E+E Elektronik EE650 User manual

GENERAL
The EE650 transmitter is designed for accurate measurement of air velocity in HVAC. It operates on the hot-film anemometer
principle and features the innovative, very robust E+E VTQ sensing element manufactured in thin-film technology combined with
state-of-the-art transfer molding.
The construction of the sensing head leads to a very low angular dependence which facilitate the installation. The mounting flange
allows for easy adjustment of the immersion depth.
The measuring range and the response time of EE650 can be selected with jumpers on the electronics board, see below
“Settings”.
EE650 is dedicated for heating, ventilation and air conditioning applications. For special applications do not hesitate to contact the
manufacturer or their local distributor.
CAUTION
• Accurate measurement results are conditioned by the correct positioning of the sensing probe in the air stream. Best accuracy
is achieved in laminar flow.
• Observe the minimum inlet and outlet path length, see page 4.
• Avoid mechanical stress onto the probe and mainly onto the sensing head.
• Observe the humidity working range 5…95% RH, non-condensing.
• Avoid installation in corrosive environment, as this may lead to sensor destruction.
CONNECTING DIAGRAM
Analogue output
AV
GND
V+
V / mA
1 ... V+ = supply voltage
2 ... GND = ground
3 ... AV = analogue output air velocity
Power supply
24 V AC/DC ±20% b ... brown
g ... green
y ... yellow
w ... white
s ... black
s w y g b
Remote sensor probe
RS485 Interface
V+
A (=D+)
RS485 B (=D-)
GND
1
2
3
4
~
Power supply
24 V AC/DC ±20 %
S1 S2
ON S1: Response time t90
ON: slow
OFF: fast
S2: Termination resistor
120 Ohm
ON/OFF
EE650 - Air Velocity Transmitter for HVAC Applications
USER‘S GUIDE

ANALOGUE SETTINGS
For performing EE650 settings via EE-PCS Product Configuration Software (download from www.epluse.com/configurator) the
working range jumper must be on HI.
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
t90
HI
MED
LO
I
U
Jumper t90
SLOW 4 sec.
(factory setting)
Jumper I
CURRENT
(factory setting)
no jumper
FAST 1 sec.
Jumper U
VOLTAGE
Jumper HI
0...20 m/s (0...4000 ft/min)
(factory setting)
Jumper MED
0...15 m/s (0...3000 ft/min)
Jumper LO
0...10 m/s (0...2000 ft/min)
Selection of response time t90
Selection of response time t90
Selection of output signal
Selection of ouput signal
Selection of measuring range
Selection of measuring range
DIGITAL SETTINGS
Hardware
The bus termination can be realized with the 120 Ohm resistor on board, slide switch S2.
Very important:
For proper function the power supply must be strong enough to ensure supply voltage within the specified range (see technical data)
at any time and at all devices in the bus. This is particularly relevant when using long and thin cables which can cause high voltage
drop; please note that a single EE650 requires peak current of 150 mA.
Address Setting
Address Switch
Address Switch
Address setting via EE-PCS Product Conguration Software:
All DIP switches at position 0 → address has to be set via PCS
Modbus (Slave device): factory setting EE650: 65 (permitted values: 1…247).
BACnet (Master device): factory setting EE650: 65 (permitted values: 0…127).
Example: Slave address is set via conguration software.
Address setting via DIP switch:
Modbus (Slave device): Setting the DIP switches to any other address than 0, overrules the slave
address set via configuration software (permitted values: 1…247).
BACnet (Master device): Setting the DIP switches to any other address than 0, overrules the slave
address set via configuration software.
BACnet Note: permitted values are 0…127.
The 8th bit of the DIP switches is ignored (ID 127 = 0111 111).
To set address 0 via DIP switches, the 8th bit shall be set to 1 (ID 0 = 1000 0000).
Example: Slave address set to 11 (= 0000 1011 binary).
00000000
0
1
11010000
0
1

