Savant ProAV PAV-VIM8S User manual

PAV-VIM8S-xx/PAV-VIM4S-xx QRG | 009-1480-04 1 of 3 45 Perseverance Way, Hyannis MA 02601
Copyright 2021 Savant Systems, Inc | 210428 Savant.com | 508.683.2500
Box Contents
(1) Audio/Video over IP Switch (PAV-VIM8S-xx/PAV-VIM4S-xx)
(1) Installation Kit (075-0192-xx/075-0197-xx)
(2) Standard 3U Rack Mounting Brackets (071-0638-xx)
(4) M5 x 8 mm Flat-head Phillips Screws (039-0180-xx)
(1) Power Cord (part number varies based on country)
(16) 3-Pin Screw Down Connector (028-9351-xx) - PAV-VIM8S
(8) 3-Pin Screw Down Connector (028-9351-xx) - PAV-VIM4S
(1) Product Regulatory Statement (009-1950-xx)
Required Components
–Savant Audio/Video over IP Output Receiver
–Savant System Host
–Savant qualified 10G Managed Network Switch
–Savant User Interface
–Savant Design and Configuration Tools
Item Description
AOn/O
Button
Reboots the main board (mcu) and power cycles
the IP Video transmit (Tx) cards.
BReset
Button
Press and Release - Resets the IP Video transmit
(Tx) cards.
Press and hold – Clears the network settings. Press
and hold the button for 5 seconds until the Status
LED blinks red rapidly; then release.
CPower
LED
O – Device is o. No power applied.
Green – Main board is powered.
DStatus 1
LED
Blinks Twice – Provisioned to the local network
and is trying to connect to the Host.
Rapid Blink (green) – The reset button was
pressed and held for five seconds, and the device
is performing a factory reset. All network settings
get cleared.
Short O Blink – Firmware is updating.
EStatus 2
LED Reserved for future use.
Front Panel
Network Configuration
To ensure the IP Address will not change due to a power outage,
Savant recommends using DHCP reservation within the router. By
using this method, IP Addresses for all devices can be managed from a
single UI, avoiding the need to access devices individually.
NOTE: Setting DHCP reservation varies from router to router. Refer to
the documentation for the router to configure DHCP reservation.
Installation
The Savant Pro AV 8-port / 4-port Transmitter chassis can be mounted
using the included rack-mounting ears and hardware in a 3U rack
style enclosure and is compatible with all standard 19-inch National
Electrical Manufacturers Association (NEMA) rack mounts. For more
information, see the Savant IP Video Deployment Guide (009-1977-xx)
on the Savant Customer Community.
On/O
Reset Power Status 1 Status 2
A
B
C
D
E
Compliance
Safety and
Emissions
FCC Part 15 CE C-Tick ETL
RoHS Compliant
Supported Releases
PAV-VIM8S-00 da Vinci 8.7 and higher
PAV-VIM4S-00
PAV-VIM8S-10 da Vinci 9.3.4 and higher
PAV-VIM4S-10
Power
Input Power 100-240V AC 50/60Hz, (5A maximum)
Nominal Power N. America - 144VA - (1.2 A @ 120V AC, 60Hz)
International - 156VA - (.68 A @ 240V AC 50Hz)
Maximum Power N. America - 400VA - (4 A @ 120V AC, 60Hz)
International - 432VA - (1.8 A @ 240V AC 50Hz)
Power Cable IEC320 C13 three-pole detachable power card.
Dimensions and Weights
Height Width Depth Weight
Device 5.21 in
(13.23 cm)
17.30 in
(43.94 cm)
14.24 in
(36.17 cm)
14.5 lb
(6.59 kg)
Shipping 22.0 in
(55.88 cm)
22.0 in
(55.88 cm)
10.0 in
(25.4 cm)
18.25 lb
(8.27 kg)
Rack Space 3U
Environmental
Temperature 32° to 104° F (0° to 40° C)
Humidity 10% to 90% Relative Humidity (non-condensing)
Cooling 70 cubic feet per minute (CFM) recommended.
BTU 1365 BTU/hr
Specifications
Network Requirements
For more information, see the Savant Device Networking Guidelines on
the Savant Customer Community
See the following documents located on the Savant Customer
Community for more information.
–Savant IP Video Deployment Guide (009-1977-xx)
–Savant IP Video Network Configuration Guide (009-1552-xx)
–Savant IP Audio Deployment Guide (009-1571-xx)
Additional Information
Savant® ProAV 8 or 4 Input Transmitter 4K UHD with Control [PAV-VIM8S/PAV-VIM4S]
Quick Reference Guide

