Epson Stylus TX400 Series Assembly instructions

Basic Operation Guide
EN
- for use without a computer -
Panduan Dasar Pemakaian
ID
- untuk penggunaan tanpa komputer -

2
About This Guide
Tentang Panduan Ini
Follow these guidelines as you read your instructions:
Ikuti pedoman berikut saat Anda membaca instruksi yang ada:
w c QR&
Warning:
Warnings must be followed
carefully to avoid bodily injury.
Caution:
Cautions must be observed
to avoid damage to your
equipment.
Must be observed to avoid
bodily injury and damage to
your equipment.
Note:
Notes contain important
information and hints for using
the printer.
Indicates a page number where
additional information can be
found.
Peringatan:
Peringatan harus diikuti dengan
hati-hati untuk menghindari
cacat sik.
Perhatian:
Perhatian harus dipatuhi untuk
menghindari kerusakan pada
peralatan Anda.
Harus dipatuhi untuk
menghindari cacat sik dan
kerusakan peralatan.
Catatan:
Catatan berisi informasi
penting dan petunjuk untuk
menggunakan printer ini.
Menunjukkan nomor halaman di
mana informasi tambahan dapat
ditemukan.

3
Handling
Penanganan
Photo Print Mode Reprint
Mode Cetak Foto Cetak ulang
Copy Mode Photos/Documents
Mode Salin Foto/Dokumen
R&19R&13
Memory Card Mode Photos Index Sheet
Mode Kartu Memori Foto Lembar Indeks
R&33
R&25

4
Important Safety Instructions............................................................................................................................. 6
Guide to Control Panel ..........................................................................................................................................8
Using the LCD Screen...........................................................................................................................................10
Handling Media
Selecting Paper..................................................................................................................................................14
Loading Paper....................................................................................................................................................15
Placing Originals ...............................................................................................................................................16
Inserting a Memory Card...............................................................................................................................17
Copying
Copying Photos or Documents ...................................................................................................................20
Copy Mode Menu List.....................................................................................................................................22
Printing from a Memory Card
Printing Photos..................................................................................................................................................26
Printing From an Index Sheet.......................................................................................................................28
Memory Card Mode Menu List ....................................................................................................................31
Photo Print Mode
Reprint / Restore Photos ................................................................................................................................34
Photo Print Mode Menu List.........................................................................................................................36
Setup Mode (Maintenance)
Checking the Ink Cartridge Status..............................................................................................................40
Checking/Cleaning the Print Head.............................................................................................................42
Aligning the Print Head..................................................................................................................................44
PictBridge Setup................................................................................................................................................46
Setup Mode Menu List....................................................................................................................................48
Solving Problems
Error Messages...................................................................................................................................................52
Replacing Ink Cartridges................................................................................................................................54
Paper Jam ............................................................................................................................................................57
Print Quality Problems....................................................................................................................................58
Print Layout Problems.....................................................................................................................................59
Contacting Customer Support.....................................................................................................................60
Index ..........................................................................................................................................................................61
Contents
EN Daftar Isi ID
Instruksi Keamanan Penting................................................................................................................................6
Panduan untuk Panel Kontrol............................................................................................................................. 8
Menggunakan Layar LCD...................................................................................................................................10
Penanganan Media
Memilih Kertas...................................................................................................................................................14
Memuatkan Kertas...........................................................................................................................................15
Menempatkan Dokumen Asli ......................................................................................................................16
Memasukkan Kartu Memori .........................................................................................................................17
Menyalin
Menyalin Foto atau Dokumen......................................................................................................................20
Daftar Menu Mode Copy................................................................................................................................22
Mencetak dari Kartu Memori
Mencetak Foto...................................................................................................................................................26
Mencetak Dari Lembar Indeks .....................................................................................................................28
Daftar Menu Mode Memory Card...............................................................................................................31
Mode Cetak Foto
Mencetak kembali/ Memulihkan Foto......................................................................................................34
Daftar Menu Mode Photo Print ...................................................................................................................36
Mode Setup (Pemeliharaan)
Memeriksa Status Cartridge Tinta...............................................................................................................40
Memeriksa/Membersihkan Print Head.....................................................................................................42
Meratakan Print Head .....................................................................................................................................44
PictBridge Setup................................................................................................................................................46
Daftar Menu Mode Setup ..............................................................................................................................48
Menyelesaikan Masalah
Pesan Kesalahan................................................................................................................................................52
Mengganti Cartridge Tinta............................................................................................................................54
Kertas Tersangkut .............................................................................................................................................57
Masalah Kualitas Cetakan..............................................................................................................................58
Masalah Penataan Cetakan...........................................................................................................................59
Menghubungi Dukungan Pelanggan .......................................................................................................60
Indeks ........................................................................................................................................................................62

