Epson Stylus NX625 Series User manual

Epson Stylus NX620/625 Series
Quick Guide
Basic Copying, Printing, and Scanning
Maintenance
Network Setup
Solving Problems
®

2Contents
Contents
Loading Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Using Special Papers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Placing Originals for Copying or Scanning. . . . . . . . . . . . . . . . 9
Copying a Document or Photo . . . . . . . . . . . . . . . . . . . . . . . . . 10
Printing From a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Inserting a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Removing Your Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Printing From Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Printing in Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Printing With a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Selecting the Correct Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Scanning a Document or Photo . . . . . . . . . . . . . . . . . . . . . . . . 17
Quick Scanning From the Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . 17
Scanning With Epson Scan Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Scanning With Mac OS X 10.6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Maintaining Your Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Checking the Print Head Nozzles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cleaning the Print Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Checking Ink Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Purchasing Epson Ink Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Replacing Ink Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Network Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Wireless Network Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Wired (Ethernet) Network Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Contents 3
Solving Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Checking for Software Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Error Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Problems and Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Where to Get Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

4Loading Paper
Loading Paper
You can print documents and photos on a variety of paper types and sizes. For
details, see page 7. (For instructions on loading envelopes, see your online
User’s Guide.)
1. Pull out the paper cassette.
Note:
If you are using legal-size paper, extend the paper cassette. See your online
User’s Guide for details.
2. Slide the edge guides to the sides of the cassette, then slide the edge guide to
your paper size.

Loading Paper 5
3. Load paper against the edge guide, with the glossy or printable side face down.
(Load letterhead or pre-printed paper top edge first. Always load paper short
edge first; don’t load it sideways.)
Note:
Make sure the paper is loaded against the edge guide and not sticking out from the
end of the cassette.
Fan the paper and align its edges before loading.
Do not use transparencies or paper with binder holes.
If you are just making a copy or printing a rough draft, plain paper is fine. However,
for the best results, use one of Epson’s special ink jet papers, as listed on page 7.
For automatic two-sided printing, use plain paper or Epson Bright White Paper.
You can load up to about 150 sheets of plain paper or 20 sheets of photo
paper. See your online User’s Guide for more information on paper loading
limits.

6Loading Paper
4. Slide the edge guides against the edges of the paper, but not too tightly.
5. Insert the cassette back into the printer.
Note:
Keep the cassette flat as you insert it.
The paper may slide forward slightly as you insert the cassette. This is normal.
Do not remove or insert the cassette while printing or copying.
6. Slide out the output tray and raise the stopper.
Note:
If you are using legal-size paper, do not raise the stopper.

Using Special Papers 7
Using Special Papers
Epson offers a wide array of high quality papers, making it easy to maximize the
impact of your documents, photos, presentations, and other projects.
You can purchase genuine Epson ink and paper at Epson Supplies CentralSM at
www.epson.com/ink3 (U.S. sales) or www.epson.ca (Canadian sales). You can
also purchase supplies from an Epson authorized reseller. To find the nearest one,
call 800-GO-EPSON (800-463-7766).
Paper name Size
Part
number
Sheet
count
Epson Presentation Paper Matte Letter (8.5 × 11 inches
[216 × 279 mm])
S041062 100
Legal (8.5 × 14 inches
[216 × 356 mm])
S041067 100
Epson Premium Presentation
Paper Matte
Borderless 8 × 10 inches
(203 × 254 mm)
S041467 50
Letter (8.5 × 11 inches
[216 × 279 mm])
S041257
S042180
50
100
Epson Premium Presentation
Paper Matte Double-sided
Letter (8.5 × 11 inches
[216 × 279 mm])
S041568 50
Epson Ultra Premium Photo
Paper Glossy
Borderless 4 × 6 inches
(102 × 152 mm)
S042181
S042174
60
100
Borderless 5 × 7 inches
(127 × 178 mm)
S041945 20
Borderless 8 × 10 inches
(203 × 254 mm)
S041946 20
Letter (8.5 × 11 inches
[216 × 279 mm])
S042182
S042175
25
50
Epson Premium Photo Paper
Semi-gloss
Borderless 4 × 6 inches
(102 × 152 mm)
S041982 40
Letter (8.5 × 11 inches
[216 × 279 mm])
S041331 20