FLOAT (read register):
Function code /
Register number1) [Dec]
Register address2)
[HEX]
Parameter
name
31003 0x03EA Temperature [°C]
31005 0x03EC Temperature [°F]
31041 0x0410 Airow [m/s]
31043 0x0412 Airow [ft/min]
SHORT (read register)3):
Function code /
Register number1) [Dec]
Register address2)
[HEX]
Parameter
name
34002 0x0FA1 Temperature* [°C]
34003 0x0FA2 Temperature** [°F]
34021 0x0FB4 Airow* [m/s]
34022 0x0FB5 Airow*** [ft/min]
* Values are stored with the scale 1:100 (e.g.: 2550 is equivalent to 25.5 °C)
** Values are stored with the scale 1:50 (e.g.: 2550 is equivalent to 51 °F)
*** Values are stored with the scale 1:1
INFO (read register):
Function code /
Register number1) [Dec]
Register address2)
[HEX]
Parameter
name
30001 0x00 Serial number (as ASCII)
30009 0x08 Firmware version
INTEGER (write register):
Function code /
Register number1) [Dec]
Register address2)
[HEX]
Parameter
name
60001 0x00 Slave-ID* (modbus address)
60002 0x01 Modbus protocol settings3)
* If the ID is set via DIP-Switch the response will be NAK.
Please see PICS (Product Implementation Conformance Statement) - available on www.epluse.com/EE650
BACnet Setup
Modbus Setup
1) Register number starts from 1
2) Register number starts from 0
3) For Modbus protocol setting please see Application Note Modbus (www.epluse.com)
MODBUS RTU EXAMPLE
Example of MODBUS RTU command for reading the temperature (oat value) T = 26,652524 °C from the register 0x03EA
Device EE650; slave ID 65
Reference document, chapter 6.3: http://www.modbus.org/docs/Modbus_Application_Protocol_V1_1b.pdf
Request [Hex]: 41 03 03 EA 00 02 EB 7B
Modbus ID
address
Function
code
Starting
address Hi
Starting
address Lo
No. of
register Hi
No. of
register Lo CRC
Request [Hex]: 41 03 03 EA 00 02 EB 7B
Response [Hex]: 41 03 04 38 5F 41 D5 0A E3
Modbus ID
address
Function
code Byte count Register 1 value Hi
Register 1
value Lo
Register 2
value Hi
Register 2
value Lo CRC
Response [Hex]: 41 03 04 38 5F 41 D5 0A E3
Protocol setting:
Address, baudrate, parity and stop bits can be set via:
1. Product Congurator Software (available on www.epluse.com/ee650)
2. Modbus protocol (please see Application Note Modbus (available on www.epluse.com/ee650)
CONFIGURATION AND ADJUSTMENT
The EE650 as ordered is ready for use immediately and requires no configuration by the user. If required, the optional Configuration
Adapter Cable and the E+E Product Configuration Software (EE-PCS) can be used for changing the factory setup as well as for adju-
sting of the air velocity measurement.
Note: The EE650 must not have any additional power supply when using the Conguration Adapter Cable HA011066.
PC
HA011066
For product data sheets EE-PCS please see www.epluse.com.
The E+E Product Configuration Software (EE-PCS) is free and can be downloaded from www.epluse.com/configurator.

TECHNICAL DATA
Measuring range
Working range 1) 0...10 m/s (0...2000 ft/min)
0...15 m/s (0...3000 ft/min)
0...20 m/s (0...4000 ft/min) (factory setting)
Accuracy at 20 °C 2) (68 °F), 0.2...10 m/s (40...2000 ft/min) ± (0.2 m/s (40 ft/min) + 3 % of m. v.)
45 % RH, 1013 hPa 0.2...15 m/s (40...3000 ft/min) ± (0.2 m/s (40 ft/min) + 3 % of m. v.)
0.2...20 m/s (40...4000 ft/min) ± (0.2 m/s (40 ft/min) + 3 % of m. v.)
Response time τ90
1) typ. 4 sec. (factory setting) or typ. 1 sec. at constant temperature
Output
Analogue 1) 0 - 10 V -1 mA < IL< 1 mA
0...10 m/s / 0...15 m/s / 0...20 m/s 4 - 20 mA (factory setting) RL< 500 Ω(linear, 3-wires)
Digital interface RS485 with max. 32 devices on one bus
Protocol Modbus RTU or BACnet MS/TP
General
Power supply (Class III) 24 V AC/DC ± 20 %
Current consumption
Electrical connection screw terminals max. 1.5 mm2 (AWG 16)
Cable gland M16x1.5
Electromagnetic compatibility EN61326-1 EN61326-2-3
Industrial Environment
Enclosure material Polycarbonate, UL94V-0 approved
Protection class Enclosure IP65 / NEMA 4, remote probe IP20
Temperature range working temperature probe -25 ... 50 °C (-13...122 °F)
working temperature electronic -10 ... 50 °C (14...122 °F)
storage temperature -30 ... 60 °C (-22...140 °F)
Working range humidity 5...95 % RH (non-condensing)
1) Selectable by jumper, only for analogue output
2) The accuracy statement includes the uncertainty of the factory calibration with an enhancement factor k=2 (2-times standard deviation).
The accuracy was calculated in accordance with EA-4/02 and with regard to GUM (Guide to the Expression of Uncertainty in Measurement).
AC supply DC supply
Analogue ouput max. 170 mA max. 70 mA
RS485 max. 120 mA max. 50 mA
DIMENSIONS MM (INCH)
6
60
Ø > 16
FOR CONDUIT
INSTALLATION
Cable gland
M16x1,5
90
~110 or 210
Ø > 13
80,6
19
101
155
15 155
46
Cable gland
M16x1,5
Type - Duct mount
Mounting flange
Type - Remote sensor probe
SCOPE OF SUPPLY
• EE650 Transmitter according to ordering guide
• Cable gland (two pieces at output RS485 for daisy chain wiring)
• Mounting flange
• Mounting materials
• Protection cap
• Quick guide
• Two self-adhesive labels for configuration changes (see user guide at www.epluse.com/relabeling)
• Test report according to DIN EN10204 - 2.2