5

6
Important Safety Instructions
Instruksi Keamanan Penting
Use only the power cord that
comes with the printer. Use of
another cord may cause re or
shock. Do not use the cord with
any other equipment.
Make sure the power cord
meets all relevant local safety
standards.
Place the printer near a wall
outlet where the power cord
can be easily unplugged.
Use only the type of power
source indicated on the label.
Do not let the power cord
become damaged or frayed.
Do not open the scanner unit
while copying, printing, or
scanning.
Gunakan hanya kabel daya
yang disertakan dengan
printer. Penggunakan kabel
lain dapat menyebabkan
kebakaran atau sengatan listrik.
Jangan gunakan kabel dengan
peralatan lain.
Pastikan kabel daya memenuhi
semua standar keamanan lokal
yang relevan.
Tempatkan printer di dekat
stopkontak dinding di mana
kabel daya dapat dicabut
dengan mudah.
Gunakan hanya jenis sumber
daya yang dsebutkan pada
label.
Jangan biarkan kabel daya
rusak atau terkoyak.
Jangan buka unit pemindai
sampai penyalinan,
pencetakan, atau pemindaian
selesai.

7
Do not use aerosol products
that contain ammable gases
inside or around the printer.
Doing so may cause re.
Except as specically explained
in your documentation, do not
attempt to service the printer
yourself.
Keep ink cartridges out of the
reach of children and do not
drink the ink.
If ink gets on your skin, wash
it o with soap and water. If it
gets in your eyes, ush them
immediately with water. If
you still have discomfort or
vision problems, see a doctor
immediately.
Do not shake ink cartridges
after opening their packages;
this can cause leakage.
If you remove an ink cartridge
for later use, protect the ink
supply area from dirt and
dust and store it in the same
environment as the printer. Do
not touch the ink supply port
or surrounding area.
Jangan gunakan produk-
produk aerosol yang
mengandung gas yang
mudah terbakar di dalam atau
di sekitar printer. Ini dapat
menyebabkan kebakaran.
Kecuali secara khusus
dijelaskan di dalam
dokumentasi Anda, jangan
pernah mencoba untuk
memperbaiki printer Anda
sendiri.
Jauhkan cartridge tinta dari
jangkauan anak-anak dan
jangan minum tinta.
Jika tinta mengenai kulit Anda,
cuci bersih dengan sabun dan
air. Jika tinta mengenai mata
Anda, siram segera dengan
air. Jika Anda masih merasa
tidak nyaman atau mengalami
masalah pengelihatan,
kunjungi dokter segera.
Jangan kocok cartridge tinta
setelah membuka bungkusnya;
ini dapat menyebabkan
kebocoran.
Jika Anda melepaskan cartridge
tinta untuk digunakan lain
waktu, lindungi wilayah
persediaan tinta dari kotoran
dan debu dan simpan di
lingkungan yang sama dengan
printer Anda. Jangan sentuh
port persediaan tinta atau
wilayah sekitarnya.

8
Guide to Control Panel
Panduan untuk Panel Kontrol
a b c
Mode
+, - x
r[Copy]C[Memory Card]J[Photo]
Enters Copy mode. Enters Memory Card
mode.
Enters Photo Print
mode.
Sets the number of
copies.
Displays detailed
settings for each
mode.
Masuk mode Copy. Masuk mode Memory
Card.
Masuk mode Photo
Print.
Menetapkan jumlah
salinan.
Menampilkan
pengaturan rinci
untuk tiap mode.

9
d e f g h i j
y F [Setup]G[Display/
Crop]x P On y
Selects photos and
menu items.
Cancels/returns to the
previous menu.
Runs maintenance
programs.
Changes the view of
photos or crops the
photos.
Starts copying/
printing.
Turns on/o printer. Stops copying/
printing or resets
settings.
Memilih foto dan item
menu.
Membatalkan/kembali
ke menu sebelumnya.
Menjalankan program
pemeliharaan.
Mengubah tampilan
foto atau memotong
foto.
Mulai menyalin/
mencetak.
Menghidupkan/
Mematikan printer.
Berhenti menyalin/
mencetak atau
mengembalikan
pengaturan.
Control panel design varies by area.
Desain panel kontrol tergantung pada wilayah.

10
Using the LCD Screen
Menggunakan Layar LCD
a b c d e
Use Copies + or - to set
the number of copies for
the selected photo.
Press lor rto select the
setting item.
Press uor dto select
the menu item. The
highlight moves up or
down.
Press rto open the
setting item list.
Press lor rto change
the photo displayed on
the LCD screen.
Gunakan Copies + atau
- untuk menentukan
jumlah salinan foto yang
dipilih.
Tekan latau r
untuk memilih item
pengaturan.
Tekan uatau d
untuk memilih item
pengaturan. Sorotan
bergeser ke atas atau ke
bawah.
Tekan runtuk
membuka daftar item
pengaturan.
Tekan latau runtuk
mengganti foto yang
ditampilkan pada layar
LCD.