8Using Special Papers
Epson Premium Photo Paper
Glossy
Borderless 4 × 6 inches
(102 × 152 mm)
S041808
S041727
40
100
Borderless 5 × 7 inches
(127 × 178 mm)
S041464 20
Borderless 8 × 10 inches
(203 × 254 mm)
S041465 20
Letter (8.5 × 11 inches
[216 × 279 mm])
S042183
S041667
25
50
Epson Photo Paper Glossy Borderless 4 × 6 inches
(102 × 152 mm)
S041809
S042038
50
100
Letter (8.5 × 11 inches
[216 × 279 mm])
S041141
S041649
S041271
20
50
100
Epson Bright White Paper Letter (8.5 × 11 inches
[216 × 279 mm])
S041586 500
Epson Photo Quality Self-
adhesive Sheets
A4 (8.3 × 11.7 inches
[210 × 297 mm])
S041106 10
Epson Iron-on Cool Peel Transfer
paper
Letter (8.5 × 11 inches
[216 × 279 mm])
S041153 10
Paper name Size
Part
number
Sheet
count

Placing Originals for Copying or Scanning 9
Placing Originals for Copying
or Scanning
Before you copy or scan, place your documents or photos (up to letter- or A4-size)
on the scanner glass.
1. Open the document cover.
2. Place your original face-down on the scanner glass, with the top against the
back left corner.
3. Close the cover gently to keep your original in place.

10 Copying a Document or Photo
Copying a Document or Photo
You can copy documents onto plain paper or Epson special paper just like you
would on a copy machine.
You can copy a photo onto 4 × 6-inch, 5 × 7-inch, 8 × 10-inch, letter-size, or A4-
size Epson photo paper (various types available) for instant photo reprints.
1. Load paper in the paper cassette (see page 4).
2. Place your original document or photo on the scanner glass (see page 9).
3. Press the Home button, then press u, d, l, or rto select Copy.
4. Press OK.
5. Press +or –to select the number of copies you want (up to 99).
6. Press uor dto select Color or B&W copies.
7. Press lor rto adjust the Density (darkness or lightness) of the copy.

Copying a Document or Photo 11
8. To change the layout, press xMenu, press uor dto select Paper and
Copy Settings, and press OK. Then press uor dto select Layout, and press
OK again. Select With Border to leave a small margin around the image or
Borderless to expand the image all the way to the edge of the paper (slight
cropping may occur), then press OK.
Note:
You cannot print borderless on plain paper.
9. To change paper type, paper size, or any other print settings, press uor d to
select the setting, then press OK. Press uor dto select an option, then press
OK.
Note:
Not all Paper Type, Paper Size, Layout, and Quality settings may be available
depending on the options you choose. See the online User’s Guide for details.
10. After you finish selecting settings, press xMenu to exit the settings menu.
11. Press the xStart button to begin copying. To cancel copying, press yStop/
Clear Settings.
Note:
Do not pull out paper as it is printing; it ejects automatically.