ACCESSORIES
• USB configuration adapter HA011066
• Product configuration software EE-PCS (free download: www.epluse.com/EE650)
• Power supply adapter V03 (see data sheet Accessories)
MOUNTING
DRILLING IN THE WALL OF THE DUCT FOR INSTALLING THE MOUNTING FLANGE
Air flow
>16 (0.63")
60 (2.4")
The arrow engraved on the sensing head of EE650 indicates the direction of the air stream during factory adjustment. When
installing the EE650 probe, make sure that the arrow matches exactly the flow direction.
Air flow
CORRECT INCORRECT
The mounting flange allows for precise setting of the EE650 immersion depth in a duct. The entire sensing head must be in the air
flow to be measured.
Immersion depth = 30 % - 50 %
of the duct diameter
duct diameter
CORRECT INCORRECT
Air flow

POSITIONING OF AIR VELOCITY SENSOR IN A VENTILATION DUCT
The reliable and accurate measurement of air velocity depends on the correct positioning of the sensor in the ventilation duct.
Accurate measurements are only possible if the air velocity probe is positioned at a location with a laminar (not-turbulent) flow.
The required length of the calming section after a fault is a function of the tube diameter D. For a rectangular channel a x b applies:
+
<6D
<6D
>3D
>3D
>6D
>6D
>6D
Mounting the sensing probe in the middle of the
channel.
The optimal position is after the filter.
Please note sufficient distance.
Positioning the probe ahead of diffusor, at a place
with high flow rate.
Positioning the probe at a location with a laminar (to-
turbulent) flow.
Turbulent flows are caused by pipe bends, branches,
behind flaps, flans, air heaters, air coolers or cross-
sectional changes.
MAINTENANCE OF THE E+E AIR VELOCITY TRANSMITTERS
Due to the absence of moving parts, the E+E air velocity transmitters are not subject to wear. The construction (shape, dimensions
and materials) of the hot film air velocity sensor is per se highly insensitive to dust and dirt. No maintenance is required under
normal environmental conditions. For operation in polluted environment it is advisable to periodically clean the sensing head by
washing it in isopropyl alcohol, preferably in an ultrasound cleaner. Alternatively shake it gently few minutes in a pot with isopropyl
alcohol and let it dry free. Do not touch or rub the sensor and do not use any mechanical tools for cleaning.

INFORMATION [phone] / [email protected]
E+E Elektronik Ges.m.b.H.
Langwiesen 7 • A-4209 Engerwitzdorf
Tel: [phone] • Fax: [phone]
[email protected] • www.epluse.com
LG Linz Fn 165761 t • UID-Nr. ATU44043101
Place of Jurisdiction: A-4020 Linz • DVR0962759
BA_EE650_e // v1.4 // Modication rights reserved
E+E Elektronik Ges.m.b.H. doesn‘t accept warranty and liability claims neither upon this publication nor in case of improper treatment
of the described products.
The document may contain technical inaccuracies and typographical errors. The content will be revised on aregular basis. These
changes will be implemented in later versions. The described products can be improved and changed at any time without prior notice.
© Copyright E+E Elektronik Ges.m.b.H.
All rights reserved.
EMC note USA (FCC):
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
EMC note Canada (ICES-003):
CAN ICES-3 (A) / NMB-3 (A)
