collector (DCT)
2Boom system 8Compressor
3Radiator 9Radio receiver
4Hydraulic oil pumps 10 Wheels
5Diesel engine 11 Electric cabinet
6Air tank

13
Operator's instructions
1. General
General system description
General description of the drill rig
This drill rig is a fully diesel-hydraulic drill rig designed for surface drilling
applications such as in quarries and on construction sites.
The drill rig consists of the following main components: (See illustration under
General Description).
Figure: General Description
Table:
1.
Diesel control panel
10. Receiver
2.
Electrical cabinet
11. Compressor
3.
Remote control
12. Hydraulic system
4.
Batteries
13. Air system
5.
Diesel engine
14. Boom
6.
Control unit
15. Dust collector
7.
Feed
16. Engine electronic board
8.
Safety cover or wire emergency
17. Emergency stop
9.
Emergency stop

14
Operator's instructions
1. General
Wheeled chassis frame
The diesel engine, chassis, dust collector, hydraulic system, air system and boom sys-
tem are mounted on the wagon frame.
The 4 wheels are driven by two steering axles with integrated brake.
The body covers the diesel engine, the compressor, the different lubrication tanks, the
valves and the hydraulic hoses. Inspection hatches facilitate access to the different
machine components. All the hatches lock in the open
position with a pneumatic spring.
The dust collector is mounted at the back of the rig on the right-hand side.
Power pack
This hydraulic drill rig is powered by a turbocharged, water-cooled diesel engine.
The diesel engine is equipped with a monitoring system that includes automatic shut-
down functions.
The drilling carriage is driven by 2 steering axles connected to each other by a
universal joint and powered by a hydraulic motor.
The hydraulic pumps and the compressor are driven by a diesel engine.
Boom system
The boom system consists of inner/outer boom bodies, boom head, feed holder and
associated hydraulic cylinders. The boom system is controlled by directional valves
for positioning the feed with the rock drill at different distances and directions.
Dust collector
The hydraulically driven dust collector features automatic cleaning and consists of a
filter unit, pre-separator, suction fan and suction hose.
Electrical system
The 24 V electrical system is supplied with current by an alternator and two batteries.
The electrical system comprises starting equipment, work lighting, electric controls
and safety devices.

15
Operator's instructions
1. General
The emergency stop buttons/cables are connected in series with the diesel engine cut-
out system. As soon as an emergency stop button/cable is activated, the diesel engine
will be stopped immediately. Reset the emergency stop buttons before restarting the
engine. The engine cannot be started while one of the emergency stops is still acti-
vated.
For further details, see separate wiring diagram.
For details of the diesel engine, see separate diesel engine instructions.
Hydraulic system
The principal components of the hydraulic system comprise oil cooler, hydraulic oil
tank, valves, hoses and four hydraulic pumps.
The four hydraulic pumps create hydraulic pressure in order to control the different
functions. The table below indicates which hydraulic pump controls which function.
Table: Description of hydraulic pump function
The hydraulic oil tank is located in the centre of the drilling carriage.
The radiator on the right side of the drilling carriage cools the water of the engine,
the intercooler and the oil compressor. The radiator on the left side cools the
hydraulic oil.
(For more information, see the separate hydraulic system drawing)
PUMP NO. DESCRIPTION
1 Winch, tramming, impact, feed drill rotation
2 Boom swing, boom lift, boom extension
3 Steering, lubricating pump, dct, stability jacks, feed swing, feed dump,
feed extension, roll over, drill steel support, RAS
4 Oil cooler

16
Operator's instructions
1. General
1
Steering
16
Impact
2
Lubrication pump
17
Feed
3
DCT
18
Drill rotation
4
Stability Jacks
19
Oil cooler
5
Feed swing
20
Pump 4
6
Feed dump
21
Diesel engine
7
Feed extension
22
Pump 1
8
Roll over
23
Pump 2
9
Drill steel support
24
Pump 3
10
RAS
25
Hydraulic tank
11
Boom Swing
26
Return filter
12
Boom lift
27
Oil collector
13
Boom extension
28
Radiator
14
Winch
29
Return oil
15
Tramming motor
30
Thermostat