12 Printing From a Memory Card
Printing From a Memory Card
Your product lets you print photos from your digital camera’s memory card. See
the online User’s Guide for instructions.
Inserting a Memory Card
1. Insert the card into the slot, as shown. Insert just one
card at a time. For a list of compatible memory cards, see
the online User’s Guide.
The memory card access light flashes, then stays on.
Caution:
If your memory card requires an adapter, attach it before
inserting the card into the slot; otherwise, the card might
get stuck.
Do not remove the card or turn off the product while the
light is flashing, or you may lose data on the card.
2. See the online User’s Guide to select and print your photos.
Removing Your Card
After you finish printing your photos, follow these steps to remove the card:
1. Make sure the memory card access light is not flashing.
2. If the product is connected to your computer with a USB cable, do one of the
following before removing the memory card or turning off the printer:
■Windows®:Right-click the name of your card (removable disk) in My
Computer or Windows Explorer, and select Eject.
■Macintosh®:Drag the removable disk icon from your desktop into
the trash.
3. Pull the card straight out of its slot.
Memory card
access light

Printing From Your Computer 13
Printing From Your Computer
This section describes the basic steps for printing from a Windows or Macintosh®
computer. For detailed instructions on printing, see the online User’s Guide.
Tip:
It’s a good idea to check for updates to your Epson product software; see page 45.
Printing in Windows
1. Open a photo or document in a printing program, and select the print option.
2. Select Epson NX620 Series or Epson Stylus NX620, then click the
Preferences or Properties button.
3. On the Main tab, select basic print settings. Make sure you choose the correct
paper Type setting for your paper (see page 16).
Tip:
For more information about print settings, click Help.
4. To resize your printout or print double-sided, click the Page Layout tab.
Select the type of
document you’re
printing (choose
Photo or Best
Photo for pictures)
Select your
document or photo
Orientation
Select your
paper Size
Select your
paper Type
Click here for
borderless photos

14 Printing With a Macintosh
5. For more printing options, click the Advanced tab.
6. Click OK to save your settings.
7. Click OK or Print to start printing. This window appears and shows the
progress of your print job.
Printing With a Macintosh
Follow the steps below to print from Mac OS®X 10.5 to 10.6.
Note:
If you’re printing from Mac OS X 10.4, see your online User’s Guide for instructions.
1. Open a photo or document in a printing program, and select the print option.
2. Select Epson Stylus NX620 as the Printer setting.
3. Click the arrow to expand the Print window, if necessary.
Cancel
printing
Click to expand
Select your Epson product

Printing With a Macintosh 15
4. Select basic copy and page settings. For borderless photos, choose a Paper
Size setting with a Borderless option.
Note:
If the setting you want isn’t shown (for example, Scale), check for it in your
application before printing or check for it at the bottom of this window.
5. Choose Print Settings from the pop-up menu, and select these print settings:
6. Choose any other printing options you may need from the pop-up menu. See
the online User’s Guide for details.
Copy and
page settings
Application
settings
Choose Print Settings
Select your Media Type
(see page 16)
Select higher quality or
faster printing (if
available)
Select Color or
Black/Grayscale output

16 Selecting the Correct Paper Type
7. Click the Advanced button to change additional settings.
Note:
For more information on print settings, click ?.
8. Click Print.
9. To monitor your print job, click the printer icon in the Dock.
Selecting the Correct Paper Type
Select the correct Type (see page 13) or Media Type (see page 15) setting in your
printer software so the ink coverage can be adjusted accordingly.
For this paper/media Select this setting
Plain paper
Epson Bright White Paper
Epson Presentation Paper Matte
Epson Iron-on Cool Peel Transfer paper
Epson Photo Quality Self-adhesive Sheets
Plain Paper/Bright White Paper
Epson Ultra Premium Photo Paper Glossy Ultra Premium Photo Paper Glossy
Epson Premium Photo Paper Glossy Premium Photo Paper Glossy
Epson Photo Paper Glossy Photo Paper Glossy
Epson Premium Photo Paper Semi-gloss Premium Photo Paper Semi-Gloss
Epson Premium Presentation Paper Matte
Epson Premium Presentation Paper Matte
Double-sided
Premium Presentation Paper Matte
Envelopes Envelope
C
ancel
printing
Select the
print job
Pause or
resume
printing