11
Q
The icon is displayed on a cropped image.
Ikon ditampilkan pada gambar yang dipotong.

12

13
Handling Media
Penanganan Media

14
Selecting Paper
Memilih Kertas
The availability of special paper
varies by area.
Ketersediaan kertas khusus
tergantung pada wilayah.
If you want to print
on this paper...
Choose this Paper
Type on the LCD
screen
Loading capacity
(sheets)
(a) Plain paper Plain Paper [12 mm] *¹
(b) Epson Bright
White Paper
Plain Paper 80
(c) Epson Premium
Ink Jet Plain Paper
Plain Paper 80
(d) Epson Matte
Paper Heavyweight
Matte 20
(e) Epson Photo
Quality Ink Jet
Paper
Matte 80
(f) Epson Premium
Glossy Photo Paper
Prem.Glossy 20
(g) Epson Premium
Semigloss Photo
Paper
Prem.Glossy 20
(h) Epson Ultra
Glossy Photo Paper
Ultra Glossy 20
(i) Epson Glossy
Photo Paper
Photo Paper 20
*1 Paper with a weight of 64 to 90 g/m².
Jika Anda ingin
mencetak pada
kertas ini...
Pilih Jenis Kertas ini
pada layar LCD
Kapasitas muatan
(lembar)
(a) Kertas biasa Plain Paper [12 mm] *¹
(b) Kertas Putih
Terang Epson
Plain Paper 80
(c) Kertas Biasa
Tinta Jet Premium
Epson
Plain Paper 80
(d) Kertas Matte
Epson Heavyweight
Matte 20
(e) Kertas Ink Jet
Kualitas Foto Epson
Matte 80
(f) Kertas Foto
Glossy Premium
Epson
Prem.Glossy 20
(g) Kertas Foto
Semigloss Premium
Epson
Prem.Glossy 20
(h) Kertas Foto
Glossy Ultra Epson
Ultra Glossy 20
(i) Kertas Foto
Glossy Epson
Photo Paper 20
*1 Kertas dengan berat 64 sampai 90 g/m².

15
Loading Paper
Memuatkan Kertas
Open and slide out.
Buka dan geser keluar.
Flip forward.
Balikkan ke depan.
Load printable side up.
Muatkan sisi yang untuk dicetak
menghadap ke atas.
Fit.
Pas kan.
A B
C D
Do not use paper with binder
holes.
Jangan gunakan kertas dengan
lubang jilidan.
Q
Align the edges of the paper
before loading.
Ratakan tepi kertas sebelum
memuatkan.
Q
See the online User’s Guide when
using Legal size paper.
Lihat Panduan Pengguna online
saat menggunakan kertas ukuran
Legal.
Q

16
Placing Originals
Menempatkan
Dokumen Asli
Place face-down horizontally.
Tempatkan menghadap ke bawah
secara horizontal.
A B
Place image in the corner.
Tempatkan gambar pada ujung.
Place photos 5 mm apart.
Tempatkan foto-foto 5 mm secara
terpisah.
You can reprint photos from
30 × 40 mm to 127 × 178 mm.
Anda dapat mencetak foto dari
ukuran 30 × 40 mm sampai
127 × 178 mm.
Q
You can copy photos of dierent
sizes at the same time if they are
larger than 30 × 40 mm.
Anda dapat menyalin berbagai
ukuran foto pada saat yang sama
jika ukurannya lebih dari 30 × 40
mm.
Q

17
Do not try to force the card all the
way into the slot. It should not be
fully inserted.
Jangan coba memaksakan kartu
masuk sepenuhnya ke dalam slot.
Kartu tidak boleh dimasukkan
sepenuhnya.
c
Inserting a Memory
Card
Memasukkan Kartu
Memori
A B
Insert one card at a time.
Masukkan kartu satu per satu.
Check the light.
Periksa lampunya.
Removing a Memory
Card
Mengeluarkan Kartu
Memori
Check the light.
Periksa lampunya.
A B
Remove.
Keluarkan.
On Flashing
Menyala Berkedip
Q

18
xD-Picture Card
xD-Picture Card
Type M
xD-Picture Card
Type H
SD Memory Card
SDHC Memory Card
MultiMediaCard
miniSD *
miniSDHC *
microSD *
microSDHC *
Memory Stick
Memory Stick Pro
MagicGate Memory
Stick
Memory Stick Duo *
Memory Stick Pro
Duo *
MagicGate Memory
Stick Duo *
Memory Stick
Micro *
Compact Flash Microdrive
*Adapter required
*Adaptor
diperlukan If the memory card needs an adapter then attach it before inserting the
card into the slot, otherwise the card may get stuck.
Jika kartu memori memerlukan adaptor, pasang adaptor sebelum
memasukkan kartu ke dalam slot, jika tidak kartu dapat macet.
c

19
Copying
Menyalin

20
Copying Photos or
Documents
Menyalin Foto atau
Dokumen
AR&15 BR&16 C
Load paper.
Muatkan kertas.
Place original horizontally.
Tempatkan dokumen asli secara
horisontal.
Enter the Copy mode.
Masukkan mode Copy.
F G
Select document layout.
Pilih penataan dokumen.
Select setting item.
Pilih item pengaturan.
Set the number of copies.
Tentukan jumlah salinan.
D E
Select a color mode.
Pilih mode warna.