PAV-VIM8S-xx/PAV-VIM4S-xx QRG | 009-1480-04 2 of 3 45 Perseverance Way, Hyannis MA 02601
Copyright 2021 Savant Systems, Inc | 210428 Savant.com | 508.683.2500
Item Description
A
1 Gigabit
Ethernet
1G of reserved network data bandwidth
commonly used to connect any network
compliant device to transmit its data onto the
Ethernet network by sharing the 10G network
link. 8-Pin RJ-45 female connection.
IMPORTANT!: Do not connect these ports to a
network switch.
B10 Gigabit
Ethernet
SFP+ Housing; Used for connectivity to the
10G Ethernet Network Switch
IMPORTANT!: For all 10G connections, use
only Savant certified SFP+ Direct-Attach
Copper (DAC) cables, or Savant certified
fiber and fiber connectors along with Savant
certified SFP+ modules.
C
Rx/Tx LEDs
(10 GbE)
Rx – Link activity LED indicator for all data
received on the 10G connection.
Tx – Link activity LED indicator for all data
transmitted from the 10G connection.
D
HDMI In
19-Pin Type A HDMI female digital audio/video
input.
–Supports HDMI 2.0a
–HDMI 2.0 compliant cable is required for
4K content.
E
Power Input
Module
100-240V AC 5A 50/60Hz power input
module with On/O switch.
I – Applies power to the device.
O – Removes power from the device.
NOTE: Includes a field replaceable 5A 250V
fast acting fuse.
F
Grounding Chassis Ground (optional)
GRS-232
Control Port
Transmits and receives serial data to and
from controllable serial devices. For pin-
out information, refer to the RS-232 Wiring
section.
HIR Control
Port
IR signaling gets transmitted via an IR Flasher
to devices with either an IR receiver (5V
tolerant) or IR input port. Pin-out information
is available in the IR Wiring section.
I
Analog
Audio Out
RCA Analog Audio Output.
Requires HDMI input stereo PCM audio format.
Direct Line Level 2.1-VRMS Output
J
Push Buttons Push buttons – Reserved for future use.
K
Ethernet 8-Pin RJ-45 female connection. Used to
communicate with the Savant Host.
L
Reserved 8-Pin RJ-45 female connection;
Reserved for future use
Rear Panel Wiring and Connections
Supported Audio and Video Formats
IR connections are made using a 3-pin connector supplied with the
device. The wire slips into the hole and locks with a screw located
at the top of the connector. See the 3-Pin Screw Down Connections
section below.
IMPORTANT PRECAUTIONS!
–IR emitters must be located 15 feet (4.6 meters) from the
controller’s location.
–Use of 3rd party blinking IR emitters with Talk Back is not
recommended. These types of emitters can draw voltage
away from the IR signal that can degrade IR performance.
IR Wiring
Serial control connections are made using a 3-pin connector supplied
with the device. The wire slips into the hole and locks with a screw
located at the top of the connector. See the 3-Pin Screw Down
Connections section below.
RS-232 Wiring
Enhanced small form-factor pluggable connection. Use a Savant
certified Direct Access Copper (DAC) SFP+ cable to connect the
chassis to the 10G switch, or Savant certified fiber and fiber connectors
along with Savant certified SFP+ modules.
Transport Distance
DAC cable 6 ft (2 m)
OM3 multi-mode Fiber 1000ft (300 m)
SFP+ 10 GbE
Video
HDR Supported
Dolby Vision Supported
Supported
Formats
640x48051280x72041920x108043840x21603
720x48051280x72051920x108053840x21604
720x57641280x102451920x120053840x21605
800x60051920x108013840x216014096x21603
1024X76851920x108033840x216024096x21605
Audio (Pass-though)
–DTS
–DTS-X
–DTS-HD Master Audio™
–DTS-HD (LBR)
–DTS-HD (HRA)
–DTS Digital Surround 96/24™
–Dolby Atmos
–Dolby TrueHD™
–Dolby Digital (AC-3)
–Dolby Digital Plus (E-AC-3)
–Multi-Channel PCM
–All HDMI Audio formats
Audio (Down Mix)
Multi-channel PCM Audio to 2-Channel Stereo PCM
1 = at 24 Hz
2 = at 25 Hz
3 = at 30 Hz
4 = at 50 Hz 5 = at 60 Hz
LRLR R LRL L
R R L L R R
G
F
E
C
B
A
HIJKL
D
3
2
1PIN 1
IR -
PIN 2 IR +
PIN 3
Not Used
Out
G
3
2
1PIN 1
Ground
PIN 2 Transmit
PIN 3
Receive
Rx
Tx
G

PAV-VIM8S-xx/PAV-VIM4S-xx QRG | 009-1480-04 3 of 3 45 Perseverance Way, Hyannis MA 02601
Copyright 2021 Savant Systems, Inc | 210428 Savant.com | 508.683.2500
ELECTRIC SHOCK HAZARD: Prior to starting the process of removing and replacing a fuse, remove the AC Power by unplugging the power
cord from the rear of the unit.
1. Verify the power cord is unplugged from either the wall outlet or
the rear of the unit.
2. With a small flat blade screwdriver or similar, pry open and pivot
down the fuse holder cover.
3. Using that same screwdriver, gently loosen and pull the fuse
cartridge slowly out from the unit. Make note of the orientation
of the fuse cartridge as it is removed. When re-Installing, it is
important that it be positioned the same way as it came out to
ensure proper operation. Refer to diagram below
TIP: Mark the chassis and fuse holder to ease the re-installation
process.
4. Remove the old fuse from the cartridge and discard. Place the new
fuse into the cartridge.
5. Place the cartridge part way into the receptacle being careful to
align it as defined in the diagram. Gently push the fuse cartridge
until it seats with the terminals at the rear of the slot. If resistance
is encountered, DO NOT apply more pressure. Stop pushing on the
cartridge, remove it, verify the orientation is correct, and repeat
step 5 until cartridge is seated.
IMPORTANT: The orientation of the cartridge within the unit and location of the fuse within the cartridge are crucial to proper operation.
Make note of the orientation of the cartridge and the fuse location within the cartridge before removing.
Replacing the Fuse
2
3
4
5
When making connections, follow the guidelines set below to ensure a
safe and secure connection.
3-Pin Screw Down Connections
1. With a small slotted screwdriver,
turn the screws on the connector
counterclockwise (CCW) until the
silver crimps open enough to slide a
wire into the square slots.
2. Strip back insulation on each wire to
/4 inch and insert the stripped wire
into the proper connection.
3. Turn the screw clockwise (CW) until
the crimps tighten around each wire.
Gently tug on each wire a bit to
verify they are secure.
< 1/8 inch of
bare wire
exposed