Scanning a Document or Photo 17
Scanning a Document or Photo
You can use your Epson Stylus NX620/625 Series to scan original documents and
photos and save them on your computer.
Quick Scanning From the Control Panel
You can quickly scan a photo or document and save it on your computer. You can
even scan a photo and have it automatically included in an email message.
Note:
For Mac OS X 10.6, see “Scanning With Mac OS X 10.6” on page 19.
1. Place your original document or photo on the scanner glass (see page 9).
2. Press the Home button, then press u, d, l,
or rto select Scan.
3. Press OK, then press uor dto select one of the
following options:
■Scan to PC automatically creates a JPG
image and saves it to your computer; ideal for
scanning photos
■Scan to PC (PDF) automatically creates a PDF file and saves it to your
computer; ideal for scanning documents
■Scan to PC (Email) automatically scans a photo, resizes it, launches your
email application, and attaches a JPG image to a new outgoing message
4. Do one of the following:
■If you connected your product to your computer with a USB cable, press
OK to select USB Connection and begin scanning.
■If you connected your product to a wireless or wired network, press
uor duntil you see your computer name, then press OK to begin
scanning.
Once your image is scanned, you see its icon in Windows Explorer or
Macintosh Finder, or as an attachment in your email application.

18 Scanning With Epson Scan Software
Scanning With Epson Scan Software
You can scan from any TWAIN-compliant application using Epson Scan. Or you
can start Epson Scan directly from your computer and save your image to a file.
Note:
For detailed scanning instructions, see the online User’s Guide. For Mac OS X 10.6, see
“Scanning With Mac OS X 10.6” on page 19.
1. Place your original document or photo on the scanner glass (see page 9).
2. Do one of the following to start Epson Scan:
■Windows:
Double-click the EPSON Scan icon on your desktop.
■Mac OS X 10.4 and 10.5:
Open the Applications folder, open the Epson Software folder, and
double-click the EPSON Scan icon
■To scan from an application, start your application. Then open the File
menu, choose Import or Acquire, and select your product.
3. Epson Scan opens in Full Auto Mode the first time you use it. (You can
change the scan mode using the Mode selector in the upper right corner.)
4. Click Scan.
Click here to change
the scan mode

Scanning With Mac OS X 10.6 19
The image is scanned and you see its icon in Windows Explorer or Macintosh
Finder.
Scanning With Mac OS X 10.6
You can scan original documents and photos and save them as files on your
computer.
1. Open an image editing application such as Preview and select Import From
Scanner from the File menu, then select Epson Stylus NX620 or Epson
Stylus NX625.
2. If you would like to select scan settings, such as Color Restoration and File
Save settings, click Show Details.
3. Click the Scan button to begin scanning. Your image is saved to the folder
selected in the Scan To pop-up menu.

20 Maintaining Your Product
Maintaining Your Product
Follow the instructions in this chapter to check and clean the print head nozzles,
check ink levels, and replace ink cartridges. If you need to align the print head, see
the online User’s Guide.
Caution:
To keep your product looking like new, don’t place anything on top of the cover or use it
as a writing surface, If you need to clean the cover, use only a soft, non-abrasive
microfiber-type cloth.
Checking the Print Head Nozzles
If your printouts are faint or have gaps in them, some of the nozzles in the print
head may be clogged or ink may be running low in one or more of the ink
cartridges. Follow the steps below to check the print head nozzles.
1. Load a few sheets of plain paper in the paper cassette (see page 4).
2. Press Home, then press u, d, l, or rto
select Setup.
3. Press OK, press uor dto select Maintenance,
then press OK again.
4. Press uor dto select Nozzle Check, press OK,
then press the xStart button.
5. Check the nozzle check pattern that prints to see if there are gaps in the lines.
6. If there are no gaps, the print head is clean. Press OK and then press
Home to continue printing.
If there are gaps or the pattern is faint, press uor dto select Head Cleaning,
then press OK to clean the print head (see page 21).
Nozzles are clean Nozzles need cleaning