17
Operator's instructions
2. Technical data
Hydraulic pumps
Hydraulic pump 1
Main hydraulic system pump 1 is a variable-displacement piston
type. The pump supplies hydraulic power to the following
functions:
Winch,
tramming,
impact,
feed drill rotation
Hydraulic pump 2
Hydraulic pump 2 supplies hydraulic oil to provide power to the boom.
Boom swing,
boom lift,
boom extension
Hydraulic pump 3
Hydraulic pump 3 supplies hydraulic oil to power the
Steering,
lubricating pump,
dct,
stability jacks,
feed swing,
feed dump,
feed extension,
roll over,
drill steel support,
RAS
Hydraulic pump 4
Hydraulic pump 4 supplies hydraulic oil to power the oil cooler motor.
Pump no. CC Flow (litre/min) Pressure (bar, max.)
1 60 139 280
2 30 62 260
3 10 26 260
4 7 26 150
Air system
The air system consists of the compressor with oil separator, hoses and valves. The
compressor is belt-driven from the diesel engine.
The compressor element is lubricated by an air-oil mixture. The mixture is separated
in the oil separator. The system supplies air for flushing in the bore hole, cleaning of
the dust collector filter and the rock drill lubrication system and ECL.

18
Operator's instructions
2. Technical data
2.Technical data
FlexiROC T20 R
Weight (standard equipment without drill steel)
FlexiROC T20 R
Weight 5750 kg
Performance
Diesel engine, Cummins QSB3.3
power output at 2400 rpm/min 82 kW 110 HP
Temperature range in operation
-25° C +40° C
Tramming speed, max.
5 Km/h
Traction force (low/high gear)
59 kN
Ground clearance
220 mm
Max. hydraulic pressure
290 bar
Noise Level
Max. engine speed (2500 giri/min.) 117 dB (A)
Drilling (2500 giri/min.) 124,5 dB (A)
128 dB(A) guaranteed
Tilt angles
Note
Stability is specified with respect to CE standards stipulating that rigs must not be
operated on inclines steeper than 20 degrees without the use of a winch.
ANGLES MUST NOT BE COMBINED!
Tilt angles for drill rig when drilling:
longitudinally, max. (Downward/Upward) 20°
lateral (left/right). 10°
laterally, (left/right), in extreme positions. 10°
Tilt angles - tramming (in direction):
downward/upward, max. without winch 20°
laterally, max. (Left/Right) 10°
downward/upward, with winch >20° - < 30°
Max pressure on the ground of stability jacks 0.5MPa

19
Operator's instructions
2. Technical data
Hydraulic systems
Hydraulic oil cooler for max. ambient
temperature 40° C
Electrical system
Voltage 24V
Batteries
Voltage 2 x 12 V/100 Ah
Front working floodlights
Voltage 2 x 70 W
Rear working floodlights
Voltage 1 x 24V LED
Column working floodlights
Voltage 2 x 24V LED
Generator
Voltage 24 V/55 Ah
Air system
Compressor: Gardner Denver E6 Plus
Max. air pressure 12 bar
Free air delivery 50 l/s
Capacities
Hydraulic oil reservoir
min/max level 50 / 60 l
Hydraulic systems
total 120 l
Fuel tank 140 l
Compressor oil 9 l
Lubricating oil tank 6 l
Diesel engine oil 8,5 l
Engine cooling system 15 l
Miscellaneous
Fire extinguisher
A-B-C powder 1 x 6Kg
Tire pressure 5,2 bar
Components weight
Boom 650Kg
Feed 600Kg max
Pomp cover 75 Kg max

20
Operator's instructions
2. Technical data
Dimensions
Dimensions
Transport dimensions
Feed lenght
Length A
Height B
Width
8 feet
5300 2580 1900
10 feet
4700 2580 1900
12 feet
4300 2580 1900
Figure: Transport dimensions
